Electrolux FAVORIT 35090 i User manual

FAVORIT 35090 i
User manual Dishwasher

2
Dear Customer
Thank you for choosing one of our highquality products.
With this appliance you will experience the perfect combination of functional
design and cutting edge technology.
Convince yourself that our appliances are engineered to deliver the best per
formance and control  indeed we are setting the highest standards of excel
lence.
In addition to this you find environmental and energy saving aspects as an inte
gral part of our products.
To ensure optimal and regular performance of your appliance please read this
instruction manual carefully. It will enable you to navigate all processes perfect
ly and most efficiently.
To refer to this manual any time you need to, we recommend you to keep it in a
safe place. And please pass it to any future owner of the appliance.
We wish you much joy with your new appliance.
The following symbols are used in this user manual:
1
Important information concerning your personal safety and information on
how to avoid damaging the appliance.
3General information and tips
2Environmental information

3Contents
Contents
Operating Instructions 4
Safety 4
Diagram of appliance 5
Control panel 6
Prior to using for the first time 8
Setting the water softener 8
Adding special salt 10
Filling up with rinse aid 10
In daily use 13
Loading cutlery and dishes 13
Adding detergent 16
Using 3in1 detergents 17
Selecting the dishwashing cycle (Cycle Table) 18
Starting a dishwashing cycle 20
Setting the Delay Timer 21
Switching off the dishwasher 21
Care and cleaning 22
What to do if… 24
Remedying small malfunctions 24
If the dishwashing results are not satisfactory 26
Disposal 27
Technical data 27
Notes for Test Institutes 28
Installation and connection instructions 29
Safety information for the installation 29
Installing the dishwasher 29
Connecting the dishwasher 30
Guarantee/Customer Service 32
Service 35

Operating Instructions4
Operating Instructions
1Safety
Prior to using for the first time
•Follow the ”Instructions for installation and connection”.
Correct use
•The dishwasher is only intended for washing domestic dishes.
•Additions or modifications to the dishwasher are not permitted.
•Use only special salt, detergent and rinse aid suitable for domestic dishwash
ers.
•Do not put any solvents in the dishwasher. This could cause an explosion.
Child safety
•Keep packaging away from children. There is a risk of suffocation.
•Children often do not recognise the hazards associated with electrical appli
ances. Don’t allow children to use the dishwasher unsupervised.
•Make sure that children and pets don’t climb into the dishwasher. Could en
danger life!
•Dishwasher detergents can cause chemical burns to the eyes, mouth and
throat. Could endanger life! Comply with the safety instructions of the dish
washer detergent manufacturer.
•The water in the dishwasher is not for drinking. Risk of chemical burns.
General safety
•Repairs to the dishwasher are only to be carried out by qualified service engi
neers.
•When the dishwasher is not being used, switch it off and shut off the water
tap.
•Never unplug the appliance by pulling on the cable. Always pull the plug.
•Ensure that the door of the dishwasher is always closed when it is not being
loaded or unloaded. In this way you will avoid anybody tripping over the open
door and hurting themselves.
•Never sit or stand on the open door.
•If the dishwasher is located in a room where there may be a frost, remove the
connection hose from the tap after each use of the dishwasher.

5Diagram of appliance
Diagram of appliance
Upper basket spray arm
and floor spray arm
Water hardness
dial
Dispenser
for special salt
Dispenser
for detergent
Dispenser
for rinse aid
Rating plate
Filters

Control panel6
Control panel
The control knob is used to select the desired dishwashing cycle. In the Off po
sition the line points vertically upwards.
Start button
Control knob
Set delay timer
Programme progress display
Control indicators
Power indicator End of cycle indicator

7Control panel
The Start button is used to:
–start the dishwasher
–set the water softener
–cancel a dishwashing cycle.
Programme progress display: The current stage of the programme is always
shown in the programme progress display.
The control indicators have the following meanings:
1)
1) These control indicators are never illuminated while a dishwashing cycle is running.
Refill with special salt
1) Refill with rinse aid

