Undercounter Dishwashers
Medical Line Undercounter
The Electrolux Dishwashing range is produced for customers with the highest conceivable demands for good
efficiency,economy and ergonomics for dishwashing operation. The product range comprises of glasswashers,
undercounter dishwashers, hood type dishwashers, rack type dishwashers, flight type dishwashers and pot
and pan washers. The medical line undercounter dishwasher is equipped with drain pump, available with or
without continuous water softner, rinse aid dispenser and has a capacity of 12 baskets per hour.
502035 502036
SANITIZATION AND
PERFORMANCE
• The atmospheric boiler
combined with the rinse booster
pump, offers perfect rinsing
performances in terms of quality,
high water temperature and
pressure, always constant at 84°C
during rinsing cycles and
independent from the water
pressure of the network (with a
minimum of 0.5 bar).
• 4 second (variable) pause after
washing and before rinsing
ensures that no drops of unclean
water will fall on the clean items at
the end of the rinsing cycle.
• Three dishwashing programs:
1st cycle of 300 seconds for lightly
soiled items, 2nd cycle of 420
seconds for normally soiled items
and 3rd cycle of 600 seconds for
heavily soiled items.
• Thermal disinfection guaranteed
thanks to the large 12 litre
atmospheric boiler which provides
a water temperature of 85°C
(measured on the items in the
basket) for the 30sec. rinsing
cycle.
• Double skinned insulated wall
ensures a low noise level and a
reduction in heat loss from the
machine.
• Fault auto-diagnosis system.

HYGIENE AND RELIABILITY
• All the machines have smooth
surfaces to facilitate cleaning.
• Large deep drawn wash tank
and internal wash area with round
corners and no pipes to avoid dirt
built-up.
• The fully automatic self-cleaning
cycle avoids the risk of bacteria
proliferation.
• The boiler drain facilitates the
evacuation of stagnant water after
long periods of inactivity to ensure
a higher level of hygiene.
• High efficiency air gap (class A)
in water inlet circuit to avoid water
being siphoned back into the
network as a result of a sudden
drop in main pressures.

Undercounter Dishwashers
Medical Line Undercounter
Internet: http://www.electrolux.com/foodservice
IBF0102011-02-25Subject to change without notice
Convertible to 230 V / 3 / 50 Hz;
230 V / 1+N / 50 Hz
230 V / 3 / 50 Hz;
230 V / 1+N / 50 Hz
230 V / 3 / 50 Hz;
230 V / 1+N / 50 Hz
Supply voltage 400 V, 3N, 50 400 V, 3N, 50 400 V, 3N, 50
Net weight - kg. 68 71 68
Noise level - dBA <65 <65 <65
total power 6.85 6.85 6.85
Rinse pump 0.26 0.26 0.26
drain pump 0.034 0.034 0.034
Power - kW
Boiler elements - kW 6 6 6
Boiler capacity - lt. 12 12 12
water consumption - lt./cycle 7.5 7.5 7.5
temperature during rinse - °C 90 90 90
duration - sec. 30 30 30
Hot rinse cycle
electrical elements - kW 2 2 2
power pump - kW 0.736 0.736 0.736
tank capacity - lt. 23 23 23
temperature -°C 55-65 55-65 55-65
Washing cycle
height 335 335 335
depth 500 500 500
width 500 500 500
Cell dimensions - mm
height 850 850 850
depth 612 612 612
width 600 600 600
External dimensions - mm
Basket capacity/h 12 12 10
Dishes capacity/h 216 216 180
Duration cycles - sec. 300/420/600 300/420/600 360/540/660
N° of cycles 3 3 3
Rinse aid dispenser ● ● ●
Detergent dispenser ●
Rinse Booster Pump ● ● ●
Drain pump ● ● ●
Water softener ●
Thermometer ● ● ●
hardness - °f 7-14 <48 7-14
temperature - °C 50 50 65
Water supply
TECHNICAL DATA
EUCAIML
502035
EUCAIMLWS
502036
EUCAIMLG
502037
• Front and side panels, door,
wash tank, tank filter and
wash/rinse arms made in heavy
duty anti-corrosive AISI 304
stainless steel to guarantee
appliance durability.
• 304L stainless steel atmospheric
boiler with higher welding
protection improves the resistance
against corrosion from chlorinated
water.
• PVC water supply hose with
metal connections resistant to
high water pressure.
• Completely closed on the
reverse by a cover plate while the
IPX4 water protection prevents
external infiltrations.
FLEXIBILITY AND ERGONOMICS
• The incorporated Soft Start
feature offers additional protection
to delicate items such as
glassware and crockery and
increases wash pump reliability.
• Simple control panel with digital
display allows on-site
personalization of washing and
rinsing cycle times and
temperatures as well as precise
rinse aid and detergent quantities
depending on the customers
needs.
• Three phase or single phase
electrical connection, convertible
on-site.
• All machines are pre-arranged to
accept external dispensers.
• Counterbalanced door with
springs to lighten the load when
opening and closing.
• The wash tank filters can be
removed without extracting the
washing and rinsing arms.
• Pre-arrangement for HACCP
system implementation and
Energy Management device.
EASY ON THE ENVIRONMENT
• 98% recyclable by weight.
• CFC free packaging.
• In compliance with H
requirements.
• Low noise level.
• Developed and produced in ISO
9001 and ISO 14001 certified
factory.
CONTINUOUS WATER SOFTENER
• Two resin containers
automatically alternate during
regeneration to provide non-stop
washing.
• Regeneration activated
automatically – no operator
intervention.
• 100% of rinse water regenerated
with no pressure drop during rinse
to ensure full detergent removal
and sanitization of items.
• Comfortable front loading of
regeneration salt.
* Duration cycles: declared actual cycle
duration times can extend when water
supply temperature is lower than
indicated.

