Electrolux EHD90341P User manual

user manual
Ceramic glass induction hob
EHD90341P

Electrolux. Thinking of you.
Share more of our thinking at www.electrolux.com
Contents
Safety information 2
Installation 3
Description of the appliance 5
Operating the appliance 6
Helpful hints and tips 9
Care and cleaning 10
What to do if... 10
Environment concerns 11
Subject to change without notice
Safety information
For your safety and correct operation of
the appliance, read this manual carefully
before installation and use. Always keep
these instructions with the appliance
even if you move or sell it. Users must
fully know the operation and safety fea-
tures of the appliance.
General safety
Warning! Persons (including children)
with reduced physical sensory, mental
capabilities or lack of experience and
knowledge must not use the appliance.
They must have supervision or
instruction for the operation of the
appliance by a person responsible for
their safety.
Child safety
• Only adults can use this appliance. Chil-
dren must get supervision to make sure
that they do not play with the appliance.
• Keep all packaging away from children.
There is a risk of suffocation.
• Keep children away from the appliance
when it is on.
Warning! Start the child safety device to
prevent small children and pets from an
accidental activation of the appliance.
Safety during operation
• Remove all packaging, stickers and layers
from the appliance before the first use.
• Set the cooking zones to "off" after each
use.
• Risk of burns! Do not put metallic objects,
for example cutlery or saucepan lids, on
the cooking surface, as they can become
hot.
• Users with an implanted pacemaker must
keep their upper body minimum 30 cm
from induction cooking zones that are
switched on.
Warning! Fire danger! Overheated fats
and oils can catch fire very quickly.
Correct operation
• Always monitor the appliance during op-
eration.
• Only use the appliance for domestic cook-
ing tasks!
• Do not use the appliance as a work or a
storage surface.
• Do not put or keep very flammable liquids
and materials, or fusible objects (made of
plastic or aluminium) on or near the appli-
ance.
• Be careful when you connect the appli-
ance to the near sockets. Do not let elec-
tricity bonds touch the appliance or hot
cookware. Do not let electricity bonds tan-
gle.
How to prevent a damage to the
appliance
• If the objects or cookware fall on the glass
ceramic, the surface can be damaged.
• Cookware made of cast iron, cast alumi-
nium or with damaged bottoms can
scratch the glass ceramic if you move
them on the surface.
• Do not let cookware boil dry to prevent the
damage to cookware and glass ceramics.
• Do not use the cooking zones with empty
cookware or without cookware.
2 electrolux

• Do not cover the parts of the appliance
with aluminium foil.
• Do not cover the ventilation space of 5 mm
between the worktop and front of the unit
below it.
Warning! If there is a crack on the
surface, disconnect power supply to
prevent the electric shock.
Installation
Before the installation , note down
this data from the rating plate:
• Model description (Modell)................
• Product number (Prod.
Nr.) ............. ....
• Serial number (Ser. Nr.) ...............
You find the rating plate of the ap-
pliance on its lower casing.
EHD90341P 949 594 120 00
58 GCD E5 AU
ELECTROLUX
220-240 V 50-60 Hz
7,4 kW
Induction 7,4 kW
Safety instructions
Warning! You must read these!
Make sure that the appliance is not dam-
aged because of transportation. Do not
connect a damaged appliance. If it is
necessary, speak to the supplier.
Only an authorised service technician
can install, connect or repair this appli-
ance. Use only original spare parts.
Only use built-in appliances after you as-
semble the appliance into correct built-
in units and work surfaces that align to
the standards.
Do not change the specifications or
modify this product. Risk of injury and
damage to the appliance.
Fully obey the laws, ordinances, direc-
tives and standards in force in the coun-
try where you use the appliance (safety
regulations, recycling regulations, elec-
trical safety rules etc.)!
Keep the minimum distances to other
appliances and units!
Install anti-shock protection, for exam-
ple install the drawers only with a pro-
tective floor directly below the appliance!
Protect the cut surfaces of the worktop
against moisture with a correct sealant!
Seal the appliance to the work top with
no space left with a correct sealant!
Protect the bottom of the appliance from
steam and moisture, e.g. from a dish-
washer or oven!
Do not install the appliance adjacent to
doors and below windows! If not, hot
cookware can be hit off the hob when
you open doors or windows.
Warning! Risk of injury from electrical
current. Carefully obey the instructions
for electrical connections.
• The electrical mains terminal is live.
• Make electrical mains terminal free of volt-
age.
• Install correctly to give anti-shock protec-
tion.
• Loose and incorrect plug and socket con-
nections can make the terminal become
too hot.
• A qualified electrician must install the
clamping connections correctly.
• Use a strain relief clamp on cable.
• Use the correct mains cable of type
H05BB-F Tmax 90°C (or higher) for a sin-
gle-phase or two-phase connection.
• Replace the damaged mains cable with a
special cable (type H05BB-F Tmax 90°C;
or higher). Speak your local Service Force
Centre.
The appliance must have the electrical instal-
lation which lets you disconnect the appli-
ance from the mains at all poles with a con-
tact opening width of minimum 3 mm.
You must have correct isolation devices: line
protecting cut-outs, fuses (screw type fuses
removed from the holder), earth leakage trips
and contactors.
Sticking on the seal
• Clean the worktop in the area of the cut-
out section.
• Bond the sealing tape to the lower edge of
the cooking surface along the outer edge
of the glass ceramic. Do not extend it. Let
stay the cut ends in the middle of one side.
electrolux 3

