eKey Fingerscan Access Control System User manual

General
© ekey biometric systems GmbH Operating instructions ekey home Page 1 / 41
OPERATING INSTRUCTIONS
ekey
home
Fingerscan Access Control System
ID16/3 :
Version
2
dated
27.1.2012

General
© ekey biometric systems GmbH Operating instructions ekey home Page 2 / 41
ENGLISH
ENGLISH ........................................................................................................................................................................... 2
1. FOREWORD .............................................................................................................................................................. 4
2. MANUFACTURER´S WARRANTY .................................................................................................................................. 4
3. CONTACT.................................................................................................................................................................. 4
4. NOTE ON THE OPERATING INSTRUCTIONS ................................................................................................................... 5
4.1 W
ARNING SIGNS AND SYMBOLS
.................................................................................................................................................................... 5
4.2 D
EPICTION CONVENTIONS
............................................................................................................................................................................ 5
4.3 V
ALIDITY
.................................................................................................................................................................................................... 5
5. PRODUCT OVERVIEW - THE EKEY HOME SYSTEM .......................................................................................................... 6
6. GENERAL SAFETY INFORMATION ................................................................................................................................
6.1 I
NTENDED USE
............................................................................................................................................................................................ 7
6.2 S
ECURITY AGAINST MANIPULATION
............................................................................................................................................................... 8
6.3
RISKS ASSOCIATED WITH INTENDED USE
..........................................................................................................................................................
6.4 REQUIREMENTS FOR THE USER ............................................................................................................................................................
6.5 N
OTE ON
P
RODUCT LIABILITY
.......................................................................................................................................................................
. EKEY HOME FINGER SCANNERS.................................................................................................................................. 10
7.1 M
ODELS AND VERSIONS
............................................................................................................................................................................. 10
7.2
OPERATING THE FINGER SCANNERS
.............................................................................................................................................................. 10
7.2.1 FUNCTION OF THE FINGER SCANNER ......................................................................................................................................... 10
7.2.2 OPERATING CORRECTLY THE FINGER SCANNER ........................................................................................................................ 11
7.2.3 WHAT YOU SHOULD NOT DO ...................................................................................................................................................... 12
7.3 O
PTI
CAL
SIGNALS ON THE EKEY HOME
F
INGER SCANNER
................................................................................................................................ 13
7.4 E
LE
CTRIC CONNECTION ....................................................................................................................................................................... 14
7.5 M
O
UNTING........................................................................................................................................................................................... 14
8. EKEY HOME CONTROL PANELS ................................................................................................................................... 14
8.1 M
ODELS
A
ND VERSIONS
............................................................................................................................................................................ 14
8.2
OPERATION
.............................................................................................................................................................................................. 15
8.2.1 ekey ho e CP IN and ekey ho e CP WM ............................................................................................................................ 15
8.2.1.1 Operating the buttons ................................................................................................................................................................ 15
8.2.1.2 Main enu .................................................................................................................................................................................. 15
8.2.1.3 Optical Signals ............................................................................................................................................................................. 15
8.2.1.4 INITIALIZING THE DEVICES.......................................................................................................................................................... 16
8.2.1.5 Overview of the progra ing enu of the control panel ...................................................................................................... 17
8.2.1.6 Entering the security code .......................................................................................................................................................... 18
8.2.1.7 Enrolling a fingerprint in the syste ......................................................................................................................................... 18
8.2.1.8 Deleting a user ............................................................................................................................................................................ 20
8.2.1.9 Setting a new security code........................................................................................................................................................ 20
8.2.1.10 Accessing serial nu ber and version nu ber......................................................................................................................... 21
8.2.1.11 Changing the relay switching ti es......................................................................................................................................... 22
8.2.1.12 Resetting to factory settings .................................................................................................................................................... 23
8.2.2 ekey ho e CP DRM 1 (2) ............................................................................................................................................................. 24
8.2.2.1 CONTROLS ................................................................................................................................................................................... 24
8.2.2.2 Main enu .................................................................................................................................................................................. 25
8.2.2.3 initial operation........................................................................................................................................................................... 25
8.2.2.4 Entering the security code .......................................................................................................................................................... 27
8.2.2.5 Enrolling a fingerprint in the syste ......................................................................................................................................... 27
8.2.2.6 Deleting a user ............................................................................................................................................................................ 31
8.2.2.7 Setting a new security code........................................................................................................................................................ 32
8.2.2.8 changing the relay switching ti es .......................................................................................................................................... 33

