Electrolux EID200QSW00 Operating manual

Publication # May 2016
Technical Service Manual
Urban Living Dryer-EID200QSW00

2

3
Table of Contents
1. Purpose of this Manual.........................................................................4
2. Safety Information...................................................................................5
3. Warnings.......................................................................................................8
4. Product Features......................................................................................9
5. Model Specifications............................................................................10
6. Tools and Equipments.........................................................................12
7. Electrical Characteristics....................................................................13
7.1 Main Control.....................................................................................13
7.1.1 User Interface (UI) Board......................................................13
7.1.2 Main Control Board................................................................14
7.2 Schematic Diagram of Controls and
Wiring Connectors.......................................................................15
7.2.1 Schematic Diagram of Main Control Board.................15
7.2.2 Schematic Diagram of User Interface Board..............15
7.3 Wiring Diagram.............................................................................16
8. Electrical Components.........................................................................17
8.1 Electrical Component’s Resistance and
Specification Table........................................................................17
9. Serviceabie Components Accessibility.......................................18
9.1 Control Panel...................................................................................18
9.2 Anti-Interfer Filter........................................................................20
9.3 Drum Vanes....................................................................................20
9.4 Main Control Board....................................................................21
9.5 Temperature Probe (NTC)......................................................24
9.6 Motor Assembly............................................................................25
9.6.1 Motor and Fan Wheels..........................................................26
9.7 Heater Assembly..........................................................................27
9.8 Pump ................................................................................................29
9.9 Fluff Filter...........................................................................................31
9.10 Condensor Assembly.................................................................31
9.11 Humidity Sensor ........................................................................33
9.12 Door Latch....................................................................................34
9.13 Door Lamp....................................................................................35
9.14 Door Switch .................................................................................37
9.15 Belt...................................................................................................38
9.16 Leveling Leg................................................................................39
10. Diagnostic System..............................................................................40
10.1 Enter Diagnostic Mode...........................................................40
10.2 Scroll Through the Tests.........................................................40
10.3 Clearing Error Codes.............................................................41
10.5Factory Default Reset.............................................................41
10.6Demo Mode.................................................................................41
10.7Enter Demo Mode.....................................................................42
10.8Clear Demo Mode......................................................................42
10.9Error Codes..................................................................................42
11. Troubleshooting Operations for Error Codes......................44
0X21: Condense Pump Error...........................................................44
0X22: Condense Pump Sensing Error.........................................45
0X31: Conductimetric Sensor Frequency Too High...............45
0X32: Conductimetric Sensor Frequency Too Low................45
0X45: Door Closed Sensing Error.................................................46
0X55: FCV Safety Error.....................................................................46
0X56: FCV Motor Plug Not Connected..................................... 47
0X57: FCV Current Trip Failure....................................................... 47
0X58: FCV Over Current Failure.................................................... 47
0X5A: FCV Board Overheating..................................................... 47
0X59: FCV Motor Not Following...................................................48
0X5B: FCV Under Voltage Failure ................................................49
0X5C: FCV Over Voltage Failure ..................................................49
0X5D: FCV Unknown Message Error..........................................49
0X5F: FCV Power Module Error.....................................................49
0X62: Heater Short Circuit Error....................................................50
0X63: Heater Error..............................................................................50
0X64: Heater Sensing Error ............................................................50
0X71: Drying NTC Error......................................................................51
0X72: Heater NTC Error....................................................................52
0X73: Steamer NTC Error.................................................................53
0X83: Selector Position Code Error.............................................54
0X86: Selector Configuration Table Error .................................54
0X87: UI Board Microcontroller Self Test Failure....................54
0X91: User Interface Communication Error..............................54
0X92: User Interface Protocol Incongruence Error..............55
0X93: Machine Configuration Checksum Error ......................55
0X94: Cycle Configuration Checksum Error.............................55
0X97: Missing Program on CTF Error .........................................55
0X9C: User Interface Configuration Checksum Error ..........55
0X9E: User Interface Touch Sensor Not Working ..................55
0XB1: Power Supply Frequency Out of Range........................56
0XB2: Power Supply Amplitude Out of Range........................56
0XB3: Power Supply Amplitude Out of Range .......................56
0XB4: Zero Watt Relay Error...........................................................56
0XBD: Line Safe Short Circuit Error.............................................. 57
0XBE: Line Safe Error......................................................................... 57
0XBF: Line Safe Sensing Error ....................................................... 57
0xF6: Safety Reset Error................................................................... 57
10.4Exit From Diagnostic Mode.................................................41

