BUILT-IN MICROWAVE OVEN
MODEL: EMO-B2361BI(SS)
Owner’s Manual
Pleasereadthismanualcarefully
beforeoperatingyourset.

 Retainitforfuturereference.

Recordmodelnumberandserial
numberoftheset.

Seethelabelattachedonthesetand
quotethisinformationtoyourdealer
whenyourequireservice.





ForTheWarrantyTerms&Conditions,PleaseReferToWarrantyCertificate.

P
PR RE EC CA AU UT TI IO ON NS S T TO O A AV VO OI ID D P PO OS SS SI IB BL LE E E EX XP PO OS SU UR RE E T TO O E EX XC CE ES SS SI IV VE E M MI IC CR RO OW WA AV VE E E EN NE ER RG GY Y 
Failuretoobservethefollowingprecautionscanresultinhamfultomicrowaveenergy:
1.Donotattempttotemperwith,ormakeanyadjustmentorrepairsthedoor,controlpanel,safety
interlocksoranyotherpartsoftheovenonyourown,itmustberepairedorreplacedbythe
authorizedserviceagentorafter‐salesservicecentreorasimilarlyqualifiedpersoninorderto
avoidhazards.
WARNING:Itishazardousforanyoneotherthanatrainedpersontocarryoutanyserviceor
repairoperationwhichinvolvestheremovalofanycoverwhichgivesprotectionagainstexposure
tomicrowaveenergy.
2.Donotplaceanyobjectbetweentheovenfrontfaceandthedoororallowsoilorcleaner
residuetoaccumulateonsealingsurfaces.
3.Donotoperatetheovenifitisdamaged.Itisparticularly importantthatthedooroftheovenis
closedproperlyandtherearenodamagestothe:
a)Door(bent),
b)Doorhingesandlatches(brokenorloosened),
c)Doorsealsandsealingsurfaces.


I
IM MP PO OR RT TA AN NT T S SA AF FE EG GU UA AR RD DS S 
a.
b.
c.
d.
Whenusingthisappliance,basicsafetyprecautionsshouldbefollowed,includingthefollowing:
WARNING:Toreducetheriskofburns,electricshock,fire,injurytopersonsorexposuretoexcessive
microwaveenergy:
1. Readallinstructionsbeforeusing.
2. Donotcontacttheplugwithwethands.
3. Donotusetheappliancewhenthepowercordisdamagedortheplugisnotproperlyinserted.
4. Neverbentorbindthepowercordorapplybyexcessiveforce,otherwiseitmaycausedamage.Ifthe
powercordisdamaged,itmustbereplacedbytheauthorizedserviceagentorafter‐salesservice
centreorasimilarlyqualifiedpersoninordertoavoidhazards.
5. Donotoperatetheovenwhenempty.
6. Donotusecorrosivechemicalsorvaporsinthisappliance.Thistypeofovenisspecificallydesignedto
heat,cookordryfood.Itisnotdesignedforindustrialorlaboratoryuse.
7. WARNING:Whentheapplianceisoperatedinthecombinationmode,childrenshouldonlyusethe
ovenunderadultsupervisionduetothetemperaturesgenerated.
8. Toreducetheriskoffireintheovencavity:
Whenheatingfoodinplasticorpapercontainer,keepaneyeontheovenduetothepossibilityof
ignition.
Removewiretwist‐tiesfrompaperorplasticbagsbeforeplacingbagintotheoven.
Ifsmokeisobserved,switchofforunplugtheapplianceandkeepthedoorclosedinordertostifle
anyflames.
Donotusethecavityforstoragepurposes.Donotleavepaperproducts,cookingutensilsorfood
inthecavitywhennotinuse.
9. WARNING:Liquidoranyotherfoodsmustnotbeheatedinsealedcontainersastheyareliableto