General
© ekey biometric systems GmbH Operating instructions ekey home Page 3 / 41
8.2.2.9 RESETting to factory settings ..................................................................................................................................................... 34
8.2.2.10 Test ode .................................................................................................................................................................................. 35
8.2.2.11 LED INTENSITY ........................................................................................................................................................................... 36
8.2.2.12 LOGGING ................................................................................................................................................................................... 37
8.2.3 Electric connection ....................................................................................................................................................................... 38
8.2.4 Mounting ...................................................................................................................................................................................... 38
10. TROUBLE-SHOOTING ................................................................................................................................................ 38
11. MAINTENANCE ........................................................................................................................................................ 40
11.1 C
ARE
.................................................................................................................................................................................................... 40
11.2 C
LEANING
............................................................................................................................................................................................. 40
12. DISPOSAL ................................................................................................................................................................ 40
13. TECHNICAL DATA ..................................................................................................................................................... 40
14. ACCESSORIES ........................................................................................................................................................... 41
15. DECLARATIONS OF CONFORMITY ............................................................................................................................... 41
16. EKEY BRANCH OFFICES .............................................................................................................................................. 41

General
© ekey biometric systems GmbH Operating instructions ekey home Page 4 / 41
.
Foreword
Congratulations on the purchase of this premium finger scanner system
ekey home.
It has been manufactured with highest accuracy and guarantees a maximum amount of recognition
performance. Enjoy the convenience - no more lost keys and no longer memorizing complicated codes.
From now on your finger is the key!
We hope you will enjoy your product a lot!
2.
Manufacturer´s warranty
ekey biometric systems (‘ekey’) guarantees, under conditions which you can view on our website
www.ekey.net, that the product is free from material or processing defects for
24 months from the date of purchase.
Warranty claims can only be made in the country where the product has been sold to you. ekey records
the production of each product.
3.
Contact
Visit the website of ekey biometric systems GmbH at:
www.ekey.net
There you can always find the most up to date version of this document, as well as other additional
information about this and other products by ekey biometric systems.
Should you still have technical questions, please contact your ekey dealer!
In order to have the most important information at hand in case of complaints, we request that you enter
the serial number below:
The serial number has 14 digits and can either be found on the label below the barcode or can be
accessed via the menu on the control panel.
ekey home finger scanner
ekey home control panel

General
© ekey biometric systems GmbH Operating instructions ekey home Page 5 / 41
4.
Note on the operating instructions
4. Warning signs and symbols
CAUTION! This symbol indicates a special notice, which you must pay attention to in the described
feature.
INFORMATION! This symbol indicates that you can find useful information and tips about the
product in the adjoining text.
STOP! This symbol indicates that you may under no circumstances carry out a given action. In the
majority of cases, in order to carry out the given feature, you need first to make some specific
settings.
Warning about dangerous electric voltage: This warning notice indicates that you are exposed
to electric voltage hazard
Warning about battery hazard
4.2 Depiction conventions
Depiction Signification
Listing
1.
2.
Follow the steps in this order
italic
underlined
Product name
4.3 Validity
These operating instructions are not subject to updating. You can find the most up-to-date version of
these instructions at www.ekey.net . Subject to optical and technical modifications, any liability for
misprints excluded.

General
© ekey biometric systems GmbH Operating instructions ekey home Page 6 / 41
5.
Product overview - the ekey home system
For a complete operational ekey home system you will need the following components:
Not all parts are supplied by ekey!
ekey home is a biometric access system which is equipped with a finger scanner. This scanner reads
special features of your finger lines and uses them to recognise people with access rights. Each one of
your fingers has specific recognition features and also varies from the fingers of other people. ekey home
is available in different functional and mechanical versions and can therefore be optimally adapted to your
needs.
ekey home finger scanner versions
ekey home FS WM 2.0 wall-mounted
ekey
home FS IN 2.0 integrable (door)
ekey home FS OM outlet-mounted
Supplied by
ekey
Models
Description
on page
ekey home
f
inger
scanner
Yes
7
ekey home
control panel
Yes
8
Power supply
Yes
Motor
lock
/
Electric strike
/
Locking
system
No
optional
Cable transfer
Yes
3
2
1
1 2 3
ekey
FS OM
mounting
height varies
according to
finger scanner
model
floor
L
min. 3 (depending on motor
locking system)

General
© ekey biometric systems GmbH Operating instructions ekey home Page 7 / 41
ekey control panel versions
The ekey home control panels are intended to directly control an electric motor lock. This is usually relay
1 for a door wiring.
ekey home CP WM 1 wall-mounted 1 relay
ekey home CP WM 3 wall-mounted 3 relays
ekey home CP IN 1 integrable 1 relay
ekey home CP IN 2 integrable 2 relays
ekey home CP DRM 1 Electric control cabinet (switching cabinet on top hat rail) 1 relay
ekey home CP DRM 2 Electric control cabinet (switching cabinet on top hat rail) 1 relay
Essentially any finger scanner may be combined to any control panel. Based on the scope of delivery,
check precisely which units you have when you start up the systems.
6.
General Safety Information
6. INTENDED USE
The ekey home system consisting of
ekey home finger scanner
ekey home control panel
ekey power supply
is a biometric access control system available in different hardware shapes and combinations. It captures
the unique features (minutea) of the fingerlines, which are then compared to the master templates saved
in the finger scanner. To authenticate a finger successfully, a certain degree of identicalness (threshold)
has to be reached. Based on this, a defined switching actuator is activated (relay output situated on the
control panel).
The system has been primarily developed for opening front doors, apartment doors, garage doors, etc. in
a residential and corporate environment. It has to be installed in a fixed position, and in accordance to the
accompanying installation manual and wiring diagrams.
Electrical Safety
All ekey home devices are to be operated by safety extra-low voltage and powered by adapters from
protection class 2 according to VDE 0140-1.
Such power adapters are typically marked with below shown symbol according to IEC 60417:
Your ekey home system is powered by electricity. Despite the exclusive operating clearance of
protection class 2 power adapters, all devices need to be handled with particular caution during
installation and wiring. For this reason, all services have to be carried out by qualified personnel
e.g. electrician, installer, etc.).
3
3
4
4
3
4
5
5
5

General
© ekey biometric systems GmbH Operating instructions ekey home Page 8 / 41
Please read carefully the provisions below before starting to wire the system:
The connections of the devices are NOT protected against reverse polarity! Incorrect
wiring of the devices can result in them being damaged beyond repair!
Only trained and qualified electricians should carry out electrical wiring of the units
and connection to the mains grid!
Lay the connecting cable between the e ey home CP (control panel) and the e ey
home FS (finger scanner) separately from any 230 V or 380 V mains voltage cables
in the house. The connecting cable carries low voltage signals that can be interfered
with by current-carrying mains voltage cables in the vicinity.
6.2 SECURITY AGAINST MANIPULATION
Your ekey home system consists of 2 electronic devices
the ekey home finger scanner
the ekey home control panel
The ekey home finger scanner is typically mounted in an outdoor environment and therefore accessible to
everyone. In order to avoid external tampering, which could theoretically result in an unauthorized
access, your system is equipped with below listed security features:
The ekey home control panel has to be mounted in a secure area. The switching actuator (relay
output) to operate a motor locking system is positioned on the control panel.
System changes (fingerprint enrollment, etc.) can only be made via the ekey home control panel
situated in a secure area.
The access to the menu in the ekey home control panel is secured with a security code. This is an
additional obstacle within the system for unauthorized users.
The finger scanner is connected to the control panel by a data line. The communication between
both components is encrypted.
The finger scanner and the control panel are “married”, i.e. they have been coupled during the
initial start-up. When replacing a device, a new coupling must be done via a specific key
combination on the control panel mounted in the secure area). Otherwise no access will be
granted.
Operation and data monitoring
Your ekey home finger scanner features software routines which run sanity checks of the system
operation data. If the system identifies inconsistencies, then the finger scanner will be recalibrated
automatically. This calibration procedure takes 3 to 5 seconds and can be followed via the LED signals
sequence (see section 7.3). These inconsistencies can be caused by:
abnormal electrostatic discharges (ESD),
abnormal electromagnetic interference fields.
It is not possible to operate the finger scanner during the calibration process. The device resumes its
normal operation after the calibration process is over.

