EINHELL Split 3500 EQ C+H User manual


tOperating Instructions for the
Indoor and Outdoor Device
Split-system Air Conditioner
 Important note:
This high-quality product will only offer optimum service
if installed correctly and in the right place, and is put into
operation for the first time by a suitably competent
person.
Avoid malfunctions by seeking competent advice from
an expert with regards to the location, installation and
starting up of the system.
We shall accept no liability for malfunctions or
inadequate cooling performance resulting from the
improper handling of the product.
In accordance with national legislation based on EU
Regulation 303/2008, every intervention in the
refrigerating circuit - including all connection activities -
may only be carried out by an air-conditioning specialist.
For this reason the DIY installation of refrigerant lines for
this air conditioner may no longer be carried out by
unskilled workers.
The 230 V socket-outlet required to supply power must
be connected and commissioned by a specialist
contractor.
If the system is to be moved to another location or
disposed of, only a suitably qualified
electricianʼs/cooling system firm is permitted to
undertake any work of disassembly or disposal.
Art.-Nr.: 23.657.16 I.-Nr.: 01017
Art.-Nr.: 23.657.36 I.-Nr.: 01017
Split 2500 EQ C+H
Split 3500 EQ C+H
Anleitung_Split_2500-3500_EQ_C_H_GB:_ 10.12.2008 11:53 Uhr Seite 1

2
1
2
21
6123 4 5
3
4576
8
10
11
9
Anleitung_Split_2500-3500_EQ_C_H_GB:_ 10.12.2008 11:53 Uhr Seite 2

3
43
6
5
7
1
3
4
5
6
7
21
22
24
23
24
27
25
26
14
13
12
11
10
8
2
9
Anleitung_Split_2500-3500_EQ_C_H_GB:_ 10.12.2008 11:53 Uhr Seite 3

4
8 9
12 13
10 11
A
Anleitung_Split_2500-3500_EQ_C_H_GB:_ 10.12.2008 11:53 Uhr Seite 4

5
1514
16
A =780 mm
CD
17
Anleitung_Split_2500-3500_EQ_C_H_GB:_ 10.12.2008 11:54 Uhr Seite 5

6
18 19
23
21
22
20
AB
X
X
Y
Y
Anleitung_Split_2500-3500_EQ_C_H_GB:_ 10.12.2008 11:54 Uhr Seite 6

7
25
28
24
27
29
26
A
AB
B
A
B
D
A
C
B
Anleitung_Split_2500-3500_EQ_C_H_GB:_ 10.12.2008 11:54 Uhr Seite 7

8
3130
34
33
35
32
B
B
A
A
Anleitung_Split_2500-3500_EQ_C_H_GB:_ 10.12.2008 11:54 Uhr Seite 8

9
36 37
40
39
41
38
A
C
I
C
K
PE
PE
B
PE
Anleitung_Split_2500-3500_EQ_C_H_GB:_ 10.12.2008 11:54 Uhr Seite 9

GB
10
Table of contents
1. Safety regulations
2. Items supplied
3. Technical data
4. Intended use
5. Description of parts
6. Display - Indoor device
7. Setting up the remote control
8. Description of the remote control functions
9. Indoor device settings
10. Cleaning notes
11. General notes
12. Troubleshooting
13. Installation accessories
14. Installation instructions
15. Ordering replacement parts
Anleitung_Split_2500-3500_EQ_C_H_GB:_ 10.12.2008 11:54 Uhr Seite 10