explode.
10. Microwaveheatingofbeveragecanresultindelayederuptiveboiling,thereforecarehastobetaken
whenhandlingthecontainer.
11. Donotfryanyfoodintheoven!Hotoilcandamagetheovenpartsandutensilsandevenresultinskin
burns.
12. Eggsintheirshellandwholehard‐boiledeggsshouldnotbeheatedinmicrowaveovenssincethey
mayexplodeevenaftermicrowaveheatinghasended.
13. Piercefoodswithheavyskinssuchaspotatoes,wholesquashes,applesandchestnutsbeforecooking.
14. Thecontentsoffeedingbottlesandbabyjarsshouldbestirredorshakenandthetemperatureshould
becheckedbeforeservinginordertoavoidburns.
15. Cookingutensilsmaybecomehotbecauseofheattransferredfromtheheatedfood.Potholdersmay
beneededtohandletheutensil.
16. Utensilsshouldbecheckedtoensurethattheyaresuitableforuseinmicrowaveoven.
17. WARNING:Itishazardousforanyoneotherthanatrainedpersontocarryoutanyserviceorrepair
operationwhichinvolvestheremovalofanycoverwhichgivesprotectionagainstexposureto
microwaveenergy.
18. Thisapplianceisnotintendedforusedbypersons(includingchildren)withreducedphysical,sensory
ormentalcapabilities,orlackofexperienceandknowledge,unlesstheyhavebeengivensupervision
orinstructionconcerninguseoftheappliancesbyapersonresponsiblefortheirsafety.
19. Thisapplianceisfordomesticandhouseholduseonly.
20. Savetheseinstructionsforfuturereference.
I
IN NS ST TA AL LL LA AT TI IO ON N 
1. Placetheovenonaflatandstablesurface.Makesureallthepackagingmaterialsareremovedfrom
theinsideofthedoor.Checktheovenwhetheraccessoriesallingoodconditions.
Warning:Checktheovenforanydamage,suchasmisalignedorbentdoor,damageddoorsealsand
sealingsurface,brokenorloosedoorhingesandlatchesinsidethecavityoronthedoor.Ifthereisany
damage,donotoperatetheovenandcontactqualifiedservicepersonnel.
2. Donotplacetheovenwhereheat,moisture,orhighhumidityaregenerated,ornearcombustible
materials.
3. Forcorrectoperation,theovenmusthavesufficientairflow.Allow20cmofspaceabovetheoven,
10cmatthebackand5cmatbothsides.Donotcoverorblockanyopeningsontheappliance.Donot
removefeet.
4. Donotoperatetheovenwithoutglasstray,rollerring,andshaftintheirproperpositions.
5. Makesurethatthepowersupplycordisundamagedanddoesnotrunundertheovenoroveranyhot
orsharpsurface.
6. Thesocketmustbereadilyaccessiblesothatitcanbeeasilyunpluggedinanemergency.
7. Donotusetheovenoutdoors.
R
RA AD DI IO O I IN NT TE ER RF FE ER RE EN NC CE E 
Operationofthemicrowaveovencancauseinterferencetoyourradio,television,orsimilarequipment.
Whenthereisinterference,itmaybereducedoreliminatedbytakingthefollowingmeasures:
1. Cleandoorandsealingsurfaceoftheoven.
2. Re‐orientthereceivingantennaofradioortelevision.

3. Relocatethemicrowaveovenwithrespecttothereceiver.
4. Movethemicrowaveovenawayfromthereceiver.
5. Plugthemicrowaveovenintoadifferentoutletsothatmicrowaveovenandreceiverareondifferent
branchcircuits.
G
GR RO OU UN ND DI IN NG G I IN NS ST TR RU UC CT TI IO ON NS S 
Thisappliancemustbegrounded.Thisovenisequippedwithacordhavingagroundingwirewitha
groundingplug.Itmustbepluggedintoawallreceptaclethatisproperlyinstalledandgrounded.Inthe
eventofanelectricalshortcircuit,groundingreducesriskofelectricshockbyprovidinganescapewirefor
theelectriccurrent.Itisrecommendedthataseparatecircuitservingonlytheovenbeprovided.Usinga
highvoltageisdangerousandmayresultinafireorotheraccidentcausingovendamage.
WARNING:Improperuseofthegroundingplugcanresultinariskofelectricshock.

