Elba EMO-H3880TFT(BK) User manual

For The Warranty Terms & Conditions, Please Refer To Warranty Certificate
Owner’s Manual
Please read this manual carefully before
operating your set.
Retain it for future reference.
Record model number and serial number
of the set.
See the label attached on the set and
quote this information to your dealer when
you require service.
BUILT-IN MICROWAVE OVEN
MODEL: EMO-H3880TFT(BK)

CONTENTS
1. SAFETY PRECAUTIONS…………....…………………………………………………………………………………………….1
2. ATTENTIONS…………………………………………………………………………………………………………………………2
3. INSTALLATION…………………..…………………………………………………………………………………………….2
3.1 BEFORE THE INSTALLATION………………………………………………………………………………………………2
3.2 INSTALLATION OF BUILT-IN OVEN…………………………………………………………………………………………3
4. CONNECTION OF THE APPLIANCE…………………………………………………………………………………………4
4.1 FITTING ON A POWER SUPPLY CABLE……………………………………………………………………………………4
4.2 CONNECTING THE SUPPLY CABLE TO THE MAINS…………………………………………………………………4
5. HOW TO USE YOUR OVEN…………………………………………………………………………………………………….4-5
6. PRODUCT DESCRIPTIONS……………………………………………………………………………………………………….5
6.1 PRODUCT OVERVIEW………………………………………………………………………………………………………………..5
6.2 OVEN CONTROL PANEL.………………………………………………………………………………………….…………………6
6.3 DISPLAY DESCRIPTIONS………….………………………………………………………………………………………………… 7
6.4 MAIN MENU ……………………………………………………………………………………………………… …………….… 8
6.5 SYMBOL …………………………………………………………………………………………………………… …………….… 8
7. PROGRAMS AND FUNCTIONS……………………………………………………………………………………….9
7.1 SELECTING THE COOKING PROGRAMS……………………………………………………………………………………9
7.2 SETTING FOR THE FIRST TIME………………………………….………………………………………………………9-12
7.3 COOKING WITH MICROWAVE…………………………………..…………………………………….………………13-14
7.4 DEFROSTING WITH MICROWAVE…………………………………………………………………….………………14-15
7.5 COOKING WITH GRILL……………………………………………………………………………….……….……………15-16
7.6 WHAT KIND OF OVENWARE CAN BE USED…………………………………………………….……….……………16
7.6.1 MIRCOWAVE FUNCTION……………………………………………………………………………….……….……………16
7.6.2 GRILLING FUNCTION……………………………………………………………………………….……….……………16
7.6.2 COMBINATION FUNCTION(MIRCOWAVE + GRILL)………………………………………….……….……………16
7.7 OVEN OPERATION……………………………………………………………………………………….…………………16-17
7.8 CHANGE THE RUNNING PROGRAM…..…..………………………….………………………………….………………17
7.9 CANCEL THE RUNNING PROGRAM…..…..…………………………..………………………………….………………18
7.10 CHILD LOCK……………………………………………………………………………….…………………………………………18
7.11 KITCHEN TIME (REMINDER)……………………………………………………………………………….………………18
8. CLEANING AND MAINTENANCE…………………………………………………………………………………….20-21
8.1 CLEANING THE OVEN CAVITY………………………………………………………………………………….…………… 20
8.2 CLEANING THE CAVITY CEILING……….…………………………………………………….…………………….……… 20
8.3 RINSE OF DOOR SEAL AND FRONT PANEL……..……………………………………….…………………….……… 20
8.4 CLEANING THE ACCESSORIES………………..……………………………………………….…………………….……… 20
9. TECHNICAL SPECIFICATION…….………………………………………………………………………………………….22

We recommend that you read the instructions in this owner’s manual carefully before using
it for the best performance and to extend the lifespan of your appliance, as it will provide you
with all the instructions you require to ensure its safe installation, use and maintenance.
1. SAFETY PRECAUTIONS
In order to avoid bump against people or oven during transportation, please grip the
handle on the two external sides. Do not carry the appliance at the front handle, this might
damage the oven door.
To ensure your safety, all electric appliances should only be installed or serviced by
qualified technician. If the supply cord is damaged, it must be replaced by the authorized
service center or similarly qualified technician in order to avoid hazard.
Do not place supply cord on the edge of table and counter, or near any heating appliance.
In order to avoid electric shock, do not immerse supply cord, plug or other parts into water.
Do not place the appliance near electric stove, heated oven, microwave or other heat
source.
In order to avoid burning or explosion, combustibles or flammable material (curtains, cloth,
wallpaper and others) should be kept away from the appliance.
Do not place paperboard, plastic or other similar items in the oven. When the oven is not
being used, everything should be removed except provided accessory.
Do not cover slag pan or other parts with tinsel since it will result overheat.
Accessible parts may become hot during use, please keep away from children.
Never obstruct vents provided for ventilation and heat dispersal.
The ends of door handle may become hot during use, please grip the middle parts.
When the appliance is faulty, please contact the authorized service center.
Always use insulation gloves to carry ovenware or handle oil plate.
Disconnect the oven from the power supply and waiting until it is cool, before cleaning or
maintenance.
In order to avoid electric shock, never use wire brush to clean the appliance since pieces
of metal is easy to touch live part.
Never use metal scouring pads or sharp scrapers which will damage the door surface or
interior wall, leading to glass broken or scratches of the enamel.
In order to avoid burn or electric shock, never put too much food or metal utensils.
Please make sure the oven function has been switched off when it is not be used.
Unplug from the socket when you are planning not to use the oven for long time.
Never use your oven outside the cabinet.
Other purpose except baking is not allowed.
Do not lean or rest on the opened oven door. This may damage the oven. The door can
bear a maximum weight of 8 kg.
1

2. ATTENTIONS
In order to avoid electric shock, please make sure the oven has been shut off before
carrying out the maintenance.
Use only original accessories provided by ELBAor its authorized service center.
Do not use wet parts of body to touch the oven.
Do not pull and push the oven by its supply cord, this may lead to socket disconnection.
Improper or dangerous operations are forbidden.
Do not let the power cord of other appliances to touch the heated parts of the oven.
The oven should not be exposed to rain or direct sunshine.
Do not use or store flammable objects near to the oven.
Distributors decline all liability for not following above instructions or some improper operations
which caused personal injury and property loss.
3. INSTALLATION
3.1 Before the Installation
Please check the products and make sure that there is no damage caused by striking or
heavy load.
The oven door is level, and you can open and close the oven door flexibly.
Specification on the marking plate is in compliance with the regulations.
If the oven appears in an abnormal way, do not install and unplug the power supply before
contacting the authorized service center. Do not attempt to repair or service the oven by yourself.
Repair or maintenance should only be carried out by a qualified technician or the authorized
service center.
This appliance must be installed only by qualified technician or the authorized service center.
Manufacturer declines all responsibility for improper installation, which may harm persons and
cause damage to the property.
Important:
The power supply to the appliance must be cut off before any adjustments or
maintenance work is carried out.
The AC power supply should be supplied with 220-240V, 50/60Hz with minimum 15A
distribution circuit fuse or at least 15A distribution circuit breaker.
2

3.2 Installation of Built-in Oven
The material of the cabinet should be insulated, and the clearance between the edge of the
cabinet and the oven should be over 100mm for ventilation. The panels of the adjacent cabinets
must be made of heat-resistant material which can withstand temperatures of up to 100°C. In
compliance with current safety standards, contact with the electrical parts of the oven must not
be possible once it has been installed.
Install 4 screw on the inner side of the oven door frame to fix the position.
Note: Please do not use the handle to carry or move the oven during installation or
handling.
3

