Korenix JetNet 5010G Series
Industrial Managed Ethernet Switch
User Manual
Ver. 2.10, Jun-2012
Firmware v2.6
Hardware v2.3
www.korenix.com

2
Korenix JetNet 5010G Series
Industrial Managed Ethernet Switch
User’s Manual
Copyright Notice
Copyright 2007-2012 Korenix Technology Co., Ltd.
All rights reserved.
Reproduction in any form or by any means without permission is prohibited.

3
Federal Communications Commission (FCC) Statement
This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user
will be required to correct the interference at his expense.
The user is cautioned that changes and modifications made to the equipment
without approval of the manufacturer could void the user's authority to operate
this equipment.

Index
1Introduction.............................................................................................1
1.1 Overview........................................................................................1
1.2 Major Features...............................................................................1
1.3 Package List ..................................................................................2
2Hardware Installation..............................................................................3
2.1 Hardware Introduction....................................................................4
2.2 Wiring Power Inputs.......................................................................6
2.3 Wiring Digital Input.........................................................................7
2.4 Wiring Digital Output......................................................................7
2.5 Wiring Earth Ground ......................................................................7
2.6 Wiring Fast Ethernet Ports.............................................................8
2.7 Wiring Combo Ports.......................................................................9
2.8 Wiring RS-232 Console Cable.......................................................9
2.9 DIN-Rail Mounting Installation......................................................10
2.10 Wall-Mounting Installation............................................................12
3Preparation for Management ...............................................................13
3.1 Preparation for Serial Console.....................................................13
3.2 Preparation for Web Interface......................................................14
3.3 Preparation for Telnet Console.....................................................16
4Feature Configuration ..........................................................................19
4.1 Command Line Interface Introduction..........................................20
4.2 Basic Setting................................................................................25
4.3 Port Configuration........................................................................42
4.4 Network Redundancy...................................................................51
4.5 VLAN............................................................................................71
4.6 Private VLAN ...............................................................................81
4.7 Traffic Prioritization.......................................................................88
4.8 Multicast Filtering.........................................................................93
4.9 SNMP...........................................................................................97
4.10 Security......................................................................................101
4.11 Warning......................................................................................108
4.12 Monitor and Diag........................................................................118
4.12 Device Front Panel.....................................................................125
4.13 Save to Flash.............................................................................126
4.14 Logout........................................................................................127
5. Appendix.................................................................................................128
5.1 Pin Assignment of the RS-232 Console Cable...........................128
5.2 Korenix SFP family.....................................................................129
5.3 Korenix Private MIB ...................................................................132
5.4 ModBus TCP /IP ........................................................................133
5.5 Revision History.........................................................................144
5.6 About Korenix ............................................................................146

1
1 Introduction
Welcome to Korenix JetNet 5010G Series Industrial Managed Ethernet Switch User
Manual. Following topics are covered in this chapter:
1.1 Overview
1.2 Major Features
1.3 Package Checklist
1.1 Overview
JetNet 5010G series, Industrial 10-port Managed Ethernet Switches, have 7 10/100Base-TX ports
and 3 combo ports, respectively 10/100/1000 RJ-45 / 100-FX / Gigabit SX/LX. JetNet 5010G is
especially designed to operate under harsh environmental conditions. The switches provide solid
foundation for a highly fault-tolerant and easily-managed network. JetNet 5010G can be remotely
configured by Telnet, Web browser, JetView and managed by Simple Network Management
Protocol (SNMP) and Remote Monitoring (RMON). You can also connect the attached RS232
console cable to manage the switch by Command Line Interface (CLI). CLI commands are
Cisco-Like commands, your engineers who are familiar with Cisco products don’t need to learn
new rules for CLI commands.
Security is enhanced with advanced features such as 802.1Q VLAN and Port/IP security.
Performance is optimized by QoS and IGMP Snooping/Query. Korenix 3nd generation Ring
technology, Multiple Super Ring, enables superb self-healing capability for network failure. The
fastest failover time is enhanced from 300ms to 5ms for 10/100TX RJ-45 ports, and 30ms for
100FX and Gigabit Fiber. This is Korenix patented ring technology, which is registered in most
countries. For interoperability with your existed network, JetNet 5010G series also come with an
advanced redundant network solution, Ring Coupling and Rapid Dual Homing technology. With
Ring Coupling and Rapid Dual Homing technology, Ethernet Ring can be extended more easily.
No matter with Korenix switch or other managed switches.
The IP31-design aluminum case further strengthens JetNet 5010G's withstand ability in harsh
industrial environment. The event warning is notified to the network administrator via e-mail,
system log, or to field engineers by relay output. JetNet 5010G Series Industrial Managed
Ethernet Switch has also passed CE/ FCC/ UL safety certifications to help ensure safe and
reliable data transmission for industrial applications. JetNet 5010G Series will be your best option
for highly-managed industrial network.
1.2 Major Features
Korenix JetNet 5010G Series products have the following features:
SFP ports support 100/1000 Fiber with Digital Diagnostic Monitoring (DDM) to
monitor long distance fiber quality