Note:
1. Ifyouhaveanyquestionsaboutthegroundingorelectricalinstructions,consultaqualifiedelectrician
orserviceperson.
2. Neitherthemanufacturernorthedealercanacceptanyliabilityfordamagetotheovenorpersonal
injuryresultingfromfailuretoobservetheelectricalconnectionprocedures.

Thewiresinthiscablemainarecolouredinaccordancewiththefollowingcode:
GreenandYellow=EARTH
Blue=NEUTRAL
Brown=LIVE

M
MI IC CR RO OW WA AV VE E C CO OO OK KI IN NG G P PR RI IN NC CI IP PL LE ES S 
1. Arrangefoodcarefully.Placethickestareastowardsoutsideofthedish.
2. Watchcookingtime.Cookfortheshortestamountoftimeindicatedandaddmoreasneeded.Food
severelyovercookedcansmokeorignite.
3. Coverfoodswhilecooking.Coverspreventspatteringandhelpfoodstocookevenly.
4. Turnfoodsoveronceduringmicrowavingtospeedcookingofsuchfoodsaschickenandhamburgers.
Largeitemslikeroastsmustbeturnedoveratleastonce.
5.Rearrangefoodssuchasmeatballshalfwaythroughcookingbothfromtoptobottomandfromthe
centerofthedishtotheoutside.
U
UT TE EN NS SI IL LS S G GU UI ID DE E 

1. Theidealmaterialforamicrowaveutensilistransparenttomicrowave,itallowsenergytopass
throughthecontainerandheatthefood.
2. Microwavecannotpenetratemetal,sometalutensilsordisheswithmetallictrimshouldnotbeused.

3. Donotuserecycledpaperproductswhenmicrowavecooking,astheymaycontainsmallmetal
fragmentswhichmaycausesparksand/orfires.
4. Round/ovaldishesratherthansquare/oblongonesarerecommend,asfoodincornerstendsto
overcook.
5. Narrowstripsofaluminumfoilmaybeusedtopreventovercookingofexposedareas.Butbecareful
don’tusetoomuchandkeepadistanceof1inch(2.54cm)betweenfoilandcavity
Thelistbelowisageneralguidetohelpyouselectthecorrectutensils.

CookwareMicrowaveGrillCombination
Heat–ResistantGlassYesYesYes
NonHeat–ResistantGlassNoNoNo
Heat–ResistantCeramicsYesYesYes
Microwave–SafePlasticDishYesNoNo
KitchenPaperYesNoNo
MetalTrayNoYesNo
MetalRackNoYesNo
AluminumFoil&FoilContainerNoYesNo
 
P
PR RO OD DU UC CT T D DE ES SC CR RI IP PT TI IO ON NS S 











1. Door Safety Lock System
2. Oven Window
1
2
4
3
5
678
9
3. Roller Ring
4. Shaft

5. Control Panel
6. Wave Guide
(Please do not remove the mica plate covering the wave guide)
7. Glass Tray
8. Grill Heater
9. Metal Rack
C
CO ON NT TR RO OL L P PA AN NE EL L 
DisplayScreen
Cookingtime,power,indicatorsandpresenttimeare
displayed.

Power
Presstoselectmicrowavepower.

Grill
Presstosetthegrillcookingprogram.

Combi.
Presstoselectoneoftwocombinationcooking
settings.

Wei.Def.
Presstoselectdefrostprogrambytheweight.

Clock/KitchenTimer
Presstosetthetimeortosetthekitchentimer.

Wei.Adj.
Presstosettheweightofdefrostandautocooking
program.

Time/Menu
Rotatetosetcookingtimeorselecttheauto‐menu.

Stop/Cancel
Tou chtostopcookingprogramorclearallprevious
settingsbeforecookingstarts.

Start/QuickStart
Presstostartcookingprogramorsetquickstart
cookingprogram.