Undercounter Dishwashers
Medical Line Undercounter
Internet: http://www.electrolux.com/foodservice
IBF0102011-02-25Subject to change without notice
YELLOW CUTLERY CONTAINER 864242 864242 864242
WIRE BASKET FOR 12 PLATES UP TO 320
MM
867014 867014
STAND FOR UNDERCOUNTER
DISHWASHER
860418 860418 860418
STAINLESS STEEL INLET HOSE KIT 864016 864016
RINSE AID LEVEL PROBE KIT FOR UC+HT
DW
864005 864005 864005
KIT TO MEASURE TOTAL/PART.WATER
HARDNESS
864050 864050 864050
KIT HACCP EKIS 922166 922166
KIT 4 PLASTIC BOXES FOR
CUTLERY-YELLOW
865574 865574 865574
KIT 4 CASTORS F.DOUBLE SKINNED
UNDERC.DW
864008 864008 864008
INTEGRATED HACCP KIT FOR UC, HT AND
POTW
864001 864001
HACCP PRINTER KIT FOR UC, HT AND
POTW
864002 864002
FILTER FOR TOTAL DEMINERALIZATION 864015 864015
FILTER FOR PARTIAL DEMINERALIZATION 864017 864017
EXT.REVERSE OSMOSIS FILT-ATMOSPH.
BOILER
864026 864026
DETERGENT PUMP KIT 864218 864218
DETERGENT LEVEL PROBE KIT FOR UC+HT
DW
864004 864004 864004
COVER GRID FOR SMALL/LIGHT ITEMS IN
RACK
867016 867016 867016
BRASS INLET VALVE KIT FOR UC AND HT 864000 864000
BASKET SEMI-PROFESSIONAL
500X500X190MM
867024 867024 867024
BASKET FOR WINE GLASSES 500X500X246 867019
BASKET FOR 5 TRAYS 530X325MM-RED 867006 867006 867006
BASKET FOR 48 SMALL CUPS/24
CUPS-BLUE
867007 867007 867007
BASKET FOR 18 DINNER PLATES
240MM-YELLOW
867002 867002 867002
8 L EXTERNAL AUTOMATIC WATER
SOFTENER
860413 860413
304 AISI BACK PANEL-OPEN-UC TOP
LEVEL-UK
864269
304 AISI BACK PANEL FOR UC TOP LEVEL 864298
12 L EXTERNAL MANUAL WATER
SOFTENER
860412 860412
ACCESSORIES
YELLOW CUTLERY CONTAINER 2 2 2
BASKET FOR 48 SMALL CUPS/24
CUPS-BLUE
111
BASKET FOR 18 DINNER PLATES
240MM-YELLOW
111
INCLUDED ACCESSORIES
EUCAIML
502035
EUCAIMLWS
502036
EUCAIMLG
502037

Undercounter Dishwashers
Medical Line Undercounter
Internet: http://www.electrolux.com/foodservice
IBF0102011-02-25Subject to change without notice
XR - Connection for detergent dispenser ● ● ●
HWI - Hot water inlet G 3/4" G 3/4" G 3/4"
EQ - Equipotential Screw ● ● ●
EI - Electrical connection 400 V, 3N, 50 400 V, 3N, 50 400 V, 3N, 50
D - Water drain 20.5mm 20.5mm 20.5mm
LEGEND
EUCAIML
502035
EUCAIMLWS
502036
EUCAIMLG
502037
502035, 502037, 502036