General
© ekey biometric systems GmbH Operating instructions ekey home Page / 41
6.3 RISKS ASSOCIATED WITH INTENDED USE
The sensor surface of the thermal line sensor, which is primarily used for the
ekey home FS WM
ekey home FS IN
can become very hot (>50°C) when exposed to direct sunlight. In order to avoid burns and scalds of the
fingertips, it is recommended to test the temperature by shortly touching the sensor. If needed, place
your hand over the scanner making a cooling shade.
Apart from that, there are no other known risks in normal use of the system.
6.4 REQUIREMENTS FOR THE USER
It is essential for the installer to study the supplied manuals (Mounting instructions, Wiring, and Operating
instructions) before installing the devices. The installer (system commissioner) is required to possess
professional certificated training in the area of electrotechnical engineering.
The user has to use the system in accordance with these instructions. Otherwise, no special knowledge is
necessary to operate the system.
6.5 NOTE ON PRODUCT LIABILITY
In below listed cases, the security provided respectively the protection of the device may be impaired.
The liability for the operability of the equipment is transferred to the operator / administrator / user:
The device is not operated, maintained and cleaned in accordance with the respective manual.
The device is used outside of the application area specified herein, e.g. in automotive applications,
hazardous areas, safety-critical applications (thereat to life or physical condition)
The operator carries out unauthorized changes on the devices
…

General
© ekey biometric systems GmbH Operating instructions ekey home Page 10 / 41
7.
ekey home finger scanners
7. MODELS AND VERSIONS
There are 3 different ekey home finger scanner models.
ekey home FS WM 2.0 – wall-mounted
ekey home FS IN 2.0 – integrable into doors and intercoms
ekey home FS OM – outlet-mounted
The individual finger scanners essentially differ in their method of installation. The method of operation,
however, is identical for all models.
7.2 OPERATING THE FINGER SCANNERS
7.2. FUNCTION OF THE FINGER SCANNER
ekey finger scanners are exclusively equipped with line (swipe) sensors. To capture a fingerprint, please
draw your finger over the sensor. The system records the image of the fingerprint lines (papillary lines)
line by line and compiles an image from the individual rows. The finger scanner then calculates a
recognition template (minutia and their relative positions), which is compared to the previously stored
finger templates (reference finger templates). If a certain degree of congruence is exceeded (threshold), a
positive match (= finger was recognized) will trigger an allocated action (e.g. switch relay output 1). It is
important to note that no fingerprint images are stored.
Which part of the finger should be recorded by the finger scanner?
It is necessary to capture an image of the 3rd
phalanx. On the contrary, your finger scanner will not
function properly.
In order to ensure this, take care to operate the finger
scanner correctly. It is fundamental to place your
finger correctly in the finger recess and move it down
across the sensor at the right speed. Ergonomically
speaking, the best fingers are the index, the middle
finger and the ring finger. The thumb and the little
finger may not be used!
A finger scanner works like a camera. It makes a picture of the bottom side, the papillary lines, of your
finger´s third phalanx. However, this picture must be of good quality, so that physical access can be
granted whenever necessary.
Imagine you wish to make a picture of someone, and this person
e ey home FS WM e ey home FS IN e ey home FS OM

General
© ekey biometric systems GmbH Operating instructions ekey home Page 11 / 41
keeps fidgetting
runs by and you try to make a picture of him at that exact moment
hides half of his face behind a tree
etc.
What do you think these pictures will look like? On some of the pictures you will not even be able to
recognize the person.
The finger scanner works in the same way. The finger scanner can only read all the information contained
in your finger, and consequently open your doors securely and reliably, if you move your finger down
across the sensor evenly and in the right position.
Let us now look at where you should place your fingers and at which speed you should move them across
the sensor, so that the „pictures“ of your fingers are perfect.
The finger recess – the control element
The finger recess allows to place the finger correctly so that a finger picture of good quality can be
captured. It actually is the control element and consists of
-Pin point - Sensor - right and left recess edges
7.2.2 OPERATING CORRECTLY THE FINGER SCANNER

