Electrolux EUF1900AOW User manual

EUF1900AOW
EN Freezer User Manual 2
FR Congélateur Notice d'utilisation 17
IT Congelatore Istruzioni per l’uso 34
TR Dondurucu Kullanma Kılavuzu 51

CONTENTS
1. SAFETY INFORMATION....................................................................................2
2. SAFETY INSTRUCTIONS..................................................................................4
3. INSTALLATION.................................................................................................. 6
4. OPERATION.......................................................................................................8
5. DAILY USE....................................................................................................... 10
6. HINTS AND TIPS............................................................................................. 10
7. CARE AND CLEANING....................................................................................11
8. TROUBLESHOOTING......................................................................................13
9. TECHNICAL DATA...........................................................................................15
WE’RE THINKING OF YOU
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that
brings with it decades of professional experience and innovation. Ingenious and
stylish, it has been designed with you in mind. So whenever you use it, you can
be safe in the knowledge that you’ll get great results every time.
Welcome to Electrolux.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.electrolux.com/webselfservice
Register your product for better service:
www.registerelectrolux.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.electrolux.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
responsible for any injuries or damage that are the result
of incorrect installation or usage. Always keep the
www.electrolux.com2

instructions in a safe and accessible location for future
reference.
1.1 Children and vulnerable people safety
•This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a
safe way and understand the hazards involved.
•This appliance may be used by children between 3
and 8 years of age and persons with very extensive
and complex disabilities, if they have been properly
instructed.
•Children of less than 3 years of age should be kept
away from the appliance unless continuously
supervised.
•Do not let children play with the appliance.
•Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
•Keep all packaging away from children and dispose of
it appropriately.
1.2 General Safety
•This appliance is intended to be used in household
and similar applications such as:
–Farm houses; staff kitchen areas in shops, offices
and other working environments
–By clients in hotels, motels, bed and breakfast and
other residential type environments
•WARNING: Keep ventilation openings, in the
appliance enclosure or in the built-in structure, clear of
obstruction.
•WARNING: Do not use mechanical devices or other
means to accelerate the defrosting process, other than
those recommended by the manufacturer.
•WARNING: Do not damage the refrigerant circuit.
ENGLISH 3

•WARNING: Do not use electrical appliances inside the
food storage compartments of the appliance, unless
they are of the type recommended by the
manufacturer.
•Do not use water spray and steam to clean the
appliance.
•Clean the appliance with a moist soft cloth. Only use
neutral detergents. Do not use abrasive products,
abrasive cleaning pads, solvents or metal objects.
•Do not store explosive substances such as aerosol
cans with a flammable propellant in this appliance.
•If the supply cord is damaged, it must be replaced by
the manufacturer, its Authorised Service Centre or
similarly qualified persons in order to avoid a hazard.
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must
install this appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Follow the installation instructions
supplied with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Make sure the air can circulate
around the appliance.
• At first installation or after reversing
the door wait at least 4 hours before
connecting the appliance to the power
supply. This is to allow the oil to flow
back in the compressor.
• Before carrying out any operations on
the appliance (e.g. reversing the
door), remove the plug from the
power socket.
• Do not install the appliance close to
radiators or cookers, ovens or hobs.
• Do not expose the appliance to the
rain.
• Do not install the appliance where
there is direct sunlight.
• Do not install this appliance in areas
that are too humid or too cold.
• When you move the appliance, lift it
by the front edge to avoid scratching
the floor.
2.2 Electrical connection
WARNING!
Risk of fire and electric
shock.
WARNING!
When positioning the
appliance, ensure the supply
cord is not trapped or
damaged.
WARNING!
Do not use multi-plug
adapters and extension
cables.
• The appliance must be earthed.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Always use a correctly installed
shockproof socket.
• Make sure not to cause damage to
the electrical components (e.g. mains
www.electrolux.com4

