Ehrgeiz Fusion FS-60 RGB/1 User manual

FS-60 RGB/1
Operating manual
Bedienungsanleitung

Operating Manual Page

2
Table of contents
1. SAFTYINSTRUCTIONS.......................................................................... 3
2. UNIT ................................................................................................... 7
2.1. REARSIDE ............................................................................................. 7
2.2. CONTROLPANEL ..................................................................................... 8
3. OPERATIONANSSETTINGS .................................................................. 9
3.1. SETUP................................................................................................... 9
3.1.1. Display........................................................................................9
3.1.2. DMX ...........................................................................................9
3.1.3. Master......................................................................................10
3.1.4. Red ...........................................................................................10
3.1.5. Green........................................................................................10
3.1.6. Blue ..........................................................................................10
3.1.7. Resettodefault........................................................................10
3.1.8. LEDPCB ....................................................................................11
3.1.9. Softwareversion ......................................................................11
3.2. DMXCONTROL .................................................................................... 11
3.2.1. DMXmodes..............................................................................11
3.2.2. Mastermode............................................................................12
3.2.3. Slavemode...............................................................................12
3.3. AUTOMATICPROGRAM .......................................................................... 12
3.4. SOUNDCONTROL .................................................................................. 14
3.5. MANUALCOLOURCONTROL.................................................................... 14
4. REFERENCE........................................................................................ 15
4.1. DMXCHANNELCHART........................................................................... 15
4.2. PROGRAMS.......................................................................................... 17
4.3. MENUSTRUCTURE ................................................................................ 22
4.4. TECHNICALDATA .................................................................................. 24

3
1. Safty instructions
FOR SAFE AND EFFICIENT OPERATION
Be careful with heat and extreme temperatureAvoid exposing it
to direct rays of the sun or near a heating appliance.
Not put it in a temperature bellow 41°F /5°C, or exceeding 95°F
/35°C.
Keep away from humidity, water and dust
Do not place the set in a location with high humidity or lots of
dust.
Containers with water should not be placed on the set.
Keep away from sources of hum and noise
Such as transformer motor, tuner, TV set and amplifier.
To avoid placing on un-stable location
Select a level and stable location to avoid vibration.
Do not use chemicals or volatile liquids for cleaning
Use a clean dry cloth to wipe off the dust, or a wet soft cloth for
stubborn dirt.
If out of work, contact sales agency immediately
Any troubles arose, remove the power plug soon, and contact
with an engineer for repairing, do not open the cabinet by
yourself, it might result a
danger of electric shock.
Take care with the power cable
Never pull the power cable to remove the plug from the
receptacle, be sure
to hold the plug. When not using the player for an extended period of
time
be sure to disconnect the plug from the receptacle.

4
Overhead Rigging
This Item must be built in a way that it can hold 10 times more of
its weight for 1 hour without causing any damages.
The installation must be secured with a secondary safety
attachment. The safety attachment has to be constructed in a
way that no part of the installation can fall down
When rigging, de-rigging or servicing the fixture staying in the
area below the installation place, on bridges, under high working
places and other endangered areas is forbidden.
Before taking the device in operation, the installation must be
approved by an expert.
The operator has to make sure that safety-relating and machine-
technical installations are approved by a skilled person once a
year.
Procedure:
The Device must be installed outside areas where persons may
walk by or be seated.
IMPORTANT! OVERHEAD RIGGING REQUIRES EXTENSIVE
EXPERIENCE, including (but not limited to) calculating working
load limits, installation material being used, and periodic safety
inspection of all installation material and the projector. If you lack
these qualifications, do not attempt the installation yourself, but
instead use a professional structural rigger. Improper installation
can result in bodily injury and/or damage to property.
Use only professional trussing systems if the Item shall be
lowered from the ceiling or high joists. Never let the Device swing
freely in a room.
Caution: Overhead Items may cause serious injuries when
crashing down!! If there is concern about the safety then DO
NOT INSTALL the Device!!!!