When you have cut it to length (add some
mm), push the two ends together.
Assembly
min. 500 mm
min.
50 mm
min.
50 mm
min.
5 mm
min. 55mm
min. 55mm
380+1mm 880+1mm
R 5mm
min.
25 mm
min.
5 mm
min.
20 mm
4 electrolux

min.
38 mm
min.
5 mm
Description of the appliance
Cooking surface layout
1 42
5
3
210
mm
210
mm
180
mm
180
mm
1Induction cooking zone 2300W, with the
Power function 3200W
2Induction cooking zone 1800W, with the
Power function 2800W
3Induction cooking zone 1800W, with the
Power function 2800W
4Induction cooking zone 2300W, with the
Power function 3200W
5Control panel
Control panel layout
123456 7
12 10 9811
Use the sensor fields to operate the appliance.
sensor field function
1
starts and stops the hob
2
a lock with an indicator starts and stops the key lock or child lock
3
activates Power function
electrolux 5

sensor field function
4
cooking zones' indicators of timer shows for which zone you set the time
5
the timer display shows the time in minutes
6
a heat setting indicators show the heat setting
7
pan detection and automatic
switch-off indicator
shows that:
• there is no cookware on the cooking zone
• the cookware is not correct
• automatic switch off is active
8
residual heat indicator shows that cooking zone stays hot
9
a control bar to set the heat setting
10
/ increases or decreases the time
11
selects the cooking zone
12
with an indicator starts and stops STOP+GO
+number in the timer display shows
that there is a malfunction.
Residual heat indicator
Warning! Risk of burns from
residual heat!
The induction cooking zones make the heat
necessary for cooking directly in the bottom
of the cookware. The glass ceramic is slightly
heated by the residual heat of the cookware.
Operating the appliance
On and Off
Touch for 1 second to start or stop the
appliance.
Automatic Switch Off
The function stops the hob automatically if:
• all cooking zones are off.
• you do not set the heat setting after you
start the hob.
• you cover a sensor field with an object (a
pan, a cloth, etc.) for longer than 10 sec-
onds. The sound operates until you re-
move the object.
• the hob gets too hot (e.g. when a sauce-
pan boils dry). Before you use the hob
again, the cooking zone must be cool.
•you use incorrect cookware. comes on
and after 2 minutes the cooking zone
stops automatically.
• you do not stop a cooking zone or change
the heat setting. After some time comes
on and the hob stops. See the table.
Automatic Switch Off times
Heat setting 1-2 3-4 56-9
Stops after 6 hours 5 hours 4 hours 1.5 hours
6 electrolux