General
© ekey biometric systems GmbH Operating instructions ekey home Page 12 / 41
Best results are achieved by using the middle finger and stretching out the index and
ring finger at the same time.. see the figure above).
The correct operation of the fingerprint scanner is your guarantee of the successful functioning of this
product. Below written recommendations apply for all hardware types:
Please use the finger which has the best finger lines in your opinion. In particular with weakly-
pronounced finger lines you should avoid pressing down too hard on the sensor so that you do not
squash the finger lines which are flat anyway.
The small fingers and thumbs should NOT be used!
The finger scanner is equipped with a fully automatic learning system, which recognizes changes in
user habits and growing children´s fingers. To optimize the fingerprint recognition, it is best to
swipe each finger at least 5 times over the sensor, every time you have enrolled a new finger, or if
you have not used the system for a long time. If any of your finger scans is rejected, then please
repeat this process. Sollte Ihr Scan abgewiesen werden, so wiederholen Sie bitte diesen Vorgang.
If none of your fingerprint scans are accepted in spite of this, please try the following:
Vary the pressure (stronger or lighter) when swiping your finger.
Take care to place your finger correctly in the finger recess
Small finger and thumb are not ideal for ergonomic reasons. The thumb is particularly very difficult
to use.
Try scanning the fingerprint at different speeds in order to find out the best speed for you.
Save the same fingerprint in several locations, if the above points do not help. You have
memory spaces available. In extreme circumstances you should use up to 10 memory spaces for
one finger.
Wet fingers show different contours. If you often have wet fingers, then save your fingerprint in
wet condition.
Children´s fingerprints are usually recognized, depending on the body height of the child, generally
from the age of 5 – please also observe the above points.
7.2.3 WHAT YOU SHOULD NOT DO

General
© ekey biometric systems GmbH Operating instructions ekey home Page 13 / 41
7.3 OPTICAL SIGNALS ON THE EKEY HOME FINGER SCANNER
Your ekey home finger scanner is equipped with LEDs that deliver information on the operational state
and individual functions of your system. The optical signaling of the individual finger scanners will differ
though. The two tables below will show you the corresponding signals and their meanings.
The LEDs are named based on their purpose as
Status LED – for details on the operational state (finger recognized, finger rejected, etc.)
Function LED– for details on the function of the system (online, offline, etc.)
LED signals on e ey home FS OM, e ey home FS IN 2.0 and e ey home FS WM 2.0
e ey home FS OM
e ey home FS IN 2.0
e ey home FS WM 2.0
Function
LED
Status LED Description
Normal mode
ORANGE
flashing
slow
Left: OFF
Right: OFF
There is no bus connection to the ekey home control panel. Please check
the connection cables or apply „Initializing the devic es“ as described in
section 8.2.1.4 or 8.2.2.3.
BLUE Left: OFF
Right: OFF The system is online – all c omponents are communicating correctly.
ORANGE
flashing
quick
Left: OFF
Right: OFF
Once you have drawn your finger over the sensor, the system will start
the processing (enrollment) and matching. The LED flashes orange
during the entire process.
GREEN Left: OFF
Right: OFF Fingerprint recognition: positive, the relay switches.
RED Left: OFF
Right: OFF
Fingerprint recognition: negative or poor image, which does not allow
any fingerprint check.
ORANGE Left: OFF
Right:OFF
Fingerprint enrollment mode. When enrolling a finger via the menu on
the control panel, this LED state indicates the system to be ready for
swiping a finger over the sensor. The system generates a reference
template from this fingerprint image.
Status LED
Function LED

General
© ekey biometric systems GmbH Operating instructions ekey home Page 14 / 41
RED GREEN
flashing
Left: OFF
Right: OFF The sensor is dirty, smudgy or wet. Clean the sensor!
During the boot procedure (power up)
GREEN
BLUE flash
BLUE
Left: off – BLUE flash
- off
Right: off – RED flash
- off
The module is booting (powering up). It takes about 1-2s counting from
the moment when power supply is available.
7.4 ELECTRIC CONNECTION
You can find further details such as the
pin assignment
wiring examples
either on the accompanying ekey home wiring diagram, or on the DVD as a .pdf file.
7.5 MOUNTING
You can find further information either on the accompanying ekey mounting instructions, or on the DVD
as a .pdf file.
8.
ekey home control panels
8. MODELS AND VERSIONS
There are 3 different ekey home control panel models.
ekey home CP IN – integrable into doors
ekey home CP WM – wall-mounted
ekey home CP DRM – 4HP DIN—rail mounted device
The individual control panels essentially differ in their method of installation. The method of operation,
however, is identical for the ekey home CP IN and the ekey home CP WM. The ekey home CP DRM is the
more recent model featuring an LCD display. In addition, the state of the relay outputs is indicated via
LEDs.
The ekey home control panels are the actuator units within the ekey home system. The finger scanner
transmits to the control panel which relay output has to be activated. This action is then executed on the
respective control panel. In addition, the system configuration is another important task of the ekey home
control panel. The respective settings (e.g. fingerprint enrollment, relay switching time, etc.) are defined
via the push buttons and the display.
The ekey home CP should always be mounted in a secured area indoors). If you mount the control
panel outdoors, where anybody can have access to it, then unauthorized people could easily unlock
the door!

