EGig eG16T User manual

16 Port Nway Fast Ethernet Switch
User's Manual
16
10 / 100M
FDX
LINK / ACT
POWER
RESET
UP-LINK
5
1234
678910 11 12 13 14 15 16
1357
2468
911 13 15
10 12 14 16

FCC Warning
This device has been tested and found to comply with limits for
a Class B digital device, pursuant to Part 2 and Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is
operated in a commercial environment. This equipment
generates, uses and radiates radio frequency energy and, if
not installed and used in accordance with the user's manual,
may cause interference in which case user will be required to
correct the interference at his own expense.
CE Mark Warning
This is a Class B product. In a domestic environment, this
product may cause radio interference in which case the user
may be required to take adequate measures.

Table Of Contents
Chapter 1 -------------------------------------------------------------------1
Introduction---------------------------------------------------------------------1
Key Features -------------------------------------------------------------------2
Chapter 2 -------------------------------------------------------------------3
Package Contents ------------------------------------------------------------3
Chapter 3 -------------------------------------------------------------------4
Front Panel Layout -----------------------------------------------------------4
16 RJ-45 10/100Mbps Switch Ports --------------------------------4
Uplink port----------------------------------------------------------------4
LED Indicators of 16 Port 10/100Mbps Switch--------------5
Reset----------------------------------------------------------------5
LED Definitions ----------------------------------------------------------6
Power LED --------------------------------------------------------------6
FDX LED -----------------------------------------------------------------6
10/100M LED -----------------------------------------------------------6
LINK/ACT LED ---------------------------------------------------------6
Chapter 4 -------------------------------------------------------------------7
Rear Panel Layout ----------------------------------------------------------7
AC input-------------------------------------------------------------------7
Optional Module----------------------------------------------------------7
HardwareSetting------------------------------------------------------8
Software Setting-------------------------------------------------------8
Chapter 5 -------------------------------------------------------------------9
RackMounting-----------------------------------------------------------------9
Chapter6------------------------------------------------------------------10
Installation---------------------------------------------------------------------10
ToconnecttheSwitchtoPCs,servers,andother
network devices. -------------------------------------------------------10
To connect the Switch to a Switch or a Hub --------------------10
Chapter 7 -----------------------------------------------------------------11
Technical Specifications ---------------------------------------------------11
I.
II.
III.
IV.
V.
I.
II.
I.
II.

Chapter 1
16 Port Nway Fast Ethernet Switch
Introduction
The Switch provides 16 10/100Mbps ports. The Switch was designed
for easy installation and high performance in an environment where
traffic on the network and the number of user increase continuously.
With the Rack-mount size was specifically designed for ROBO
(Remote Office & Branch Office) and medium to large workgroups.
The Switch can be installed where space is limited; moreover it
provides smooth network migration and easy upgrades to network
capacity.
-1-
16
10 / 100M
FDX
LINK / ACT
POWER
RESET
UP-LINK
5
1234
678 9 10 11 12 13 14 15 16
1357
2468
911 13 15
10 12 14 16

Key Features
16 Port 10/100Base T/TX Nway (Auto-negotiation)
Switch with RJ-45 connectors.Plus 1 fiber
(100Base-FX) module port
19-inch standard Rack- mount size
Auto-detect of Full/Half-duplex modes in all ports
Dedicated full-duplex 200Mbps bandwidth on each
port
Broadcast storm control
Store & Forward switching methods
IEEE 802.3x flow control for Full-duplex
Zero-Packet Loss Back-pressure flow control for
Half-duplex
Non-blocking & Non-head-of-line blocking full wire
speed forwarding
Auto-learning of networking configurations
Provided front panel reset button
Status LEDs: Power, Speed, Link/Activity And
Full/Half-duplex
Smart plug & play