4
1. Purpose of this Manual
The purpose of this Manual is to provide information regarding repair procedures of Dryer fitted with the Electro-
Mechanical Control System. This Manual is intended for the use of Service Engineers of Electrolux.
The Manual includes the following topics:
• Safety Information, Warnings, Product Features, Model Specifications, Tools and Equipments
• Electrical Characteristics, Specifications and Serviceable Components
• Accessibility of the Electro-Mechanical Components
• Diagnostics System
• Troubleshooting and Error codes

5
Read the entire Manual before attempting to service this product. Pay attention to all Warnings, Cautions, Notes
and Important Information. Failure to do so could result in serious personal injury and / or equipment damage.
DEFINITIONS
WARNING
Indicates a hazardous situation which, if not avoided, could result in serious injury or death.
CAUTION
Used with the safety alert symbol, indicates a hazardous situation which, if not avoided, could result in
minor or moderate injury.
NOTE
Used to address practices not related to personal injury.
IMPORTANT
Information that requires special attention from the user.
2. Safety Information

6
208-240 V Electric Dryer
UL-Approved Service Cord must be
installed on Electric Dryers (not provided
with unit except those manufactured
for sale in Canada).
14-30 R
4-Wire
(Fused 30 Amp)(Fused 30 Amp)
10-30 R
3-Wire
Avoid Fire Hazard or Electrical Shock. Do not use an Adapter Plug or Extension Cord or remove Grounding
Prong from the Electrical Power Cord. Failure to follow this warning can cause serious injury, fire, and death.
WARNING
Risk of Fire
To reduce the risk of fire, electrical shock, or injury to persons when using this Dryer, comply with basic
warnings listed below. Failure to comply with these warnings could result in serious personal injuries. You
could be killed or seriously injured if you do not follow these Important Safety Instructions.
Prevent Fire
• Do not dry items that have been previously cleaned in, soaked in, or spotted with gasoline, cleaning
solvents, kerosene, waxes, and so on. Do not store these items on or near the Dryer. These substances give
off vapors that could ignite or explode.
• Do not place items exposed to cooking oils in your Dryer. Items contaminated with cooking oils may
contribute to a chemical reaction that could cause a load to catch fire.
• Do not dry articles containing rubber, plastic or similar materials such as brass, galoshes, bath mats, rugs,
bibs, baby pants, plastic bags and pillows that may melt or burn. Some rubber materials, when heated,
under certain circumstances, could produce fire by spontaneous combustion.
• Do not use heat to dry items containing feathers or down, foam rubber, plastics similarly textured, rubber-
like materials.
• Clean the Lint Screen before or after each load. The interior of the Dryer and Lint Screen housing should be
cleaned approximately every 18 months by a Qualified Service Engineer. An excessive amount of lint build-
up in these areas could result in inefficient drying and possible fire. See Care and Cleaning Guide.
• Do not operate the Dryer if the Lint Screen is blocked, damaged or missing. Fire hazard, overheating and
damage to fabrics can occur.
• Do not obstruct the flow of ventilating air. Do not stack or place laundry or throw rugs against the front or
rear of the Dryer.
• Do not spray any type of aerosol into, on or near Dryer at any time.
• Do not use fabric softeners or products to eliminate static unless recommended by the manufacturer of the
fabric softener or product.
• Do not continue to use the Dryer if you hear squeaking, grinding, rubbing or other unusual noises. This could
be a sign of mechanical breakdown and lead to fire or serious injury. Contact a Qualified Service Engineer
immediately.
• Failure to comply with these warnings could result in fire, explosion, serious bodily injury and / or damage to
the rubber or plastic parts of the Dryer.
Safety Information