plug, mains cable, compressor).
Contact the Authorised Service
Centre or an electrician to change the
electrical components.
• The mains cable must stay below the
level of the mains plug.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
2.3 Use
WARNING!
Risk of injury, burns, electric
shock or fire.
The appliance contains flammable
gas, isobutane (R600a), a natural gas
with a high level of environmental
compatibility. Be careful not to cause
damage to the refrigerant circuit
containing isobutane.
• Do not change the specification of this
appliance.
• Do not put electrical appliances (e.g.
ice cream makers) in the appliance
unless they are stated applicable by
the manufacturer.
• If damage occurs to the refrigerant
circuit, make sure that there are no
flames and sources of ignition in the
room. Ventilate the room.
• Do not let hot items to touch the
plastic parts of the appliance.
• Do not put soft drinks in the freezer
compartment. This will create
pressure on the drink container.
• Do not store flammable gas and liquid
in the appliance.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
• Do not touch the compressor or the
condenser. They are hot.
• Do not remove or touch items from
the freezer compartment if your hands
are wet or damp.
• Do not freeze again food that has
been thawed.
• Follow the storage instructions on the
packaging of frozen food.
• Wrap the food in any food contact
material before putting it in the freezer
compartment.
2.4 Care and cleaning
WARNING!
Risk of injury or damage to
the appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains
plug from the mains socket.
• This appliance contains hydrocarbons
in the cooling unit. Only a qualified
person must do the maintenance and
the recharging of the unit.
• Regularly examine the drain of the
appliance and if necessary, clean it. If
the drain is blocked, defrosted water
collects in the bottom of the
appliance.
2.5 Service
• To repair the appliance contact the
Authorised Service Centre.
• Use original spare parts only.
2.6 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains cable and discard it.
• Remove the door to prevent children
and pets to be closed inside of the
appliance.
• The refrigerant circuit and the
insulation materials of this appliance
are ozone-friendly.
• The insulation foam contains
flammable gas. Contact your
municipal authority for information on
how to discard the appliance
correctly.
• Do not cause damage to the part of
the cooling unit that is near the heat
exchanger.
ENGLISH 5

3. INSTALLATION
WARNING!
Refer to Safety chapters.
3.1 Positioning
Install the appliance in a dry, well
ventilated indoors where the ambient
temperature corresponds to the climate
class indicated on the rating plate of the
appliance.
Climate
class Ambient temperature
SN +10°C to + 32°C
N +16°C to + 32°C
ST +16°C to + 38°C
T +16°C to + 43°C
Some functional problems
might occur for some types
of models when operating
outside of that range. The
correct operation can only
be guaranteed within the
specified temperature range.
If you have any doubts
regarding where to install the
appliance, please turn to the
vendor, to our customer
service or to the nearest
Authorised Service Centre.
3.2 Levelling
When placing the appliance ensure that
it stands level. This can be achieved by
two adjustable feet at the bottom in front.
If you place the appliance on a stand:
1. Unscrew the foot of the door hinge.
2. Screw the spare foot, found in the
bag with the egg tray, into the
cabinet.
3.3 Rear spacers
In the bag with the documentation, there
are two spacers which must be fitted as
shown in the figure.
1. Fit the spacers into the holes. Make
sure that the arrow (A) is positioned
as shown in the picture.
45°
45°
A
1
2
2
2. Turn counter-clockwise the spacers
through 45° until they lock into place.
3.4 Location
It must be possible to
disconnect the appliance
from the mains power
supply; the plug must
therefore be easily
accessible after installation.
The appliance should be installed well
away from sources of heat such as
radiators, boilers, direct sunlight etc.
Ensure that air can circulate freely
around the back of the cabinet. To
ensure best performance, if the
appliance is positioned below an
overhanging wall unit, the minimum
distance between the top of the cabinet
and the wall unit must be at least 100
mm . Ideally, however, the appliance
should not be positioned below
overhanging wall units. Accurate levelling
www.electrolux.com6

is ensured by one or more adjustable
feet at the base of the cabinet.
100 mm
15 mm 15 mm
3.5 Door reversibility
WARNING!
Before carrying out any
operations, remove the plug
from the power socket.
CAUTION!
To carry out the following
operations, we suggest that
this be made with another
person that will keep a firm
hold on the doors of the
appliance during the
operations.
1. Tilt back the appliance carefully so
that the compressor cannot touch the
floor.
2. Unscrew both adjustable feet.
3. Unscrew the screws of the door
bottom hinge.
4. Take off the appliance door by pulling
it slightly downwards.
5. Unscrew the top door hinge pin of the
appliance then screw it back on the
other side.
2
1
6. Fit the appliance door on the upper
door hinge pin.
7. Remove the lower hinge. Put over
the pin in the direction of the arrow.
8. Unscrew and install the screw on the
opposite side.
9. Install the lower hinge on the
opposite side leaving the position of
the door unchanged.
10. Screw in the one screw in the place
set free on the other side as well as
the adjustable feet (2 pieces).
11. Remove and install the handle on the
opposite side.
12
3
4
CAUTION!
Reposition, level the
appliance, wait for at least
four hours and then connect
it to the power socket.
ENGLISH 7