Chapter 2
Package Contents
Before you start to install the Switch, please verify your package that
contains the following items:
One Fast Ethernet Switch
Rack-mount Kit For Rack Installation
One Power Cord
One User's Manual
Note: If any of these items is found missing or damaged, please
contact your local supplier for replacement.
-3-
16 Port Nway Fast Ethernet Switch
User's Manual
16 Port Switch
Power Cord
Rack-mount Kit
User's Manual
16
10 / 100M
FDX
LINK / ACT
POWER
RESET
UP-LINK
5
1234
678910 11 12 13 14 15 16
1357
2468
91113 15
10 12 14 16
16
10/100M
FDX
LINK/ ACT
POWER
RESET
UP-LINK
5
1234
678910 1112 13 14 15 16
1357
2468
91113 15
10 12 14 16

Chapter 3
Front Panel Layout
I. 16 RJ-45 10/100Mbps Switch Ports
There are 1~16 RJ-45 connectors on the front panel for connecting
to servers, workstation or other devices. The Switch provides 16
10/100Mbps switching ports that could sense the 10/100M speed
and negotiate Full/Half-duplex mode automatically. These switching
ports allow users to connect the Switch to 10BASE-T and 10ASE-TX
devices.
II. Uplink Port
Uplink port shared with the port #15 for expanding to another Hub or
Switch. The Uplink port and port 15 share the same port & function.
Do not use both of the Uplink port and port 15 at the same time.
-4-
16
POWER
RESET
UP-LINK
1 3 5 7
10 / 100M
FDX
LINK / ACT
1 3 5 7 9 11 13 15 17 19 21 23 1 3 5 7
10 12 14 16
2 4 6 8
9 11 13 15
Uplink Port
Reset
RJ-45 Port
LED Display
UP-LINK
10 12 14 16
9 11 13 15
UP-LINK
10 12 14 16
9 11 21 15

III. LED Indicators of 16 Port 10/100Mps Switch
LED Color Status Description No. Of LED
Power Yellow On Power on 1
FDX Green On Full-duplex 16(1~16)
Off Half-duplex 16(1~16)
Flashing Partial collision 16(1~16)
occurs
10/100M Green On Port is on the 16(1~16)
100M status
Off Port is on the 16(1~16)
10M status
LINK/ACT Yellow On 10/100Mbps port 16(1~16)
for connection
Flashing 10/100Mbps for 16(1~16)
data activating
IV. Reset
Allows the users refresh Automatic-learning of network configuration.
-5-
10 / 100M
FDX
LINK / ACT
POWER
RESET
1 3 5 7 9 11 13 15 17 19 21 23
Yellow
Yellow
Green
Green

V. LED Definitions
Power LED
On : The unit is powered on and ready for use.
Off : The unit is powered off.
FDX
On : The port is operating at Full-duplex.
Off
Flashing : Collisions occurred and the port is
operating at Half-duplex mode.
10/100M LED
On : The port is on the 100Mbps status.
Off : The port is on the 10Mbps status.
LINK/ACT LED
On : The port is ready for 10/100Mbps
connection.
Flashing : The data is transmitted or received on
the port.
-6-
: The port is operating at Half-duplex
without any data being transmitted or
received.

Chapter 4
Rear Panel Layout
I. AC input
AC input (90~260V/AC, 50~60Hz) UL Safety.
II. Optional Module
This 100BASE-FX Module is for use with Fiber Optics cable with one
SC or ST type connector.
The fiber module supports non-console switch with hardware setting.
For console switch, the fiber module supports software setting.
Please refer to the following procedures at page 8:
-7-
OFF 50~60Hz
ON 90~260VAC
100BASE-FX MODULE
SC mode
100BASE-FX MODULE
ST mode
TX RX
TX RX

Hardware Setting
To setup duplex mode of fiber port.
Step 1: To inset HW1 PIN. (Hardware configuration)
Step 2: To set up the fiber port to Half-duplex mode, please inset the
HALF1 pin. In addition, to change the fiber port to Full-duplex,
please pull out the HALF1 pin.
Software Setting
If your Switch supports console port, please use the software setting.
For detail information, please to see the console port user's manual.
Note: The power must be turned off before inserting or removing
modules.
-8-
TXRX
HW1
HALF1
HW1
TXRX
HW1
HALF1
HALF1
Half Duplex Full Duplex
or HALF1