5
DANGER OF FIRE!
When installing the device, make sure there is no highly-
inflammable Material (decoration articles, etc.) within a distance
of min. 0.5 m.
Mount the projector with the mounting-bracket to your trussing
system using an appropriate clamp.
For overhead use, always install a safety-rope that can hold at
least 12 times the weight of the fixture. You must only use safety-
ropes with quick links with screw cap. Pull the safety-rope
through the hole in the mounting-bracket and over the trussing
system or a safe fixation spot. Insert the end in the quick link and
tighten the safety screw.
The maximum drop distance must never exceed 20 cm.
A safety rope which already held the strain of a crash or which is
defective must not be used again.
Adjust the desired inclination-angle via the mounting-bracket and
tighten the fixation screws.
DANGER TO LIFE!
Before taking into operation for the first time, the installation has
to be approved by an expert!
Power Connection
!! CAUTION !!
Never leave this device running unattended!! Every person that
is involved with this Item has to be qualified!!
Connect item with the main plug. The voltage and frequency
must exactly be the same as stated on the device. The power
plug must always be inserted without force.
Cleaning and Maintenance

6
Please make sure that safety-relating and machine-technical
installations are inspected by a skilled person once a year.
1. Make sure before installing that all screws are tightly
connected and not corroded.
2. There must be no deformations on the housings, fixations
and installations spots.
3. No damages must be showed on the power supply
cables, material fatigue and sediments.
If the device is going to be cleaned, please use moist, lint free
cloths. Never use alcohol or solvents!!
The cooling fan must be cleaned monthly!
To clean the interior of the device please use a vacuum cleaner
or an air jet.
We recommend cleaning the lenses weekly to keep the light
output as long as possible.

7
2. Unit
The Fusion is a LED bar developed for wall, background, stage and
ambient lighting.
2.1. Rear Side
1.) Bracket for mounting ( M10 Screw)
2.) M10 Screw
3.) Rail to adjust the bracket
4.) Control panel

8
2.2. Control panel
1.) DMX output 5 pin
2.) DMX output 3 pin
3.) DMX input 5 pin
4.) DMX Input 3 pin
5.) Data input for software updates
6.) Mode button
7.) Up button
8.) Down button
9.) Enter button
10.)LC Display
11.)PowerCon input
12.)PowerCon output

9
3. Operation ans settings
The operations on the unit are taking place on the digital display.
The settings can be changed comfortably by the 4 buttons under the
display.
3.1. Setup
- Push the UP or DOWN button until SETUP SETINGS appears
in the display.
- Confirm by pressing ENTER to enter the submenu
- In the submenu you can choose between the menus by
pressing the UP or DOWN button, confirm the submenu by
pressing ENTER. By pressing MODE you are able to leave the
menu.
3.1.1. Display
Here you can determine if the display shall stay on or off
steady.
Press the UP or DOWN button until ON or OFF is marked with
a little star. Confirm with ENTER. If ON is marked the display
will stay on steady. If OFF is marked the display will stay off
steady after 10 seconds.
3.1.2. DMX
Here you can decide how the unit reacts after the DMX Signal
is lost.
Press the UP or DOWN button until FREEZE or BLACKOUT
appears in the display. Confirm your choice with ENTER.
FREEZE means that the last released DMX signal will be kept.
BLACKOUT means that the unit shuts down the light when the
DMX signal is lost.