Do a final check to make
sure that:
• All screws are tightened.
• The magnetic seal
adheres to the cabinet.
• The door opens and
closes correctly.
If the ambient temperature is
cold (i.e. in Winter), the
gasket may not fit perfectly
to the cabinet. In that case,
wait for the natural fitting of
the gasket.
In case you do not want to
carry out the above
mentioned operations,
contact the nearest
Authorised Service Centre.
The Authorised Service
specialist will carry out the
reversibility of the doors at
your cost.
3.6 Electrical connection
• Before plugging in, ensure that the
voltage and frequency shown on the
rating plate correspond to your
domestic power supply.
• The appliance must be earthed. The
power supply cable plug is provided
with a contact for this purpose. If the
domestic power supply socket is not
earthed, connect the appliance to a
separate earth in compliance with
current regulations, consulting a
qualified electrician.
• The manufacturer declines all
responsibility if the above safety
precautions are not observed.
• This appliance complies with the
E.E.C. Directives.
4. OPERATION
4.1 Control panel
12 3 4 5
1Green On/Off Power Indicator Light
2Temperature Regulator and On/Off
Switch
3Yellow FastFreeze Indicator Light
4Acoustic Signal Stop and FastFreeze
Switch
5Red Alarm Indicator Light
4.2 Switching on
Leave the appliance to stand upright for
4 hours after installation.
1. Insert the plug into the wall socket.
2. Turn the Temperature Regulator
clockwise to a medium position.
The Green On/Off Indicator Light will
light up and Red Alarm Indicator
Light will blink.
The lighting up of the Green On/Off
Indicator Light means that the
appliance is switched on.
www.electrolux.com8

The blinking of the Red
Alarm Indicator Light and the
acoustic alarm means an
improper temperature in the
freezing compartment. Press
the Acoustic Signal Stop and
FastFreeze Switch to
deactivate the acoustic
alarm. The alarm indicator
continues to flash until the
normal conditions are
restored.
When switching on the
freezer for the first time, the
Red Alarm Indicator Light
will blink until the internal
temperature has reached a
level required for the safe
conservation of frozen food.
4.3 Switching off
1. To turn off the appliance, turn the
Temperature Regulator to the O
position.
The Green On/Of Indicator Light will
switch off.
2. To disconnect the appliance from the
power, disconnect the mains plug
from the wall socket.
4.4 High temperature alarm
Under normal operating conditions, the
internal temperature of the freezer will
ensure the long-term conservation of the
stored food.
The temperature increase above a
certain level in the freezer (-12 °C, for
example due to an earlier power failure)
is indicated by flashing the Red Alarm
Indicator Light and sounding the acoustic
alarm.
To deactivate the alarm press the
Acoustic Signal Stop.
The Red Alarm Indicator
Light continues to flash until
the internal temperature has
reached a level required for
the safe conservation of
frozen food.
4.5 Temperature regulation
CAUTION!
Do not place heavy nor hot
objects on top of the
appliance to avoid any
damage.
The temperature within the appliance is
controlled by the Temperature Regulator
situated on the control panel.
To operate the appliance, proceed as
follows:
• turn the Temperature Regulator
toward lower settings to obtain the
minimum coldness.
• turn the Temperature Regulator
toward higher settings to obtain the
maximum coldness.
A medium setting is
generally the most suitable.
However, the exact setting should be
chosen keeping in mind that the
temperature inside the appliance
depends on:
• room temperature
• how often the door is opened
• the quantity of food stored
• the location of the appliance.
4.6 FastFreeze function
If more than 3-4 kg of food is to be
frozen:
1. Press the FastFreeze button for 2-3
seconds to activate the FastFreeze
function 6-24 hours before placing
the fresh food in the freezer, the
Yellow FastFreeze Indicator Light will
illuminate. The compressor will now
run continuously, to ensure that the
fresh food is frozen as quickly as
possible.
It is possible to
deactivate the function at
any time by pressing the
FastFreeze button for
2-3 seconds.
2. Place the food in the freezing
compartment or compartments and
leave the FastFreeze function for a
further 24 hours.
ENGLISH 9

