Viatron Autrix User manual

Page 1of 23
Viatron GmbH -KNX
MultiRoom Audio -Autrix
Technical Manual

Page 2of 23
Contents Page
1General description:.................................................................................................................4
2Block diagramm........................................................................................................................5
2.1 Schema Autrix with 4 zones...............................................................................................................5
2.2 Schema Autrix with 8 zones...............................................................................................................5
3Connections to he unit (rear side oft he unit).........................................................................6
3.1 Loudspeaker connections..................................................................................................................6
3.2 Audio Output (NF)................................................................................................................................6
3.3 Audio Input (NF)...................................................................................................................................6
3.4 RS232 Port............................................................................................................................................6
3.5 KNX Port...............................................................................................................................................7
3.6 Option ...................................................................................................................................................7
3.7 Power Supply.......................................................................................................................................7
4KNX Object description / general functions............................................................................7
4.1 General describtion.............................................................................................................................7
4.2 Switching the Amplifier board ON/OFF.............................................................................................7
4.3 Amplifier - board temperature............................................................................................................7
4.4 Master mute ON / OFF.........................................................................................................................8
4.5 Alarm - overheating.............................................................................................................................8
5KNX Object description / Amplifier..........................................................................................8
5.1 Anplifier n: Input signal - stepwise....................................................................................................8
5.2 Amplifier n: Input signal - value.........................................................................................................9
5.3 Amplifier n: Input signal - status........................................................................................................9
5.4 Amplifier n: Mute ON / OFF...............................................................................................................10
5.5 Amplifier n: Volumne - status...........................................................................................................10
6KNX Object description / Sound settings .............................................................................11
6.1 Amplifier n: Treble, setting - steppwise ..........................................................................................11
6.2 Amplifier n: Treble, setting - value...................................................................................................11
6.3 Amplifier n: Treble - status...............................................................................................................12
6.4 Amplifier n: Middle, setting - steppwise..........................................................................................12
6.5 Amplifier n: Middle, setting - value..................................................................................................13
6.6 Amplifier n: Middle - status...............................................................................................................13
6.7 Amplifier n: Bass, setting - steppwise.............................................................................................14
6.8 Amplifier n: Bass, setting - value.....................................................................................................14
6.9 Amplifier n: Bass - status .................................................................................................................15
7KNX object description / Input gain.......................................................................................15
7.1 Explanation ........................................................................................................................................15
7.2 Audio input n: Setting the input gain - steppwise..........................................................................15
7.3 Audio input n: Setting the input gain - value..................................................................................16
7.4 Audio input n: Input gain - status ....................................................................................................16
8KNX object description / Setting (save/reset).......................................................................16
8.1 Explanation ........................................................................................................................................16
8.2 Sound settings: Save ........................................................................................................................17
8.3 Sound Settings: Reset ......................................................................................................................17
9Operating via frontpanel.........................................................................................................17
9.1 Power / ON - OFF ...............................................................................................................................17
9.2 Setting an input source for a zone...................................................................................................18
9.3 Setting the volumne for a zone ........................................................................................................18
9.4 Setting the tone control for a zone (bass control) .........................................................................18
9.5 Setting the tone control for a zone (treble control)........................................................................18
9.6 MasterMute / ON - OFF......................................................................................................................19
10Installing and connecting the device.....................................................................................19

Page 3of 23
11Technical Data ........................................................................................................................20
11.1Data sheet...........................................................................................................................................20
11.2System and error messages (LEDs Front)......................................................................................21
12Maintenance and care ............................................................................................................22
13Important Information.............................................................................................................22
13.1Liability exclusion..............................................................................................................................22
13.2Approved use.....................................................................................................................................22
13.3Warranty .............................................................................................................................................22
13.4Warning notices.................................................................................................................................22
14Contact....................................................................................................................................23

Page 4of 23
1 General description:
The Autrix is an Audiomatrix with integrated amplifier stages. With the Autrix music can be distributed into
varies areas. Scope of application is from private homes to office buildings.
Basically due to the modulare structure, there is the possibility of various expansion options.
The basic version is available with the following technical features:
Input: 4 stereo audio input (NF signals)
Output: up to 8 speaker output (8 Ohm)
2 stereo audio output (NF signals)
The AUTRIX is directly connected to the KNX building bus. So the controlling can be made by the installed
switch range/visualisation.
The device can also be controlled directly over the front panell located on front of the device.

