Gasmate SOLARIS Series Instruction Manual

03719 10/18
Important: Retain these instructions for future use.
SOLARIS
RADIANT CERAMIC HEATERS
SOLARIS
RH205
SOLARIS DELUXE
RH200
OPERATION, INSTALLATION AND MAINTENANCE MANUAL
If you smell gas:
1. Shut off the gas to the appliance.
2. Extinguish any open flame.
3. If odour continues, keep away from he appliance
and immediately call your gas supplier or your
fire department.
Do not store or use gasoline or other flammable
vapour and liquids in the vicinity of this or any other
appliance.
DANGER
Improper installation, adjustment, alteration, service
or maintenance can cause injury or property
damage.
Read the instructions thoroughly before installing or
servicing this equipment.
WARNING
FOR OUTDOOR USE ONLY
PROPANE GAS / NATURAL GAS
THIS APPLIANCE MUST NOT BE INSTALLED OR
USED INDOORS.
APPLIANCE IS TO BE PROTECTED FROM RAIN
AND WIND
WARNING
Gasmate® is a registered trademark of: Sitro Group Australia Pty Ltd www.gasmate.com.au
Aber Living, N.Z. www.gasmate.co.nz

Table of Contents
Important Safety Rules 1
Product Overview 2-3
Installation Servicing 4-6
Operation Instructions 7-11
RH200 Auto Electrical Diagram 12
RH200 Automatic Ignition Overview 13-14
Safe Appliance Locations 15
Troubleshooting 16
Spare Parts 17-18
2
Installation, Operation and Maintenance Instructions
1. This appliance shall not be installed or used
indoors, in buildings, garages or any other
enclosed area.
2. DO NOT place articles on or against this
appliance.
3. DO NOT use or store flammable materials near
this appliance.
4. Children and adults should be alerted to the
hazards of high surface temperatures, burns
and clothing ignition.
5. Children should be carefully supervised when
they are in the area of the appliance.
6. NEVER hang anything including clothes or
other flammable items on the appliance.
7. DO NOT operate this appliance unless it is
fully assembled with burner guard in place.
8. DO NOT SPRAY AEROSOLS IN THE
VICINITY OF THIS APPLIANCE WHILE IT IS
IN OPERATION.
9. Installation and repair should be done by a
qualified service person. The appliance must
be inspected before use and at least annually
by a qualified service person. It is imperative
that control compartment, burners and
circulating air passages of the heater be kept
clean.
10. This appliance must be only used in a well
ventilated area.
11. Do not perform maintenance until heater has
been turned off, and heater has cooled to
room temperature.
12. Do not expose the burner to water or moisture.
The appliance must be protected from rain and
wind.
13. Avoid inhaling fumes emitted from the heater’s
first use. Smoke and odour from the burning
of oils used in manufacturing will appear.
Both the smoke and odour will dissipate after
approximately 20-30 minutes.
14. Any modification to the heater not described in
the installation instructions may compromise
the safety of this appliance. Special concern is
as follows:
(1) DO NOT bypass thermocouple safety burner;
(2) DO NOT operate appliance without the guard;
15. Clothing or other flammable materials should
not be hung from the appliance, or placed
on or near the appliance. The area above the
burner may be extremely hot. Direct contact
with these metal surfaces should be avoided in
order to prevent burns or clothing ignition.
16. The appliance must be used or installed in a
location such that it is readily accessible for
servicing and have no restriction of air flow to
the air inlet of the heater’s casing.
17. Special conditions that must be avoided,
e.g. marine environment and any conditions
necessary to ensure optimum performance.
IMPORTANT SAFETY RULES

3
Prior to Installation and Assembly of your appliance,
the following must be reviewed. Compliance with the
following should result in satisfactory heater operation.
This instruction manual should be retained for future
reference. The installation must conform with local
codes or authority having jurisdiction.
1. The appliance is intended for heating residential and
non-residential outdoor spaces. The installation
must conform with local codes and with the
Australian Standard AS/NZS 5601.
2. Adequate clearance around air openings into the
combustion chamber, clearances from combustible
materials, provisions for accessibility and for
combustion and ventilating air supply must be
maintained at all times when the appliance is
operating.
3. Proper clearance from combustible materials must
be maintained at all times. The minimum clearances
are as follows:
Minimum Clearance from Combustibles:
Side 1000 mm Bottom 2000 mm
Ceiling 400 mm
Combustible materials are considered to be wood,
compressed paper, plant fibres, plastic, plexiglas or
other materials capable of being ignited and burned.
Such materials shall be considered combustible even
though flame proofed, fire-retardant treated or plastered.
Additional clearance may be required for glass, painted
surfaces and other materials which may be damaged by
radiant or convection heat.
Gas Requirements:
Solaris LPG Models
1. Use Propane (LPG) gas only.
2 The approved inlet pressure to the appliance is
2.75KPA.
To convert the product to (LPG), call the Sitro service
team for injector, hose and regulator requirements.
Note! Heater must be installed and serviced by a
licenced gas fitter or plumber
Solaris Natural Gas Models
1. Use Natural Gas Only.
2 Always use Natural Gas Regulator (supplied).
3. Ensure that inlet pressure to the regulator does not
exceed 5KPA.
4. The approved inlet pressure to the appliance is
1.0KPA (RH205) / 0.8KPA (RH200).
PRODUCT OVERVIEW

1. The hose must be protected from contact with
hot or sharp surfaces both during use and while
in storage. The hose assembly should be visually
inspected prior to each use of the appliance. If
excessive abrasion or wear is evident, or the hose
is cut, it must be replaced prior to operating the
appliance. The replacement hose assembly may be
obtained from the manufacturer.
2. DO NOT use any pressure regulator or hose
assembly other than those supplied with the
appliance. Replacement pressure regulator
and hose assembly must be those specified.
Replacement parts maybe obtained from the
manufacturer or your local sales
representative.
3. Installation and use of this appliance must conform
with local codes and AS/NZS 5601.
LPG GUIDELINES
If the product has been converted to LPG, then you
must ensure the following conditions:
1. This appliance is designed to operate with a
standard 9kg propane cylinder with Approved
Cylinder Connection.
2. The valve outlet must be maintained in good
condition. When the cylinder is not in use, be sure
to cover it with a dust cap. A leak test should be
performed with soapy water whenever connecting a
new cylinder. NEVER use a match to test for leaks.
3. The propane cylinder must be turned off whenever
the appliance is not in use. When the appliance is
to be stored indoors, the propane cylinder and the
appliance must be disconnected and the cylinder
stored in accordance with the Standard for Storage
and Handling of Liquefied Gases.
IMPORTANT
Storage of an appliance indoors with the cylinder
attached is only permitted if the size of the cylinder
complies with AS/NZS 1596; otherwise cylinders
must be stored outdoors in a well ventilated area.
The guards are fitted to this appliance to reduce the
risk of fire or injury from burns and no part of it should
be removed.
This appliance must be protected from exposure to
rain and wind.
SPECIFICATIONS
Gas type LPG NATURAL GAS
Manufactured by Gasmate
AGA Approval No.
Gas Consumption 35 MJ/h 35 MJ/h
Gas Type Propane Gas (LPG) Only Natural Gas
Gas Pressure 2.75 KPA 1 KPA (RH205), 0.8KPA (RH200)
Injector Size 1.6mm 2.80mm (RH205), 2.85mm (RH200)
Weight RH200 - 15Kg RH205 - 14Kg
Voltageq 200-240V AC 50HZ
Current >1 Amp
Note: If the appliance cannot be adjusted to perform correctly it should not be used until serviced or repaired.
Heater specifications can be found on the data label.
PRODUCT OVERVIEW
4