2
Multiple Super Ring (recovery time <5ms), Rapid Dual Homing, Multiple Ring, and
MSTP/RSTP
VLAN, Private VLAN, QinQ, GVRP, QoS, IGMP Snooping V1/V2/V3, Rate Control,
Port Trunking, LACP, Online Multi-Port Mirroring
32Gbps Non-Blocking, switch backplane 8K MAC address table
Supports LLDP and JetViewPro i2NMS software for auto topology visualization and
efficient group management
Supports console CLI , Web, SNMP V1/V2c/V3, RMON, HTTPS, SSH for remote
management
Advanced security feature supports IP Security, Port Security
DHCP Server, IP and MAC Binding, 802.1x network access control
Event Notification by E-mail, SNMP trap, Syslog, Digital Input and Relay Output
Supports Modbus TCP/IP client for Factory Automation
Supports Multiple Language for Web User Interface
Dual 12-48VDC power inputs (before v2.2 hardware) , 10.5~60Vdc (v2.3 Hardware)
IP31 rugged aluminum case
Operating temperature -25~70°C for JetNet 5010G, -40~75°C for JetNet 5010G-w
(v2.3); For the UL 60950-1, the high temperature only support 60°C for all models
Note: The detail spec is listed in Appendix 5.1.
1.3 Package List
Korenix JetNet 5010G Series products are shipped with following items:
One industrial Managed Ethernet switch
One DIN-Rail clip (attached to the switch)
One wall mounting plate and 4 screws (M3 in 6 mm length)
One RS-232 DB-9 to RJ-45 console cable
Documentation and Software CD
Quick Installation Guide
If any of the above items are missing or damaged, please contact your local sales
representative.

3
2 Hardware Installation
This chapter includes hardware introduction, installation and configuration information.
Following topics are covered in this chapter:
2.1 Hardware Introduction
Dimension
Panel Layout
Bottom View
2.2 Wiring Power Inputs
2.3 Wiring Digital Input
2.4 Wiring Relay Output
2.5 Wiring Ethernet Ports
2.6 Wiring Combo Ports
2.7 Wiring RS-232 console cable
2.8 DIN-Rail Mounting Installation
2.9 Wall-Mounting Installation

4
2.1 Hardware Introduction
Dimension (v2.3 hardware)
JetNet 5010G Industrial Gigabit Switch dimension (W x H x D) is 96mm x 137mm x
119mm

5
Panel Layout
The front panel includes 10/100Mbps Fast Ethernet ports, Gigabit Ethernet ports, SFP
slot, RS232 console port, System / Combo Port LED and Reset button.
Bottom View
The bottom view of the JetNet 5010G Industrial Gigabit Managed Switch consists of three
terminal block connectors with two DC power inputs, two Digital Inputs, 2 Relay Outputs
and 1 Earth Ground.
Note: The unit intended to use vertical direction, with DIN-rail or
wall-mount only.