4. CONNECTION OF THE APPLIANCE
4.1 Fitting on a Power Supply Cable
The appliance has to be equipped with a three-core power supply cable which is designed to
operate with an alternating current. The AC power supply should be supplied with 220-240V,
50/60Hz and a minimum 15A distribution circuit fuse or at least 15Adistribution circuit breaker.
4.2 Connecting the Supply Cable to the Mains
Install a standardized plug corresponding to the load indicated on the marking plate. The supply
cable should be positioned so that it does not reach a temperature of more than 50℃with
respect to the room temperature, anywhere along its length, or protected by insulation having an
appropriate rating.
Before making the connection, check that:
The electrical safety of this appliance can only be guaranteed if the appliance is correctly
and efficiently earthed, in compliance with regulations on electrical safety.
Always ensure that the earthing is connected. If you have any doubts please contact a
qualified technician to check the connection. The manufacturer declines all liability of
damage resulting from a connection which has not been earthed properly.
Before plugging the appliance into the mains, check that the specifications indicated on
the marking plate correspond to the electrical mains system of your home.
Check that the electrical capacity of the system and sockets will support the maximum
power of the appliance, as indicated on the marking plate.
If the socket and appliance plug are not compatible, have the socket replaced with a
suitable model by a qualified technician. The latter, in particular, will also have to ensure
that the cross sections of the socket cables are suitable for the power absorbed by the
appliance.
The use of adapters, multiple sockets and /or extensions, is not recommended. If their
use cannot be avoided, remember to use only single or multiple adapters and extensions
which comply with current safety regulations. In these cases, never exceed the maximum
current capacity indicated on the single adapter or extension and the maximum power
indicated on the multiple adapter .The plug and socket must be easily accessible.
5. HOW TO USE YOUR OVEN
The first time you use your appliance, we recommend that set the thermostat to the
highest setting and leave the oven on for about half an hour with nothing in it, with the
oven door shut completely. Then open the oven door and let the air in. The odor that is
often detected during this initial use is due to the evaporation of substances used to
protect the oven during storage and until it is installed.
Place the baking tray provided at the bottom shelf of the oven to prevent any sauce
and/or grease from dripping onto the bottom of the oven only when grilling food or when
using the rotisserie. For all other types of baking, never use the bottom shelf and never
place anything on the bottom of the oven when it is in operation because this could
4

damage the enamel. Always place your cookware (dishes, aluminum foil, etc.) on the
grilling rack provided with the appliance inserted especially along the oven guides.
After baking food contains sugar and salt, please clean your oven promptly, or these will
attach to the oven surface.
Use baking tray to roast high temperature food such as meat, poultry, fish, and others.
6. PRODUCT DESCRIPTION
6.1 Product Overview
1. Door Handle
2. Drive Shaft
3. Roller Ring
4. Glass Tray
5. Heating Element
6. TFT Panel Screen
7. Control Button
1
2
3
4
5
6
7
5

6.2 Oven Control Panel
Number
Icon
Descriptions
1
ON / OFF Button,
Press button to turn appliance on or off.
2
Buzzer Button,
Press button and set the countdown timer for reminder.
3
Light Button,
Press button to turn light on or off.
4
Menu Button,
Press button to return to the main menu screen.
5
Return / Cancel Button,
Press button to stop the program or back function.
6
Child Lock Button,
Press button to lock the display selection.
7
Display Current Selection / Program.
6

6.3 Display Descriptions
Number
Descriptions
1
Menu
2
Current Time
3
Program Selection
4
Scroll Up
5
Scroll Down
Press to turn on appliance. The main menu appears in the display with a list of options.
Select the program by touching the screen. If the desire program is not appear in display screen,
please scroll up or down to search for the programs.
6.4 Main Menu
Program
Temperature
Microwave
Default 800W, from 0W to 1000W
Grill
Default 180°C, from 110°C to 200°C
Convection
Default 180°C, from 50°C to 250°C
Microwave + Grill
Default 600W,170°C, from 0W to 1000W(Microwave),
from 100°C to 200°C(Grill)
Grill + Convection
Default 180°C, from 50°C to 250°C
Microwave + Convection
Default 600W, 180°C, from 0W to 1000W(Microwave),
from 50°C to 250°C(Convection)
Microwave + Grill + Convection
Default 600W, 180°C, from 0W to 1000W(Microwave),
from 50°C to 250°C(Convection/Grill)
Defrost
Defrost only
Recipe
Preset programs with multi program selection
Setting
To set the date, time, language, brightness and others.
7