General
© ekey biometric systems GmbH Operating instructions ekey home Page 15 / 41
8.2 OPERATION
8.2. EKEY HOME CP IN AND EKEY HOME CP WM
8.2.1.1 OPERATING THE BUTTONS
Four buttons are used for the operation:
= OK button: is used to enter the menu and to confirm entries.
< and > buttons: are used to change the values on the display or for navigating in the programming
menu (see diagram in section 8.2.1.5)
ESC button (X): is used to cancel the current entry.
8.2.1.2 MAIN MENU
Menu item Display____________
Normal mode (flashing dot) .
Enrol user (Enroll user) Eu
Delete user (delete user) du
Set the security code (Security code) Sc
Serial and version number (Information) In
Reset to factory settings rr
Change relay switching times (Relay time) rt
8.2.1.3 OPTICAL SIGNALS
Displays from the menu navigation are not described here.
Display Information Description
Both dots are lit up
The terminal
is new or has been reset to factory
settings. The link with the fingerprint scanner is not
active.
Left dot flashing
Normal mode, everything is functioning properly.
"Nu" - Need Update
This terminal requires a firmware update. This display
also appears during updating.
„E0“- Error code
There is no connection to the finger scanner, or the
energy supply to the system has been interrupted.
The system will be rebooted.
„E “-Error code
fingerprints have already been registered
No more
fingerprints can be registered. Where
necessary delete existing fingerprints in order to
record new ones.

General
© ekey biometric systems GmbH Operating instructions ekey home Page 16 / 41
„E2“-Error code
30min lock after the security code has been entered
incorrectly three times. Wait 30 minutes before
entering the security code again
.
„E3“-Error code
Devices connected incorrectly. Connect the devices
again, as one of the devices has been manipulated.
to
Display
s
a number between
“” and “99
” and the dot on
the right is lit up.
Shows the user number of the recognized fingerprint.
to
Control panel counts down
from „44“ to „0“
State when connected to live current, with no
connection having been created to the finger scanner.
If the control panel does not switch to normal mode
after a few seconds, but continues to
count down, the
physical connection (cable) with the finger scanner is
not intact and has to be checked / corrected.
8.2.1.4 INITIALIZING THE DEVICES
CAUTION! The electrical connection of the system can only be carried out by a specialist!!!
Before you connect the systems to the mains, make sure that both the mounting and the wiring
have been done correctly.
You may only manipulate the electric connections after having separated the system from the
mains!
You will find mounting and wiring instructions in sections 7.4 and 7.5.
CONNECTION BETWEEN CONTROL PANEL AND FINGER SCANNER
When the devices are connected to the power supply, the control panel display starts to count down until
a connection has been created with the finger scanner. Afterwards two red dots appear. During this time
the status display on the finger scanner lights up red. Once the boot procedure has been completed, the
status display begins to flash orange. Now the initialization can be started.
If the counter does not stop on the control panel and you are not taken to the language settings,
please double check the RS485 bus connection clamp 1 and 2). Alternatively, please check
whether the finger scanner is properly powered LED blinking or illuminated).
1.) Press the OK button
2.) Press the ESC button. "EF" appears on the display, which stands for "Enroll Finger".
3.) A) Initialization after having replaced the control panel
If it was necessary to replace the control panel because it was defective, then fingers had
already been recorded in the ekey home finger scanner. In order not to have them deleted, a
pre-recorded finger may now be swiped over the sensor, and the initialization process is
started without deleting any data.
B) New installation
If this is a new system (new installation), press the ESC button once again.
The system now initializes. All the fingers recorded previously on the finger scanner will be
deleted.
4.) The initialization process runs completely automatically, in the course of which the devices are
connected with each other. This connection is meant to prevent unauthorized people gaining
access in case of an improper finger scanner replacement.
DISPLA Y KEY STROKE DISPLAY KEY STROKE DISPLAY KEY STROKE DISPLAY DISPLA Y
The de vices have now been
initialized. You may start enrolling
users->
see B:
FINISHED
X
X
START

