Electro-Voice Xlc Series Xlc-127DVX User manual

Key Features:
•AccurateVertical Control & Coverage
•Compact, Lightweight
•Fast, Simple Integrated Rigging
•Tri-Amp or Optional Bi-Amp Operation
•True 3-Way Design
•LAPS Aiming Software
• 120°Horizontal Full-Range Line-Array
•Quik-RigTM or Fixed Installation Rigging
XLC127DVX
XLCi127DVX
3-Way,High-Output
Compact Line-Array
Element
General Description:
TheXLCfamilyisdesignedtoprovidethehighestquality
performanceforavarietyofapplications. Itiscomprised
oftwofull range systems;XLC127DVX(120° line-array
element),XLC907DVX(90°line-arrayelement),andtwo
subwoofers;XLC118, XLC215. TheXLC127DVXusesa
DVX3121, two DVN2065 neodymium midrange
transducers, and two ND6 high frequency transducers.
The DVX3121 is a high performance low frequency
transducer with forced air, directional voice coil cooling
for high power and efficiency. The suspension and
magneticcircuit were optimizedfor long, linear travel to
provide low distortion and greater LF extension in a
lightweighttransducer. TheDVN2065transducerutilizes
neodymium to provide very high output with lightweight
andlowerdistortion.The 3-Way designiscomprisedof;
a 12" vented LF, 2 x 6.5" MF transducers on a 120°
horizontal waveguide, and 2 x 3" HF transducers
combiningthrough Hydrason a120° x 7° waveguide. It
canbeusedin tri-amp mode, orbi-amp3-wayusingthe
optionalsophisticatedinternal24dB/octavepassiveMF
to HF network. The asymmetrical box design was
optimizedtoproduceasymmetricalpolarpatternwitha
uniformpowerresponse. Designedforuseingroups of
fourormore the XLC127DVXdeliverspredictabilityand
control. Combinedwithanadvancedintegratedrigging
system,one-maninstallationsareareality. XLC systems
canalsobegroundstacked. Idealforapplicationsranging
from live reinforcement to performing arts venues to
houses of worship, to sports facilities, XLC can deliver
unprecedented performance, particularly in difficult
acoustical environments. LAPS modeling software
providesquick,accurateresults for array configurations
andrigginginformation.
Technical Specifications:
esnopseR.qerF
1
:)Bd3-(zHk81-zH56
egnaR.qerF
1
:)Bd01-(zHk02-zH05
LPSdetaluclaCxaM
1
:kPBd051,.tnoCBd441
:egarevoClatnoziroH°021
:egarevoClacitreVelbanifeDerawtfoS,tnadnepeDyarrA
:)sepyThtoB(gniggiR,stnemercni°1,munimulAevitpaCylluF rotcaFytefaS1ot8htiwstnemele61
:gnildnaHrewoPFLkaePW0002,.tnoCW005
:gnildnaHrewoPBMkaePW0021,.tnoCW003
:gnildnaHrewoPFHkaePW006,.tnoCW051
)FH/BM/FL(ytivitisneS:Bd111/101/59
:qerFrevossorcBMotFLzH005
:qerFrevossorcFHotBM)evitcAroevissaP(zH0061
:dnabssaPFL :reifilpmAdednemmoceR smho8,1213XVD"21x1 7GT/5GT,S0004/0003PC,LR0003PVE
:dnabssaPBM :reifilpmAdednemmoceR smho8,5602NVD"5.6x2 7GT/5GT,S0004/0003PC,LR0003PVE
:dnabssaPFH :reifilpmAdednemmoceR smho8,61-6DNx2 7GT/5GT,S0004/0003PC,LR0003PVE
:srotcennoC8LNx2
:lairetaMerusolcnEtaoCVE/wdoowylphcribylp-31
MT
:ellirGtniaptaocredwophtiwleetsdetalpcniZ
:cepSlatnemnorivnE018LIM,42PI925CEI
giR-kiuQ
MT
:)DxWxH(miD
:)DxWxH(miDllatsnI
"5.22x"93x"52.41 )mm275x099x263( "5.22x"5.63x"52.41 )mm275x729x263(
giR-kiuQ(thgieWteN
MT
:):)llatsnI( )gk9.94(sbl011 )gk1.84(sbl501
thgieWgnippihS giR-kiuQ(
MT
:):)llatsnI( )gk2.25(sbl511 )gk9.94(sbl011
1 Full Space Measurement of 4 Elements.

200
100
50
20
10
5
2
110001005020 2000010000
Frequency (Hz)
Impedance (Ohms)
HF MB
LF
20 100 1000 10000 20000
360
100
20
3.6
Frequency(Hz)
-6dB Beamwidth (degrees)
BlockDiagram:
DimensionDrawings(inches/metric):
PerformanceMatch:
• XLC907DVX - 90° Full-Range LineArray Element
• XLC215 - Dual 15” Subwoofer Loudspeaker System
• XLC118 - Single 18” Subwoofer Loudspeaker System
• P3000 - Precision SeriesTM Power Amplifier
• CP3000S - Precision SeriesTM Power Amplifier
• CP4000S - Precision SeriesTM Power Amplifier
• P3000RL - Precision SeriesTM Remote Control Power Amplifier
• P1200RL - Precision SeriesTM Remote Control Power Amplifier
• TG5/TG7 - Tour Grade Power Amplifiers
• Dx38 - Digital Sound System Controller
• DN9848 - Digital Sound Controller
• XLC-127 Cover - Protective Cover for Transporting
• XCOV4 Cover - Protective Cover Fits 4 XLC127’s for Transporting
• XFD-127 - Front Dolly for Rigging and Transporting
• XBD - 4-Tall Bottom Dolly for Rigging and Transporting
• XLC Series Quik-RigTM Grid B1 - Grid for Hanging XLC Line-Arrays
PerformanceMatch,InstallVersions:
• XLCi215 - Dual 15” Subwoofer Install Loudspeaker System
• XLCi118 - Single 18” Subwoofer Install Loudspeaker System
• XLCi Series Fixed Installation Grid B2 - Grid for Hanging XLCi
Line-Arrays
• XO-127DVX - Crossover Retrofit Kit for XLC/XLCi127DVX
(Part Number KIT000003-000)
XLC127DVXPartNumbers:
• XLC127DVX (Black Finish) - 302060-001
• XLCi127DVX (Black Finish) - 302061-001
• XLCi127DVX (White Finish) - 302061-002
12000 Portland Avenue South, Burnsville, MN 55337
Phone:[phone], Fax:[phone]
www.electrovoice.com
© Telex Communications, Inc. 6/2007
PartNumberLIT000017 RevB
U.S.A. and Canada only. For customer orders, contact Customer Service at:
800/392-3497 Fax: [phone]
Europe, Africa, and Middle East only. For customer orders, contact Customer Service at:
+ 49 9421-706 0 Fax: + 49 9421-706 265
Other International locations. For customer orders, contact Customer Service at:
+ 1 952 884-4051 Fax: + 1 952 736-4212
For warranty repair or service information, contact the Service Repair department at:
800/685-2606
For technical assistance, contact Technical Support at: 866/78AUDIO
Specifications subject to change without notice.
SideFront
Top
pmairT :FL2sniP
:BM3sniP
:FH4sniP
Connection Chart
(Pins 1 Pass Through)
Note: Quik-RigTM Loudspeaker shown. All dimensions
for Install version equal to Quik-RigTM version except
where shown.
Beamwidth:
Impedance:
