Electrolux EUCAIWL User manual

Electrolux Dishwashing
Wine Line Undercounter
The Electrolux Dishwashing range is produced for customers with the highest conceivable demands for good
efficiency,economy and ergonomics for dishwashing operation. The product range comprises of glasswashers,
undercounter dishwashers, hood type dishwashers, rack type dishwashers, flight type dishwashers and pot
and pan washers. The wine-line undercounter dishwasher is equipped with drain pump, detergent dispenser
and has a capacity of 40 baskets per hour.
502040
SANITIZATION AND
PERFORMANCE
• The atmospheric boiler
combined with the rinse booster
pump, offers perfect rinsing
performances in terms of quality,
high water temperature and
pressure, always constant at 84°C
during rinsing cycles and
independent from the water
pressure of the network (with a
minimum of 0.5 bar).
• 4 second (variable) pause after
washing and before rinsing
ensures that no drops of unclean
water will fall on the clean items at
the end of the rinsing cycle.
• Three dishwashing programs:
1st cycle of 90 seconds for lightly
soiled items, 2nd cycle of 113
seconds for normally soiled items
and 3rd cycle of 173 seconds for
heavily soiled items.
• Fault auto-diagnosis system.
• Specifically designed to clean
and rinse delicate, high quality
long stem glasses at minimum
breakage thanks to the specific
washing and rinsing conditions:
washing temperature at 50-55°C
lower than standard temperature
of 55-65°C and longer rinsing time
in cycle 2 and cycle 3.
• Special basket able to fit all sorts
of long stem glasses, allowing
better washing and rinsing of the
internal surface and dramatically
increasing the average glass-life
time.
• Double skinned insulated wall
ensures a low noise level and a
reduction in heat loss from the
machine.
HYGIENE AND RELIABILITY
• All the machines have smooth
surfaces to facilitate cleaning.
• Large deep drawn wash tank
and internal wash area with round
corners and no pipes to avoid dirt
built-up.

Electrolux Dishwashing
Wine Line Undercounter
Internet: http://www.electrolux.com/foodservice
IBE0102011-02-25Subject to change without notice
Convertible to 230 V / 3 / 50 Hz;
230 V / 1+N / 50 Hz
Supply voltage 400 V, 3N, 50
Net weight - kg. 68
Noise level - dBA <65
total power 6.85
Rinse pump 0.26
drain pump 0.034
Power - kW
Boiler elements - kW 6
Boiler capacity - lt. 12
water consumption - lt./cycle 3.8
temperature during rinse - °C 84
duration - sec. 16
Hot rinse cycle
electrical elements - kW 2
power pump - kW 0.736
tank capacity - lt. 23
temperature -°C 50-55
Washing cycle
height 335
depth 500
width 500
Cell dimensions - mm
height 850
depth 612
width 600
External dimensions - mm
Basket capacity/h 40
Dishes capacity/h 720
Duration cycles - sec. 90/113/173
N° of cycles 3
Rinse aid dispenser ●
Detergent dispenser ●
Rinse Booster Pump ●
Drain pump ●
Thermometer ●
hardness - °f 7-14
temperature - °C 50
Water supply
TECHNICAL DATA
EUCAIWL
502040
• The fully automatic self-cleaning
cycle avoids the risk of bacteria
proliferation.
• The boiler drain facilitates the
evacuation of stagnant water after
long periods of inactivity to ensure
a higher level of hygiene.
• High efficiency air gap (class A)
in water inlet circuit to avoid water
being siphoned back into the
network as a result of a sudden
drop in main pressures.
• Front and side panels, door,
wash tank, tank filter and
wash/rinse arms made in heavy
duty anti-corrosive AISI 304
stainless steel to guarantee
appliance durability.
• 304L stainless steel atmospheric
boiler with higher welding
protection improves the resistance
against corrosion from chlorinated
water.
• PVC water supply hose with
metal connections resistant to
high water pressure.
• Completely closed on the
reverse by a cover plate while the
IPX4 water protection prevents
external infiltrations.
FLEXIBILITY AND ERGONOMICS
• The incorporated Soft Start
feature offers additional protection
to delicate items such as
glassware and crockery and
increases wash pump reliability.
• Simple control panel with digital
display allows on-site
personalization of washing and
rinsing cycle times and
temperatures as well as precise
rinse aid and detergent quantities
depending on the customers
needs.
• Three phase electrical
connection, convertible on-site.
• All machines are pre-arranged to
accept external dispensers.
• Counterbalanced door with
springs to lighten the load when
opening and closing.
• The wash tank filters can be
removed without extracting the
washing and rinsing arms.
• Pre-arrangement for HACCP
system implementation and
Energy Management device.
EASY ON THE ENVIRONMENT
• 98% recyclable by weight.
• CFC free packaging.
• In compliance with H
requirements.
• Low noise level.
• Developed and produced in ISO
9001 and ISO 14001 certified
factory.


* Duration cycles: declared actual cycle
duration times can extend when water
supply temperature is lower than
indicated.

Electrolux Dishwashing
Wine Line Undercounter
Internet: http://www.electrolux.com/foodservice
IBE0102011-02-25Subject to change without notice
YELLOW CUTLERY CONTAINER 864242
WIRE BASKET FOR 12 PLATES UP TO 320 MM 867014
STAND FOR UNDERCOUNTER DISHWASHER 860418
RINSE AID LEVEL PROBE KIT FOR UC+HT DW 864005
KIT TO MEASURE TOTAL/PART.WATER HARDNESS 864050
KIT HACCP EKIS 922166
KIT 4 PLASTIC BOXES FOR CUTLERY-YELLOW 865574
KIT 4 CASTORS F.DOUBLE SKINNED UNDERC.DW 864008
INTEGRATED HACCP KIT FOR UC, HT AND POTW 864001
HACCP PRINTER KIT FOR UC, HT AND POTW 864002
FILTER FOR TOTAL DEMINERALIZATION 864015
FILTER FOR PARTIAL DEMINERALIZATION 864017
EXT.REVERSE OSMOSIS FILT-ATMOSPH. BOILER 864026
DETERGENT LEVEL PROBE KIT FOR UC+HT DW 864004
COVER GRID FOR SMALL/LIGHT ITEMS IN RACK 867016
BRASS INLET VALVE KIT FOR UC AND HT 864000
BASKET SEMI-PROFESSIONAL 500X500X190MM 867024
BASKET FOR WINE GLASSES 500X500X246 867019
BASKET FOR 5 TRAYS 530X325MM-RED 867006
BASKET FOR 48 SMALL CUPS/24 CUPS-BLUE 867007
BASKET FOR 18 DINNER PLATES 240MM-YELLOW 867002
8 L EXTERNAL AUTOMATIC WATER SOFTENER 860413
304 AISI BACK PANEL FOR UC TOP LEVEL 864298
12 L EXTERNAL MANUAL WATER SOFTENER 860412
ACCESSORIES
BASKET FOR WINE GLASSES 500X500X246 1
BASKET FOR 48 SMALL CUPS/24 CUPS-BLUE 1
INCLUDED ACCESSORIES
EUCAIWL
502040

Electrolux Dishwashing
Wine Line Undercounter
Internet: http://www.electrolux.com/foodservice
IBE0102011-02-25Subject to change without notice
XR - Connection for detergent dispenser ●
HWI - Hot water inlet G 3/4"
EQ - Equipotential Screw ●
EI - Electrical connection 400 V, 3N, 50
D - Water drain 20.5mm
LEGEND
EUCAIWL
502040