Prior to using for the first time8
Prior to using for the first time
3If you wish to use 3 in 1 detergent:
– First read the section “Using 3in1 detergents”.
– Do not fill up with special salt or rinse aid.
If you do not use 3in1 detergent, before using for the first time
1. Set the water softener
2. Fill up with special salt for water softeners
3. Fill up with rinse aid
Setting the water softener
The water softener must be set manually and electronically:
3To avoid scale deposits on the dishes and in the dishwasher, the dishes must be
washed with soft water, i.e. water with a low lime content. The water softener
must be set according to the table to the water hardness in the area where you
live. Your local water company will be able to give you information about the
water hardness in your area.
The dishwasher must be switched off.
Setting manually:
1. Open the dishwasher door.
2. Remove the lower basket from the
dishwasher.
3. Turn water hardness dial on the left wall of
the dishwasher interior to 1 or 2 (see table).
Setting electronically:
4. Press and hold Start button.
5. Turn control knob clockwise as far as the first
programme.
6. Then release Start button.
–The indicator for the Start button will flash.
–The number of times that the indicator for the end of the dishwashing cycle
flashes corresponds to the hardness setting.
–This sequence of flashes is repeated several times, with a 3 second pause in
between.
7. Pressing the Start button increases the hardness setting by 1.
(Exception: hardness setting 1 follows hardness setting 10).

9Prior to using for the first time
8. If the hardness setting is correctly set, turn control knob to the Off position.
The hardness setting is now saved.
If the water softener is set electronically to “1”, this switches off the control in
dicator for special salt.
Water hardness Adjusting the hardness setting Number of
flashes
in °d1)
1) (°d) German degree, measure of the hardness of water
in mmol/l2)
2) [mmol/l] millimol per litre, international unit for water hardness
Range Manual Electronic
51  70
43  50
37  42
29  36
23  28
9,0  12,5
7,6  8,9
6,5  7,5
5,1  6,4
4,0  5,0
IV
2*
103)
9
8
7
6
3) On this setting the length of the dishwashing cycle may be slightly longer.
*) factory setting
10
9
8
7
6
19  22
15  18
3,3  3,9
2,6  3,2 III 5* 4
5
4
1
11  14 1,9  2,5 II 3 3
4  10 0,7  1,8 I/II 2 2
below 4 below 0.7 I
1
no salt
necessary
1

Prior to using for the first time10
Adding special salt
To decalcify the water softener, it must be filled up with special salt. Use only
special salt suitable for domestic dishwashers.
If you do not use 3 in1 detergent, fill up with special salt:
–Before using the dishwasher for the first time.
–When the control indicator for special salt is illuminated on the control panel.
1. Open the door and remove the lower
basket.
2. Screw open the lid on the salt dispenser by
turning it anticlockwise.
3. Only when using the dishwasher for the
first time:
Fill the salt dispenser with water.
4. Place the funnel (supplied) over the dis
penser opening.
Fill the dispenser with special salt; the ca
pacity of the dispenser is approx. 1.01.5
kg, depending on the size of the grains. Do
not overfill the dispenser.
3If water overflows when filling up with special salt, this is completely harmless.
5. Clean away any salt remnants from the dispenser opening.
6. Screw the lid back on in a clockwise direction.
7. Run a dishwashing cycle after filling the salt dispenser with special salt.
This will wash away salt water and salt crystals that have been spilt.
3Depending on the size of the salt grains, it can take several hours for the salt to
dissolve in the water and for the control indicator for special salt to go out.
Filling up with rinse aid
With rinse aid the rinsing water drains away better and so you get smearfree,
gleaming dishes and clear glasses.
If you do not use 3in1 detergent, fill up with rinse aid:
–Before using the dishwasher for the first time.
–When the control indicator for rinse aid is illuminated on the control panel.

11Prior to using for the first time
Use only special rinse aid for dishwashers
and no other liquid detergents.
1. Open the door.
The rinse aid compartment is located on
the inside of the dishwasher door.
2. Press the release button on the rinse aid
compartment.
3. Open the cover.
4. Pour rinse aid in slowly right up to the bro
ken “max” line;
this corresponds to a volume of approx.
140 ml when full.
5. Press the lid shut until it clicks into place.
6. Wipe up any spilt rinse aid with a cloth.
Otherwise there will be too much foam
when rinsing.