General
© ekey biometric systems GmbH Operating instructions ekey home Page 17 / 41
8.2.1.5 OVERVIEW OF THE PROGRAMMING MENU OF THE CONTROL PANEL
You can access lower menu levels by pressing the OK button. You can move back up by pressing the ESC
button. You can navigate by pressing the left < and right > buttons. You can choose a particular option by
pressing OK.
Keypad on
ekey home CP WM
and
ekey home CP IN
. Flashing dot
Normal mode
. 0..99
Enter safety code
Eu
Enroll user
du
delete user
Sc
Set Security
code
In
Information
rr
Factory
settings
rt
Set relay
impulse
..99
Select user #
F ..F9,F 0
Select finger
#
o …o3; od
Select relay
o …o3
Select relay
..99
Select user #
See section
8.2.1.7
0..99
Enter security
code
See section
8.2.1.8
See section
8.2.1.
0..99
Enter security
code
See section
8.2.1.12
0..99
Define relay
switching time
See section
8.2.1.11
Sn
Serial #
US
Version
Cu
Control panel
FS
Finger scanner
Cu
Control panel
FS
Finger scanner
See section
8.2.1.10
OK
= : to enter the menu and to confirm entries
><
or : to navigate in the menu or to select values during setup and
finger enrollment
X = ESC: to cancel the current entry

General
© ekey biometric systems GmbH Operating instructions ekey home Page 18 / 41
8.2.1.6 ENTERING THE SECURITY CODE
The security code allows you to avoid system manipulations by unauthorized people. Since the control
panel is to be mounted in a secure area, an unauthorized person will have to get access to this secured
area first. This security code can then be described as an additional hurdle.
After 3 incorrect attempts, the device is blocked for 30 minutes and the control panel display
shows error code . If the control panel is disconnected from the mains, the counter resets itself
once is has been re-connected to the mains.
The factory default setting for this code is „99“. Change this code as soon as you have started up the
system to any 2-digit code of your choice.
1.) Press the OK button on the control panel.
2.) Enter the left digit of the security code using the < and > buttons (factory setting is )
3.) Press the OK button.
4.) Enter the right digit of the security code using the < and > buttons (factory setting is )
5.) Press the OK button.
The display shows „Eu“ (Enroll user).
8.2.1.7 ENROLLING A FINGERPRINT IN THE SYSTEM
In ekey home a maximum of fingerprints can be enrolled. These fingerprints can be assigned to
user IDs. You can for example
administrate 11 users, each one enrolling fingerprints or
administrate users, each one enrolling only 1 fingerprint or
opt for any other mixed setup.
Generally speaking, we recommend to:
save at least 2 fingerprints per user (ideally from different hands)
use index and middle fingers. From an ergonomic point of view, they are best suited for proper
operation resulting in the highest level of recognition.
avoid using thumbs and little fingers.
create a user list assigning the user ID to a user name. You can find a template in the
accompanying DVD.
stick to the suggested numbering of the respective fingerprints (see below).
Before adding a fingerprint into the system, please read through section 7.2
“Operating the finger scanners“, or watch the movie on proper use on the
accompanying DVD. Using the finger scanner properly is essential for a stable
operation, and this in turn starts during the fingerprint enrollment. Properly
recorded fingerprints will simply work better!
DISPLA Y KEY
STROKE
DISPLA Y +
SETTING
KEY STROKE DISPLA Y+
SETTING
KEY STROKE DISPLA Y
Set
security code
DIGIT
Set security code
DIGIT 2
STA R
T
FINISHED

