Electrolux SMART 726685 User manual

Approval: ___________________________________________
Item No. ___________________________________
The Electrolux range of freezer counters combines the con-
venience of worktop space with cold storage located below.
This range of counters is manufactured throughout in AISI
304 Stainless steel to meet the highest hygiene standards.
The range comprises three sizes of counter, with built-in
compressor units, in various door and drawer configura-
tions and in refrigerator or freezer versions. The model
detailed on this sheet benefit from the advantages of smart
electronic control. It has two full doors and operates over
the temperature range of -5 °F to -11 °F (-15 °C to -24 °C).
Short Form Specification
Electrolux Professional, Inc.
www.electroluxusa.com/professional
10200 David Taylor Drive, Charlotte, NC 28262 • Telephone Number: 866-449-4200 • Fax Number: 704-547-7401
ITEM # _______________________________________________
MODEL # _____________________________________________
PROJECT NAME # ______________________________________
SIS # _________________________________________________
AIA # _________________________________________________
Main features
EASY TO INSTALL
• Mounted on legs with height adjustment.
• Built-in compressor to suit operating conditions.
• Suitable for use in ambient temperatures of up to 109 °F (43 °C).
• Touch pad selection for the five most common food staffs the smart
electronic control sets the appropriate temperature and humidity.
EASY TO CLEAN
• Constructed from AISI 304 stainless steel throughout to meet the highest
hygiene standards.
• Rounded internal corners for ease of cleaning.
• Mounted on stainless steel legs to give 6″(150 mm) clearance for
ease of cleaning the floor.
• The SMART defrosting cycle only starts if it is necessary (by checking the
intensity of ice on the evaporator).
EASY TO USE
• Adjustable temperature range from -5 °F to -11.2 °F (-15 °C to -24 °C)
to suit meat, fish and dairy storage requirements.
• Anti-tilt runners accept GN1/1 containers.
• Electronic microprocessor control with external digital temperature display.
• Forced air circulation for rapid cooling and an even temperature distribution.
• HACCP incorporated - all events are recorded, displaying, date and time.
• A memory function keeps the information for working even when a probe
failed.
• Worktop in AISI 304 stainless steel with a 2″(50 mm) thickness.
EASY TO MAINTAIN
• Access to all components from the front.
• In compliance with ETL requirements.
• Fault code display.
EASY ON THE ENVIRONMENT
• CFC and HCFC free (ecological refrigerant type: R404a, - gas in foam:
cyclopenthane).
• 2.36″(60 mm) insulation for energy saving.
• Less on energy consumption due to smart defrosting cycles.
• Developed and produced in ISO 9001 and ISO 14001 certified factory.
Included Accessories
• 1/1 GN grey “RILSAN” grid (PNC 881435)
Optional Accessories
• Plastic container GN 1/1 H = 3.93″(100 mm) (PNC 811451)
• Top panel(flat) for 2-door HD tables (PNC 880153)
• Kit 2 drawers 1/2 + rack-ref. counters (PNC 880156)
• Kit 3 drawers 1/3 + rack-ref. counters (PNC 880157)
• Kit 1 bottler + 1 drawer-ref. counter (PNC 880158)
• 2 wheels, one with brake, (PNC 880539)
for HD refrigerated undercounters
(recommended to order 2 sets per unit)
• Plastic container GN 1/1 H = 2.55″ (65 mm) (PNC 881038)
• Plastic container GN 1/1 H = 6.0″ (150 mm) (PNC 881040)
• 1/1 GN grey “RILSAN” grid (PNC 881435)
• Lock for refrigerated counter (PNC 881499)
Refrigeration
SMART Undercounter 2 Door Freezer
726685 (RCEF2M2U) 10.2 ft3Full Size
Undercounter Freezer -
2 door 115 V/1p/60Hz
Refrigeration
SMART Undercounter 2 Door Freezer
Refrigeration
SMART Undercounter
2 Door Freezer
5-20P

Refrigeration
SMART Undercounter 2 Door Freezer
Supply voltage:
726685 (RCEF2M2U) 115 V/1p/60Hz - 10A
Electric
The company reserves the right to make modifications to the products
without prior notice. All information correct at time of printing.
3-7-11
Front View
Top View
Side View
LEGEND
C - Water Drain: 0.63″(16 mm)
I - Electrical Connection: 115 V/1p/60Hz
TECHNICAL DATA
Built-in Compressor and Refrigeration Unit
External Dimensions
Width: 50.16″ (1274 mm)
Depth: 27.56″(700 mm)
Depth/with doors open: 43.70″ (1110 mm)
Height/with legs fully extended: 35.46″(900 mm)
Number and type of doors: 2 Full
Door hinges: 1 Left + 1 Right
Number and type of grids
(included): 2, GN 1/1
Compressor power: 3/4 HP
Refrigerant type: R404a
Refrigerant quantity: 5.36 oz (280g)
Refrigerant Power: 925W
Power: 750 watts
Net weight: 284.40 lb (129 kg)
Key Information
Refrigeration
SMART Undercounter 2 Door Freezer