3. Once the food is completely frozen,
press the FastFreeze button for 2- 3
seconds and the Yellow FastFreeze
Indicator Light will go out.
4. Move frozen food from the freezing
compartments into the storing
compartments to make room for
another freezing.
5. DAILY USE
WARNING!
Refer to Safety chapters.
5.1 Freezing fresh food
The freezer compartment is suitable for
freezing fresh food and storing frozen
and deep-frozen food for a long time.
To freeze fresh food activate the
FastFreeze function at least 24 hours
before placing the food to be frozen in
the freezer compartment.
Place the fresh food to be frozen in the
two top compartments.
The maximum amount of food that can
be frozen in 24 hours is specified on the
rating plate, a label located on the
inside of the appliance.
The freezing process lasts 24 hours,
during this period do not add other food
to be frozen.
When the freezing process is completed,
you can restore previously set
temperature (see "FastFreeze function").
5.2 Storage of frozen food
When first starting-up or after a period
out of use, before putting the products in
the compartment let the appliance run at
least 2 hours on the higher settings.
In the event of accidental
defrosting, for example due
to a power failure, if the
power has been off for
longer than the value shown
in the technical
characteristics chart under
"rising time", the defrosted
food must be consumed
quickly or cooked
immediately and then re-
frozen (after cooling).
5.3 Thawing
Deep-frozen or frozen food, prior to
being used, can be thawed in the
refrigerator compartment or at room
temperature, depending on the time
available for this operation.
Small pieces may even be cooked still
frozen, directly from the freezer: in this
case, cooking will take longer.
6. HINTS AND TIPS
6.1 Normal operating sounds
The following sounds are normal during
operation:
• A faint gurgling and bubbling sound
from coils sound when refrigerant is
pumped.
• A whirring and pulsating sound from
the compressor when refrigerant is
pumped.
• A sudden cracking noise from inside
appliance caused by thermic dilatation
(a natural and not dangerous physical
phenomenon).
• A faint click noise from the
temperature regulator when the
compressor switches on or off.
www.electrolux.com10

6.2 Hints for energy saving
• Do not open the door frequently or
leave it open longer than absolutely
necessary.
6.3 Hints for freezing
• Freeze only top quality, fresh and
thoroughly cleaned food products.
• For more efficient freezing and
thawing divide food into small
portions.
• Wrap the food in aluminium foil or
polythene. Make sure that the
packages are airtight.
• To avoid increase in temperature of
already frozen food, do not place
fresh unfrozen food directly next to it.
• Lean foods store better and longer
than fatty ones. Salt reduces the
storage life of food.
• Do not eat ice cubes, water ices or ice
lollies immediately after taking them
out of the freezer. Risk of frostbites.
• It is advisable to show the freezing
date on each individual pack to
enable you to keep tab of the storage
time.
6.4 Hints for storage of frozen
food
• Make sure that the commercially
frozen food products were adequately
stored by the retailer.
• Make sure that frozen foodstuffs are
transferred from the food store to the
freezer in the shortest possible time.
• Once defrosted, food deteriorates
rapidly and cannot be refrozen.
• Do not exceed the storage period
indicated by the food manufacturer.
7. CARE AND CLEANING
WARNING!
Refer to Safety chapters.
7.1 General warnings
CAUTION!
Unplug the appliance before
carrying out any
maintenance operation.
This appliance contains
hydrocarbons in its cooling
unit; maintenance and
recharging must therefore
only be carried out by
authorized technicians.
The accessories and parts of
the appliance are not
suitable for washing in a
dishwasher.
7.2 Cleaning the interior
Before using the appliance for the first
time, the interior and all internal
accessories should be washed with
lukewarm water and some neutral soap
to remove the typical smell of a brand-
new product, then dried thoroughly.
CAUTION!
Do not use detergents,
abrasive powders, chlorine
or oil-based cleaners as they
will damage the finish.
7.3 Periodic cleaning
CAUTION!
Do not pull, move or damage
any pipes and/or cables
inside the appliance.
CAUTION!
Do not damage the cooling
system.
The equipment has to be cleaned
regularly:
1. Clean the inside and accessories
with lukewarm water and some
neutral soap.
2. Regularly check the door seals and
wipe them clean to ensure they are
clean and free from debris.
3. Rinse and dry thoroughly.
4. If accessible, clean the condenser
and the compressor at the back of
the appliance with a brush.
ENGLISH 11