Prior to using for the first time12
Setting the amount of rinse aid required
3Only change the amount dispensed, if smears, milky spots (reduce the amount)
or dried on water spots (increase the amount) can be seen on glasses and dishes.
(See section “If dishwashing results are not satisfactory”.) The dosage can be set
from 16. The dosage is preset to “4” in the factory.
1. Open the dishwasher door.
2. Press the release button on the rinse aid
compartment.
3. Open the cover.
4. Set the dosage level.
5. Press the lid shut until it clicks into place.
6. If rinse aid has leaked out, wipe it away
with a cloth.

13In daily use
In daily use
Loading cutlery and dishes
1Sponges, cleaning cloths and any other objects that can absorb water must not
be washed in the dishwasher. Plastic and Tefloncoated dishes and pans tend to
retain water droplets. These dishes and pans therefore do not dry as well as
those made of china and stainless steel.
•Before loading the dishes, you should:
–Remove the worst of the food residues.
–Soak pans with burnton food residues.
•When loading the dishes and cutlery, please note:
–Dishes and cutlery must not impede the rotation of the spray arms.
–Load bowls, cups, glasses, pans, etc. with the opening downwards so that
water cannot collect in them
–Dishes and items of cutlery must not lie inside one another or cover one an
other
–To avoid damage to glasses, they must not touch one another
–Don’t put small items (e.g. lids) in the baskets for the dishes, but in the cut
lery basket, so that they can’t fall through the holes.
For washing in the dishwasher, the following cutlery/dishes/pots and pans
are not suitable: are of limited suitability:
•Cutlery with wooden, horn, china or
mother of pearl handles
•Plastic items that are not heat re
sistant
•Older cutlery with cement
that is sensitive to temperature
•Dishes or cutlery with glued parts
•Pewter or copper items
•Lead crystal glass
•Steel items that rust
•Wooden boards/platters
•Items made from synthetic materials
•Only wash stoneware in the dishwasher if it is spe
cifically marked by the manufacturer as being dish
washersafe.
•Glazed patterns may fade if washed very frequently
in the dishwasher.
•Silver and aluminium parts have a tendency to dis
colour during washing. Food remains, e.g. egg white,
egg yolk and mustard often cause discoloration and
staining on silver. Therefore always clean food resi
dues from silver immediately, if it is not to be
washed straight after use.
•Glass can become dull after a large number of wash
es.

In daily use14
Loading cutlery
1Warning: Sharp knives and other items of cutlery with sharp edges must be laid
in the cutlery rack or in the upper basket to avoid the risk of injury.
To ensure that all items of cutlery in the cutlery basket can be reached by the
water, you should:
For larger utensils, such as whisks, leave off one half of the cutlery grid.
Pots, Pans, Large Plates
Load larger and heavily soiled dishes and
pans in the lower basket.
(Max. diameter for plates 29 cm).
1.Place the grid insert on the cutlery
basket
2.Place forks and spoons in the cutlery
basket's grid insert with their han
dles pointing downwards.

15In daily use
To make it easier to load larger dishes, the
two plate rests on the right in the lower
basket can be folded down.
Cups, Glasses, Coffee Service
Load smaller, fragile crockery and long,
sharp cutlery in the upper basket.
•Arrange items of crockery on and under
the folding cup racks so that they are
offset from each other and water can
reach all items.
•The cup racks can be folded up out of the
way for tall crockery items.
•Lay or hang wine and brandy glasses in
the slots in the cup racks.

In daily use16
Adding detergent
Detergents remove the dirt from dishes and
cutlery.
The detergent must be added before the
cycle starts.
1Only use detergent intended for domestic
dishwashers.
The detergent compartment is located on
the inside of the door.
1. If the lid is closed:
Press the release button.
The lid will spring open.
2. Place the detergent in the detergent dis
penser. The markings indicate the dosing
levels for powder detergents: “20/30” cor
responds to approx.
20/30 ml of detergent.
Follow the manufacturer’s instructions
with regard to dosing and storage.
3. Close the lid and press until it locks into
place.
3In the case of very heavily soiled dishes, fill
the adjoining compartment (1) with addi
tional detergent. This detergent comes into
use during the prewash cycle.
Concentrated detergents
Today’s detergents for dishwashers are almost exclusively lowalkaline concen
trated detergents with natural enzymes in tablet or powder form.
2Using 50°C dishwashing cycles in conjunction with these concentrated deter
gents reduces pollution and is good for your dishes, as these dishwashing cycles
are specially matched to the dirtdissolving properties of the enzymes in con
centrated detergents. It is for this reason that using 50 °C dishwashing cycles in
conjunction with concentrated detergents can achieve the same cleaning results
that can otherwise only be achieved using 65 °C cycles.