GB
11
Important!
When using the equipment, a few safety precautions
must be observed to avoid injuries and damage.
Please read the complete operating instructions and
safety regulations with due care. Keep this manual in
a safe place, so that the information is available at all
times. If you give the equipment to any other person,
hand over these operating instructions and safety
regulations as well. We cannot accept any liability for
damage or accidents which arise due to a failure to
follow these instructions and the safety instructions.
1. Safety instructions
앬Read the safety instructions before you start to
use the device.
앬These points set out extremely important
precautionary measures that you must comply
with.
앬Keep the Operating Instructions in a safe place
once you have read them.
앬Check that the drainage line is correctly
connected. If not, water will escape.
앬Warning!
Do not extend the cable and never use multiple
plugs. A poor electrical connection, poor
insulation or voltage which is higher than
permitted can cause fire.
앬Remove all dirt from the power plug and plug
it in firmly. Soiled plugs can cause fire or an
electric shock.
앬Warning!
앬Never pull out the plug while the device is in use.
앬Never permit cool air to be blown directly at you
for any lengthy period of time.
앬In the event of any abnormalities (e.g. smell of
burning), immediately switch off the device and
pull the plug. Contact your service partner.
앬Never poke fingers or sticks in the air inlet and
outlet vents.
앬Never attempt to repair the air conditioner
yourself. Always contact your service partner if it
requires repair.
앬Never pull the plug out by pulling on the cable.
Hold the plug firmly and pull it out of the plug
socket, otherwise there is a risk of damaging the
cable.
앬Always switch off the device and pull the plug
before you start to clean it.
앬Never actuate any switches with wet hands.
앬Never clean the air conditioner with water.
앬Never place any plants or animals under a
location to which cool air flows as this could have
an undesirable affect on them.
앬Never use combustible cleaning agents as these
could cause a fire or deformation.
앬If the air conditioner is to be used in conjunction
with other heaters, the air should be refreshed
periodically, otherwise there is a risk of lack of
oxygen.
앬Never use the device for any other purpose than
the intended use. Never place food, precision
instruments, plants, animals, paint, etc. on the
device.
앬Never hold any burning objects close to the
device if they could be directly affected by the
emitted air.
앬Always pull out the power plug if the device is not
going to be used for any lengthy period of time.
Collections of dust can cause fire.
앬Never step onto the outdoor device and never
place anything on it.
앬Never use an unsteady or rusty base.
앬Never allow the device to run for too long with the
doors or windows open, or if the humidity is very
high. If the air conditioner runs for a long time in
cooling mode and the humidity is high (over
80%), condensed water may drip out of the
device.
앬Never stand on an unsteady base when you
remove the device from the holder on the wall.
앬Check that the condensation water can run off
unhindered. Water damage can result if the
condensation water cannot run off properly.
앬Never touch any metal parts on the indoor device
when removing the air filter. You may injure
yourself.
앬Never install the device in a room in which
combustible gases can be emitted. Emitted
gases may collect and cause an explosion.
앬Always switch off the device and pull out the
power plug during a storm. Electrical parts may
get damaged.
앬Earthing connection!
The power cable (plug) comes with an earthing
wire. Do not, therefore, change the plug.
앬For electrical safety purposes we recommend
that you install an earth-leakage circuit-breaker.
앬Leave the electrical installation of the 230 V
socket for the system to an authorized electrical
contractor. Incorrect installation can lead to injury
or damage to property.
앬If you are not confident in being able to assemble
the system, ask our customer service team or a
refrigeration contractor of your choice to do the
refrigeration part of the installation work. Incorrect
installation can lead to injury or damage to
property.
앬Incorrect installation may cause injury or damage
to the device.
Anleitung_Split_2500-3500_EQ_C_H_GB:_ 10.12.2008 11:54 Uhr Seite 11

GB
12
앬Check the mains lead at regular intervals for
signs of defects or damage. A damaged mains
lead may only be replaced by an electrician or
ISC GmbH in compliance with the relevant
regulations.
앬The device must not be installed in laundries.
앬The device must be installed so that the plug is
accessible.
앬The temperature in the cooling circuit may
become very hot. You should therefore keep all
cables away from the copper pipes.
 CAUTION!
Read all safety regulations and instructions.
Any errors made in following the safety regulations
and instructions may result in an electric shock, fire
and/or serious injury.
Keep all safety regulations and instructions in a
safe place for future use.
Packaging:
The unit is supplied in packaging to prevent it from
being damaged in transit. The raw materials in this
packaging can be reused or recycled.
Tips on saving energy
Only use the air conditioner when you really need to.
Do not select too high a temperature for heating or
too low a temperature for cooling. Select the “Sleep”
function during the night.
Close all windows, doors and Venetian blinds in
order to reduce incoming sunlight as far as possible.
Principle of operation for cooling
Heat is extracted from the air in the room by the air
heat-exchanger (evaporator) in which the coolant
circulates. This air is conveyed to the outside air
heat-exchanger (condenser).
This gives off heat to the outdoor air. Electrical
energy is required for this. In certain circumstances
condensation may form on the evaporator on the
indoor unit, which will be removed by the
condensation hose.
2. Items supplied
Split 2503 EQ C+H
1 indoor device (box 1, art. no. 23.654.18)
1 outdoor device (box 2, art. no. 23.654.19)
1 set of installation accessories (for details, see page
20)
Split 3500 EQ C+H
1 indoor device (box 1, art. no. 23.654.36)
1 outdoor device (box 2, art. no. 23.654.37)
1 set of installation accessories (for details, see page
20)
3. Technical data
Split 2500 EQ C+H
Cooling capacity 2600 watts
Heating capacity 2800 watts
Energy efficiency B (EER 3.09/COP 3.33)
Air capacity 410 m3/h
Absorbed humidity (30°C/80%RH) 1.0 l/h
Timer 24 h
Operating voltage 220 - 240 V ~ 50 Hz
Socket fusing 16 A
Nominal power consumption, cooling 840 watts
Nominal current consumption, cooling 3.7 A
Nominal power consumption, heating 830 watts
Nominal current consumption, heating 3.7 A
Compressor Rotary piston
Compressor starting current 22 A
Outdoor temperature, cooling operation °C
+18 - +43 (DB)
Outdoor temperature, heating operation °C
-7 - + 24 (DB)
Fluid line Ø A 6.35 mm
Suction pipe Ø A 9.53 mm
Length of refrigerant line supplied 5 m
Length of refrigerant line, max. 10 m
Max. difference in height between indoor/outdoor
device 5 m
Refrigerant R 410 A
Refrigerant filling capacity 730 g
Refrigerant refill quantity from 5 m 20 g/m
Sound pressure level
Inside ≤ 39 dB (A)
Outside ≤ 53 dB (A)
Dimension Inside 79 x 27,5 x 19 cm
Dimension Outside 78 x 54 x 25 cm
Weight Inside 8,5 kg
Weight Outside 28 kg
Anleitung_Split_2500-3500_EQ_C_H_GB:_ 10.12.2008 11:54 Uhr Seite 12