This will improve the performance of
the appliance and save electricity
consumption.
7.4 Defrosting of the freezer
CAUTION!
Never use sharp metal tools
to scrape off frost from the
evaporator as you could
damage it.
Do not use a mechanical
device or any artificial
means to speed up the
thawing process other than
those recommended by the
manufacturer.
About 12 hours prior to
defrosting set a lower
temperature in order to build
up sufficient chill reserve in
case of any interruption in
operation.
A certain amount of frost will always form
on the freezer shelves and around the
top compartment.
Defrost the freezer when the frost layer
reaches a thickness of about 3-5 mm.
1. Switch off the appliance or pull out
electrical plug from the wall socket.
2. Remove any stored food, wrap it in
several layers of newspaper and put
it in a cool place.
CAUTION!
A temperature rise of the
frozen food packs during
defrosting may shorten
their safe storage life.
Do not touch frozen
goods with wet hands.
Hands can freeze to the
goods.
3. Leave the door open. Protect the
floor from the defrosting water e.g.
with a cloth or a flat vessel.
4. In order to speed up the defrosting
process, place a pot of warm water in
the freezer compartment. In addition,
remove pieces of ice that break away
before defrosting is complete.
5. Insert the plastic scraper in the
appropriate seating at the bottom
centre.
6. When defrosting is complete, dry the
interior thoroughly. .
7. Switch on the appliance and close
the door.
8. Set the temperature regulator to
obtain the maximum coldness and
run the appliance for two or three
hours using this setting.
Only after this time put the food back into
the freezer compartment.
7.5 Periods of non-operation
When the appliance is not in use for long
periods, take the following precautions:
1. Disconnect the appliance from
electricity supply.
2. Remove all food.
3. Defrost the appliance (if necessary).
4. Clean the appliance and all
accessories.
5. Leave the door/doors open to
prevent unpleasant smells.
CAUTION!
If you want to keep the
appliance switched on, ask
somebody to check it once
in a while to prevent the food
inside from spoiling in case
of a power failure.
www.electrolux.com12

8. TROUBLESHOOTING
WARNING!
Refer to Safety chapters.
8.1 What to do if...
Problem Possible cause Solution
The appliance does not
operate.
The appliance is switched
off.
Switch on the appliance.
The mains plug is not con‐
nected to the mains socket
correctly.
Connect the mains plug to
the mains socket correctly.
There is no voltage in the
mains socket.
Connect a different electri‐
cal appliance to the mains
socket. Contact a qualified
electrician.
The appliance is noisy. The appliance is not sup‐
ported properly.
Check if the appliance
stands stable.
Audible or visual alarm is
on.
The cabinet has been re‐
cently switched on.
Refer to "Door Open
Alarm"or "High Tempera‐
ture Alarm".
The temperature in the ap‐
pliance is too high.
Refer to "Door Open
Alarm"or "High Tempera‐
ture Alarm".
Power indicator light is
flashing.
An error has occurred in
measuring the tempera‐
ture.
Contact a qualified electri‐
cian or contact the nearest
Authorized Service Centre.
The appliance is not work‐
ing properly.
Contact a qualified electri‐
cian or contact the nearest
Authorized Service Centre.
The temperature in the ap‐
pliance is too high.
Contact a qualified electri‐
cian or contact the nearest
Authorized Service Centre.
The compressor operates
continually.
Temperature is set incor‐
rectly.
Refer to "Operation" chap‐
ter.
Many food products to be
frozen were put in at the
same time.
Wait a few hours and then
check the temperature
again.
The room temperature is
too high.
Refer to climate class chart
on the rating plate.
Food products placed in
the appliance were too
warm.
Allow food products to cool
to room temperature be‐
fore storing.
ENGLISH 13