6.5 Symbol
The following symbols will be appear in the display screen.
Symbol
Descriptions
You may scroll up or down by touching and button.
A tick will appear behind the option which is currently selected.
This indicates additional information is available.
This information window will be turned off by selecting OK button.
The display panel is locked.
A buzzer reminder has been set.
When a function is selected, the following symbol may appear in the display screen, it depends
on program selection.
Symbol
Descriptions
Heating-up phase
Cooling phase
Start time
Duration
Finish time
8

7. PROGRAMS AND FUNCTIONS
7.1 Selecting the Cooking Programs
To select the cooking programs, turn the knob to desire program. The detail of the programs
as below:
Symbol
Function Descriptions
Microwave: This function is ideal for reheat, melting defrosting with several of power
voltage selection. The power can up from 200W to 1,000W.
Grill: The top grilling element switches on and off to maintain at certain temperature.
The temperature range can be set within the range of 50-250ºC. Suitable for grilling
small amount of meat and ribs.
Convection: The top and bottom element work together to provide convectional
cooking. The oven needs to be pre-heated to the required temperature and is ideal
for single item such as large cakes. Best results are achieved by placing food in the
center of the oven.
Microwave + Grill: This function is ideal for fast cooking and food browning after
cooking. The microwave and the grill work simultaneously. The microwave cooks
and the grill toasts.
Grill + Convection: This function is ideal for food browning and have a uniform heat.
The food is exposed to a high heat with grill function and the heat will more evenly
with the help on convection function.
Microwave + Convection: This function to use microwave to heat up the food, it also
uses even heat from the heating element to cook the dishes.
Microwave + Grill + Convection: This function is good to use on frozen food that you
want to grill, as the microwave will help defrost the inside of the food while the grill
browns the outside and heat evenly.
Defrost: The circulation of air at room temperature enables quicker thawing of
frozen food (without the use of any heat). It is a gentle but quick way to speed up the
defrosting time and thawing of ready-made and cream filled dishes.
7.2 Setting for the first time
To enter the basic settings for the first time use, in the main menu, scroll down until “Setting”
menu.
The list of options will show as follow:
Date
Time
Clock Format
Language
Brightness
Buzzer Tone
Temperature Units
Factory Default Setting
Theme
9

DATE
Click date setting and enter the actual date by touching the keyboard input. The date sequence
will display as “YEAR / MONTH / DATE” (YYYY/MM/DD).
Click “OK” to save and return back to setting interface.
TIME
Click time setting and enter the actual time by touching the keyboard input. The time sequence
will display as “HOURS : MINUTES”(12:59). The real time display will show on the top right
corner.
Click “OK” to save and return back to setting interface.
(If clock format in 12 hours, the maximum for time setting is 12:59, if clock format in 24 hours,
the maximum for time setting is 23:59)
CLOCK FORMAT
Click clock format setting and select the clock format by touching the screen. The clock format
selection are 12 hours or 24 hours. Click the desire clock format and your selection will show as
“√”behind the option.
Click “OK” to save and return back to setting interface.
10

LANGUAGE
Click language setting and select the language by touching the screen. The language selection
are Simplified Chinese and English. Click the desire language and your selection will show as
“√”behind the option.
Click “OK” to save and return back to setting interface.
BRIGHTNESS
Click brightness setting and select the brightness by sliding the screen. Slide left to turn the
screen brightness to darker and slide right to turn the screen brightness to brighter.
Click “OK” to save and return back to setting interface.
BUZZER TONE
Click buzzer tone setting and select the buzzer toner volume by sliding the screen. Slide left to
turn the volume to lower and slide right to turn the volume to higher.
Click “OK” to save and return back to setting interface.
11