The heat setting
Touch the control bar at the necessary heat
setting. The heat setting indicators come on.
The automatic heat up
The Automatic heat up function sets the
highest heat setting for some time, and then
decreases to the necessary level.
Touch . The indicator flashes. Set the heat
setting (1-8). The indicator of the heat setting
comes on. The indicator above comes on
and after some time goes out.
The time of the automatic heat up changes
for different heat settings.
1
2
3
4
5
6
7
8
9
10
11
0
123456789
Switching the Power function on and off
The Power function makes more power avail-
able to the induction cooking zones. The
Power function is activated for 10 minutes at
most. After that the induction cooking zone
automatically switches back to the highest
heat setting (9). To switch on, touch , the
indicator above comes on. To switch off,
touch a heat setting (1-9).
Power management
The power management divides the power
between two cooking zones in a pair (see the
figure). The power function increases the
power to the maximum level for one cooking
zone in the pair and automatically decreases
in the second cooking zone to a lower power
level. The display for the reduced zone alter-
nates.
Using the Timer
Count Down Timer
Use the Count Down Timer to set how long
the cooking zone operates for one cooking
session.
Set the Count Down Timer after the se-
lection of the cooking zone.
You can set the heat setting before or after
you set the timer.
•Selection of the cooking zone: touch
again and again until the indicator of a
necessary cooking zone comes on.
•Starting the Count Down Timer: touch
of the timer to set the time (
00
-
99
minutes). When the indicator of the cook-
ing zone flashes slower, the time counts
down.
•Checking the remaining time: select
the cooking zone with . The indicator of
the cooking zone flashes faster. Display
shows the remaining time.
•Changing the Count Down Timer: se-
lect the cooking zone with touch or
.
electrolux 7

•Stopping the timer: select the cooking
zone with . Touch . The remaining
time counts backwards to
00
. The indi-
cator of the cooking zone goes out. To
switch off You can also touch and at
the same time.
When the time elapses, the sound oper-
ates and
00
flashes. The cooking zone
switches off.
•Stopping the sound: touch
CountUp Timer (Count up timer)
Use the CountUp Timer to monitor how long
the cooking zone operates.
•Selection of the cooking zone (if more
than 1 cooking zone operate): touch
again and again until the indicator of a
necessary cooking zone comes on.
•Starting the CountUp Timer: touch of
the timer comes on. When the indicator
of the cooking zone flashes slower, the
time counts up, display switches between
and time elapsed (minutes)
•Checking the elapsed time: select the
cooking zone with . The indicator of the
cooking zone flashes faster. Display
shows the elapsed time.
•Stopping the CountUp Timer: select
the cooking zone with and touch or
to switch off the timer. The indicator of
the cooking zone goes out.
Minute Minder
You can use the timer as a Minute Minder
while cooking zones do not operate. Touch
. Touch or of the timer to select the
time. When the time elapses, the sound op-
erates and
00
flashes.
Starting the STOP+GO
The function sets all cooking zones that
operate to a keep warm setting.
•Touch to start this function. The sym-
bol comes on.
•Touch to stop this function. The heat
setting that you set before comes on.
does not stop the timer function.
fully locks the control panel but not the
sensor field .
Locking / unlocking the control panel
You can lock the control panel, but not .
It prevents an accidental change of the heat
setting.
Touch the symbol . The display comes on.
The Timer still operates.
Touch the symbol to switch off this func-
tion. The display goes out.
When you switch off the appliance, you also
switch off this function.
The child safety device
This function prevents an accidental opera-
tion of the hob.
Starting the child safety device
•Start the hob with . Do not set the
heat settings .
•Touch for 4 seconds. The indicator
comes on.
•Stop the hob with .
Switching off the child safety device
•Start the hob with . Do not set the
heat settings . Touch for 4 seconds.
The indicator goes out.
•Stop the hob with .
Overriding the child safety device for one
cooking session
•Start the hob with . The indicator comes
on.
•Touch for 4 seconds. Set the heat
setting in less than 10 seconds. You
can operate the hob.
•When you stop the hob with , the child
safety device operates again.
OffSound Control (Switching off and on
the sounds)
Switching off the sounds
Switch off the appliance.
Touch for 3 seconds. The displays come
on and go out. Touch for 3 seconds.
comes on, the appliance is in standard
mode. Touch , comes on, the sound
is off.
When the sound is off, you hear only when
you touch , Minute Minder or Count Down
Timer come down or when you cover the
control panel.
Switching on the sounds
Switch off the appliance.
8 electrolux