6
2.2 Wiring Power Inputs
Follow below steps to wire JetNet 5010G redundant DC power inputs.
1. Insert positive and negative wires into V+ and V- contacts respectively of the
terminal block connector
2. Tighten the wire-clamp screws to prevent DC wires from being loosened.
3. Power 1 and Power 2 support power redundancy and polarity reverse protection
functions.
4. Positive and negative power system inputs are both accepted, but Power 1 and
Power 2 must apply the same mode.
Note 1: It is a good practice to turn off input and load power, and to unplug power terminal
block before making wire connections. Otherwise, your screwdriver blade can
inadvertently short your terminal connections to the grounded enclosure.
Note 2: The range of the suitable electric wire is from 12 to 24 AWG.
Note 3: If the 2 power inputs are connected, JetNet 5010G will be powered from the
highest connected voltage. The unit will alarm for loss of power, either PWR1 or PWR2.
Note 4: To use the UL Listed LPS power supply with output Rating 12-48 Vdc or
10.5~60Vdc for 2.3 hardware version, minimum 1 A.

7
2.3 Wiring Digital Input
JetNet 5010G provides 2 digital inputs. It allows users to connect the termination units’
digital output and manage/monitor the status of the connected unit. The Digital Input pin
can be pulled high or low; thus the connected equipments can actively drive these pins
high or low. The embedded software UI allows you to read and set the value to the
connected device.
The power input voltage of logic low is DC 0~10V. Logic high is DC 11~30V.
Wire the digital input just like wiring the power input introduced in chapter 2.2.
2.4 Wiring Digital Output
JetNet 5010G provides 2 digital outputs, also known as Relay Output. The relay contacts
are energized (open) for normal operation and will close for fault conditions. The fault
conditions include power failure, Ethernet port link break or other pre-defined events
which can be configured in JetNet 5010G UI.
Wiring digital output is exactly the same as wiring power input introduced in chapter 2.2.
2.5 Wiring Earth Ground
To ensure the system will not be damaged by noise or any electrical shock, we suggest
you to make exact connection with JetNet 5010G with Earth Ground.
On the bottom side of JetNet 5010G, there is one earth ground screw. Loosen the earth
ground screw by screw drive; then tighten the screw after earth ground wire is connected.

8
2.6 Wiring Fast Ethernet Ports
JetNet 5010G includes 7 RJ-45 Fast Ethernet ports. The fast Ethernet ports support
10Base-T and 100Base-TX, full or half duplex modes. All the fast Ethernet ports will
auto-detect the signal from connected devices to negotiate the link speed and duplex
mode. Auto MDI/MDIX allows users to connect another switch, hub or workstation without
changing straight through or crossover cables.
Note that crossover cables simply cross-connect the transmit lines at each end to the
received lines at the opposite end.
Straight-through Cabling Schematic
Cross-over Cabling Schematic
Note that Ethernet cables use pins 1, 2, 3, and 6 of an 8-pin RJ-45 connector. The signals
of these pins are converted by the automatic MDI-X function, as shown in the table below:
Pin MDI-X
Signals
MDI Signals
1
RD+
TD+
2
RD-
TD-
3
TD+
RD+
6
TD-
RD-
Connect one side of an Ethernet cable into any switch port and connect the other side to
your attached device. The LNK LED will light up when the cable is correctly connected.
Refer to the LED Indicators section for descriptions of each LED indicator. Always make
sure that the cables between the switches and attached devices (e.g. switch, hub, or

