ELCOS RO-405 User manual

ELCOS SRL - Parma - RO-405 RO-803/00 - EN 1
OIL HEATERS
TYPE RO-405 RO-803/00
17
14.5
17
41 84
TYPE RO-405
TIYPE RO-803/00
HOLES TO FIX SUMP
CABLE LENGTH
3m
YELLOW/
GREEN
230 V
OIL SUMP
MOUNTING AND CONNECTING
TECHNICAL CHARACTERISTICS
- Power supply 230 VAC (± 10%) 50÷60 Hz
- Insulaonvoltage 250V
- Dielectricstrengthbetween
 terminalsandcontactor 2000VACx1minute
- Powerabsorbed RO-405 350W
RO-803/00 700 W
-Service connuous
- Workthermostat non-adjustable
-disengagedheang at72°C±10%
-engagedheang at57°C±10%
-SiliconecableLD-PE withbraiding
-Degreeofprotecon IP54
-Temperaturerange -20÷+120°C
-Weight RO-405 1500g
  RO-803/00 3600g
OPERATION
Theheater,onceithasbeenmountedincontactwith
theengineoilsump,preventsthetemperatureoftheoil
fromfallingbelowacertainsetvalue.
Thisvalueismaintainedviatheinternalthermostat.
Alloftheelectricalconneconsarerenderedeasybythe
presenceofacable.
ORDERING INFORMATION
TypeRO-405230V350W code00706017
TypeRO-803/00230V700W code00706016
TYPE RO-405TYPE RO-405
THREADED HOLE
THREADED HOLE

ELCOS SRL - Parma - RO-405 RO-803/00 - EN
2
NOTICES
Usedtokeepthedieselenginelubricangoilcupheated.
Warning:
Adhere closely to the following advice
- Takegreatcaretoconnectcorrectlytheconductorscomingoutoftheequipment.
- Adherecloselytotheenclosedinstallaonindicaons.
- Theequipmentmustbeearthedusingtherelevantwire.
- Nevertrytoopentheequipment,asthiswillhaveanegaveinuenceonitsdegreeofprotecon.
- Onlyinstallbypressingitincontactwiththeengineoilcup,supplyingitinothercondionswillreduce
itsworkinglife.
THIS HEATER IS NOT SUITABLE FOR OPERATING IN THE FOLLOWING CONDITIONS:
-Wheretheenvironmentaltemperatureisoutsidethelimitsindicatedintheenclosedtechnicalsheet.
-Wherethereistheriskofreorexplosions.
-Wherethepanelcanreceivestrongvibraonsorknocks.
-Whereaacksfrommouldorsmallanimalsarepossible.
ELECTROMAGNETIC COMPATIBILITY
ThisequipmentfunconscorrectlyonlyifinsertedinplantswhichconformwiththeCEmarkingstan-
dards;itmeetstheexemponrequirementsofthestandardEN61326-1,butitcannotbeexcludedthat
malfunconscouldoccurinextremecasesduetoparcularsituaons.
Theinstallerhasthetaskofcheckingthatthedisturbancelevelsarewithintherequirementsofthestan-
dards.
CONDUCTION AND MAINTENANCE
Thefollowingmaintenanceoperaonsshouldbeperformedeveryweek:
 - checkthatthesecuringscrewsandboltsareght.
 - Checkthattheterminalstowhichtheequipmentislinkedareght.
 - Checkthecondionofthesupplycablesheath.
UNLESS WE MAKE A WRITTEN DECLARATION STATING THE CONTRARY, THIS PANEL IS NOT SUITABLE FOR
USE AS A CRITICAL COMPONENT IN EQUIPMENT OR PLANTS RESPONSIBLE FOR KEEPING PERSONS OR
OTHER LIVING BEINGS ALIVE
YOUR ELECTRICAL TECHNICIAN CAN ASK US ANYTHING ABOUT THIS OIL HEATERS BY TELEPHONING ONE
OF OUR TECHNICIANS