7
Protect Children
• Do not allow children to play on or in the Dryer.
Close supervision of children is necessary when
the Dryer is in use. As the children grow, teach
them the proper and safe way of using all the
Appliances.
• Dispose the carton and plastic bags after the
Dryer is unpacked. Children might use them for
playing. Cartons covered with rugs, bedspreads,
or plastic sheets can become air tight chambers
causing suffocation. Place all the materials in a
garbage container or keep the materials away
from children.
• Keep laundry products out of children’s reach. To
prevent personal injury, observe all warnings on
product labels.
• Before the Dryer is removed from service or
discarded, remove the Dryer Door to prevent
accidental entrapment.
• Failure to comply with these warnings could result
in serious personal injuries.
Prevent Injury
• To prevent shock hazard and assure stability
during operation, the Dryer must be installed
and electrically grounded by a Qualified Service
Engineer in accordance with local codes.
Installation instructions are packed in the Dryer
for the installer’s reference. Refer to Installation
Instructions Guide for detailed grounding
procedures. If the Dryer is moved to a new
location, have it checked and reinstalled by a
Qualified Service Engineer.
• Always disconnect the Dryer from the electrical
supply before attempting any service or cleaning.
Failure to do so can result in an electrical shock or
injury.
• Do not use any type of spray cleanser when
cleaning the Dryer from inside. Hazardous fumes
or electrical shock could occur.
• To prevent injury, do not reach into the Dryer if the
drum is moving. Wait until the Dryer has stopped
completely before reaching into the drum.
Prevent Injury and Damage to the Dryer
• All repairs and servicing must be performed by an
authorized Servicer Engineer unless specifically
Safety Information
recommended in the Owner’s Guide. Use only
authorized factory parts.
• Do not tamper with controls.
• Do not sit on, step on or stand on the Dryer. Do
not rest heavy loads on top. The Dryer is not
meant to support weight.
• Do not install or store the Dryer where it will be
exposed to the weather.
• Failure to comply with these warnings could result
in serious personal injuries.

8
3. Warnings
• Any work on Electrical Appliances must be carried out by qualified professional only.
• Confirm that the Power System is operational before working on the Appliance.
• Check that the Appliance is restored to its original safety condition after the operation is complete. Take the
plug out of the socket to disconnect the power supply before you access internal components. This platform
is not fitted with an ON / OFF switch.
• Replace the Heating Element with one that has the same characteristics to
maintain safety measures for the Appliance (See Fig. 1).
• Always empty the Appliance before laying it on its side for any servicing.
• Always wear gloves before servicing any components.
• The resistance values of the components shown in this Service Manual are
purely indicative and approximate.
• Warning Sensors located on the display board could be at a potential of 220
Volts (If applicable).
• Do not place any container under the Appliance to avoid collecting drops of
water.
Fig. 1: Heating Element
with Different Specification

9
4. Product Features
Reversible Door
Condenser Access
Door Latch
Lint Filter
Door Striker
Moisture Sensor
Door Latch
Condenser Access
Door
Adjustable Leveling Leg
Drum Light
LED Display
Control Lock
Water Container
Drying Rack*
* Not all models come with a drying rack and stacking kit from the factory. They may be purchased as
accessories.
Fig. 2: Product Features

10
5. Model Specifications
DESCRIPTION EIED200QSW00
Capacity D.O.E. 4.0 Cu. Ft.
Features
Pull-to-Open Door Yes
IQ-Touch™ Electronic Controls Yes
Dry System Condensing
LED Lighting Yes
Tumble System Reversing
Moisture Sensor Yes
Dryer Drum Stainless Steel
Reversible Door Yes
Adjustable Leveling Legs Yes
Cycles
Normal, Heavy Duty, Delicates, Casual, Mixed
Load,Touch Up, Towels 7 Dry
Jeans, Fast Dry, Wool, Timed Dry 4 Specialty
Options
Temperature Selections 3
Electronic Auto Dry System Yes
Manual Timed Dry Selections 11
Delay Start Yes
End-of-Cycle Chime ON / OFF Yes
Wrinkle Release Yes
Dryness Levels 4
Installation Options
Freestanding, Under Counter , Stacked (Above
Washer), Pedestal, Recessed Alcove Yes
Accessories
Pedestal –White – PN # EPWD200QSW Optional
Dryer Stacking Kit – PN # STACKIT24 Optional
Direct Drain Kit Included
Drying Rack – (PN # 916093163) Optional

11
DESCRIPTION EIED200QSW00
Specifications
Color Silver White
Power Supply Connection Location Right Top Rear
Voltage Rating 208 / 240 V AC
Connected Load (KW Rating) @ 208 / 240 Volts 2800 W
Amps @ 208 / 240 Volts 16
Heating Element @ 208 / 240 Volts (Watts) 1,200
Shipping Weight (Approx.) 125 Lbs.
Product Dimensions
Height (without 12" Pedestal) (with 12” Pedestal
33-1/2”
46”
Width 24"
Depth (to Center of Arc Not Including Hose) (with
Door 90° Open)
24”
43”
Model Specifications