General
© ekey biometric systems GmbH Operating instructions ekey home Page 1 / 41
1.) First, enter the security code as per section 8.2.1.6:
2.) When the display shows "Eu", press the OK button.
3.) Select the user: The display shows the number "1". If this user number is already in use, this is
signalized by a lighted dot next to the number. For example: „ .“. Set the desired user number
using the < and > button.
4.) Press the OK button.
5.) Select the finger: On the display "F " stands for finger 1 = small finger on the left hand. Please
begin counting with the little finger on the left hand.
The little finger on the right hand is number 10 (= setting "F0" on the display). If a finger number
has already been allocated, then this is also signalized with a dot next to the number. For example
set the index finger on the right hand as “F7". If the finger has already been recorded, then you
will see a flashing dot beside the finger number, e.g. „F1.“. You may still record the finger however
if you wish to do so. The preceding finger will then be automatically overwritten.
6.) Press the OK button.
7.) Consider step 7 only if you have an ekey home control panel with more than 1 relay:
ekey home CP IN 2
ekey home CP WM 3
You can now determine which relay is meant to be controlled by the previously selected
fingerprint. "o " on the display signalizes that at the moment the first relay (the motor lock) is
selected (standard setting).
“o ” … Relay 1
“o2”… Relay 2
“o3“... Relay 3
“od”… Double relay function: Relay and relay 2 switch simultaneously with one
finger swipe only. Both relays switch according to the set relay switching times (e.g. relay 1
3 seconds and relay 2 6 seconds).
Use the < and > buttons to select the relay to be controlled.
8.) Press the OK button.
KEY
STROKE
DISPLAY
Swipe
USER
FINGER
DISPLAY
DISPLAY
DISPLAY
Enter security
code
DISPLAY
KEY STROKE
DISPLAY +
SETTING
KEY STROKE
DISPLAY +
SETTING
KEY STROKE
DISPLAY +
SETTING
Enter security
code
Select
USER
NUMBER
0-99
Select FINGER
NUMBER F -
F 0
Select RELAY
o -o3 or od
1
5
6
0
STA R
T
The red dot only flashes if this memory space
has already been allocated (there already is a
user or a finger on this position)!
User finger recorded
!
FINISHED

General
© ekey biometric systems GmbH Operating instructions ekey home Page 20 / 41
Once „EF“ appears on the display, you have 60 seconds time to swipe your finger, starting at the
top knuckle downwards, over the sensor. The finger scanner status LED lights up orange =
operation mode Enrollment. The device is waiting for a finger to enroll.
The fingerprint should be recorded in the manner described in section 7.2. The finger scanner
possesses a (LED) status display, which signalizes using two different colors, after you have swiped
your finger over the sensor, if the enrollment was successful or not:
Red: The finger could not be scanned successfully,
Please repeat the enrollment process. Read section xxx before doing so.
Watch the movie on the DVD.
Green: The finger has been succesfully recorded (scanned). The enrollment was
successful Enter the user name on the user list, which you maybe have on paper,
at the corresponding place.
8.2.1.8 DELETING A USER
The “DELETE USER” (du) function always relates to all of the user´s data. It is NOT possible to delete
individual fingers. If a user is deleted, all his recorded fingers will be irrecoverably deleted.
1.) Look up in the handwritten user list the user number which you wish to delete.
2.) First enter the security code as per 8.2.1.6
3.) Press the > button several times until “du” (delete user) is displayed.
4.) Press the OK button.
5.) Use the < and > buttons to select the desired user number to be deleted from the system.
6.) Press the OK button.
7.) “OK” is then shown on the display for a short time. The device then returns to normal mode.
8.2.1. SETTING A NEW SECURITY CODE
Please be aware that the device cannot be operated further without setting a new security code. If you
enter a new security code, then you will always need this code in the future in order to make changes
(finger enrollment, delete user, etc.) in your ekey home system.
1.) First enter the security code as per 8.2.1.6
D: DELETE USER (du)
ENTER SECURITY
CODE
DISPLA Y + SE TTING KEY STROKE DISPLA Y +
SETTING
KEY STROKE DISPLAY DISPLA Y
SEE
B:
Select MENU
ITEM du
Select USER
NUMBER
STA RT
FINISHED
The selected user has
been deleted!
De r NEUE
Sicherheitscode ist
dam it aktiv!
F: CHANGING THE SECURITY CODE (Sc)
ENTER SECURITY
CODE
DISPLA Y +
SETTING
KEY STROKE DISPLAY +
SETTING
KEY STROKE DISPLAY +
SETTING
KEY STROKE DISPLA Y DISPLAY
SEE B:
Select
MEN
U
ITEM
Sc
NEW CODE
DIGIT
NEW CODE
DIGIT 2
FINISHED
STA RT