Chapter 5
Rack Mounting
Optional Rack-mounting brackets are available to mount Switch in
standard EIA 19-inch rack. 16 port 10/100Mbps Switch is supplied
with two mounting brackets, eight screws.
First, put the Switch on the flat surface. Locate the mounting bracket
on the sides of the Switch with the mounting holes on each. Next,
insert the screw through the bracket and into the bracket mounting
holes in the Switch. Then, place the Switch in to 19-inch rack.
-9-

Chapter 6
Installation
I.To connect the Switch to PCs, servers, and other network
devices.
Use straight-through twisted-pair cable (Cat. 5) to connect the Switch
to PCs, servers and other network devices. Networks can be built as
figure shown.
II. To connect the Switch to a Switch or a Hub
Use straight-through twisted pair cable to connect the Switch to
another Switch or Hub on uplink port. If you connect the Switches on
port 1 to port 16, the cable should be changed to crossover cable.
-10-
PC MAC
Server
Workstation
1234
Dual Speed Hub
Uplink
Uplink
Uplink
Fast Ethernet Switch
Fast Ethernet Switch
PC
PC
PC
PC PC
MAC
Server
Server
Workstation
16
10/ 100 M
FDX
LINK/ ACT
POWER
RESET
UP-LINK
5
1234
678910 11 12 13 14 15 16
1357
2468
911 13 15
10 12 14 16
16
10/ 100M
FDX
LINK/ ACT
POWER
RESET
UP-LINK
5
1234
678910 1112 13 14 15 16
1357
2468
91113 15
10 12 14 16

Chapter 7
Technical Specifications
1. Standards Compliance
- IEEE 802.3 10BASE-T; IEEE 802.3u 100BASE-TX
2. Number Of Ports
- 16 integrated ports: 10/100Mbps Nway port
3. Expansion Interface
- 1 uplink port
4. Fully Flow Control Supported
- Half-duplex mode: Backpressure
- Full-duplex mode: IEEE 802.3x
5. Network Transmission Media
- 10BASE-T Cat. 3, 4, 5 UTP/STP
- 100BASE-TX Cat. 5 UTP/STP
6. Network Status Monitoring LEDs
- Per port: LINK/ACT, 10/100M, FDX
- System: POWER
7. Buffer Memory
- RAM: 4Mbits per device
- RAM buffer dynamically allocated for each port
8. Filter/Forward Rate
- Packet Filtering/ Forwarding Rates
100Mbps port - 148,800pps
10Mbps port - 14,880pps
9. MAC Address
- Up to 8K per device
10. Power
- AC input (90~260V/AC, 50~60Hz) UL Safety
11. Power Consumption
- 9.2 Watts (Max)
-11-

12. Operating Temperature
- 0 C ~ 60 C
13. Store Temperature
- -20 C ~ 90 C
14. Humidity
- 10% ~90% RH (Non-condensing)
15. Dimension (L x W x H)
- 440mm x 220mm x 44mm
16. Weight
- 2.57 Kg
17. Safety & EMI Certificates
- CE & FCC-B
-12-
24
10/ 100M
FDX
10/ 100M
FDX
LINK/ ACT
LINK/ ACT
POWER
RESET UP-LINK
135791113 15 17 19 21 23
246810 12 14 16 18 20 22 24
1357
2468
91113 15
18 20 22 24
10 12 14 16
17 19 21 23
PC
PC PC
FTP Server
Web Server
Proxy Server
Laptop
Print
Print Server
WAN
Router
Firewall
Fast Ethernet Switch
Fast Ethernet Switch Fast Ethernet Switch

DOC-UMWR160T001
Table of contents
Other EGig Network Router manuals