Page 5of 23
2 Block diagramm
2.1 Schema Autrix with 4 zones
Figure: Schema Autrix with 4 amplifier zones
2.2 Schema Autrix with 8 zones
Figure: Schema Autrix with 8 amplifier zones

Page 6of 23
3 Connections to he unit (rear side oft he unit)
Electrical voltage !
Working on electrical systems or devices could be a danger to life due to possible hazard of
electric shock or fire hazard!
Work on the 230 V network may only be carried out by skilled electricians!
Figure: rear side of unit
Speaker Audio OUT Audio IN RS232 KNX Option Net
3.1 Loudspeaker connections
Only speakers with the following features can be connected to the AUTRIX:
Capacity: min. 30 W
Impedance: 8 Ohm
The speaker cabling is connected to the Autrix via srew terminals. These srew terminals allow the connection
of cabels up to 2,5 qmm.
3.2 Audio Output (NF)
In addition to the amplifier outputs the Autrix also sends unreinforced audio signals. These signals can be
connected to external amplifier.There are two of those audio outputs available:
Audio signal of zone 1 (stereo)
Audio signal of zone 2 (stereo)
These NF-signals are logically connected to the same KNX communication objects, as the amplifier output.
3.3 Audio Input (NF)
Up to 4 onsite audio devices, are connected to the 4 audio NF inputs (stereo RCA sockets) of the Autrix.
These audio input signals are then available for all integrated amplifier stages (up to 8 amplifier).
3.4 RS232 Port
Not available in current version.

Page 7of 23
3.5 KNX Port
The connection to the KNX bussystem occurs by screw terminal type Hartmann/PTR BU9502, which is
included in the scope of delivery.
The power consumption of the KNX connection is listed in the data sheet.
3.6 Option
The ports are not occupied and irrelevant for the operation at the KNX system.
3.7 Power Supply
The power supply is send to the Autrix via a power cord (IEC60320-C13), which is included in the scope of
delivery.
4 KNX Object description / general functions
4.1 General describtion
The Autrix comes with several data interfaces. Which means that the device can be activated over several
protocols. Normaly the device is destined for the connection to the KNX builduíng bus. This section
describes the controlling of the Autrix over the KNX communication objects..
4.2 Switching the Amplifier board ON/OFF
Object
Designation
Function
Data type
1
Amplifier board ON/OFF
switch
1.001 ON/OFF
2
Amplifier board ON/OFF
status
1.001 ON/OFF
Via the communication object 1 the amplifier board can be switched ON or OFF. Object 2 sends back the
status. Even after switching off the amplifier boards the Autrix can still receive or send telegrams.
Switching off the amplifier board is recommended, if the autrix will not be in use for a longer period of time
(for example: nighttime, vaccation etc.).
4.3 Amplifier - board temperature
Object
Designation
Function
Data type
3
Amplifier board temperature
status
9.001 temperature
The object sends the temperature of the amplifier board as a status to the KNX bus. The correspondent
telegram will always be send, if the temperature has changed by minimum 1 degree.

Page 8of 23
4.4 Master mute ON / OFF
Object
Designation
Function
Data type
4
Master mute ON/OFF
switch
1.001 ON/OFF
5
Master mute ON/OFF
status
1.001 ON/OFF
Via the communication object 4 the master mute can be switched ON or OFF. Object 5 sends back the
status. If master mute (value 1) is set, all amplifiers are on silent.
The value 0 sets the amplifier back to the state before the muting.
Switching off the amplifiers via the master mute is recommended, when all amplifier outputs need to be set
to silent momentary (for example incomming phonecall, announcement etc.).
4.5 Alarm - overheating
Object
Designation
Function
Data type
8
Alarm overheating
status
1.002 Boolesch
In case of overheating of the system this object will be sent with value 1.
At the end of the alarm (temperature back to normal) the status will send the value 0.
During the period of the alarm the Autrix M4 is switched off automatically. Afterwards the Autrix M4 needs to
be turned on again (through KNX Bus or trough the front panel oft he device).
5 KNX Object description / Amplifier
5.1 Anplifier n: Input signal - stepwise
Object
Designation
Function
Data type
31
Amplifier 1 Input-signal
stepwise
step
1.007 step
51
Amplifier 2 Input-signal
stepwise
step
1.007 step
71
Amplifier 3 Input-signal
stepwise
step
1.007 step
91
Amplifier 4 Input-signal
stepwise
step
1.007 step
111
Amplifier 5 Input-signal
stepwise
step
1.007 step
131
Amplifier 6 Input-signal
stepwise
step
1.007 step
151
Amplifier 7 Input-signal
stepwise
step
1.007 step
171
Amplifier 8 Input-signal
stepwise
step
1.007 step
The input signals for the amplifiers (audio zones) are selected via these communication objects. There are 4
input signals available. By sending the value 1 to a communication object, it will be switched to the next
higher input number. Equivalent the value 0 switches to the next lower input number.

