Electro-Harmonix MIG-50 User manual

MIG-50
50W All Tube Guitar Amplifier
Congratulations on your purchase of the Electro-Harmonix MIG-50, an all tube, two channel,
50W guitar amplifier head. The EHX MIG-50 is a faithful reissue of the Sovtek MIG-50 with
modern enhancements to both the electronics and mechnical design. The MIG 50 comes
installed with 5 Tung-Sol tubes, three 12AX7s and two 5881 power tubes.
IMPORTANT SAFETY INSTRUCTIONS
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Clean only with a dry cloth.
Do not block any ventilation openings.
Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
Do not defeat the safety purpose of the polarized or grounding type plug. If the provided plug does not fit
into your outlet, consult an electrician for replacement of the obsolete outlet.
Protect the power cord from being walked on or pinched.
Unplug this amplifier during lightning storms or when unused for long periods of time.
WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
Do not expose this apparatus to dripping or splashing and ensure that no object filled with liquids is
placed on the equipment.
Maintain at least six inches of unobstructed air space behind the unit to allow for proper ventilation and
cooling. Air must be capable of freely moving around the amplifier.
This amplifier is capable of producing very high sound pressure levels which may cause temporary or
permanent hearing damage. Use care when adjusting volume levels during use.
Do not turn the amplifier on without a loudspeaker.
Refer all servicing and maintenance to qualified service personnel including replacement of fuses and
vacuum tubes. Changes and modifications not expressly approved by EHX can void the warranty.
DO NOT attempt to remove the amplifier chassis. There are no serviceable parts.
The lightning flash with arrowhead symbol within an equilateral triangle, is intended to alert the
user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that
may be of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operation and maintenance (servicing) instructions in the literature
accompanying the product.

GETTING STARTED-
Before plugging in your EHX MIG-50 Amp make sure of the following:
1. Both the POWER and STANDBY toggle switches are off; set to their DOWN
position.
2. The AC voltage switch on the rear panel is set to the correct voltage setting
for your region or the AC voltage powering your amp.
3. Your MIG-50 amp should be hooked up to a speaker cabinet with the correct
impedance (a four ohm cabinet to the four ohm jack, etc.). WARNING:
Running your amp to a speaker cabinet that doesn’t have matching
impedance or with no cabinet at all could severely damage the MIG-50 and
void your warranty. Be sure to select a cabinet that can handle the full rated
power rating for your amp.
To power up your EHX MIG-50 Amp:
1. Turn on the POWER switch. Wait thirty seconds for the tubes to warm up.
2. Flip the STANDBY switch to the “on” position. It’s best to keep the volume
low when turning your amp on and then adjust it to the level you need.
3. OK! ROCK & ROLL!
FRONT PANEL Controls:
INPUT I Jack – This ¼” jack is the audio input for the normal channel.
INPUT II Jack – This ¼” jack is the audio input for the bright channel.
VOL I Knob – Controls the overall loudness of channel I, the normal channel.
VOL II Knob – Controls the overall loudness of channel II, the bright channel.
TONE Knobs – TREBLE, MIDDLE, BASS and PRESENCE controls are used to alter
the amplifier’s frequency response. Adjust to taste and experiment with different
settings.
Lamp – Lights up when the POWER switch is on.
REAR PANEL:
LOUDSPEAKERS – These output jacks are for 4 ohm, 8 ohm and 16 ohm
loudspeakers connections.
AC Switch – Depending on your region the correct voltage should be selected
on the back of your MIG-50. This switch will be set at the EHX factory prior to
shipping to one the following regions:
USA / CANANDA – 117 VAC
EUROPE / AUSTRALIA / NEW ZEALAND – 230 VAC
JAPAN – 100 VAC
- WARRANTY INFORMATION -
Please register online at http://www.ehx.com/product-registration or complete and
return the enclosed warranty card within 10 days of purchase. Electro-Harmonix will
repair or replace, at its discretion, a product that fails to operate due to defects in
materials or workmanship for a period of one year from date of purchase. This
applies only to original purchasers who have bought their product from an authorized
Electro-Harmonix retailer. Repaired or replaced units will then be warranted for the
unexpired portion of the original warranty term.
If you should need to return your unit for service within the warranty period, please
contact the appropriate office listed below. Customers outside the regions listed
below, please contact EHX Customer Service for information on warranty repairs at
[email protected] or [phone]. USA and Canadian customers: please obtain a
Return Authorization Number (RA#) from EHX Customer Service before returning
your product. Include with your returned unit: a written description of the problem
as well as your name, address, telephone number, e-mail address, and RA#; and a
copy of your receipt clearly showing the purchase date.
United States & Canada
EHX CUSTOMER SERVICE
ELECTRO-HARMONIX
c/o NEW SENSOR CORP.
55-01 2ND STREET
LONG ISLAND CITY, NY 11101
Tel: [phone]
Email: [email protected]
Europe
JOHN WILLIAMS
ELECTRO-HARMONIX UK
13 CWMDONKIN TERRACE
SWANSEA SA2 0RQ
UNITED KINGDOM
Tel: [phone]
Email: [email protected]
This warranty gives a purchaser specific legal rights. A purchaser may have even
greater rights depending upon the laws of the jurisdiction within which the product
was purchased.