Problem Possible cause Solution
The door is not closed cor‐
rectly.
Refer to "Closing the door".
The FastFreeze function is
switched on.
Refer to "FastFreeze func‐
tion".
There is too much frost
and ice.
The door is not closed cor‐
rectly or the gasket is de‐
formed/dirty.
Refer to "Closing the door".
The water drainage plug is
not correctly positioned.
Position the water drain‐
age plug in the correct
way.
Food products are not
wrapped properly.
Wrap the food products
better.
Temperature is set incor‐
rectly.
Refer to "Operation" chap‐
ter.
The compressor does not
start immediately after
pressing the "FastFreeze",
or after changing the tem‐
perature.
This is normal, no error
has occurred.
The compressor starts af‐
ter a period of time.
Temperature cannot be
set.
The "FastFreeze function"
is switched on.
Switch off "FastFreeze
function" manually, or wait
until the function resets au‐
tomatically to set the tem‐
perature. Refer to "Fast‐
Freeze function".
Door is misaligned or inter‐
feres with ventilation grill.
The appliance is not level‐
led.
Refer to "Levelling".
The temperature in the ap‐
pliance is too low/too high.
The temperature regulator
is not set correctly.
Set a higher/lower temper‐
ature.
The door is not closed cor‐
rectly.
Refer to "Closing the door".
The food products' temper‐
ature is too high.
Let the food products tem‐
perature decrease to room
temperature before stor‐
age.
Many food products are
stored at the same time.
Store less food products at
the same time.
The thickness of the frost
is greater than 4-5 mm.
Defrost the appliance.
The door has been opened
often.
Open the door only if nec‐
essary.
www.electrolux.com14

Problem Possible cause Solution
The FastFreeze function is
switched on.
Refer to "FastFreeze func‐
tion".
There is no cold air circula‐
tion in the appliance.
Make sure that there is
cold air circulation in the
appliance.
Door does not open easily. You attempted to re-open
the door immediately after
closing.
Wait a few seconds be‐
tween closing and re-open‐
ing of the door.
If the advice does not lead to
the desired result, call the
nearest Authorized Service
Centre.
8.2 Closing the door
1. Clean the door gaskets.
2. If necessary, adjust the door. Refer
to "Installation".
3. If necessary, replace the defective
door gaskets. Contact the Authorised
Service Centre.
9. TECHNICAL DATA
9.1 Product information sheet
Trade Mark Electrolux
Model EUF1900AOW 933013431
Category 8. Upright freezer
Energy efficiency class A+
Energy consumption in kWh per year, based on
standard test results for 24 hours. The actual en‐
ergy consumption will depend on how the appli‐
ance is used and where it is located
230
Storage volume in litres, Fridge -
Storage volume in litres, Star -
Storage volume in litres, Cellar zone -
Storage volume in litres, Wine -
Storage volume in litres, Total 168
Storage volume in litres, Freezer 168
Storage volume in litres, Chiller -
Storage volume in litres, Other compartments -
Star rating of freezer compartment with highest
storage volume (l)
****
ENGLISH 15

Design temperature of other compartments > 14
°C (°C), if any
-
Frost free (Y/N), Fridge -
Frost free (Y/N), Freezer No
Power cut safe in h 18
Freezing capacity in kg/24h 20
Climate class SN-N-ST-T
Lowest ambient temperature at which this appli‐
ance is intended to be used, in °C
10
Highest ambient temperature at which this appli‐
ance is intended to be used, in °C
43
Acoustical noise emissions dB(A) re1 pW 40
Built in appliance Y/N No
This appliance is intended to be used exclusively
for the storage of wine Y/N
No
9.2 Additional technical data
Dimensions of the appliance
Height 1250 mm
Width 545 mm
Depth 639 mm
Voltage 230 - 240 V
Frequency 50 Hz
The technical information is situated in
the rating plate, on the external or
internal side of the appliance and on the
energy label.
10. ENVIRONMENTAL CONCERNS
Recycle materials with the symbol .
Put the packaging in relevant containers
to recycle it. Help protect the
environment and human health by
recycling waste of electrical and
electronic appliances. Do not dispose of
appliances marked with the symbol
with the household waste. Return the
product to your local recycling facility or
contact your municipal office.
www.electrolux.com16