Page 9of 23
5.2 Amplifier n: Input signal - value
Object
Designation
Function
Data type
32
Amplifier 1 Input signal-
value
value
5.010 counting impulse
52
Amplifier 2 Input signal-
value
value
5.010 counting impulse
72
Amplifier 3 Input signal-
value
value
5.010 counting impulse
92
Amplifier 4 Input signal-
value
value
5.010 counting impulse
112
Amplifier 5 Input signal-
value
value
5.010 counting impulse
132
Amplifier 6 Input signal-
value
value
5.010 counting impulse
152
Amplifier 7 Input signal-
value
value
5.010 counting impulse
172
Amplifier 8 Input signal-
value
value
5.010 counting impulse
The input signals for the amplifiers (audio zones) are selected via these communication objects.
There are 4 input signals available. Sending…….
….value 1 connects the amplifier n with the audio input 1.
….value 2 connects the amplifier n with the audio input 2.
….value 3 connects the amplifier n with the audio input 3.
….value 4 connects the amplifier n with the audio input 4.
Value 0 would clear the routing.
5.3 Amplifier n: Input signal - status
Object
Designation
Function
Data type
33
Amplifier 1 Input signal-
status
status
5.010 counting impulse
53
Amplifier 2 Input signal-
status
status
5.010 counting impulse
73
Amplifier 3 Input signal-
status
status
5.010 counting impulse
93
Amplifier 4 Input signal-
status
status
5.010 counting impulse
113
Amplifier 5 Input signal-
status
status
5.010 counting impulse
133
Amplifier 6 Input signal-
status
status
5.010 counting impulse
153
Amplifier 7 Input signal-
status
status
5.010 counting impulse
173
Amplifier 8 Input signal-
status
status
5.010 counting impulse
Via these communication objects the Autrix M4 sends back the number of the audio input, which was
currently selected.

Page 10 of 23
5.4 Amplifier n: Mute ON / OFF
Objekt
Designation
Function
Data type
34
Amplifier 1 Mute ON/OFF
switch
1.001 ON/OFF
35
Amplifier 1 Mute ON/OFF
status
1.001 ON/OFF
54
Amplifier 2 Mute ON/OFF
switch
1.001 ON/OFF
55
Amplifier 2 Mute ON/OFF
status
1.001 ON/OFF
74
Amplifier 3 Mute ON/OFF
switch
1.001 ON/OFF
75
Amplifier 3 Mute ON/OFF
status
1.001 ON/OFF
94
Amplifier 4 Mute ON/OFF
switch
1.001 ON/OFF
95
Amplifier 4 Mute ON/OFF
status
1.001 ON/OFF
114
Amplifier 5 Mute ON/OFF
switch
1.001 ON/OFF
115
Amplifier 5 Mute ON/OFF
status
1.001 ON/OFF
134
Amplifier 6 Mute ON/OFF
switch
1.001 ON/OFF
135
Amplifier 6 Mute ON/OFF
status
1.001 ON/OFF
154
Amplifier 7 Mute ON/OFF
switch
1.001 ON/OFF
155
Amplifier 7 Mute ON/OFF
status
1.001 ON/OFF
174
Amplifier 8 Mute ON/OFF
switch
1.001 ON/OFF
175
Amplifier 8 Mute ON/OFF
status
1.001 ON/OFF
Via these communication objects the amplifier mute can be switched ON or OFF. If the amplifier mute (value
1) is set, the equivalent amplifier is set on silent. Value 0 sets the amplifier back to the state before the
muting.
The master mute (see previous chapter) is always higher ranking than the amplifier (zone) mute. If master
mute is set, all zones (amplifiers) are muted. But the master mute does not overwrite the communication
object of the muting of the individual amplifiers. So if the master mute is set to vealue 0, again this data point
is relevant to mute or unmute the individual zone.
5.5 Amplifier n: Volumne - status
Objekt
Designation
Function
Data type
33
Amplifier 1 Volume
status
status
5.001 percent (0-100)
53
Amplifier 2 Volume
status
status
5.001 percent (0-100)
73
Amplifier 3 Volume
status
status
5.001 percent (0-100)
93
Amplifier 4 Volume
status
status
5.001 percent (0-100)
113
Amplifier 5 Volume
status
status
5.001 percent (0-100)
133
Amplifier 6 Volume
status
status
5.001 percent (0-100)
153
Amplifier 7 Volume
status
status
5.001 percent (0-100)
173
Amplifier 8 Volume
status
status
5.001 percent (0-100)
Via these communication objects the Autrix sends back the currently volume level of an amplifier.
