Electrolux EX401ISB User manual

Current as at Jul 2007.
© 2006 Electrolux Home Products Pty Ltd. EDIMDWEX401ISB
installation guide
electrolux E:Line built-in dishwasher
Model: EX401ISB
All measurements in millimetres.
Page 1 of 2
2mm
600mm
596mm
550mm
820mm - 900mm
min. 818mm max. 898mm
Drain hose supplied
240V switched power outlet
Inlet hose supplied
Cold water supply
Waste
Loop drain hose and locate
10mm beneath benchtop
Notes:
• Ensure that hoses are not crushed or
kinked under or behind the dishwasher.
• After connecting hose to the tap, turn
the tap on and check to ensure that
there are no leaks.
IMPORTANT
This is a guide of product dimensions only.
For complete installation instructions, refer
to the manual provided with product.
Note: Hole at bottom of spigot on sink drain
must be drilled out completely. Position of
spignot from base of dishwasher floor must
be 300mm minimum. Maximum height of
drain hose from floor must be 1000mm.
Notes:
• If the floor is not level, the levelling legs should be adjusted to fit
• The dishwasher must be fixed to the cabinets with the screws provided
• The entire plastic membrane from the sink trap to be removed before
fitting and securing the drain hose
• Cold water connection is recommended
• Water flow rate10L/minute min.
• Water temperature 65° max.
• Water pressure cold, 50-800kPa
• Water pressure hot, 50-800kPa
dishwasher dimensions and
pre-installation instructions
Note: Rear leg adjustment
via screw at front

Current as at Jul 2007.
© 2006 Electrolux Home Products Pty Ltd. EDIMDWEX401ISB
installation guide
electrolux E:Line built-in dishwasher
Model: EX401ISB
All measurements in millimetres.
Page 2 of 2
step 2step 1
Thickness:
16mm - 26mm
595mm
height of door
determined
by cabinet and
kickboard height
min. 2kg
max. 10kg
step 3
step 4 step 5
fitting door panel
Note: Refer to instructions and pattern
supplied with dishwasher for hole locations
and dimensions
Note: Ensure that there is clearance
between door panel and kickboard, reduce
height of kickboard if necessary.
Note: Ensure that
the dishwasher is
fixed to cabinet
IMPORTANT
This is a guide of product dimensions only.
For complete installation instructions, refer
to the manual provided with product.