TABLE DES MATIÈRES
1. INFORMATIONS DE SÉCURITÉ..................................................................... 17
2. CONSIGNES DE SÉCURITÉ........................................................................... 19
3. INSTALLATION................................................................................................ 21
4. FONCTIONNEMENT........................................................................................24
5. UTILISATION QUOTIDIENNE..........................................................................25
6. CONSEILS........................................................................................................26
7. ENTRETIEN ET NETTOYAGE.........................................................................27
8. DÉPANNAGE................................................................................................... 29
9. CARACTÉRISTIQUES TECHNIQUES.............................................................32
NOUS PENSONS À VOUS
Merci d'avoir choisi ce produit Electrolux. Avec ce produit, vous bénéficiez de
dizaines d'années d'expérience professionnelle et d'innovation. Ingénieux et
élégant, il a été conçu sur mesure pour vous. Grâce à cet appareil, vous savez
que chaque utilisation vous apportera satisfaction.
Bienvenue chez Electrolux.
Visitez notre site Internet pour :
Obtenir des conseils d'utilisation, des brochures, de l'aide, des informations :
www.electrolux.com/webselfservice
Enregistrez votre produit pour obtenir un meilleur service :
www.registerelectrolux.com
Acheter des accessoires, consommables et pièces de rechange d'origine pour
votre appareil :
www.electrolux.com/shop
SERVICE APRÈS-VENTE
Utilisez toujours des pièces d'origine.
Avant de contacter le service après-vente, assurez-vous de disposer des
informations suivantes : Modèle, PNC, numéro de série.
Vous trouverez ces informations sur la plaque signalétique.
Avertissement/Consignes de sécurité
Informations générales et conseils
Informations en matière de protection de l'environnement
Sous réserve de modifications.
1. INFORMATIONS DE SÉCURITÉ
Avant d'installer et d'utiliser cet appareil, lisez
soigneusement les instructions fournies. Le fabricant ne
pourra être tenu pour responsable des blessures et
dégâts résultant d'une mauvaise installation ou
FRANÇAIS 17

utilisation. Conservez toujours les instructions dans un
lieu sûr et accessible pour vous y référer ultérieurement.
1.1 Sécurité des enfants et des personnes
vulnérables
•Cet appareil peut être utilisé par des enfants de plus
de 8 ans, ainsi que des personnes dont les capacités
physiques, sensorielles et mentales sont réduites ou
dont les connaissances et l'expérience sont
insuffisantes, à condition d'être surveillés ou d'avoir
reçu des instructions concernant l'utilisation sécurisée
de l'appareil et de comprendre les risques encourus.
•Cet appareil peut être utilisé par des enfants entre 3 et
8 ans et des personnes ayant un handicap très
important et complexe à condition d'avoir reçu de
bonnes instructions.
•Les enfants de moins de 3 ans doivent être tenus à
l'écart de l'appareil, à moins d'être surveillés en
permanence.
•Ne laissez pas les enfants jouer avec l'appareil.
•Les enfants ne doivent pas nettoyer ni entreprendre
une opération de maintenance sur l'appareil sans
surveillance.
•Ne laissez pas les emballages à la portée des enfants
et jetez-les convenablement.
1.2 Sécurité générale
•Cet appareil est conçu uniquement pour un usage
domestique et des situations telles que :
–dans des fermes, des coins cuisines réservés au
personnel dans des magasins, bureaux et autres
–l'utilisation par les clients des hôtels, motels, des
environnements du type chambres d’hôtes et autres
environnements à caractère résidentiel
•AVERTISSEMENT : Veillez à ce que les orifices de
ventilation, situés dans l'enceinte de l'appareil ou dans
la structure intégrée, ne soient pas obstrués.
www.electrolux.com18

