Electrolux T4900CR User manual

Operating manual
Tumble dryers
T4900CR, T41200CR
Type N4...
Compass Control
438 9214-21/EN
2020.01.14
Original instructions

3
Contents
Safety instructions ....................................................................................... 5
General......................................................................................................... 7
Control panel........................................................................................... 7
Control knob............................................................................................ 7
Display..................................................................................................... 8
Drying program ............................................................................................ 9
Drying functions ......................................................................................... 10
Start....................................................................................................... 10
Stop....................................................................................................... 10
Changing drying program after starting ................................................ 10
Handling..................................................................................................... 11
Starting with control knob ..................................................................... 11
Error codes................................................................................................. 13
Maintenance............................................................................................... 15
Contents
The manufacturer reserves the right to make changes to design and
component specifications.

4Safety Precautions
This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved
Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children
without supervision.
Children of less than 3 years should be kept away unless
continuously supervised.
The machine is not to be used if industrial chemicals have
been used for cleaning.
Do not dry unwashed items in the machine.
Items that have been soiled with substances such as cooking
oil, acetone, alcohol, petrol, kerosene, spot removers,
turpentine, waxes and wax removers should be washed in hot
water with an extra amount of detergent before being dried in
the machine.
Items such as foam rubber (latex foam), shower caps,
waterproof textiles, rubber backed articles and clothes or
pillows fitted with foam rubber pads should not be dried in the
machine.
Fabric softeners or similar products should be used as
specified by the fabric softener instructions.
The final part of a drying cycle occurs without heat (cool down
cycle) to ensure that the items are left at a temperature that
ensures that the items will not be damaged.
Remove all objects from pockets such as lighters and
matches.

5
Safety Precautions
WARNING. Never stop the machine before the end of the
drying cycle unless all items are quickly removed and spread
out so that the heat is dissipated.
Adequate ventilation has to be provided to avoid the back
flow of gases into the room for appliances burning other fuels,
including open fires.
Exhaust air must not be discharged into a flue which is used
for exhausting fumes from appliances burning gas or other
fuels.
The machine must not be installed behind a lockable door, a
sliding door or a door with a hinge on the opposite side to that
of the machine in such a way that a full opening of the machine
is restricted.
If the machine has a lint trap this has to be cleaned frequently.
The lint must not be accumulated around the machine.
DO NOT MODIFY THIS APPLIANCE.
Servicing shall be carried out only by authorized personnel.
Only authorized spare parts shall be used.
When performing service or replacing parts, the power must
be disconnected.
In accordance with the wiring rules: mount a multi-pole switch
prior to the machine to facilitate installation and service
operations.

6Safety Precautions
Gas heated tumble dryer:
Before installation, check that the local distribution conditions,
nature of gas and pressure and the adjustment of the
appliance are compatible.
The machine is not to be installed in rooms containing cleaning
machines with perchloroethylene, TRICHLOROETHYLENE or
CHLOROFLUOROCONTAINING HYDROCARBONS as cleaning
agents.
CAUTION: This appliance shall not be installed where the
public has access.
If you can smell gas:
• Do not switch on any equipment
• Do not use electrical switches
• Do not use telephones in the building
• Evacuate the room, building or area
• Contact the person responsible for the machine
In order to prevent damage to the electronics (and other parts) that may occur as
the result of condensation, the machine should be placed in room temperature for 24
hours before being used for the first time.
CAUTION
Caution
Read the instructions before using the machine
Symbols
Caution, hot surface

7
3
1
2
General
2
3
1
General
Control Panel
The control panel is used to choose the drying program with options and
to start and stop the machine. The panel houses a control knob and a display.
Control knob
The control knob is used to select drying
program and any other available functions.
Turn the knob until the required program is
shown on the display.
Confirm your choice by pushing in the knob.
Repeat this procedure until all the required
functions have been chosen.
Display Control knob

8
4
General
4
EXTRA DRY
DRY
Display
The display presents the drying programs and
additional functions. The up and down arrows on
the right-hand side of the display indicate that
there are more options available in the current
menu. Turn the knob for next program.
Note!
If there is not enough room to show all the
text on the display, the first part will be dis-
played briefly before the text scrolls to the
side to display the second part. This sequen-
ce will be repeated as long the text in ques-
tion is activated.

9
1
2
3
General
2
1
3
EXTRA DRY
DRY
DRY
15 MINUTES
15 MINUTES
30 MINUTES
Drying Program
The machine is programmed with a number of
programs adapted to the range of uses to which
the machine is intended.
The following drying programs can be available:
Drying program EXTRA DRY.
Drying program DRY.
Time program X MINUTES. Duration depends on
the selected time, up to 90 minutes.

10 General
1
2
2
1
EXTRA DRY
HIGH TEMP
START
CHANGE TEMPERATURE
Drying Functions
START
Turn the control knob to the START row. Press
the knob to start the selected program.
STOP
Press the control knob to stop the program.
Restart the drying program by pressing the
control knob again.
Changing drying program after starting
Press the control knob to stop the program. Turn
the control knob to the new program and press.