GB
13
Split 3500 EQ C+H
Cooling capacity 3300 watts
Heating capacity 3600 watts
Energy efficiency B (EER 3.14/COP 3.42)
Air capacity 620 m3/h
Absorbed humidity (30°C/80%RH) 1.2 l/h
Timer 24 h
Operating voltage 220 - 240 V ~ 50 Hz
Socket fusing 16 A
Nominal power consumption, cooling 1050 watts
Nominal current consumption, cooling 4.9 A
Nominal power consumption, heating 1050 watts
Nominal current consumption, heating 4.9 A
Compressor Rotary piston
Compressor starting current 33 A
Outdoor temperature, cooling operation °C
+18 - +43 (DB)
Outdoor temperature, heating operation °C
-7 - + 24 (DB)
Fluid line Ø A 6.35 mm
Suction pipe Ø A 12.7 mm
Length of refrigerant line supplied 5 m
Length of refrigerant line, max. 10 m
Max. difference in height between indoor/outdoor
device 5 m
Refrigerant R 410 A
Refrigerant filling capacity 840 g
Refrigerant refill quantity from 5 m 25 g/m
Sound pressure level
Inside ≤ 43 dB (A)
Outside ≤ 54 dB (A)
Dimension Inside 79 x 27,5 x 19 cm
Dimension Outside 78 x 54 x 25 cm
Weight Inside 9 kg
Weight Outside 35 kg
Note:
The specified capacities and performances are
based on the following conditions (EN 14511):
Cooling:
Air temperature at the inlet on the indoor device:
27°C for dry thermometer bulb (DB), 19°C for wet
thermometer bulb (WB). Outdoor air temperature:
35°C for dry thermometer bulb (DB), 24°C for wet
thermometer bulb (WB).
Heating:
Air temperature at the inlet on the indoor device:
20°C for dry thermometer bulb (DB), 15°C for wet
thermometer bulb (WB). Outdoor air temperature:
7°C for dry thermometer bulb (DB), 6°C for wet
thermometer bulb (WB).
Temperature ranges:
Cooling
Room temperature 17°C ~ 32°C
Outdoor temperature 18°C ~ 43°C
Heating
Room temperature 17°C ~ 30°C
Outdoor temperature -7°C ~ 24°C
Dehumidifying
Room temperature 17°C ~ 32°C
Outdoor temperature 18°C ~ 43°C
Notes:
1. For health reasons the room temperature should
be no more than 5 – 6°C below the outdoor
temperature in cooling mode.
2. The perfect performance of the system is
achieved within the temperature ranges shown in
the table.
3. If the air conditioning system is operated below
the temperature range shown above, protection
functions may be activated in certain
circumstances which will cause the device to
operate abnormally.
4. If the air conditioner is operated in a relative
humidity level of over 80%, condensation may be
deposited on the top of the system which will
then drip on to the floor. In this case set the
horizontal air flap to its maximum angle
(perpendicular to the floor) and set the FAN to
“HIGH”.
4. Intended use
The Split 2500 EQ C+H air-conditioning system is
only designed for air-conditioning privately used dry
rooms with a maximum room volume of 80 m3(Split
3500 EQ C+H is suitable for a maximum room
volume of 110 m3). The room volume depends on the
local conditions. Large window areas, additional heat
sources (PC, television, people, etc.), poor wall
insulation, etc. serve to reduce this room volume.
The machine is to be used only for its prescribed
purpose. Any other use is deemed to be a case of
misuse. The user / operator and not the
Anleitung_Split_2500-3500_EQ_C_H_GB:_ 10.12.2008 11:54 Uhr Seite 13