•AVERTISSEMENT : N'utilisez aucun dispositif
mécanique ou autre appareil pour accélérer le
processus de dégivrage que ceux recommandés par
le fabricant.
•AVERTISSEMENT : N'endommagez pas le circuit
frigorifique.
•AVERTISSEMENT : N'utilisez pas d'appareils
électriques à l'intérieur des compartiments de
conservation des aliments de l'appareil, sauf s'ils sont
du type recommandé par le fabricant.
•Ne pulvérisez pas d'eau ni de vapeur pour nettoyer
l'appareil.
•Nettoyez l'appareil avec un chiffon doux humide.
Utilisez uniquement des produits de lavage neutres.
N'utilisez pas de produits abrasifs, de tampons à
récurer, de solvants ni d'objets métalliques.
•Ne conservez aucune substance explosive dans cet
appareil, comme des aérosols contenant un produit
inflammable.
•Si le câble d'alimentation est endommagé, il doit être
remplacé par le fabricant, son service après-vente ou
des personnes de qualification similaire afin d'éviter
un danger.
2. CONSIGNES DE SÉCURITÉ
2.1 Installation
AVERTISSEMENT!
L'appareil doit être installé
uniquement par un
professionnel qualifié.
• Retirez l'intégralité de l'emballage.
• N'installez pas et ne branchez pas un
appareil endommagé.
• Suivez scrupuleusement les
instructions d'installation fournies
avec l'appareil.
• Soyez toujours vigilants lorsque vous
déplacez l'appareil car il est lourd.
Utilisez toujours des gants de sécurité
et des chaussures fermées.
• Assurez-vous que l'air circule autour
de l'appareil.
• Lors de la première installation ou
après avoir inversé la porte, attendez
au moins 4 heures avant de brancher
l'appareil sur le secteur. Cela permet
à l'huile de refouler dans le
compresseur.
• Avant toute opération sur l'appareil
(par ex. inversion de la porte),
débranchez la fiche de la prise de
courant.
• N'installez pas l'appareil à proximité
d'un radiateur, d'une cuisinière, d'un
four ou d'une table de cuisson.
• N'exposez pas l'appareil à la pluie.
FRANÇAIS 19

• N'installez pas l'appareil dans un
endroit exposé à la lumière directe du
soleil.
• N'installez pas l'appareil dans une
pièce trop humide ou trop froide.
• Lorsque vous déplacez l'appareil,
veillez à le soulever par l'avant pour
éviter de rayer le sol.
2.2 Branchement électrique
AVERTISSEMENT!
Risque d'incendie ou
d'électrocution.
AVERTISSEMENT!
Lorsque vous installez
l'appareil, assurez-vous que
le câble d'alimentation n'est
pas coincé ou endommagé.
AVERTISSEMENT!
N'utilisez pas d'adaptateurs
multiprises ni de rallonges.
• L’appareil doit être relié à la terre.
• Vérifiez que les paramètres figurant
sur la plaque signalétique
correspondent aux données
électriques de votre réseau.
• Utilisez une prise correctement
installée et protégée contre les chocs.
• Veillez à ne pas endommager les
composants électriques tels que la
fiche secteur, le câble d'alimentation
ou le compresseur. Contactez le
service après-vente agréé ou un
électricien pour changer les
composants électriques.
• Le câble d'alimentation doit rester en
dessous du niveau de la fiche
secteur.
• Ne branchez la fiche d’alimentation à
la prise de courant qu’à la fin de
l’installation. Assurez-vous que la
prise principale est accessible une
fois l’appareil installé.
• Ne tirez jamais sur le câble
d’alimentation électrique pour
débrancher l’appareil. Tirez toujours
sur la fiche de la prise secteur.
2.3 Utilisation
AVERTISSEMENT!
Risque de blessures, de
brûlures, d'électrocution ou
d'incendie.
L'appareil contient un gaz
inflammable, l'isobutane (R600a), un gaz
naturel ayant un niveau élevé de
compatibilité environnementale. Veillez à
ne pas endommager le circuit frigorifique
contenant de l'isobutane.
• Ne modifiez pas les caractéristiques
de cet appareil.
• Ne placez aucun appareil électrique
(sorbetière, etc.) dans l'appareil, en
l'absence d'indications du fabricant.
• Si le circuit frigorifique est
endommagé, assurez-vous de
l'absence de flammes et de sources
d'ignition dans la pièce. Aérez la
pièce.
• Évitez tout contact d'éléments chauds
avec les parties en plastique de
l'appareil.
• Ne placez jamais de boissons
gazeuses dans le congélateur. Cela
engendrerait une pression sur le
récipient de la boisson.
• Ne stockez jamais de gaz ou de
liquide inflammable dans l'appareil.
• Ne placez pas de produits
inflammables ou d'éléments imbibés
de produits inflammables à l'intérieur
ou à proximité de l'appareil, ni sur
celui-ci.
• Ne touchez pas le compresseur ni le
condenseur. Ils sont chauds.
• Ne retirez pas et ne touchez pas les
éléments du compartiment
congélateur avec les mains mouillées
ou humides.
• Ne recongelez jamais un aliment qui a
été décongelé.
• Respectez les instructions de
stockage figurant sur l'emballage des
aliments surgelés.
• Emballez les aliments dans un
emballage adapté au contact avec
des aliments avant de les placer dans
le compartiment congélateur.
www.electrolux.com20
