Electro-Voice PA2400T User manual

General Description:
The Electro-Voice® PA2400T is from the PA series of
professional commercial audio amplifiers. The direct path
airflow design reduces the heat buildup significantly and
allows for more amplifier channels and output power in
slim two rack space chassis. The audio performance of the
PA2400T is superior and fulfills the requirements in many
demanding long term applications from sound
reinforcement, paging or life safety installations.
High performance torroidal power and output transformers
combine clean saturation free audio performance with cool
running operation. The PA2400Tfeatures many of the same
comprehensive protection circuits typical in EV amplifiers.
Complete protection is provided for high temperature, audio
limiters, power up delay and peak current limiters. In addition
to the rated output power, the PA2400T provides excellent
headroom for a wide dynamic range on music signals. The
onboard dynamic limiter ensures that the output clipping of
the PA2400T will not will not generate excessive distortion.
The amplifier channels can be bridged for more power
flexibility.
Marked level controls on the rear panel provide hidden
reliable level adjustments for each channel. Front panel
LEDs indicate signal present, 0 dB, and limit. Phoenix type
connectorsforinputsandoutputsprovideaneasy rackwiring.
Key Features:
• 2 x 430W at 70V or 4 Ohms
• 2 U Rack Space Chassis
• Rear Level Controls
• Complete Protection Package
• Bridge Mode Operation Provides
1 x 860W at 8 Ohms
• Selectable 50Hz or 300Hz Hi-Pass Filter for
each Channel
• PhoenixType Inputs
• PhoenixType Outputs
• High Efficiency Circuit Design
• Front Panel Power On/Off
PA2400T
Two-Channel
PowerAmplifier
Technical Specifications:
Low Impedance Outputs:
- Min. Rated Load for Single Channel Operation is 4 Ohms. 2 Ohm Load is Not Recommended.
- Min. Rated Load for Bridged Operation is 8 Ohms. 4 Ohm Load is Not Recommended.
slennahCforebmuN2
ecnadepmIdaoLmhO8mhO4V07
)daoLdetaR*(rewoPtuptuOdetaR zHk1,%1<DHT W512W034W034
)daoLdetaR*(rewoPtuptuOdetaR zHk02…zH02,%2.0<DHT W002W004W004
zHk1taetaRwelSsµ/V52 sµ/V64
zHk1.feR,Bd1-,esnopseRycneuqerFzHk04-zH56 -zH56 zHk02
,zHk1/zH001ta,rotcafgnipmaD mhO4 052>A/N
.feR,%1=DHThtdiwdnaBrewoP rewoPflaH,zHk1 zHk02>-zH54
,zHk02...zH02,ecnadepmItupnI decnalaB mhOk02>
dethgieW-A,oitaResioN-ot-langiSBd301
tuptuOdetaRtaytivitisneStupnI zHk1,egatloVrorewoP )Vm577(uBd0
,rewoptuptuodetartaDHT zHk1,zHk08=WBM %1.0<
zHk7,zH06,ETPMS-DMI%1.0<
zHk51,zHk51.3,03MID%1.0<
detaR%01ta,zHk1.feR,klatssorC rewoPtuptuO Bd57-<
stnemeriuqeRrewoP-zH05,V032roV021 zH06
noitcetorPsretimiLoiduA erutarepmeThgiH sretimiLtnerruCkaeP yaleDnO-nruT
gnilooCraeR-ot-tnorF
mm,)DxHxW(snoisnemiD )uR2(mm604x88x384 "61x"5.3x"91
thgieW)sbl72.75(gk62

12000 Portland Avenue South, Burnsville, MN 55337
Phone:[phone], Fax:[phone]
www.electrovoice.com
© Telex Communications, Inc. 1/2006
PartNumberLIT-0000XX Rev1
U.S.A. and Canada only. For customer orders, contact Customer Service at:
800/392-3497 Fax: [phone]
Europe, Africa, and Middle East only. For customer orders, contact Customer Service at:
+ 49 9421-706 0 Fax: + 49 9421-706 265
Other International locations. For customer orders, contact Customer Service at:
+ 1 952 884-4051 Fax: + 1 952 736-4212
For warranty repair or service information, contact the Service Repair department at:
800/685-2606
For technical assistance, contact Technical Support at: 866/78AUDIO
Specifications subject to change without notice.
PA2400TPartNumber:
PA2400T, 120V -- D170406
Block Diagram:
Dimension Drawings:
Rear View: Front View
Top View
All Dimensions
inMillimeters