O
OP PE ER RA AT TI IN NG G T TH HE E M MI IC CR RO OW WA AV VE E O OV VE EN N  
TOSETTHETIMER
Thisisa12and24hourstimer.Youcantakethestepsbelowtosetthetimer.

1. Presstheclock/kitchentimerbuttonfor3seconds.“Hr12”willshowsonthescreen,pressthebutton
onceifyouwanttoset24hoursclock.
2. Adjustthetime/menuknobuntilthecorrecthourisdisplayed.
3. Presstheclock/kitchentimerbuttonagain.
4. Adjustthetime/menuknobuntilthecorrectminuteisdisplayed.
5. Presstheclock/kitchentimerbuttontoconfirm.

MICROWAVECOOKING
Microwavecookingallowsyoutocustomizethecookingpowerandtime.First,selectapowerlevelby
pressingthepowerbutton(seethetablebelow).Maximumcookingtimeis95minutes.
Supposeyouwanttocookfor5minutesat60%PowerLevel.

1. Openthedoorandplacethefoodintotheoven,closeit.
2. Presspowerbuttontillthescreenshowtheintendedpower.

PressPowerbuttonPower
Once100%(P100)
Twice80%(P‐80)
3times60%(P‐60)
4times40%(P‐40)
5times20%(P‐20)
6times0%(P‐00)

3. Adjustthetime/menuknobtoselectthecookingtimeuntilthecorrectcookingtime5:00(5minutes)is
displayed.
4. Pressthestart/quickstartbuttontostartcooking.

NOTE:
Youcancheckthepowerwhilecookingisinprogressbypressingthepowerbutton.Afterthecookingtime
ends,thesystemwillbeeponceand‘End’isdisplayed.Beforestartinganothercookingsession,pressany
padoropenthedoortoclearthedisplayandresetthesystem.



GRILL
Grillcookingisparticularlyusefulforthinslicesofmeat,steaks,chops,kebabs,sausagesandpiecesof
chicken.Itisalsosuitableforhotsandwichesandaugratindishes.Maximumcookingtimecanbesetis95
minutes.
Supposeyouwanttoprogramgrillcookingfor12minutes.

1. Openthedoorandplacethefoodintotheoven,closeit.
2. Pressgrilbuttononce.
3. Adjustthetime/menuknobto12:00(12minutes).
4. Pressthestart/quickstartbuttontostartcooking.

MICRO+GRILL
Themaximumcookingtimethatcanbesetis95minutes.
Supposeyouwanttosetcombinationcookingfor25minutes.

1. Openthedoorandplacethefoodintotheoven,closeit.
2. Pressthecombi.buttononceortwice.

Cookingtime
Presscombi.buttonCombination
MicrowaveGrill
Use
once Co‐130%70%fish,potatoesoraugratin
twiceCo‐255%45%pudding,omelets,baked
potatoesandpoultry

3. Adjustthetime/menuknobto25:00(25minutes).
4. Pressthestart/quickstartbuttontostartcooking.

QUICKSTART
Usethisfeaturetoprogramtheoventostartat100%powerconveniently.Themaxtimecanbesetis
10minutes.Duringcooking,youcanalsopressthisbuttontoaddthecookingtime.

1. Openthedoorandplacethefoodintotheoven,closeit.
2. Pressstart/quickstartbuttoninquicksuccessiontosetthecookingtime.Theovenwillauto‐start
immediately.



KITCHENTIMER
Youcouldsettheoventimertoremindyouthecookingtime.Thelongesttimeyoucansetis95minutes.
Supposeyouwanttosetthekitchentimerfor30minutes:

1. Presstheclock/kitchentimerbuttononce.
2. Adjustthemenu/timeknobtoset30:00(30minutes).
3. Pressthestart/quickstartbuttontoconfirm.
NOTE:Whenthetimeriscounting,youcanpresstheclock/kitchentimerbuttontoseethetimerandpress
stop/cancelwithin5secondstocancelit.