10
3.1.3. Master
Set up the maximum light output of the Fusion.
Press ENTER to change the value. Press the UP or DOWN
button to set up the maximum light output from 0 to 100%.
Confirm with ENTER. This setting can not be overwritten by the
DMX signal. It has the highest priority.
3.1.4. Red
Set up the maximum light output of the colour red.
Press ENTER to change the value. Press the UP or DOWN
button to set up the maximum light output from 0 to 100%.
Confirm with ENTER. This setting can not be overwritten by the
DMX signal. It has the highest priority.
3.1.5. Green
Set up the maximum light output of the colour green.
Press ENTER to change the value. Press the UP or DOWN
button to set up the maximum light output from 0 to 100%.
Confirm with ENTER. This setting can not be overwritten by the
DMX signal. It has the highest priority.
3.1.6. Blue
Set up the maximum light output of the colour blue.
Press ENTER to change the value. Press the UP or DOWN
button to set up the maximum light output from 0 to 100%.
Confirm with ENTER. This setting can not be overwritten by the
DMX signal. It has the highest priority.
3.1.7. Reset to default
Press ENTER to reset the unit to the default settings.

11
3.1.8. LED PCB
Shows the temperature of the LED board. If the temperature is
higher than 75°C, the unit regulates down the light output until
the temperature is within the working temperature.
3.1.9. Software version
Shows the actual software version.
3.2. DMX control
- Press the UP or DOWN button until DMX MODE SETUP
appears in the display.
- Confirm with ENTER to enter the submenu.
- In the submenu you can choose between the menus by
pressing the UP or DOWN button, confirm the submenu by
pressing ENTER. By pressing MODE you are able to leave the
menu. The display is blinking if there is no DMX signal.
3.2.1. DMX modes
In this menu you can select the control channel quantity and the
excitation.
You can set up also the DMX mode (MODE) and the DMX address
(ADD)
- with the UP or DOWN button you can choose MODE or ADD
- Choose a function and press ENTER. Now set up the desired
value by pressing the UP or DOWN button and confirm again
with ENTER. In this way you can proceed with every set up
possibility.
The DMX modes are like the following diagram shows.

12
3.2.2. Master mode
The master mode has not to be set up. It is automatically
started in the automatic program, the music control or in the
manual control. It’s important to make sure that the other
plugged units are working in the slave mode, and that there is
only one master unit in the line.
3.2.3. Slave mode
In this mode the unit reacts congruent to the master unit. If you
have plugged a few units into one line and connected them by
using a DMX cable, you are able to make one unit to be the
master. In this unit you can change your settings, and all other
units in the slave mode will follow you master instructions.
3.3. Automatic program
- Press the UP or DOWN button until AUTOMATIC MODE
appears in the display.
- Confirm with ENTER to enter the submenu
- Here you can obtain the predefined programs (PROG) and the
speed of them (SPEED).You can choose PROG or SPEED by
pressing the UP or DOWN button. You will find a program
overview in the chapter “reference”
- Choose one of the functions and press ENTER. Then set up
the desired value by pressing the UP or DOWN button and

13
confirm again with ENTER. In the same way you can go on with
the other values
- By pressing MODE you are able to leave the menu.

14
3.4. Sound control
- Press the UP or DOWN button until SOUND MODE appears in
the display.
- Confirm by pressing ENTER to enter the submenu
- Here you can choose the submenu SOUND to choice the
sound active programs or you can choose SENS to set up the
sensitivity of the built in microphone. Use the UP or DOWN
button to choose SENS or SOUND
- Choose one of the functions and confirm with ENTER. Set up
the desired value by pressing the UP or DOWN button and
confirm again with ENTER. Go on with the set up in the same
way
- By pressing MODE you are able to leave the menu.
3.5. Manual colour control
- Press the UP or DOWN button until CIOLOUR SELECT
appears in the display
- Confirm by pressing ENTER to enter the submenu. In this
menu your are able to control manual the colours red green
and blue
- With the UP or DOWN button you can take your choice
between R, G and B.
- Choose one of the functions and press ENTER to confirm. Set
up the desired value by pressing the UP or DOWN button and
confirm again with ENTER. Go on with the set up in the same
way.
- By pressing MODE you are able to leave the menu.

15
4. Reference
4.1. DMX channel chart

16

17
4.2. Programs

18

19
