EIP WRD-5000 User manual

Drawing : - TPC343
Issue : - 3
Date : - 30/11/16
Whole Room Dryer
10290MG-GB
USER MANUAL

Drawing : - TPC343
Issue : - 3
Date : - 30/11/16
INTRODUCTION
The user manual tells you how to operate the WRD-5000. Please read thoroughly before operating the unit. If you
have any questions please contact our Customer Service Department at the address shown at the back of this
section or phone [phone]
IMPORTANT
Your WRD-5000 is packed in a plastic wrapping – please ensure that it is disposed of safely and where it will not be
a danger to small children.
UNPACKING
Carefully remove the unit from its transit box and wrapping, and visually check for any signs of transit damage. If
there are any signs of damage DO NOT attempt to operate the unit, call your supplier for advice. Retain the
packaging for further use, or dispose of it considerately
OPERATION
The WRD-5000 should only be operated in the horizontal position and with the unit standing on a firm, level floor.
The WRD-5000 is designed to blow large quantities of air across wet surfaces to speed up the drying process. The
WRD-5000 should be positioned in the centre of the area to be dried. Connect the power cord to a suitable supply
and the unit is ready for operation.
SWITCHING ON
The WRD-5000 ON/OFF switch is located on the side of the unit. To start the fan, set the switch to the ON position
(I). Since the WRD-5000 has a considerably high suction, always ensure that the inlet grille is kept free of any
obstruction during operation.
SWITCHING OFF
Set the ON/OFF switch to the OFF position (0). Turn off the power and disconnect. Do not use the supply cord to
adjust or move the unit. Use the handle provided.
The unit is fitted with rubber feet to allow it to be stored in the vertical position.
ELECTRICAL CONNECTIONS
The wires in the mains lead are coloured in accordance with the following code:
GREEN & YELLOW…………EARTH
BLUE………………………….NEUTRAL
BROWN...…………………….LIVE
As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings
identifying the terminals in your own plug, proceed as follows.
The wire which is coloured Green and Yellow must be connected to the terminal marked E or by the Earth Symbol or
coloured Green or Green and Yellow. The wire which is coloured Blue must be connected to the terminal in the plug
marked with the letter N or is coloured Black. The wire which is coloured Brown must be connected to the terminal
which is marked with the letter L or is coloured Red.
You must safely dispose of the non rewireable plug once it has been removed from the flexible cord. It is dangerous
to attempt to inset the plug into any electrical socket.
If the supply cord is damaged it must be replaced by qualified Ebac personnel or other similar qualified persons in
order to avoid hazard.
CHANGING THE FUSE
Only 13 amp fuses that are ASTA approved to BS1362 should be used.
NON REWIREABLE PLUGS
The fuse cover must be refitted after replacement of the fuse.
SERVICE
Always turn off the power and unplug the unit before removing any guards.
This machine should be serviced by qualified Ebac personnel or other persons having technical competence in
servicing electrical equipment following the instructions in the Ebac Service Manual.
WARNING
–
T IS APPLIANCE MUST BE EART ED

Drawing : - TPC343
Issue : - 3
Date : - 30/11/16
SPECIFICATIONS
Model WRD-5000
Part Number 10290MG-GB
Height 300 mm
Width 660 mm
Depth 660 mm
Weight 18Kg
Power 280W
Voltage 230 V
Airflow 5000M³/h
Fan Speed 1360rpm
Fan Blade Diameter 420mm
Noise Level <70dbA
IP Rating IP22
SAFETY PRECAUTIONS
WARNING- THIS FAN IS NOT FLAMEPROOF
♦DO NOT ALLOW CHILDREN TO PLAY WITH OR AROUND THE UNIT. ENSURE THE UNIT IS INACCESIBLE
TO CHILDREN WHEN NOT ATTENDED.
♦DO NOT USE THIS UNIT IN AN ENVIRONMENT CONTAINING FLAMMABLE FUMES
♦DO NOT USE THIS UNIT IF THE CABINET OR POWER CORD IS DAMAGED
♦DO NOT INSERT OBJECTS INTO ANY OF THE GRILLES ON THE MACHINE
♦DO NOT COVER OR OBSTRUCT AIRFLOW FROM THE GRILLES
♦DO NOT OPERATE THE UNIT WITH THE COVERS REMOVED
♦DO NOT ATTEMPT ANY REPAIRS SHOULD THE UNIT FAIL TO OPERATE
♦DO NOT STAND ON THE UNIT
♦DO NOT LIFT THE UNIT WHEN SWITCHED ON
♦DO CHECK THE PLUG ON THE EQUIPMENT MATCHES THE SUPPLY
♦DO USE THE UNIT FOR THE PURPOSE FOR WHICH IT WAS DESIGNED
♦DO ENSURE THE POWER CORD AND SUPPLY IS EARTHED CORRECTLY
♦DO USE A RESIDUAL CURRENT DEVICE “RCD” WHERE POSSIBLE
♦DO KEEP THE UNIT DRY. NEVER USE A HOSE OR PRESSURE WASHER TO CLEAN THE UNIT.
♦ This appliance can be used by children from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the application in a safe way and
understand the hazards involved.
♦ Cleaning and user maintenance shall not be made by children without supervision.