MENUCOOK
Forfoodorthefollowingcookingmode,itisnotnecessarytoprogramthetimeandthecookingpower.Itis
sufficienttoindicatethetypeoffoodthatyouwanttocookaswellastheweightofthefood.

1.
2.
3.
4.
Openthedoorandplacethefoodintotheoven,closeit.
Adjustthetime/menuknobinthepositionofanti‐clockwisedirectiononceandturnitagaintoselect
foodcode.
Pressthewei.adj.toselecttheweight,checkthescreenfornumberofservingsorpresetweights,
whichshouldmatchweightoffoodyouhaveplacedintheoven.
Pressthestart/quickstartbuttontostartcooking.

FoodCodeMenuCookingmode
A‐1POPCORN(99g)MICRO.
A‐2COFFEE(200ml/cup)MICRO.
A‐3FRESHVEGETABLE(g) MICRO.
A‐4POTATO(230g/unit)MICRO.
A‐5PIZZA(g)MICRO.
A‐6REHEAT(g)MICRO.
A‐7GRILLEDCHICKEN(*g) COMBINATION
A‐8GRILLEDSTEAK(g)COMBINATION
*Itisadvisablethattheweightofthechickenthatwanttobegrillismorethan800g.Iftheweightofthechicken
islessthat800g,watchthecookingprocesstoavoidthechickentobeovercooked.

NOTE:
1. Theuserisrequiredtoselecttheweightandthentheovenwillsetthecookingtimeautomatically.
2. ForGRILLEDCHICKENandGRILLEDSTEAK,beepscanbeheardandtheovenpauseduringcookingto
remindusertoturnthefood(forevenlycooked),thenpressstart/quickstartbuttontoresume.

WEIGHTDEFROST
Weightdefrostenablesyoutodefrostfoodaccordingtotheweightoffoodyouinsert.Theweightrangeis
from100gto1800g.Supposeyouwanttosettheoventoweightdefrostfor200goffood.

1. Openthedoorandplacethefoodintotheoven,closeit.
2. Pressthewei.def.buttononce.
3. Pressthewei.adj.buttontoselecttheweight.
4. Pressstart/quickstartbuttontostartcooking.

NOTE:Duringthedefrostingprocess,theovenwillpauseandsoundbeepstoremindyoutoturnfoodover,
(forevenlycooked)afterthat,pressthestart/quickstartbuttontoresumedefrostingprocess.

MULTI‐STAGECOOKING
Thismicrowaveovenallowsyoutoprogramupto3automaticcookingsequences.
Supposeyouwanttosetthefollowingcookingprogram.

Microwavecooking(100%)

Microwavecooking(60%)

1. Openthedoorandplacethefoodintotheoven,closeit.
2. Pressthepowerbuttontosetpowerat100%.
3. Adjustthetime/menuknobtoprogramthecookingtime.
4. Pressthepowerbuttontosetpowerat60%.
5. Adjustthetime/menuknobtoprogramthecookingtime.
6. Pressthestart/quickstartbuttontostartcooking.

NOTE:Weightdefrost,menucookandquickstartcannotbesetinthismulti‐stagecookingprogram.

CHILDPROOFLOCK
Thechildprooflockpreventsunsupervisedoperationbychildren.Tosetthechildprooflock,pressthe
stop/cancelbuttonfor3seconds,thenabeepsoundwillheardandtheindicatorlightwillturnon.Inthe
lockstate,allbuttonsaredisabled.

Tocancelthechildprooflock,pressthestop/cancelbuttonfor3seconds,thenabeepwillheardandthe
indicatorlightwillturnoff.


TOSTOPTHEOVENWHILETHEOVENISOPERATING
1. Pressthestop/cancelbutton.Youcanrestarttheovenbypressingthestart/quickstartbutton.
Pressthestop/canceltoeraseallinstructions.
2. Openthedooroftheoven.Youcanrestarttheovenbyclosingthedoorandpressthestart/quickstart
button.

NOTE:Theovenstopsoperatingwhenthedoorisopened.