GB
14
manufacturer will be liable for any damage or injuries
of any kind caused as a result of this.
Please note that our equipment has not been
designed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
5. Description of parts (Fig. 1)
1 Front panel
2 Air inlet
3 Air filter
4 Air outlet
5 Horizontal air flow grille
6 Vertical air slit
7 Display panel
8 Remote control
9 Refrigerant line, condensate hose
10 Air inlet
11 Air outlet
6. Indoor device display (Fig. 2)
1 AUTO display
The display will be lit when the device is set
to AUTO mode.
2 DE-ICING display
This display will be lit when the device starts
the “De-icing” function automatically or the
hot air monitor is active in “Heat” mode.
3 TEMPERATURE display
Show the temperature set for the room when
the device is operating.
4 OPERATION display
This display flashes after the mains plug has
been inserted into the socket and is lit when
the device is operating.
5 TIMER display
This display is lit if the timer “ON” / “OFF” is
switched on.
6 SIGNAL RECEIVER for the remote control
7. Setting up the remote control
Insert batteries
1. Open the battery compartment cover.
2. Insert two new batteries. Be sure to observe the
correct polarity (+/-) of the batteries.
3. Close the battery compartment cover.
Notes
앬The radio signal has a range of approx. 8 m.
앬Use two alkali batteries, type R03 AAA (1.5 V).
앬Always replace both batteries at once when you
can no longer see the LCD display.
앬Never use a combination of new and used
batteries.
앬Never use a battery type other than the specified
one.
앬If the remote control is not used for a lengthy
period of time, remove the batteries to prevent
them leaking.
앬The service life of the batteries if the remote
control is used normally is approximately 12
months.
앬Dispose of spent batteries properly.
Notes
Keep the remote control approximately 1 m from
television sets or other electrical appliances. Direct
sunlight may considerably reduce the range of the
remote control.
Objects between the remote control and the IR
receiver which can impede reception of the signal
must be avoided. Handle the remote control with
care. Do not drop it, keep it away from heat and
moisture so as not to damage the remote control.
8. Description of the remote control
functions (Fig. 3/4)
Button assignment
1. TEMP v: Pressing this button reduces the
temperature set for the room.
2. TEMP ^: Pressing this button increases the
temperature set for the room.
3. MODE: Pressing this button allows you to select
the mode for the device. The mode will change
each time you press the button in the following
sequence: AUTO – COOL – DRY – HEAT –
FAN.
4. SWING: Pressing this button will activate the
automatic direction change for the ventilation
flaps. The air flow is adjusted
upwards/downwards. Pressing the button a
second time will stop this function.
5. RESET: Pressing this button deletes all current
settings and returns the device to its default
settings.
6. AIR DIRECTION: Pressing this button enables
you to fix the angle of the ventilation flap.
7. LED DISPLAY: Pressing this button stops the
temperature being shown on the display of the
indoor device. Pressing it a second time will
Anleitung_Split_2500-3500_EQ_C_H_GB:_ 10.12.2008 11:54 Uhr Seite 14