Touch for 3 seconds. The displays come
on and go out. Touch for 3 seconds.
comes on, because the sound is off. Touch
, comes on, the appliance is in stand-
ard mode. The sound is on.
Helpful hints and tips
Cookware for induction cooking zones
Important! In induction cooking a powerful
electromagnetic field generates an almost
instant heat inside the cookware.
Cookware material
•correct: cast iron, steel, enamelled steel,
stainless steel, a multi-layer bottom
(marked as correct by a manufacturer).
•not correct: aluminium, copper, brass,
glass, ceramic, porcelain.
Cookware is correct for an induction hob if
…
• ... some water boils very quickly on a zone
set to the highest heat setting..
• ... a magnet pulls on to the bottom of the
cookware.
The bottom of the cookware must be
as thick and flat as possible.
Cookware dimensions : induction
cooking zones adapt to the dimension of
the bottom of the cookware automati-
cally to some limit. But, the magnetic
part of the bottom of the cookware must
have a minimum diameter of approxi-
mately 3/4 of the cooking zones.
Operating noises
If you can hear
• cracking noise: cookware is made of dif-
ferent materials (Sandwich construction).
• whistling: you use one or more cooking
zones with high power levels and the
cookware is made of different materials
(Sandwich construction).
• humming: you use high power levels.
• clicking: electric switching occurs.
• hissing, buzzing: the fan operates.
The noises are normal and do not refer
to any defects.
Energy saving
• If possible, always put the lids on the
cookware.
• Put cookware on a cooking zone be-
fore you start it.
• Stop the cooking zones before the
end of the cooking time to use residual
heat.
• The bottom of pans and cooking
zones must have the same dimen-
sion.
Öko Timer (Eco Timer)
To save the energy, the heater of the
cooking zone switches itself off earlier
than count down timer signal. The heat-
ing time reduction depends on cooking
level and cooking time.
Examples of cooking applications
The data in the table is for guidance only.
Heat
set-
ting
Use to: Time Hints
-1 Keep cooked foods warm as re-
quired
Cover the food
1-2 Hollandaise sauce, melt: butter, choco-
late, gelatine
5-25 min Mix occasionally
1-2 Solidify: fluffy omelettes, baked eggs 10-40
min
Cook with a lid on
2-3 Simmer rice and milkbased dishes, heat-
ing up ready-cooked meals
25-50
min
Add at least twice as much liquid as
rice, stir milk dishes part way through
3-4 Steam vegetables, fish, meat 20-45
min
Add a few tablespoons of liquid
electrolux 9