TEMPERATURE UNITS
Click temperature units setting and select the temperature units by touching the screen. The
temperature unit selection are ºC / ºF. Click the desire temperature unit and your selection will
show as “√”behind the option.
Click “OK” to save and return back to setting interface.
FACTORY DEFAULT SETTING
Click factory default setting if you wish to restore all the setting into default setting. Select the
factory default setting and “YES” button will appear. Click “OK” to conduct the restore to default
setting.
(Please be remind that all the data entry that previously saved will be deleted)
THEME
Click theme setting if you wish to change the theme color. The theme color selection are Orange
and Cyan. Click the desire color and your selection will show as “√”behind the option.
Click “OK” to save and return back to setting interface.
12

7.3 Cooking with Microwave
Warning! Read the section “Safety Precautions” before cooking with your microwave.
Follow these recommendations when cooking with microwave:
Before heating or cooking foods with skin (e.g. apples, tomatoes, potatoes, sausages)
peel them so that they do not burst. Cut the food up before starting to prepare it.
Before using a container or dish make sure that it is safe for microwave use (see the
section on types of ovenware).
When cooking food with very little moisture (e.g. defrosting bread, making popcorn, etc.)
evaporation is very quick. The oven then works as if it was empty and the food may burn.
The appliance and the container may be damaged in such situation. You should therefore
set just the cooking time necessary and you should keep a close eye on the cooking
process.
It is not possible to heat with much oil (frying) in the microwave.
If you have several containers, such as cups, for example, set them out uniformly on the
turntable plate
Do not seal plastic bags with metal clips. Use microwave safe plastic clips instead. Prick
the bags for several holes so that the steam can escape.
There might be steam on the oven glass door during cooking and may start to drip. This
situation is normal and may be more noticeable if the room temperature is low. The
process of cooking is not affected by this. After you have finished cooking, clean up the
condensation on the glass door.
When heating liquids, use containers with a wide opening, so that the steam can
evaporate easily.
Prepare the foods as per the instructions and keep in mind the cooking times and power
levels indicated in the tables.
Keep in mind that the figures given are only indicative and can vary depending on the initial state,
temperature, moisture and type of food. It is advisable to adjust the time and power levels
according to each situation. Depending on the exact characteristics of the food you may need to
increase or shorten the cooking time or increase or decrease the power levels.
Cooking with Microwave
1. The greater the amount of food, the longer the cooking time.
2. The lower the microwave power, the longer the cooking time.
3. Foods containing a lot of liquid will heat up more quickly.
4. Cooking will be more uniform if the food is evenly distributed on the turntable. If you put
dense foods on the outer part of the plate and less dense ones on the center of the plate,
you can heat up different types of food simultaneously.
5. You can open the oven door at any time. When you do this the oven switches off
automatically. The microwave will only start working again when you close the door and
press the start key.
6. It takes less time if we put a cover over food, but the cover should have vents avoiding
extreme pressure.
13

Vegetables
Name
Weight (G)
Water
(ml)
Microwave
Power
Time
(Min)
Notice
Cauliflower
500
100
800
9-11
Cut into slices and
cover well
Broccoli
300
50
800
6-8
Mushroom
250
25
800
6-8
Peas
Carrots
300
250
100
25
800
800
7-9
8-10
Cut into slices or blocks,
cover well
Potatoes
250
25
800
5-7
Peel and cut into uniform size,
cover well
Chives
250
25
800
5-7
Cut into segments or slices,
cover well
Frozen Cabbage
300
50
800
6-8
Cover well
7.4 Defrosting with Microwave
1. When defrosting, use only dishes that are safe for microwave oven use.
2. The defrost function by weight and the tables refer to the defrosting of raw food.
3. The defrosting time depends on the quantity and thickness of the food.
4. Distribute the food well. You can use aluminum foil for delicate food.
5. Important: The aluminum foil should not come into contact with the oven inner cavity of the
oven.
6. Thick portions of food should be turned over several times in the process of cooking.
7. Distribute the frozen food as evenly as possible since narrow and thin portions defrost
more quickly than the thicker and broader parts.
8. Fat-rich foods such as butter, cheese and cream should not be completely defrosted. If
they are kept at room temperature they will be ready to be served in a few minutes. With
ultra-frozen cream, if you find small pieces of ice in it, you should mix these in before
serving.
9. Place poultry on an upturned plate so that the meat juices can run off more easily.
10.Bread should be wrapped in a napkin so that it does not become too dry.
11.Remove frozen food from its wrapping and do not forget to take off any metal twist-tags.
For containers that are used to keep frozen food in the freezer and which can also be used
for heating and cooking, all you need to do is take off the lid. For all other cases you
should put the food into containers that are safe for microwave oven use.
12.The liquid resulting from defrosting, principally that from poultry should be discarded. In no
event should such liquids be allowed to come into contact with other foods.
13.Do not forget that by using the defrosting function you need to allow for standing time until
the food is completely defrosted.
14.In defrost process, please turn food over when microwave oven alarms and displays
"turn".
14