17In daily use
Detergent tablets
3Detergent tablets from different manufacturers dissolve at different rates. For
this reason, some detergent tablets do not attain their full cleaning power dur
ing short cycles. Therefore please use dishwashing cycles with prewash when
using detergent tablets.
Using 3in1 detergents
These products are detergents with a combined cleaning, rinsing and salt func
tion.
If you want to use 3in1 products
1. There is no need to fill up with special salt or rinse aid.
2. Set the water softener to water hardness range “I”.
3. Set the rinse aid dosage to “1”.
Before the start of the dishwashing cycle put 3in1 detergent in the detergent
dispenser.
If you do not want to use 3in1 products any more
If you want to stop using 3in1 products, please do the following:
•Fill up the dispensers for salt and rinse aid again.
•Switch the water softener to the highest setting and perform up to three nor
mal cycles without loading any dishes.
•Then set the water softener to the water hardness in your area.
If you want to use 4in1 products
When using "4 in 1" detergents that integrate also anti glass corrosion agent
into "3 in 1" formula, please follow the same indication as given for "3 in 1" de
tergents.

In daily use18
Selecting the dishwashing cycle (Cycle Table)
Dishwashing
cycle
Suitable
for:
Type of
soiling
Programme
sequence
Consumption
values1)
1) The consumption values were obtained under standardised conditions. They depend on how full the bas
kets for the dishes are. Variations are therefore possible in practice.
Prewash Main wash Intermediate rinse Final rinse Drying Length (minutes) Energy (kWh) Water (litres)
INTENSIV
CARE 70°2)
2) During the final rinse, the temperature is increased to 68° for 10 minutes to sanitize e.g. babies’ bottles,
plastic chopping boards or jam jars.
Dinner service and
cookware
heavily soiled,
driedon food remains,
in particular protein
and starch
••
2x
••
120  130
1,80  2,00
23  25
30 MIN
(60°)3)
3) When using this cycle, only load the dishwasher half full.
Dishes, excluding
saucepans
just used, lightly to nor
mally soiled  • •
30
0,8
9
NORMAL 65° Dinner service and
cookware
normally soiled
driedon food remains •••••
100  110
1,20  1,40
17  19
ECO 50°4)
4) Test programme for Test Institutes
Dinner service and
cookware, tempera
turesensitive
crockery
normally soiled •••••
130  160
0,95  1,05
16  18
(cold)5)
5) This cycle does not need any detergent.
All types of dishes
Used dishes that are be
ing stored in the dish
washer and are to be
washed later.
•
12
< 0,1
4

19In daily use
Selecting a programme
When your dishes look like this, select:
an intensive programme.
a normal or energysaving programme.
a short programme (e.g. 30 minute pro
gramme).

In daily use20
Starting a dishwashing cycle
1. Check that the spray arms can turn freely.
2. Turn the water tap on fully.
3. Close the door.
4. Select the desired cycle.
The programme progress indicators flash.
5. Press Start button.
The dishwashing cycle starts.
Interrupting or aborting a dishwashing cycle
Only interrupt a dishwashing cycle that is in progress if it is absolutely necessary.
Interrupting the dishwashing programme by opening the dishwasher door
1Hot steam may escape when the door is opened. There is a risk of scalding.
1. Open the door carefully. The dishwashing cycle will stop.
2. Close the door. The cycle will continue.
Cancelling the dishwashing cycle
1. Press and hold Start button, until the programme progress indicators flash.
2. Release Start button.
3. Turn control knob to Off position.
The dishwashing cycle has been cancelled.
If you want to start a new dishwashing cycle, check whether there is any deter
gent in the dispenser.
3If you simply turn the control knob to the Off position, a selected dishwashing
cycle is only interrupted, not cancelled. The cycle will recommence when the
dishwasher is turned back on again.