GB
15
reactivate the display.
8. FAN SPEED: Pressing this button enables you
to select the fan speed. Each time you press this
button the speed will be switched in the following
sequence:
LOW – MED – HIGH – AUTO.
9. ON/OFF: Pressing this button enables you to
switch on the device. Pressing it a second time
will switch off the device.
10. TIMER ON: Pressing this button enables you to
set the time at which the device will switch on
(0.5 – 24 hours). Each time you press this button
the activation time will move in steps of 30
minutes (steps of one hour after 10 hours). Set
0:00 to deactivate this mode.
11. SLEEP: Pressing this button enables you to
select economy mode. Pressing it a second time
will deactivate this mode. The mode will also be
deactivated as soon as you press another
button. This function can only be used in COOL,
HEAT and AUTO modes.
12. TIMER OFF: Pressing this button enables you to
set the time at which the device will switch off
(0.5 – 24 hours). Each time you press this button
the deactivation time will move in steps of 30
minutes (steps of one hour after 10 hours). Set
0:00 to deactivate this mode.
13. LOCK: Pressing this button locks all current
settings and the remote control will not allow you
to change any more settings. Pressing it a
second time will cancel LOCK mode.
14. TURBO: Not assigned.
Display
21. DIGITAL DISPLAY AREA: The set temperature
will normally be displayed here. If the “Timer On”
or “Timer Off” buttons are pressed, the TIMER
settings will be displayed. Nothing will be
displayed in FAN mode.
22. TRANSFER SIGNAL: This arrow will be lit as
soon as the remote control transfers signals to
the indoor device. The indoor device will then
confirm with a signal tone.
23. ON/OFF: This symbol will go out as soon as the
device has been switched on using the remote
control. It will go out as soon as the device has
been switched off.
24. MODES: As soon as you press the MODE
button, an arrow will appear in front of the mode
that is currently active.
25. LOCK: The LOCK display will be displayed after
you have pressed the LOCK button. If the LOCK
button is pressed a second time the display will
go out.
26. TIMER DISPLAY: As soon as an activation time
has been selected, TIMER ON will appear in this
area. If a deactivation time has been selected,
TIMER OFF will be displayed. If both functions
have been selected, TIMER ON OFF will be
displayed.
27. FAN SPEED DISPLAY: If you have pressed the
FAN SPEED button, an arrow will appear here
before the currently selected fan speed
(exception: if AUTO speed has been selected, no
arrow will be displayed).
Operating modes
A) AUTO (Automatic) mode
1. Press the MODE button to select AUTO mode.
2. Pressing the TEMP buttons enables you to
select the required room temperature. The most
comfortable temperature settings are between
21°C and 28°C.
3. Pressing the ON/OFF button enables you to
switch on the air conditioner. OPERATION and
AUTO will be lit on the display of the indoor
device. In addition the temperature set on the
remote control will be displayed. The fan speed
will be set automatically.
4. Pressing the ON/OFF button a second time
enables you to switch off the air conditioner.
NOTE
In AUTO mode the air conditioner will automatically
select on the COOL, FAN and HEAT modes by
detecting the temperature difference between the
actual room temperature and set temperature.
B) COOL, HEAT and FAN modes
1. You can select the required COOL, HEAT or
FAN mode by pressing the MODE button.
2. Pressing the TEMP buttons enables you to
select the required room temperature.
3. Pressing the FAN SPEED button enables you to
select the fan speed. Each time you press the
button, the speeds will be selected in the
following sequence: AUTO – LOW – MED –
HIGH.
4. Pressing the ON/OFF button enables you to
switch on the air conditioner. OPERATION will
be lit on the display of the indoor device. In
addition the temperature set on the remote
control will be displayed.
5. Pressing the ON/OFF button a second time
enables you to switch off the air conditioner.
NOTE
FAN mode cannot be used to control the
temperature. Only settings 1, 3, 4 and 5 can be
made in this mode.
Anleitung_Split_2500-3500_EQ_C_H_GB:_ 10.12.2008 11:54 Uhr Seite 15

C) DRY (dehumidifier) mode
1. Press the MODE button to select DRY mode.
2. Pressing the TEMP buttons enables you to
select the required room temperature. The
device will alternately activate the fan function
and the cooling function.
3. Pressing the ON/OFF button enables you to
switch on the air conditioner. AUTO will be lit on
the display of the indoor device. In addition the
temperature set on the remote control will be
displayed. The air conditioner runs at low fan
speed in DRY mode.
4. Pressing the ON/OFF button a second time
enables you to switch off this mode.
D) TIMER mode
Press the TIMER ON button to set the automatic
activation time for the device and the TIMER OFF
button to set the automatic deactivation time for the
device.
Setting the activation (deactivation) time
1. Press the TIMER ON (TIMER OFF) button. The
remote control display will now show TIMER ON
(TIMER OFF), the last time set for the starting
(stopping) the deviceʼs operation and the “h”
symbol. Now set the time when you want the
device to start (stop).
2. Each time you press TIMER ON (TIMER OFF),
you will put the activation (deactivation) time 0.5
hours back (when you reach 10 hours, the
interval will be one hour).
3. After a few seconds the TIMER control light will
be permanently lit on the indoor device.
NOTES
1. If you have selected an activation and a
deactivation time, TIMER ON/OFF will be shown
on the display.
2. To change the TIMER ON/OFF time, press the
appropriate TIMER button and reset the time.
3. To delete the TIMER ON/OFF setting, set the
TIMER time to 0:00.
E) SLEEP (economy) mode
1. Press the SLEEP button on the remote control
during cool, heat or auto mode.
2. The air conditioning system will automatically
increase (cool mode) or lower (heat mode) the
set temperature by 1°C after one hour.
3. After a further hour this process will be repeated
automatically.
4. This mode allows you to save energy whilst
maintaining a pleasant temperature.
9. Indoor device settings
Remote control fails to work (emergency
operation) (Fig. 5)
If the remote control fails to work (empty batteries or
malfunction), use the emergency switch (Auto/Cool).
a) Open the front panel and lift it until the panel
audibly clicks into position in an open position.
b) Press the button until the AUTO display is lit. The
device is now operating in forced automatic mode
(the default temperature is 24°C)
c) Close the front panel again.
Caution
1. If you press the button repeatedly, the operating
mode will change in the following sequence:
AUTO, COOL, OFF.
2. If you press the button twice, the device will be
set to forced cool mode. This mode is only
designed for testing purposes.
3. The third press of the button will stop the device.
4. Use the remote control to restart control using
the remote control.
Setting the vertical air flow direction (Fig. 6)
The left-hand and right-hand side flow directions can
be adjusted manually. Perform these adjustments
before you start the device because once it has been
started the slats vibrate and there is a risk of your
fingers getting caught.
Setting the horizontal air flow direction
(Fig. 7/8)
The air conditioning system automatically set the
horizontal air flow direction with the operating mode.
1. Use this function when the device is operating.
2. Press and hold the AIR DIRECTION button on
the remote control to move the air flap in the
required direction.
3. Set the horizontal air flow direction to the
required position.
4. Every time you start the device thereafter, the
horizontal air flow will automatically be set to the
direction in which the air flap was moved when
you pressed the AIR DIRECTION button.
Automatic horizontal air flow change (Fig. 7/9)
1. Use this function when the device is operating.
2. Press the SWING button on the remote control.
To end the function, press the SWING button a
second time.
3. Press the AIR DIRECTION button to fix the air
flap in the required position.
GB
16
Anleitung_Split_2500-3500_EQ_C_H_GB:_ 10.12.2008 11:54 Uhr Seite 16