9
workstation) are less than 100 meters (328 feet).
The wiring cable types are as below.
10Base-T: 2-pair UTP/STP Cat. 3, 4, 5 cable, EIA/TIA-568B 100-ohm (100m)
100 Base-TX: 2-pair UTP/STP Cat. 5 cable, EIA/TIA-568B 100-ohm (100m)
1000 Base-TX: 4-pair UTP/STP Cat. 5 cable, EIA/TIA-568B 100-ohm (100m)
2.7 Wiring Combo Ports
JetNet 5010G includes 3 RJ-45 Gigabit Ethernet ports. The speed of the gigabit Ethernet
port supports 10Base-T, 100Base-TX and 1000Base-TX. JetNet 5010G also equips 3
gigabit SFP ports combo with gigabit Ethernet ports. The speed of the SFP port supports
100Base-FX and 1000Base-SX/LX. The SFP ports accept standard MINI GBIC SFP
transceiver. But, to ensure system reliability, Korenix recommends using the Korenix
certificated Gigabit SFP Transceiver. The certificated SFP transceiver includes
100Base-FX single/multi mode, 1000Base-SX/LX single/multi mode ranger from 550m to
80KM.
To keep best performance, the SFP fiber ports will not support Fiber Link First
function anymore after firmware version v2.4b, since the SFP fiber transceiver
vendor have applied energy saving technology and changed the circuit design that
will cause SFP transceiver can’t offer energy of fiber link signature to switches the
connection from RJ-45 to fiber, even the SFP fiber transceiver already link up.
To fix that issue, new v2.4b firmware have applied plug-in and switch to fiber mode
feature. It forced the connection change from RJ-45 to SFP immediately, once the
SFP transceiver inserted and detected by CPU.
Note: The Ethernet Switch has to use UL recognized fiber transceiver with Class 1
Laser/LED Diode.
Note: It is recommended don’t plug-in SFP fiber transceiver and link up RJ-45 port
at same time, it might cause the connection does not work properly.
2.8 Wiring RS-232 Console Cable
Korenix attaches one RS-232 DB-9 to RJ-45 cable in the box. Connect the DB-9
connector to the COM port of your PC, open Terminal tool and set up serial settings to
9600, N,8,1. (Baud Rate: 9600 / Parity: None / Data Bit: 8 / Stop Bit: 1) Then you can
access CLI interface by console able.
Note: If you lost the cable, please contact with your sales or follow the pin assignment to
buy a new one. The Pin assignment spec is listed in the appendix.

10
2.9 DIN-Rail Mounting Installation
The DIN-Rail clip is already attached to the JetNet 5010G when packaged. If the DIN-Rail
clip is not screwed on the JetNet 5010G, follow the instructions and the figure below to
attach DIN-Rail clip to JetNet 5010G.
Follow the steps below to mount JetNet 5010G to the DIN-Rail track:
1. First, insert the upper end of DIN-Rail clip into the back of DIN-Rail track from its
upper side.
1. Use the screws to attach DIN-Rail clip to the real panel of
JetNet5010G.
2. To remove DIN-Rail clip, reverse step 1.

11
2. Lightly push the bottom of DIN-Rail clip into the track.
3. Check if DIN-Rail clip is tightly attached on the track.
4. To remove JetNet 5010G from the track, reverse the steps above.
Notes: The DIN Rail should compliance with DIN EN50022 standard.
Using wrong DIN rail may cause system install unsafe.

12
2.10 Wall-Mounting Installation
Follow the steps below to install JetNet 5010G with the wall mounting plate.
1. To remove DIN-Rail clip from JetNet 5010G, loosen the screws from DIN-Rail clip.
2. Place the wall mounting plate on the rear panel of JetNet 5010G.
3. Use the screws to tighten the wall mounting plate onto JetNet 5010G.
4. Use the hook holes at the corners of the wall mounting plate to hang JetNet 5010G
onto the wall.
5. To remove the wall mounting plate, reverse the steps above.
Note: To avoid damage the internal circuit, be sure use the screw included in
the package to screw and tight the wall-mount kit onto the rear side of the
JetNet switch. The specification of screw is M3 in 6 mm length.