Heat
set-
ting
Use to: Time Hints
4-5 Steam potatoes 20-60
min
Use max. ¼ l water for 750 g of po-
tatoes
4-5 Cook larger quantities of food, stews and
soups
60-150
min
Up to 3 l liquid plus ingredients
6-7 Gentle fry: escalope, veal cordon bleu,
cutlets, rissoles, sausages, liver, roux,
eggs, pancakes, doughnuts
as re-
quired
Turn halfway through
7-8 Heavy fry, hash browns, loin steaks,
steaks
5-15 min Turn halfway through
9Boil large quantities of water, cook pasta, sear meat (goulash, pot roast), deep fry chips
The Power function is suitable for heating
large quantities of water.
Information on acrylamides
Important! According to the newest
scientific knowledge, if you brown food
(specially the one which contains starch),
acrylamides can pose a health risk. Thus, we
recommend that you cook at the lowest
temperatures and do not brown food too
much.
Care and cleaning
Clean the appliance after each use.
Always use cookware with clean bottom.
Warning! Sharp objects and abrasive
cleaning agents will damage the
appliance.
For your safety, do not clean the appli-
ance with steam blasters or high-pres-
sure cleaners.
Scratches or dark stains on the glass
ceramic have no effect on how the ap-
pliance operates.
Removing the dirt:
1. – Remove immediately: melting plas-
tic, plastic foil, and food containing
sugar. Use a special glass ceramic
scraper. Put the scraper on the glass
ceramic surface at an acute angle and
slide the blade on the surface.
–Stop the appliance and let it cool
down before you clean: limescale
rings, water rings, fat stains, shiny met-
allic discolorations. Use a special
cleaner for glass ceramic or stainless
steel.
2. Clean the appliance with a damp cloth
and some detergent.
3. At the end rub the appliance dry with
a clean cloth.
What to do if...
Problem Possible cause and remedy
You cannot start the appliance or
operate it.
• You touched 2 or more sensor fields at the same time. Only
touch one sensor field.
• There is water or fat stains on the control panel. Clean the control
panel
•The child safety device or key lock or operates . See the
chapter Operating the appliance.
• Start the appliance again and set the heat setting within 10 sec-
onds.
A sound operates (6x) and the
appliance stops or a sound op-
erates when the appliance is off.
You covered one or more sensor fields. Uncover the sensor fields.
10 electrolux

Problem Possible cause and remedy
The residual heat indicator does
not come on.
The cooking zone is not hot because it operated only for a short
time. If the cooking zone is supposed to be hot, speak to the After
Sales Service.
A sound operates and appliance
starts and stops again. After 5
seconds one more sound oper-
ates.
You covered . Uncover the sensor field.
Heat setting alternates The Power management is active. See the section Power man-
agement.
comes on • No cookware on the cooking zone. Put cookware on the cook-
ing zone.
• Not correct cookware. Use the correct cookware.
• The diameter of the bottom of the cookware is too small for the
cooking zone. Move cookware to a smaller cooking zone.
• The automatic switch-off operates. Stop the appliance and start
it again.
• Overheating protection for the cooking zone operates. Switch
off the cooking zone. Switch on the cooking zone again.
and number come on. There is an error in the appliance.
Disconnect the appliance from the electrical supply for some time.
Disconnect the fuse from the electrical system of the house. Con-
nect again. If comes on again, speak to the after sales service.
comes on There is an error in the appliance, because a cookware boils dry
or you use not correct cookware. Overheating protection for the
cooking zone operates. The automatic switch-off operates.
Switch off the appliance. Remove the hot cookware. After approx-
imately 30 seconds switch on the cooking zone again. should
disappear, residual heat indicator can stay. Cool down the cook-
ware and check it with the section "Cookware for the induction
cooking zone".
If you tried the above solutions and cannot
repair the problem, speak to your dealer or
the Customer Care Department. Give the da-
ta from the rating plate, three-digit-letter
code for the glass ceramic (it is in the corner
of the cooking surface) and an error message
that comes on.
If you operated the appliance incorrectly, the
servicing by a customer service technician or
dealer will not be free of charge, even during
the warranty period. The instructions about
the customer service and conditions of guar-
antee are in the guarantee booklet.
Environment concerns
The symbol on the product or on its
packaging indicates that this product may
not be treated as household waste. Instead
it should be taken to the appropriate
collection point for the recycling of electrical
and electronic equipment. By ensuring this
product is disposed of correctly, you will help
prevent potential negative consequences for
the environment and human health, which
could otherwise be caused by inappropriate
waste handling of this product. For more
detailed information about recycling of this
product, please contact your local council,
electrolux 11

your household waste disposal service or the
shop where you purchased the product.
Packaging material
The packaging materials are friendly to
the environment and can be recycled.
The plastic components are identified by
marking: >PE<,>PS<, etc. Discard the
packaging materials as household
waste at the waste disposal facilities in
your municipality.
12 electrolux

electrolux 13

14 electrolux

electrolux 15

892932452-B-012010
www.electrolux.com
www.electrolux.be