Please refer to the following table for different temperature of various foods.
Type of Food
Weight (G)
Defrosting Time
(Min)
Follow-up Time
(Min)
Frequency of
turnover
Meat
(Veal, Beef, Pork)
100
200
500
1000
1500
2000
2-3
4-5
10-12
21-23
32-34
43-45
5-10
5-10
10-15
20-30
20-30
25-35
1
1
2
2
2
3
Beef Stew
500
1000
8-10
17-19
10-15
20-30
2
3
Minced Meat
100
500
2-4
10-14
10-15
20-30
2
3
Sausage
200
500
4-6
9-12
10-15
15-20
2
3
Poultry
Chicken
Fish Fillet
Trout
Prawn
250
1000
200
250
100
5-6
20-24
4-5
5-6
2-3
5-10
20-30
5-10
5-10
5-10
1
2
1
1
1
Fruit
200
300
500
4-5
8-9
11-14
5-10
5-10
10-20
1
1
2
Bread
200
500
800
4-5
10-12
15-17
5-10
10-15
10-20
1
1
2
Butter
250
8-10
10-15
Cheese
250
6-8
10-15
Cream
250
7-8
10-15
7.5 Cooking with Grill
IMPORTANT:
1. There will be some smoke and smell when the grill is used for the first time. That is
because of oil left from the manufacture process.
2. The oven glass door becomes hot when the oven is operating. Keep children away.
3. When the grill is used for extended period of time, it is normal to find that the elements
will switch off temporarily due to the safety thermostat.
4. When food is to be grilled or cooked in containers you should check that the container is
suitable for microwave oven safe.
5. When the grill is used it is possible that some splashes of fat may go onto the elements
and be burnt. This is a normal situation and does not mean there is any kind of operation
fault.
6. After you have finished cooking, clean the oven interior and the accessories.
15

GRILL ELEMENT
Name
QUANTITY(G)
TIME(MIN.)
INSTRUCTIONS
FISH
Bass
Sardines
800
6-8 FISH
18-24
15-20
Spread lightly with butter. After half of
cooking time turn and spread with
seasoning.
MEAT
Sausages
6-8 UNITS
22-26
Prick after half cooking time and turn.
Frozen Hamburgers
3 UNITS
18-20
Spare Rib (approx.3 cm thick)
400
25-30
After half of cooking time, baste and turn.
Toast
4 UNITS
3/2-3
Watch toasting.
Toasted Sandwiches
2 UNITS
5-10
Watch toasting.
7.6 What kind of ovenware can be used?
7.6.1 Microwave Function
For the microwave function, notice that glass, china, clay, plastic, and paper can be used as
container. Metal pans, dishes or containers with metal parts or decorations cannot be used in
the microwave. Glassware and clay with metallic decoration or content (e.g. lead crystal) cannot
be used for microwave oven.
The ideal material for microwave oven is glass, refractory china or clay, or heat resistant plastic.
Very thin, fragile glass or china should only be used for short period of time (e.g. heating)
7.6.2 Grilling Function
For the grill function, the ovenware should be resistant to temperature of at least 300ºC. Plastic
dishes are not suitable for the grill function.
7.6.3 Combination Function (Microwave + Grill)
In the combination functions, the ovenware used should be suitable for both microwave and grill.
7.7 Oven Operation
Below is the quick overview for the oven operation.
1. Press to turn on appliance. The main menu appears in the display with a list of
options. Select the program by touching the screen. If the desire program is not appear
in display screen, please scroll up or down to search for the programs.
2. After the program is selected, the below option will be appear in the display screen.
Temperature
Duration
Start Time
Finish Time
Heating-up Phase
16