13
3 Preparation for Management
JetNet 5010G series Industrial Managed Switch provides both in-band and out-band
configuration methods. You can configure the switch via RS232 console cable if you
don’t attach your admin PC to your network, or if you lose network connection to your
JetNet 5010G. This is so-called out-band management. It wouldn’t be affected by
network performance.
The in-band management means you can remotely manage the switch via the network.
You can choose Telnet or Web-based management. You just need to know the device’s
IP address and you can remotely connect to its embedded HTTP web pages or Telnet
console.
Following topics are covered in this chapter:
3.1 Preparation for Serial Console
3.2 Preparation for Web Interface
3.3 Preparation for Telnet console
3.1 Preparation for Serial Console
In JetNet 5010G package, Korenix attached one RS-232 DB-9 to RJ-45 console cable.
Please attach RS-232 DB-9 connector to your PC COM port, connect RJ-45 to the
Console port of the JetNet 5010G. If you lose the cable, please follow the console cable
PIN assignment to find one. (Refer to the appendix).
1. Go to Start -> Program -> Accessories -> Communication -> Hyper Terminal
2. Give a name to the new console connection.
3. Choose the COM name
4. Select correct serial settings. The serial settings of JetNet 5010G are as below:
Baud Rate: 9600 / Parity: None / Data Bit: 8 / Stop Bit: 1
5. After connected, you can see Switch login request.
6. Login the switch. The default username is “admin”, password, “admin”.
Booting...
Sun Jan 1 00:00:00 UTC 2006
Switch login: admin
Password:
JetNet5010G (version 2.1.5-20080414-11:04:13).
Copyright 2006-2008 Korenix Technology Co., Ltd.
Switch>

14
3.2 Preparation for Web Interface
JetNet 5010G provides HTTP Web Interface and Secured HTTPS Web Interface for
web management.
3.2.1 Web Interface
Korenix web management page is developed by JAVA. It allows you to use a standard
web-browser such as Microsoft Internet Explorer, or Mozila, to configure and interrogate
the switch from anywhere on the network.
Before you attempt to use the embedded web interface to manage switch operation,
verify that your JetNet 5010G Series Industrial Ethernet Switch is properly installed on
your network and that every PC on this network can access the switch via the web
browser.
1. Verify that your network interface card (NIC) is operational, and that your operating
system supports TCP/IP protocol.
2. Wire DC power to the switch and connect your switch to your computer.
3. Make sure that the switch default IP address is 192.168.10.1.
4. Change your computer IP address to 192.168.10.2 or other IP address which is
located in the 192.168.10.x (Network Mask: 255.255.255.0) subnet.
5. Switch to DOS command mode and ping 192.168.10.1 to verify a normal response
time.
Launch the web browser and Login.
6. Launch the web browser (Internet Explorer or Mozila Firefox) on the PC.
7. Type http://192.168.10.1 (or the IP address of the switch). And then press Enter.
8. The login screen will appear next.
9. Key in user name and the password. Default user name and password are both
admin.
10. Select Language type, this feature is available from firmware v2.5 that supports
English and Simplified Chinese.
Click on Enter or OK. Welcome page of the web-based management interface will then
appear.

15
Once you enter the web-based management interface, you can freely change the
JetNet’s IP address to fit your network environment.
Note 1: IE 5.0 or later versions do not allow Java applets to open sockets by default.
Users have to directly modify the browser settings to selectively enable Java applets to
use network ports.
Note 2: The Web UI connection session of JetNet 5010G will be logged out
automatically if you don’t give any input after 30 seconds. After logged out, you should
re-login and key in correct user name and password again.
3.2.2 Secured Web Interface
Korenix web management page also provides secured management HTTPS login. All
the configuration commands will be secured and will be hard for the hackers to sniff the
login password and configuration commands.
English language
Simplified Chinese
Language

16
Launch the web browser and Login.
1. Launch the web browser (Internet Explorer or Mozila Firefox) on the PC.
2. Type https://192.168.10.1 (or the IP address of the switch). And then press Enter.
3. The popup screen will appear and request you to trust the secured HTTPS
connection distributed by JetNet 5010G first. Press Yes to trust it.
4. The login screen will appear next.
5. Key in the user name and the password. The default user name and password is
admin.
6. Click on Enter or OK.Welcome page of the web-based management interface will
then appear.
7. Once you enter the web-based management interface, all the commands you see
are the same as what you see by HTTP login.
3.3 Preparation for Telnet Console
3.3.1 Telnet
Korenix JetNet 5010G supports Telnet console. You can connect to the switch by Telnet
and the command lines are the same as what you see by RS232 console port. Below
are the steps to open Telnet connection to the switch.