ESSENTIAL INFORMATION
The warranty to the product will be voided if any
component of the patio heater is tampered with, or
altered.
To have these units altered or serviced by an
unauthorised person may render the product inefficient,
and at worst dangerous.
SERVICING INSTRUCTIONS
Appliances should be serviced at least annually and
servicing must only be carried out by a Licensed
Plumber or Authorised Person.
1. Remove Guard from Burner Housing.
2. Clean the Burner Ports and top with a Soft Brush.
Inspect and clean all combustion air inlets.
3. Clean thermocouple tip and spark igniter using a
soft wire brush.
4. Check operation of the igniter and the
thermocouple. Should new parts be required
contact the Supplier or Sitro Group Australia.
INSTALLATION FOR WALL MOUNTED
Natural Gas Heaters must be installed by an Authorised
Person.
Brackets for suspended installation must be permanently
fixed to a solid structure.
Positioning of both floor mounted and suspended
heaters must maintain required clearances.
i.e. 1000mm above, 1000mm on all sides and 500mm
below the heater emitter mesh.
It is a Standards Australia requirement that an approved
metal tube such as copper or galvanized steel or an
AGA certified stainless steel braided hose assembly be
utilised to convey gas to the burner head, and must be
installed by an authorised person, i.e. licensed plumber.
A Natural Gas Patio Heater is not designed for relocation
to varying locations, so the most preferable permanent
location should be selected prior to installation.
TO BE INSTALLED ONLY BY AN AUTHORISED PERSON
HEATER ASSEMBLY
NOTE: Recommended clearances must be
maintained.
* Remove transit protection material.
TOOLS REQUIRED: Drill
Masonry drill bit
Adjustable spanner
Phillips head screwdriver
STEP 1.
Firmly attach the mounting bracket using expanding
fasteners to a solid wall or alternatively speak with your
hardware supplier.
STEP 2.
Attach the natural gas regulator between the manual
shut off valve of the supply line and the heater gas hose
or pipe and set the outlet pressure at 1kPa.
GAS PIPING
1. Where it is not practical to install solid tube an
AGA certified stainless steel braided hose can be
installed. This hose assembly must comply with AS/
NZS 5601. Gas Installations, pipe sizing tables and
shall not exceed 3 metres in length. The internal
diameter of the hose must not be less than 15mm.
2. Check with local and state plumbing and heating
codes regarding sizing of the gas lines.
3. All gas pipe connections to the heater(s) must
be sealed with a gas pipe compound resistant to
Natural Gas.
4. Installation of a drip leg if required in the gas supply
line going to each heater must conform to AS/NZS
5601.
5. When checking for gas leaks, do no use an open
flame. Use a soap and water solution and check for
bubbles indicating gas leakage (refer Page 6).
6. Installation of 1/8” NPT plugged tapping, accessible
for test gauge connections, is required upstream of
the gas supply connection to the heater.
INSTALLATION AND SERVICING
5

6
400mm
2000mm
1000mm
RADIANT CERAMIC HEATER
Minimum Clearances from Combustible
Surfaces*:
Care should be taken to ensure that the heater is not
installed:
• Where heat/ignition can cause damage to gas
cylinders lines
• Near other combustible materials
• In open locations subject to rain
• In indoor residential locations
• In areas without sufficient clearances (refer below)
INSTALLATION AND SERVICING
IMPORTANT
This appliance must only be used in a well ventilated
area. *Combustible materials are considered to be wood,
compressed paper, plant fibres, plastic or other materials
that are capable of being ignited and burned.
Refer Page 15 for safe appliance locations

7
400mm
2000mm
1000mm
LEAK TESTING THE PRODUCT
A gas leak test must be done after assembly and before
operating the appliance. Procedure as follows:
1. If the product is installed on Natural Gas, the hose &
regulator must be connected to both the heater and
mains supply. If the product is installed on LPG then
the hose & regulator must be connected to both the
heater and a full gas cylinder.
2. Must ensure the unit is not running when leak test is
being performed
RH200 (Auto): Power must be switched off
RH205 (Manual): Do not light the unit
3. Make a mild soapy water solution. Apply with a
spray bottle, soft cloth or brush to the following
connections:
Hose connection to mains supply if on
natural gas (See image 1) or if on LPG, it
is the regulator connection to gas cylinder
Hose connection to regulator (See image 2)
Hose connection to the heater (See image 3)
4. Turn on the gas supply either at the mains or gas
cylinder
5. Apply the soapy water solution to the 3 connections
6. If soap bubbles appear at any of the connections,
there is a gas leak
7. If a gas leak is detected, turn the gas supply off.
Tighten any leaking fittings and repeat the process
8. If soap bubbles still appear (gas is still leaking), you
must:
If on natural gas, turn off the gas supply at the
mains then contact the licenced gas installer
If on LPG, turn off the gas supply at the
cylinder and disconnect the regulator, then
contact the licenced gas installer
INSTALLATION AND SERVICING
IMPORTANT
Any threaded connection that is required in the
assembly of the hose & regulator must be tightened
with a shifter or spanner. Failing to do this may lead
to a gas leak at the connection.
IMPORTANT
It is the responsibility of the gas installer to ensure
there are no leaks when installing the product. DO
NOT contact the place of purchase or supplier, you
must contact the licenced gas installer.
IMAGE 1
IMAGE 3
IMAGE 2