GB
17
Notes:
1. If the air conditioning system is not switched on
or TIMER ON is active, the AIR DIRECTION and
SWING buttons will have no effect.
2. The air conditioning system should not be
operated for a lengthy period of time with the air
flow directed downwards in cool or dehumidify
(DRY) mode. Otherwise condensation may be
deposited on the horizontal air flap and can then
drip on to the floor or on to furniture.
3. Do not adjust the horizontal air flap manually.
Always use the AIR DIRECTION or SWING
button for this purpose. If you adjust the air flap
by hand, it may suffer a malfunction in certain
circumstances. If a malfunction does occur, the
system must be stopped and restarted.
4. If the air conditioning system is restarted
immediately, it is possible that in certain
circumstances the horizontal air flap will not
move for approx. 10 seconds.
5. Do not operate the device with the horizontal air
flap closed.
6. If the air conditioning system is connected to the
power supply (the first time the power supply is
switched on), in certain circumstances the
horizontal air flap may generate a sound which
lasts for ten seconds. This is normal and is not a
malfunction.
10. Cleaning notes
Important!
Switch the device off and pull the mains plug each
time before cleaning.
Note!
The time intervals at which the device should be
cleaned are a factor of the area of installation. The
time intervals listed below should be maintained in
most cases.
Keep the outdoor device and the area around the
outdoor device clean. Regularly remove leaves, etc.
which can collect around the outdoor device.
Cleaning the housing of the indoor device
앬Clean the housing of the indoor device using
only a soft, wet cloth when necessary.
앬In order to avoid damaging the housing and
electronics, avoid the use of gasoline, thinners,
scouring powder, cleaners and the like when
cleaning.
Cleaning the air filters of the indoor device
Make sure that the air filters are clean! Soiled air
filters reduce the air output of the device. The air
filters of the indoor device should be checked and, if
necessary, cleaned on a monthly basis.
1. Raise the front panel of the indoor device until
the panel audibly clicks into position in its open
position (Fig. 10).
2. Raise the air filter slightly using the handle (Fig.
11 / Item A) to take the filter out of the filter
holder and then pull it downwards to remove it.
Take the air filter out of the indoor device (Fig.
12).
3. Additional filters are fitted to both air filters. The
yellow vitamin C filter is designed to convert
active oxygen into O2 and achieves a positive
effect for sustaining beautiful skin. The green bio
filter acts against unpleasant odors, bacteria,
viruses and allergens. Take the filters (Fig. 13)
out of the holder frames.
4. Clean the vitamin C / bio filters once per month
and change the filter every 24 months.
Replacement filters are available from ISC
GmbH.
5. Clean the vitamin C / bio filters carefully using a
vacuum cleaner.
6. Clean the netting in the air filter with a vacuum
cleaner or wash it out with warm water (max.
40°C).
7. Then dry the filter in a cool place.
8. Fit the vitamin C / bio filters back into the holder
frames. Place the two filters back on the air
filters.
9. Place the top part of the air filter back into the
device and ensure that its left and right edges
are correctly aligned. Then insert the filter in full
(Fig. 14).
10. Close the front panel again.
Cleaning the heat exchanger of the indoor device
The heat exchanger must be cleaned at least once
annually. To do this, remove the air filters from the
indoor device as described above.
앬Using a vacuum cleaner or a long-bristled brush,
carefully remove any dirt deposits on the heat
exchanger; this will avoid damaging the heat
exchanger fins. A damaged heat exchanger will
lead to higher operating costs.
앬Take steps to ensure that you do not injure
yourself on the fin edges!
Anleitung_Split_2500-3500_EQ_C_H_GB:_ 10.12.2008 11:54 Uhr Seite 17

