Electrolux 253.28712809 Manual

P08F0137.eps P08D0624.eps P08C1202.eps R08S0525.wmf
REPAIR
PARTS
LIST
253.28712809
For Parts or Service:
Call
1-800-4-MY-HOME®
(1-800-469-4663)
Or Visit
www.sears.com
UPRIGHT FREEZER
In all orders or correspondence, avoid delays and misunderstandings
by always giving the complete model number shown on the left side of
the access panel.
All repair parts listed are available for immediate purchase or special
order when you visit your nearest Sears Parts & Repair Center, or the
Service Department at most Sears stores. To order parts by phone, call
the toll-free number listed to the left or visit sears.com.
When requesting service or ordering parts, always provide the following
information:
• Product Type • Part Number
• Model Number • Part Description
Sears Brands Management Corporation, Hoffman Estates, IL 60179
Publication number 5995603247

253.28712809
11/11 2
DOOR
CAUTION: Use the Kenmore part number to order part, not the illustration number.
18
79
79
80
80
59
13
21A
151
12
1
9
93
26
27
73
72
48C
49
49
49
74
64
P08D0624
22
11
2
5
2A

253.28712809
# Functional Parts 3 11/11
* Non-Illustrated Parts
CAUTION: Use the Kenmore part number to order part, not the illustration number.
POS. NO PART NO. DESCRIPTION
1 216522359 Gasket-door, white
2 297318600 Lock Assy
2A 297213300 Clip, spring
5 297147700 Key, lock
9 297185800 Panel-inner door, frzr
11 297317202 Panel-outer door, white
12 297086400 Nameplate
13 297154800 Door Stop, RH
18 297218020 Handle, ELITE, white
* 240537301 Nut-anchor, door hdl screw
21A 216850900 Screw, hex washer hd, 1/4 x 7/8, door stop/hng
22 216970800 Bearing, hinge w/o'ring, top
26 216524201 Gasket, secondary
27 5304472186 Clip, panel mtg
27* 5304406520 Clip, panel mtg kit, (40)
48C 297350100 Bin-door, w/lid
49 297187200 Bin-door, 2-liter
59 216974500 Bearing, door closer
64 216403700 Plug-button, hole filler, door base
72 297186701 Shelf, tilt out, wire
73 216513900 End Cap, shelf, LH, tilt-out
74 216514000 End Cap, shelf, RH, tilt-out
79 218755402 Screw-set, 10-32 x 0.375
80 218755504 Screw-shoulder, #10 AB, handle mounting
93 5304460605 Screw, ph truss head, 8-18AB x 0.500
151# 297366203 Control-electronic, white, 115V

253.28712809
11/11 4
CABINET
163
6
37
37
16
34
15
25
19
71A
59
68
69
156
59A
93
72
59B
60
60
79
79
71A 71A
69
38
41
40
42C
156A
170
9
47
47A
9
7
P08C1202
63
3
32
29
152
41 28
93A
93A
169
50
13
5
139
139
138
138
42A
42
137C
137B
14

253.28712809
# Functional Parts 5 11/11
* Non-Illustrated Parts
CABINET
POS. NO PART NO. DESCRIPTION
3 216503100 Screen-drain
5 # 216325600 Fan Blade
6 297200600 Breaker Kit w/corners, no lock slot
7 297200800 Breaker Kit w/corners, incl lock catch
9 297200100 Breaker Kit w/corners, 32", top and bottom
13 # 297250000 Motor, fan, 115 V
14 216822900 Switch, light/lamp, ramp
15 297114000 Light Bulb, short, blue tint, 40W
16 297139500 Socket, light/lamp
19 216204902 Gasket-evap cover
25 297099251 Cover-evaporator
28 297179300 Hinge, bottom/RH
29 216313503 Hose-drain
32 5308005500 Drain
34 297184400 Shield-light
37 297273900 Trim-cabinet corner, white, (2)
38 297154600 Hinge-upper
40 297154701 Cover-upper hinge, white
41 297236200 Screw, tamper proof, 1/4-20 x 5/8
42 297166800 Glass-shelf
42A 297166801 Glass-shelf
* 216502400 Grommet-shelf mtg
42C 297183801 Divider, blue, glass shelf
47 297192901 Baffle, air
47A 297205801 Diffuser, air, blue, (2)
50 216394050 Bracket, fan motor mount
59 297308800 Basket, bottom
59A 216486500 Stop-basket, (2)
59B 297308400 Basket, mid-level
60 297013500 Slide, shelf
63 216396900 Screw, leveling foot, plastic, adjustable
63* 297164650 Bracket, LH leg levelor
63* 297164651 Bracket, RH leg levelor
68 08009560 Glide-basket
69 5305878546 Bumper-basket
71A 297146820 Screw, 8-18AB x.470 QX
72 297198900 Grille/Kickplate, 32", white
79 3017666 Nut-insert
93 5304460605 Screw, ph truss head, 8-18AB x 0.500
93A 297174300 Screw, self pierce, #8, 18x.63
* 216327800 Clip, wire
137B 297166900 Frame
137C 297166901 Frame, shelf
138 297203601 Trim-shelf, front
139 297218201 Trim-shelf, rear
152 216974600 Bearing, hinge closer
156 297202501 Divider, basket, btm
156A 297202301 Divider, basket
163 297185301 Shelf, pizza
169 216912401 Screw, hex washer head, 8-32 x 0.500, bracket fan mtr, (2)
170 297280400 Valve, breather
* 5995603247 Repair Parts List
* 5303305324 Paint, touch-up, white
* 297251900 Use & Care Guide
* 297246001 Service Data Sheet
* 216910411 Energy Guide
* 297257300 Label, start guide
* 297258300 Instructions, elect guide, Precision
* 297001704 Insulation, 24", drain tube

253.28712809
11/11 6
SYSTEM

253.28712809
# Functional Parts 7 11/11
* Non-Illustrated Parts
SYSTEM
POS. NO PART NO. DESCRIPTION
1 # 5300083897 Condenser
2 5308000110 Strap-evap/heater, aluminum, (2)
4 216987501 Dryer-filter
5 # 297237602 Harness-main
14 # 297348700 Defrost Heater, w/thermostat, termination swt
15 # 216997300 Evaporator
15A 297217900 Heat Exchanger, suct/cap tube
18 297078701 Insulator-evap, styrofoam, RH
19 297078801 Insulator-evap, styrofoam, LH
27 297293302 Grommet, compressor
29 # 297352151 COMPRESSOR EGX70HLC
30 216954205 Controller, compressor
31A 216994100 Pan-drain
* 5303311565 Clip-cable
32 297359700 Clip, controller
35 297368500 Bolt, compressor
43B 297315800 Clip, wire
55 297286802 Capacitor-run, 250 VA, 12 MF
86 216036601 Screw, RWHD, 8-32A x 0.500, GX-CA
100# 297169904 Cord-power
130 297244700 Support, evaporator mtg
* 216502500 Sleeve, suction line
* 297014702 Plug-suction line
* 297018400 Thermistor
* 240555002 Screw-#8-32 X 3/8
* 297174300 Screw, self pierce, #8, 18x.63