12
6. Tools and Equipments
Fig. 3: Tools and Equipments

13
7. Electrical Characteristics
7.1 Main Control
The Main Control is made up of the following components:
1. User Interface (UI) Board
2. Main Control Board
7.1.1 User Interface (UI) Board
The User Interface (UI) board contains the selector buttons to adjust temperature (high, normal, low and air dry)
and options (chime, wrinkle, release, and so on).
normal
My Favourites+
12 34 5
Temperature Start/Pause
mixed
load
touch up towels
specialty
cycles wrinkle
release
chime
on/off
delicates casuals dryness dry
time
delay
start
heavy
duty
Cycle count down/
delay start timer
normal
mixed
load
touch up towels specialty
cycles
delicates casuals dryness dry
time
wrinkle
release
chime
on/off
delay
start
heavy
duty
Chime
Indicator
Delay Start
My Favorites
My Favorites
+
Temperature Start/Pause
Maintenance
Indicators
Status Display Control Lock
Indicator
End of cycle
indicator Control Lock
key combination
1. Power Button 3. My Favorites Button 5. Temperature Button
2. Cycle Selection 4. Cycle Options / Cycle Status Display 6. Start / Pause Button
Fig. 4: User Interface Board Buttons and Options
Fig. 5: User Interface Board Buttons and Options

14
7.1.2 Main Control Board
The Main Control Board supplies the power supply voltage to the User Interface (UI) Board and all other
electrical components.
Fig. 6: User Interface (UI) Board
Electrical Characteristics
The Main Control Board performs the following actions:
1. It controls the temperature of exhaust air via the Temperature Probe Sensor.
2. It senses opening and closing of the Door.
3. It controls the speed of the Motor.
4. Its controls the Heater Assembly.
The commands received by the User Interface (by turning the selector, selecting an option, and so on) are sent
to the Electronic Control Board, which powers all the electrical components (such as Heater Assembly and the
User Interface (UI) Board).
Fig. 7: Main Control Board

15
7.2 Schematic Diagram of Controls and Wiring Connectors
J2 J5
J2 Connector
to Control Board’s
J16 Connector
(4 Blue wires)
J5 Connector
to Control Board’s
J6 Connector
(2 Blue wires)
Blue Blue Blue Blue
Blue
Blue
User Interface Board
Electrical Characteristics
J8
J11
J9
J16
J6
J13
JE1
J3
J4
J1
JE2 J2
White
White
White
J2 Connector
Motor
JE2 Connector
General Earth
(Yellow –Green Wire)
Grey
Grey
J1 Connector
Filter
Pink
Pink
J3 Connector
Heating Element
J4 Connector
Heating Element
J8 Connector
Condensation Pump
Blue
Blue
J8 Connector
NTC2
Blue Blue
J11 Connector
Drum Light
Black
Black
Black
Black
J11 Connector
Door Switch
Pink
J9 Connector
Temperature Probe
J9 Connector
Tank Sensing
Blue
Blue
Blue
Blue
J16 Connector
User Interface
Board
Anti-
Interfer
Anti-Interfer
Filter
Condensation
Pump
Door
Switch
Drum
LightNTC2 Heating
Element
Yellow- Green
Motor
User Interface
Board
Heating
Element
Temperature
Probe
J6 Connector
User Interface
Board
Blue
Blue
J13 Connector
Humidity Sensor
(2 White Wires)
(4 Blue Wires)
(4 Blue Wires)
(2 Blue Wires) (2 Blue Wires) (2 Grey Wires) (3 White Wires)
(2 Pink Wires)
(1 Pink Wire)
(2 Blue Wires)(2 Black Wires) (2 Black Wires) (2 Black Wires)
White
White
Humidity Sensor
JE1 Connector
General Earth
(Yellow –Green Wire)
Yellow-Green
Main Control Board
Black
Black
Blue Blue
7.2.1 Schematic Diagram of Main Control Board
7.2.2 Schematic Diagram of User Interface Board
Fig. 8: Schematic Diagram of Electronic Control Board
Fig. 9: Schematic Diagram of User Interface Board

