Electrolux Granul-line WTGL04 User manual

Granul-line Pot washers
Granul line ING 16-05-2006 12:49 Pagina 1

electrolux granul-line2
WTGL08
Granul-line
The Granul-line offers the maximum possible performance for utensil
washing: a combined washing action of granules, detergent and water
ensure that even the dirtiest utensils wash-up perfectly. Whether pots,
pans or gastronorm containers are washed, the result is always the
same, truly amazing.
WTGL05 WTGL04
Granul line ING 16-05-2006 12:49 Pagina 2

electrolux granul-line 3
No more back braking scrubbing for kitchen staff because
only the light scraping away of bulky food is required.
Granul-line does the rest.
This either leaves the workers staff free to perform other
tasks or even reduces the number of workers in the
pot washing area.
Water and detergent consumption is also minimised and
hygienic results are guaranteed.
The granule
The heart of the system is the granule. It is made from
a special plastic, approved even by the FDA, and not
hazardous if accidentally swallowed. It is very resistant
against acids and alkaline chemicals as well as elevated
temperatures up to 150°C. It is harmless to sewage
systems and degrades with water and carbon dioxide.
How do they work?
Granules are mixed together with water and detergent, pumped
at high pressure against the pots and pans. The granules provide enough
friction to remove even hard water baked on food. Once the granule cycle
is finished, the Granul-line continues washing for 1 minute with just water
to remove any granules that may have become attached to a pan.
A final rinse of 85OC for 30 seconds provides the necessary hygiene to
finish the job.
Granul line ING 16-05-2006 12:49 Pagina 3

electrolux granul-line4
WTGL04 includes a condensing unit,
therefore no ventilation hood is
required above the machine in order to
vent the steam. The rinse is provided by
an atmospheric boiler with a rinse
booster pump to guarantee both a
constant pressure and rinse
temperature.
Capacity of 4 GN 1/1(200mm deep)
or 8 GN 1/2 (200mm deep)
containers with a washing result of
65 GN 1/1 containers per hour.
WTGL04 incorporates a fixed capacity pot rack perfect for medium sized
kitchen installations up to 500 meals per day. Compact design, occupying
only 5m2area.
Granul line ING 16-05-2006 12:49 Pagina 4

electrolux granul-line 5
Accessories
Flexible insert for kitchens
needing to wash a mix of
pans, (saucepans, pots,
basins etc). Combined with
other accessories, it allows
an even more varied
collection utensils to be
washed.
Insert that allows the
washing of Gastronorm
containers from
GN 1/9 to GN 1/1.
Insert which allows GN
containers of all sizes to be
washed, from small 1/9 to
large 2/1 as well as
medium to large size pots.
The middle divider can
easily be moved to the right
for washing various sorts
of utensils.
Insert for washing lids and
trays. Can also be used for
smaller trays and other
flat utensils.
Granul line ING 16-05-2006 12:49 Pagina 5

6 electrolux granul-line
Fixed rack version occupies only 5m2.
The roll-in rack version allows a greater
capacity because while one rack is
washing, another one can be prepared.
The cassette is designed to accept
mixed items in one wash cycle.
Spray pipes can easily be removed
without the use of tools.
Pre-arranged for detergent and rinse aid
dosing equipment.
WTGL08 incorporates a condensing unit
that means no ventilation hood is
required above the machine to vent
steam. The rinse is provided by an
atmospheric boiler with rinse booster
pump to guarantee both a constant
pressure and rinse temperature.
The fixed rack version is able to wash
115 GN 1/1 containers per hour.
The performances of the roll-in versions
are: 122 GN 1/1 containers for the single
rack and 144 GN 1/1 containers per
hour for double roll-in.
The largest Granul-line model having an 8 gastronorm container capacity,
ideal for large kitchens up to 2000 meals per day in the fixed rack version
or 3000 meals per day in the roll-in version.
Granul line ING 16-05-2006 12:49 Pagina 6

7electrolux granul-line
Multirack capacity 8 GN 1/1
for pots, pans, bowls,
dough hooks and all types
of 1/1 and 2/1 Gastronorm
containers stacked directly
in the lower part of the rack
without accessories.
Inserts for lids, trays and
similar utensils. It is best
placed in the lower runners
of the cassettes.
Utensil holder for ladles,
whisks and similar items.
It is placed in one of the
upper runners in the rack.
Cassette trolley for the
simple and ergonomic
handling of cassettes.
Accessories
Roll-in double rack version:
increased loading/unloading
efficiency allows a washing
capacity of 144 GN 1/1
containers per hour.
Granul line ING 16-05-2006 12:49 Pagina 7

electrolux granul-line8
Hood lifting is fully automatic.
The rinse is provided by an atmospheric
boiler with rinse booster pump that
guarantees both a constant pressure
and rinse temperature.
Capacity of 5 GN 1/1 (100mm deep)
containers equivalent to 112 GN 1/1
containers per hour.
WTGL05 incorporates a condensing unit.
WTGL05 is a hood-type pass-through model ideally suited to restaurants
where a large number of pots are used suitable for 800 meals per day
establishments. Compact design, requiring light pre-scraping and exit
table, occupying only 5m2area.
Granul line ING 16-05-2006 12:49 Pagina 8

electrolux granul-line 9
Holder for pots,
saucepans, basins or
smaller preparation
containers.
Ladles, beaters, spatulas
and similar utensils can be
washed in the wire basket in
the middle of the holder.
Flexible pot holder for larger
pots and pans. Stretch the
rubber bands around
the items to keep them
from moving during
the wash cycle.
Standard included wash
basket for kitchens using
GN containers. Capacity is
5 GN 1/1, max depth
200mm. The basket can
also be used for ABC
containers.
Accessory for washing lids.
Capacity 5 lids/basket.
Can also be used for
smaller trays and flat items.
Accessories
Granul line ING 16-05-2006 12:49 Pagina 9

Granul line ING 16-05-2006 12:49 Pagina 10

electrolux granul-line 11
Technical data WTGL04 WTGL08 WTGL05
Type Fixed Rack Fixed Rack Roll-in single Rack Roll-in double Rack Pass-through
Meals/day 500 2000 3000 4000 800
Capacity (GN 1/1)* GN 1/1 4 8 5
GN 1/1 per hour 51 115 122 144 112
External dimensions
width mm 845 1452 850
depth mm 965 1106 980
height mm 1745 2029 1730
Loading Hole
width mm 790 1290 760
depth mm 600 850 800
height mm 920 1300 720
Cycles
No of cycles 3 3 3
Duration of cycles 3 mins 40 secs 2 mins 40 secs 2 mins 10 secs
5 mins 40 secs 4 mins 40 secs 4 mins 10 secs
7 mins 40 secs 7 mins 40 secs 6 mins 10 secs
Washing
Tank capacity l 84 165 83
Tank elements kW 9 16 3
Pump power kW 3 4,4 2,6
Rinsing
Boiler capacity l 13 14 11
Boiler elements kW 9 16 9
Water consumption/cycle l/cycle 8 14 8
Total Power kW 12,5 21 14,8
Voltage 400V 3 50Hz 400V 3 50Hz (no neutral) 400V 3 50Hz
(no neutral) (no neutral)
Steam versions available as special execution.
*Max capacity including handling GN 1/1 up to 200mm depth
Granul line ING 16-05-2006 12:49 Pagina 11

www.electrolux.com/foodservice
9JEB6U The Company reserves the right to change specifications without notice.