C
CL LE EA AN NI IN NG G A AN ND D C CA AR RE E 
1. Turnofftheovenandremovethepowerplugfromthewallsocketbeforecleaning.
2. Keeptheinsideoftheovenclean.Whenfoodsplattersorspilledliquidsadheretoovenwalls,wipe
withadampcloth.Milddetergentmaybeusediftheovengetsverydirty.Avoidtheuseofsprayand
otherharshcleanersastheymaystain,streakordullthedoorsurface.
3. Theoutsidesurfacesshouldbecleanedwithadampcloth.Topreventdamagetotheoperatingparts
insidetheoven,watershouldnotbeallowedtoseepintotheventilationopenings.
4. Wipethedoorandwindowonbothsides,thedoorsealsandadjacentpartsfrequentlywithadamp
clothtoremoveanyspillsorspatters.Donotuseabrasivecleaner.
5. Donotallowthecontrolpaneltobecomewet.Cleanwithasoft,dampcloth.Whencleaningthe
controlpanel,leaveovendooropentopreventovenfromaccidentallyturningon.
6. Ifsteamaccumulatesinsideoraroundtheoutsideoftheovendoor,wipewithasoftcloth.Thismay
occurwhenthemicrowaveovenisoperatedunderhighhumiditycondition.Anditisnormal.
7. Itisoccasionallynecessarytoremovetheglasstrayforcleaning.Washthetrayinwarmsudsywateror
inadishwasher.
8. Therollerringandovenfloorshouldbecleanedregularlytoavoidexcessivenoise.Simplywipethe
bottomsurfaceoftheovenwithmilddetergent.Therollerringmaybewashedinmildsudsywateror
dishwasher.Whenremovingtherollerringfromcavityfloorforcleaning,besuretoreplaceinthe
properposition.
9. Removeodorsfromyourovenbycombiningacupofwaterwiththejuiceandskinofonelemonina
deepmicrowaveablebowl,microwavefor5minutes.Wipethoroughlyanddrywithasoftcloth.
10. Whenitbecomesnecessarytoreplacetheovenlight,pleaseconsulttheauthorizedserviceagentor
after‐salesservicecentreorasimilarlyqualifiedpersontohaveitreplaced.
11. Theovenshouldbecleanedregularlyandanyfooddepositsremoved.Failuretomaintaintheovenina
cleanconditioncouldleadtodeteriorationofthesurfacethatcouldadverselyaffectthelifeofthe
applianceandpossiblyresultinahazardoussituation.
12. Pleasedonotdisposethisapplianceintothedomesticrubbishbin,itshouldbedisposedtothe
particulardisposalcenterprovidedbythemunicipalities.
13. Whenthemicrowaveovenwithgrillfunctionisfirstused,itmayproduceslightsmokeandsmell.This
isanormalphenomenon,becausetheovenismadeofasteelplatecoatedwithlubricatingoil,andthe
newovenwillproducefumesandodorgeneratedbyburningthelubricatingoil.Thisphenomenonwill
disappearafteraperiodofusing.


S
SP PE EC CI IF FI IC CA AT TI IO ON NS S
Power Supply 230-240V~50Hz
Power Consumpon (Microwave) 1400W
Power Consumpon (Grill) 1000W
Rated Microwave Power Output 900W
Operaon Frequency 2450MHz
Oven Cavity Dimensions 340mm(W)x220mm(H)x320mm(D)
Dimensions 595mm(W)×390mm(H)×390mm(D)
Built-in Dimensions 560mm(W)×365mm(H)×410mm(D)
Oven Capacity 23 Litres
Cooking Uniformity Turntable System
Net Weight Approx. 14.5kg

1
Sequence Quantity Name
1
21
Cabinet
Microwave Oven
12
A4
Screw3x20
A 3x20mm
EMO-B2361BI(SS)

Make a cabinet to the dimension
2
3
1
Space for ventilation
Fasten the oven into the
cabinet with 4 screws
Installtion complete