16
7.3 Wiring Diagram
Electrical Characteristics
Fig. 10

17
8. Electrical Components
8.1 Electrical Component’s Resistance and Specification Table
S.NO. COMPONENT SPECIFICATION
1 Heating Element 208 V, 1428 W and 26.8 Ω at 20 °C
2 Thermistor Working Temperature–140 ± 5 ˚C
Reset Temperature–35 ± 5 ˚C
3Door Switch Maximum Ambient Temperature-85 ˚C
Rating–12 V DC / Min current-10 mA; Max current: 250 mA
4 Drum Light 150 mA–3.3 V
5 Motor 190 V 240 Hz RPM 3600
6 Temperature Probe
Temperature
[°C]
Rated
Resistance [Ω]
Maximum
Resistance [Ω]
Minimum
Resistance
[Ω]
NTC Sensor Thermistor Nominal Values
40 2563 2666 2460
60 1196 1222 1170
80 602.6 622.5 582.7
NTC Sensor Thermistor Measured Values
Dissipation
Factor 3 mW/K AIR
40 2817 2886 2748
60 1393 1419 1367
80 725 743 707
7 Pump 220-240 V AC, 15 W, 60 Hz 219 ± 10%, 3600 RPM
8Humidity Sensor -

18
9. Serviceable Components Accessibility
1
2
3
Fig. 15: Top View without
Top Panel
Fig. 11
Fig. 13
Fig. 12
Fig. 14
Fig. 16
Fig. 17
9.1 Control Panel
Steps to disassemble the Control Panel:
1. Start by gently sliding out the Water Tank (See
Fig. 11).
2. Remove the screw (See Fig. 12).
3. Remove 2 screws from the Rear Panel that hold
the Top Panel (See Fig. 13).
4. Slide out the Top Panel (See Fig. 14).
Following components can be accessed after
removing the Top Panel, (See Fig. 16):
• Control Panel (1)
• Anti-Interfer Filter (2)
• Drum Vanes (Inside the Drum) (3)
5. Remove the 3 screws that hold the Control Panel
in its Place as shown (See Fig. 17).

19
Serviceable Component Accessibility
Fig. 21: User Interface Board Assembly
Fig. 20
Fig. 19
Fig. 18
Fig. 22
6. Pull out the Control Panel using little force (See
Fig. 18).
7. Unplug the 2 connectors (See Fig. 19).
8. Release 6 snaps to take out the User Interface
Board Assembly from the Control Panel (See Fig. 20).
3. Start by aligning Control Panel at its screw
position (See Fig. 22).
Steps to assemble the Control Panel:
1. Align the User Interface Board in its position to
fix 6 snaps to hold the User Interface Board with the
Control Panel as illustrated (See Fig. 20).
2. Plug the 2 connectors (See Fig. 19).
4. Tighten the 3 screws that hold the Control Panel
with the unit (See Fig. 17).
5. Slide in the Top Panel to align it exactly at its
screw position as in the shown direction (See Fig. 23).
Fig. 24
Fig. 23
6. Tighten 2 screws of the Rear Panel (See Fig. 13).
7. Tighten the screw that hold the Top Panel in its
position (See Fig. 12).
8. Slide in the Water Tank (See Fig. 24).

20
Fig. 26Fig. 25
Fig. 27
Fig. 28 Fig. 29
Serviceable Component Accessibility
Fig . 30: Anti-Interfer Filter
9.2 Anti-Interfer Filter
Steps to disassemble the Anti-Interfer Filter:
1. For disassembling the Anti-Interfer Filter, remove
the Top Panel (Refer first 4 steps of Control Panel
Disassemble Procedure).
2. In order to take out the Anti-Interfer Filter, take out
the Terminal Block (See Fig. 26).
3. Remove the 3 screws to take out the Terminal
Block Box (See Fig. 25).
4. Remove the screw and then the nut inside the
Terminal Block Box Cover (See Fig. 27).
5. Unplug the connector and the terminal to take out
the Anti Interfer Filter (See Fig. 28 and Fig. 29).
Steps to assemble the Anti-Interfer Filter:
1. Insert Anti Interfer Filter in its position and plug
the connector and the connector terminal (See Fig. 28
and Fig. 29).
2. Tighten the nut and then screw in this order inside
the Terminal Block Box Cover (See Fig. 27).
3. Tighten the 3 screws that hold the terminal block
box (See Fig. 25).
4. Reassemble the Top Panel (Refer last 4 steps of
Control Panel Assemble Procedure).
9.3 Drum Vanes
Steps to disassemble the Drum Vanes:
1. For disassembling the Drum Vanes, remove
the Top Panel (Refer first 4 steps of Control Panel
Disassemble Procedure).