TEMPERATURE
The temperature default setting is 180ºC, the minimum is 50ºC / 120ºF and up to maximum
250ºC / 480ºF. The defrost function will be excluded the temperature setting.
Slide left to lower down the temperature and slide right to set the higher temperature. Each slide
is about 10ºC. You may click the fine adjustment +5ºC / -5ºC (in ºC format), +10ºF / -10ºF (in ºF
format).
Click “OK” to save and return back to function interface.
DURATION
Click duration and enter cooking duration by touching the keyboard input. The cooking time
duration sequence will display as “HOURS : MINUTES”(02:00). The default duration time will
be set as 2 hours. If you wish to change the cooking time duration, just set to the desire time you
wish to cook by using the keyboard input.
Click “OK” to save and return back to function interface.
START TIME
Click start time and enter cooking start timer by touching the keyboard input. The start time
sequence will display as “HOURS : MINUTES”(04:15). The default start time will remain blank
unless user wish to apply it. If you wish to set the start time, just set to the desire time you wish
to start by using the keyboard input (For example the current time is 04:10 (12Hours Clock
format) and you wish to start the oven after 5 minutes, so just set the time to 04:15. The oven will
start operate on the set timer).
Click “OK” to save and return back to function interface.
(If the start time setting is not set, the oven will operate on the current clock time and end on the
duration time that previously set).
FINISH TIME
Click finish time and enter cooking end timer by touching the keyboard input. The finish time
sequence will display as “HOURS : MINUTES”(06:15). The finish time will base on the duration
time unless user wish to extend or shorten the time. If you wish to set the finish time, just set to
the desire time you wish to end by using the keyboard input (For example the current time is
04:15 (12Hours Clock format) and you duration has been set for 2 hours. The finish time
automatically will become 06:15. If the cooking time is shorter, you may key in the finish timer by
using the keyboard input. The oven will end operate on the set timer).
Click “OK” to save and return back to function interface.
(If the start time setting is not set, the oven will operate on the current clock time and end on the
duration time that previously set).
HEATING-UP PHASE
Touch the heating-up phase and select the heating-up phase that you wish to apply. The
heating-up phase selection are Normal and Fast. Click the desire heating-up phase and your
selection will show as “√”behind the option. The default setting for the heating-up phase will be
Normal.
Click “OK” to save and return back to function interface.
7.8 Change the running program
In the process of program is running, you may click “CHANGE” button to return to the interface
of function parameters. You may edit the temperature setting, duration, start time, finish time
and heating-up phase. The program will stop temporarily until the latest entry has been enter.
Click “OK” to save and continue with the latest program.
17

7.9 Cancel the running program
In the program is running, you may touch button to return to the function interface. The
display will show the message as below. Touch “YES” to back on the function interface and will
terminate the running program. If you wish to continue to running program, touch “NO” to
continue.
7.10 Child Lock
When the oven is in standby mode, touch and hold for 3 seconds, the control panel
will be locked.
When the oven is in operating mode, touch and hold for 3 seconds, the current
operating interface or function will be locked.
To release the child lock function, touch and hold for 3 seconds, the control panel will
be back to normal.
7.11 Kitchen Timer (Reminder)
To set the kitchen timer
Touch and enter to setup interface. Click time setting and enter the timer by touching the
keyboard input. The timer sequence will display as “HOURS : MINUTES”(01:00). The timer
display will show on the top right corner and countdown began.
Click “OK” to save and return back to menu.
(When the time has been displayed in 00:00, the buzzer will ring and last for 2 minutes. If want
to stop the prompt within 2 minutes, touch and buzzer will stop immediately).
18
