Electrolux SMART 726599 User manual

Approval: ___________________________________________
726599 (RH14FE2FEU) 50 ft3Full Size Freezer
2 door 115 V/1p/60Hz
727014 (RH14F2FERU) 50 ft3Full Size Freezer
2 door 115 V/1p/60Hz
remote version
Item No. ___________________________________
The Electrolux range of refrigerated cabinets are built with
external and internal AISI 304 Stainless steel. High-density
expanded polyurethane insulating foam, 3″(75 mm) in thick-
ness. Full door with lock and microswitch to switch off the fan
when the door is opened. Built-in refrigeration unit; ventilated
operating mode; SMART Electronic Control equipped with:
history (HACCP) for critical high temperature, alarm service,
full diagnostic, remote control via modem; electronic defrost
only when required; defrost outlet pipe; external digital tem-
perature display. Humidity level adjustment. Internal lighting.
Cavity drain. For ambient temperatures up to 110 °F (43 °C).
CFC and HCFC free. R134a gas in refrigeration circuit. Gas in
foam: cyclopentane. Energy Star certification for energy
savings. Supplied with n. 4 x 2/1GN Rilsan® coated grids and
n. 4 sets of 2 stainless steel grid runners.
Covered by Electrolux Platinum Star®Service Program two-
year parts and one-year labor warranty, installation start-up
and performance check-up after one year from installation.
Short Form Specification
Electrolux Professional, Inc.
www.electroluxusa.com/professional
10200 David Taylor Drive, Charlotte, NC 28262 • Telephone Number: 866-449-4200 • Fax Number: 704-547-7401
ITEM # _______________________________________________
MODEL # _____________________________________________
PROJECT NAME # ______________________________________
SIS # _________________________________________________
AIA # _________________________________________________
Refrigeration
SMART 2 Door Freezer
(50 FT3)
Main features
EASY TO INSTALL
• Mounted on adjustable stainless steel feet, with castors as an option.
• Choice of doors to suit varying kitchen requirements.
• Freezer models have operating temperatures that can be adjusted from 5 °F
to -11 °F (-15 to -24 °C) to suit both meat and dairy storage requirements.
• Performance guaranteed at ambient temperatures of 110 °F (43 °C).
EASY TO CLEAN
• Forced air circulation for rapid cool down and even temperature uniformity.
• Constructed from the highest quality AISI 304 stainless steel.
• Interior base with corners, pressed from a single sheet.
• Sides and back of the 1-door models are formed from a single sheet of
Stainless steel to avoid dirt traps.
• Evaporator unit is placed outside the cell to provide the maximum storage
capacity.
• Refrigerators are fitted with outlet pipe.
EASY TO USE
• Accommodates GN 2/1 containers or shelves on anti-tilt runners.
• External digital temperature display.
• Interior light and lockable door.
• SMART electronic control gives the following benefits:
• HACCP: when temperature exceeds critical limits, an acoustic and visual
alarm are activated. All events are recorded displaying date and time of all
events.
• SMART defrost: the defrost cycle is activated only when necessary thanks to
the four-probe control and a patented algorithm for ice detection.
• Intelligence when failure: when a probe breaks it remembers its perfor-
mance of last 24 hours and continue to work. In this way food is safe and
service can be called.
• Diagnostic: four probes constantly control working condition of the
appliances.
• Food categories: depending by food stored it can be selected appropriate
temperature and humidity just pushing a button.
EASY TO MAINTAIN
• Heavy-duty construction that avoids use of any plastic parts.
•The cooling unit (compressor, condenser and evaporator) can be removed
with a single operation from either the top or back.
• Evaporator cover is easily removable for service.
• Fault indication from the smart control.
EASY ON THE ENVIRONMENT
• SMART electronics defrost only when required to save energy.
• Cabinet fitted with up to 3″(75 mm) thickness of cyclopentane insulation
for best insulating performance. CFC and HCFC-free insulation.
• Refrigerant type: R134a or R404a.
Accessories
• Pair of stainless steel runners for
23 and 50 ft3SMART refrigerators 8
• Rilsan®coated full-size sheet grid 8
Optional Accessories
• Basic HACCP Printer (PNC 880048)
• 4 wheels (2 with brake) (PNC 880121)
• Pair of stainless steel runners for
23 and 50 ft3SMART refrigerators (PNC 880175)
• Rilsan®coated full-size sheet grid (PNC 880176)
• Pedal opening for 50 ft3SMART refrigerators (PNC 881459)
Refrigeration
SMART 2 Door Freezer (50 FT3)
Refrigeration
SMART 2 Door Freezer (50 FT3)
5-20P

Refrigeration
SMART 2 Door Freezer (50 FT3)
Supply voltage:
726599 (RH14FE2FEU) 115 V/1p/60Hz - 15A
727014 (RH14F2FERU) 115 V/1p/60Hz - 15A
Electric
The company reserves the right to make modifications to the products
without prior notice. All information correct at time of printing.
3-7-11
Front View
Top View
Side View
LEGEND
C - Water Drain 1/2″(12.7 mm)
I – Electrical Connection 115 V/1p/60Hz
TECHNICAL DATA
Operating temperature min.: 5 °F (-15 °C)
Operating temperature max.: -11 °F (-24 °C)
Built-in Compressor and Refrigeration Unit
External Dimensions:
Width:59″(1500 mm)
Depth: 31-7/8″(810 mm)
Depth (with doors open) 57-1/2″(1463 mm)
Height: 80-11/16″(2050 mm)
Min/Max internal humidity % : 75/ 90
Number and type of doors: 2 Full
Door hinges: 1 Left, 1 Right
Number and type of grids (included): 8, GN 2/1
Compressor power: 1 HP
Refrigerant type: R404a
Refrigerant quantity: 380g
Refrigerant Power: 1471W
Power: 1 kW
Net weight: 547 lbs (248 kg)
Key Information
Refrigeration
SMART 2 Door Freezer (50 FT3)
