Electrolux concept counters
Freezers
Electrolux Professional has designed and produced a complete range of refrigerated
tables, that combines the dual function of worktop and refrigerated table. This versatility
allows notable savings in space while offering functional and modular solutions to kitchen
requirements. The models represented here have a temperature range of -15 to -20 °C and
are available with built in or remote refrigerating unit, various combinations of doors and
drawers and with no worktop, flat top or top with splashback.
728635
• Built-in compressor.
• Suitable for use in ambient
temperatures of up to 43°C.
• Constructed in stainless
steel to meet the highest
hygiene standards.
• Rounded internal corners
for ease of cleaning.
• Mounted on stainless steel
legs with plastic interior to
give 150 mm clearance for
ease of cleaning the floor.
• Adjustable temperature
range from –15°C to -20°C
to suit all storage
requirements.
• Anti-tilt runners accept
GN1/1 trays and grids.
• Digital control with
temperature display.
• Forced air circulation for
rapid cooling and an even
temperature distribution.
• Internal and external
doors, front and side panels
and worktop in 304 AISI
stainless steel.
• Access to all components
from the front panel.
• In compliance with H
requirements.
• CFC and HCFC free
(ecological refrigerant type:
R404a, - gas in foam:
cyclopenthane).
• 50 mm insulation
thickness for energy saving.
• Developed and produced
in ISO 9001 and ISO 14001
certified factory.

Electrolux concept counters
Freezers
Internet: http://www.electrolux.com/foodservice
HBBD0102010-06-11Subject to change without notice
S/S STRUCTURE TO SUPPORT 6 GRIDS (R+L) 880140 880140 880140 880140
PRINTER FOR HACCP BASIC VERSION REFRIG. 881457 881457 881457 881457
LOCK KIT FOR REFRIGERATED TABLES 880130 880130 880130 880130
KIT INTEGRATED HACCP-DIG. REFR. (IR33) 880205 880205 880205 880205
KIT HACCP EKIS 922166 922166 922166 922166
KIT DOOR REVERSIBILITY FOR REF.TABLES 880046 880046 880046 880046
KIT 4 WHEELS (2 W/BRAKE)+4 (40MM)SPACERS 880025 880025 880025 880025
KIT 2 S/S GRIDS GN1/1 FOR REFRIG.TABLES 880139 880139 880139 880139
ACCESSORIES
1/1 GN GREY "RILSAN" GRID 2 1 3 2
INCLUDED ACCESSORIES
Power supply - V, phases, Hz 230 V, 1N, 50 230 V, 1N, 50 230 V, 1N, 50 230 V, 1N, 50
Net weight - kg. 119 125 142 147
Noise level - dBA 60 60 59.5 59.5
installed-electric 0.52 0.52 0.7 0.7
Power - kW
Refrigeration power - W 910 910 910 910
Refrigerant quantity - g. 160 160 200 200
Refrigerant type R404a R404a R404a R404a
N° defrost in 24 hrs. 4/28' 4/28' 4/28' 4/28'
Compressor power - HP 3/4 3/4 3/4 3/4
N° and type of grids (included) 2, GN 1/1 1, GN 1/1 3, GN 1/1 2, GN 1/1
Door hinges 1 Left+1 Right Right Side 1 Left+2 Right 1 Left+1 Right
N° of drawers 2x1/2 2x1/2
Top material 304 AISI 304 AISI 304 AISI 304 AISI
Worktop type Stainless Steel Stainless Steel Stainless Steel Stainless Steel
height 543 543 543 543
depth 580 580 580 580
Internal dimensions - mm
height 850 850 850 850
depth/with open doors 700, 1098 700, 1098 700, 1098 700, 1098
width 1238 1238 1721 1721
External dimensions - mm
Gross capacity (D.I.N. 8952) - l. 265 265 415 415
internal 304 AISI 304 AISI 304 AISI 304 AISI
external 304 AISI 304 AISI 304 AISI 304 AISI
Type of stainless steel
Operating mode Ventilated Ventilated Ventilated Ventilated
Operating temperature - min/max °C -20/-15 -20/-15 -20/-15 -20/-15
TECHNICAL DATA
RCHBF2P
728635
RCHBF1P2C
728304
RCHBF3P
728636
RCHBF2P2C
728305

Electrolux concept counters
Freezers
Internet: http://www.electrolux.com/foodservice
HBBD0102010-06-11Subject to change without notice
EI - Electrical connection 230 V, 1N, 50 230 V, 1N, 50
LEGEND
RCHBF2P
728635
RCHBF1P2C
728304
728635, 728304

Electrolux concept counters
Freezers
Internet: http://www.electrolux.com/foodservice
HBBD0102010-06-11Subject to change without notice
EI - Electrical connection 230 V, 1N, 50 230 V, 1N, 50
LEGEND
RCHBF3P
728636
RCHBF2P2C
728305
728636, 728305