8
START - TURNING THE HEATER ON
1. Before operating this appliance:
If there is any uncertainty in relation to the guidelines
stated in this instruction manual or to obtain a copy,
please call the Sitro Service Team on 1300 174 876
(Mon – Fri) 8.00am – 5.00pm or Email
[e-mail] for technical support.
2. Turn the gas supply on:
- If the heater is connected to a ball valve
socket containing an on/off tap, then turn the
gas on at the tap. See image 1
- If the heater is connected to a bayonet point
then you can move straight to step 3, as the
gas is already flowing to the unit. See image 2
3. Ensure the appropriate gas pressure is set:
Refer to page 2 of the instruction manual under the
heading Gas Requirements.
4. Turn the power on at the power point.
5. Automatic Ignition: Once the power is turned on and
gas is flowing to the unit, it should automatically
begin to ignite the heater. Visually you should see
a spark at the base of the centre tile, which will
eventually ignite the gas and light the tiles. See
image 3
- Once the heater is lit the tiles will start to
glow orange giving indication that the unit is
fully functional.
RH200 SOLARIS DELUXE HEATER – OPERATING INSTRUCTIONS
IMPORTANT
It is imperative that you ensure that the gas
installation and power installation has been
carried out in accordance with the manufacturers
guidelines in this instruction manual. A certificate
of compliance should be provided by the licenced
installer at the completion of any installation.
Make sure you read the instruction manual
thoroughly prior to use.
IMAGE 1
IMAGE 2
IMAGE 3
Ignition Spark

9
RH200 SOLARIS DELUXE HEATER – OPERATING INSTRUCTIONS
6. Ignition Failure: If the heater fails to ignite, then turn
the power off at the power point.
- Wait 10 seconds, then turn the power back on
at the power point. If the heater fails to
ignite after 6 attempts, refer to the troubleshooting
guide in the back of the instruction manual for
further guidance or alternatively contact the Sitro
Service Team on 1300 174 876 (Mon – Fri)
8.00am – 5.00pm or Email
[e-mail] for technical support.
STOP - TURNING THE HEATER OFF
1. Turning the unit off temporarily: To turn the heater off
temporarily, simply turn the power off at the power
point leaving the gas supply on.
2. Turning the unit off permanently: Firstly, turn the
power off at the power point and secondly shut the
gas off at the gas supply.
- If the heater is connected to a ball valve socket
containing an on/off tap, then simply turn the gas
off at the tap.
- If the heater is connected to a bayonet point,
then the hose will need to be disconnected from
the bayonet socket to shut the gas off.
Note:
The heater must be completely shut off for 10 minutes
before being relighted. This allows for any excess gas to
dissipate and for the unit to cool down.
IMPORTANT
Popping Noise:
When turning the heater on and off, there will be
a slight popping noise which is normal when the
burner is ignited or extinguished. If, however a
popping noise occurs when the unit is running,
turn off the heater at the power and gas supply
and contact the Sitro Service Team for further
advice.
Smoke & Odour:
Fumes will be emitted from the heater upon first
use which is smoke and odour from oil from
manufacturing being burnt. Important to avoid
inhaling the fumes. Generally, odour and smoke
will dissipate after approx. 20-30 minutes.
Wind Protection:
Important to protect the heater from wind while
attempting to light.

10
START - TURNING THE HEATER ON
1. Before starting this appliance:
If there is any uncertainty in relation to the guidelines
stated in this instruction manual or to obtain a copy,
please call the Sitro Service Team on 1300 174 876
(Mon – Fri) 8.00am – 5.00pm or Email service.group@
sitro.com.au for technical support.
2. Turn the gas supply on:
- If the heater is connected to a ball valve
socket containing an on/off tap, then turn the
gas on at the tap. See image 1
- If the heater is connected to a bayonet point
then you can move straight to step 3, as the
gas is already flowing to the unit. See image 2
3. Ensure the appropriate gas pressure is set:
Refer to page 2 of the instruction manual under the
heading Gas Requirements.
4. Igniting the unit: Pull and hold down the ignition
cord on right and maintain tension for approx. 10
seconds to ignite the tiles. Maintain the hold for a
further 15 seconds to heat the thermocouple, then
release the ignition cord.
Note:
Visually you should see a spark at the base of the
centre tile when holding down the ignition cord.
RH205 SOLARIS HEATER – OPERATING INSTRUCTIONS
IMPORTANT
It is imperative that you ensure that the gas
installation and power installation has been
carried out in accordance with the manufacturers
guidelines in this instruction manual. A certificate
of compliance should be provided by the licenced
installer at the completion of any installation.
Make sure you read the instruction manual
thoroughly prior to use.
IMAGE 1
IMAGE 2
IMAGE 3
Ignition Cord
Pull Down
Ignition Spark