11. General notes
Restarting after lengthy non-use
If the air-conditioning system has not been used for a
lengthy period, check the following before you switch
it on:
1. there are no objects covering the outdoor or
indoor unit.
2. the socket from which the unit is operated has
been installed correctly
3. the air filters are clean
Care precautions
If the air conditioner is not going to be used for some
period of time:
1. Let the fans run for 6 hours to allow the device to
completely dry out. Set the highest possible
temperature level while the fans are running.
2. Switch off the device and pull the power plug.
3. Clean the air filters and housing parts.
4. Remove all dirt from the outdoor unit.
5. Take the batteries out of the remote control.
If the following events occur during operation,
they do not constitute a fault.
1. Safety function of the air conditioning system,
compressor trip
a) After the system has been switched on again,
the compressor will not cut in until after a delay
of three minutes.
b) The device has a special function that prevents
cold air being blown out in heat mode if the heat
exchanger in the indoor device is in one of the
following situations and the set temperature has
not yet been reached:
– Heat mode has just been started.
– De-icing taking place.
– Heat mode with a low temperature setting.
c) The internal and external fans will be shut down
during de-icing. De-icing is taking place.
d) If the outdoor temperature is high and the
humidity is high, the outdoor device may ice up
whilst it is operating. This will result in reduced
heat output by the air conditioning system. If this
is the case the air conditioning system will
terminate heat mode and start de-icing mode
automatically. The de-icing time may be 4 – 10
minutes depending on the outdoor temperature
and the amount of ice deposited on the outdoor
device.
2. “White mist” is emitted from the indoor device
a) If the temperature difference between the air inlet
and air outlet is large and the relative humidity in
the room is also high. “white mist” may be
generated in cool mode.
b) If the air conditioning system is restarted in heat
mode after de-icing, “white mist” may be
generated by moisture in certain circumstances.
3. A low noise is emitted by the air conditioning
system
a) When the compressor is running or shortly after
it has been switched off, a hissing noise may be
heard, caused by the refrigerant flowing through
the pipes.
b) When the compressor is running or shortly after
it has been switched off, a “screeching” noise
may be audible, caused by the heat expansion
and cold contraction of the plastic parts in the
device due to temperature changes.
c) The first time the power supply is switched on,
the air flap will return to its initial position.
4. Dust is blown out of the indoor device
a) This is normal if the air conditioning system has
been switched off for a lengthy period of time
and when it is started for the first time.
5. A strange odor emanates from the indoor
device
a) This odor is generated in the indoor device and
is emitted by certain materials or pieces of
furniture or by cigarette smoke.
6. The air conditioning system switches to
exclusive fan mode from cool or heat mode
When the indoor temperature has reached the set
temperature, the compressor will cut out
automatically and the air conditioning system will be
operated in FAN mode. As soon as the indoor
temperature in COOL mode rises above the set
value or in HEAT mode it falls under the set value,
the compressor will cut in again.
7. In rooms with high relative humidity (over
80%), water droplet are deposited on the surface
of the indoor device in cool mode
Set the horizontal air flap to the vertical air outlet
position and select a HIGH fan speed.
8. Heat mode
In heat mode, the air conditioning system draws in
warm air from the outdoor device and dissipates it
through the indoor device to the indoor area. If the
outdoor temperature falls, the volume of hot air
drawn in through the air conditioning falls
accordingly. At the same time the heat load of the air
conditioning system increases as a result of the large
difference between the indoor and outdoor
temperature. This may result in the air conditioning
GB
18
Anleitung_Split_2500-3500_EQ_C_H_GB:_ 10.12.2008 11:54 Uhr Seite 18

system being unable to achieve an adequate room
temperature. Please note that the heat function is
only really suitable for use during autumn and spring.
9. Automatic restart function: The device shuts
down complete in the event of a power failure
during operation
The OPERATION display flashes on the indoor
device after the power supply returns. Press the
ON/OFF button on the remote control to restart the
device.
10. A lightning strike or the mobile phone in a car
in use near the system may cause faults in the
device
In this case disconnect the deviceʼs power supply
briefly and then reconnect it. Press the ON/OFF
button on the remote control to restart the device.
12. Troubleshooting
Device does not start. Check the following:
1. Is voltage present at the plug socket outlet?
2. Check the plug fuse!
3. Is the timer set?
The device does not provide satisfactory cooling!
Check the following:
1. Has an appropriate temperature been set?
2. Is the air filter soiled? Clean and fit back in place.
3. Are the inlets and outlets on the outdoor device
blocked?
4. Has the sleep mode been set during the day?
5. Are the connections between the indoor and
outdoor device adequately sealed? There may not
be enough coolant? If so, please contact your
service company.
The remote control does not work!
(Important! It only works within a range of 8 m
from the indoor device.)
1. Are the batteries still OK? Replace if necessary!
2. Have the batteries been inserted correctly?
Check that the + and – terminals are correct!
3. Are there any objects between the indoor unit
and the remote control which may interfere with
the signal? Remove these objects.
In the event of a power failure, check the
following:
Press the ON/OFF key after a power failure.
If the problems remain after checking through the
above points, switch off the device and contact your
service company.
Please contact our service partner immediately if
the following fault codes are displayed
Display E1
Defective air circulation sensor in the indoor device
Display E2
Defective heat exchanger sensor in the indoor device
Display E4
No cooling / heating power
Display E5
Cool mode – frost guard tripped /
Heat mode – overheating guard tripped
GB
19
Anleitung_Split_2500-3500_EQ_C_H_GB:_ 10.12.2008 11:54 Uhr Seite 19

13. Installation accessories
Please check that all the installation accessories
have been supplied prior to carrying out the
installation work.
1 mounting plate for the indoor device
1 infrared remote control
2 batteries (type AAA, 1.5 V)
1 condensed water hose (L = 2 m)
2 sealing compound
1 wall hole cap
2 roll of plastic wrapping tape
1 set of refrigerant lines (L = 5 m)
1 pipe insulation (Ø 35 x 500 mm)
8 screws ST 3.9x25
8 wall plugs
1 wall passage hole
14. Installation instructions (Fig. 15):
Check that the actual mains voltage is the same
as the mains voltage specified on the rating
plate.
앬Important. Make sure that there are no electric
cables or other installations (for example water
pipes) near the drill holes.
앬Earth the outdoor device in accordance with
current regulations.
앬The device must have separate protection
against short-circuits.
앬Leave the electrical installation work (230 V
socket-outlet) to a specialist contractor.
앬Have all refrigeration installation work performed
by a specialist contractor if you are not confident
of doing this yourself.
앬Incorrect installation can lead to injury or damage
to property.
앬Always wear ear muffs, goggles and work gloves
when performing work of installation.
Notes on electrical connection!
All electrical connection work (230 V, 16 A socket)
must be performed by a qualified electrician
authorized to do so such work by the applicable
electricity supply company. The system must have
separate protection against short-circuits. Select a
suitably large cable cross-section. The yellow/green
wire is to be used as a protective conductor only and
under no circumstances as a voltage carrying
conductor. The fixed electrical connection of the
device must be capable of being isolated from the
mains power supply by a device with an isolating
distance of at least 3 mm (e.g. circuit-breaker).
Connect the electrical connections of the indoor and
outdoor devices together first and then connect to
the mains power supply. Check first that the entire
system is voltage-free. Secure the system from being
switched on again.
A. Selecting the place of installation
Indoor device
1. The openings for the inlet and outlet air must
never be covered, otherwise the air will not be
distributed throughout the entire room.
2. Install the indoor device in a location which
ensures that the distance through the wall to the
outdoor device is as short as possible.
3. Make sure that the drainage hose does not have
any kinks or upward inclines when you connect it
with the outside.
4. Do not select a location adjacent to a source of
heat, high humidity or inflammable gas.
5. Select a location which is firm enough for
installation so that the device is not subjected to
vibrations.
6. Check that the device has been installed
correctly and exactly.
7. Make sure that there is sufficient space available
for later repair and service work.
8. The device should be installed at a distance of at
least 1 m from all other electrical devices and
installations, e.g. TV, radio, computer, etc.
9. Select a location for the device which is easily
accessible so that the filter can be cleaned or
replaced without difficulty.
10. The maximum distance between the standard
indoor unit and outdoor unit is 5 m. The
maximum possible length of the refrigerant line is
10 m with a maximum height difference of 5 m.
11. Avoid direct sunlight.
Outdoor device
1. Select a location which avoids causing a
nuisance to neighbours from noise and air
emissions from device.
2. Select a location which is sufficiently well
ventilated.
3. Never cover the air inlets and outlets.
4. The location must be sufficiently firm for
installation and the prevention of vibrations.
5. There must be no risk presented by combustible
gas or gas escaping as a result of corrosion.
6. Check that the device is installed in accordance
with regulations.
7. It should be installed at least 20 cm above the
GB
20
Anleitung_Split_2500-3500_EQ_C_H_GB:_ 10.12.2008 11:54 Uhr Seite 20
