(1) Power
(2) My Favorites
(3) : Rice, ,
(4) Kids:Popcorn, Pizza,
(6) Number Buttons:0-9
(7) Timer/Clock
(8) Stop/Cancel: clears all previous setting pressed before cooking starts. During
cooking: press once to stop oven; twice to stop and clear all entries.
( ) Start/+30S
(5) Functions: Defrost, Warm, Bake, , Melt
On Touche Nuggests
Cook, Keep Warm
VegetablesPotatoes
9
(1)
(2)
(5)
(8)
(5)
(3)
(4)
(6)
(7)
(9)

EN-10
1. POWER LEVEL
11 power levels are available.
Level
Power
Display
10
100%
PL10
9
90%
PL9
8
80%
PL8
7
70%
PL7
6
60%
PL6
5
50%
PL5
4
40%
PL4
3
30%
PL3
2
20%
PL2
1
10%
PL1
2. CLOCK SETTING
(1) Press " TIMER/CLOCK "once, "00:00" will display.
(2) Press the number keys and enter the current time. For example,
time is 12:10 now, please press "1,2,1,0" in turn.
(3) Press " TIMER/CLOCK " to finish clock setting. ":" will flash and the clock will be
lighted.
(4) If the numbers input are not within the range of 1:00--12:59, the setting will be invalid
until valid numbers are input.
3. KITCHEN TIMER
(1) Press "TIMER/CLOCK " twice, LED will display 00:00, the first hour figure flash.
(2) Press the number keys and enter the timer time.(the maximum cooking time is
99 minutes and 99 seconds)
(3) Press " START/+30SEC. " to confirm setting.
(4) When the timer time arrives, the buzzer will ring 5 times.
If the clock be set (12-hour system), LED will display the current time.
Note: 1) The kitchen time is differ from 12-hour system,Kitchen Timer is a timer.
2) During kitchen timer, anny program cannot be set.
4. MICROWAVE COOKING
(2) Press number keys to input the cooking time the maximum cooking time is 99
minutes and 99 seconds.
0
0%
PL0
Note: (1) In the process of clock setting, if the " STOP/CANCEL " button is pressed or if
there is no operation within 1 minute, the oven will go back to the former setting
automatically.
(2)If the clock need to be reset, please repeat step 1 to step 3.
(1) Press "COOK" once, LED will display "00:00".
(3) Press " POWER " once, LED will display "PL10". The default power is 100% power.
Now you can press number keys to adjust the power level.
(4) Press " START/+30S
OPERATION
,
EC." to start cooking.

EN-11
Note:1) In the process of setting, if the " STOP/CANCEL" button is pressed or if there is
no operation within 1 minute, the oven will go back to the former setting automatically.
2) If "PL0" selected, the o en will work with fan for no power. You can use this level to
remove the odour of the oven.
3)During microwave cooking, "POWER" can be pressed to change the power you need.
After pressing "POWER",the current power flash for 3 seconds, now you can press number
button to change the power. The oven will work with the selected power for the rest time.
Example: to cook the food with 50% microwave power for 15 minutes.
a. Press "COOK" once."00:00" displays.
b.Press "1","5","0","0" in order.
c.Press "POWER" once,then press "5" to select 50% microwave power.
d.Press "START/+30S
v
(1) Press " DEFROST " twice, LED will display "dEF2".
(2) Press number pads to input defrosting time. The effective time range is 0:01~99:99
(3) The default microwave power is power level 3. If you want to change the power level,
press " POWER " once, and the LED will display "PL 3", then press the number pad
of the power level you wanted.
(4) Press " START/+30S
displayed.
(1) Press " DEFROST "once, LED will display "dEF1".
(2) Press numerical buttons to input weight to be defrosted.
Input the weight ranged between 100~2000 g.
(3) If the weight input is not within 100~2000, the input will be invalid.
(4) Press " START/+30S
displayed.
5. WEIGHT DEFROST
6. TIME DEFROST
(1) Press " " , LED will display " ".
(2) Press number pads to input time. The effective time range is 0:01~99:99
(3) The default microwave power is power level 3. If you want to change the power level,
press " POWER " once, and the LED will display "PL 3", then press the number pad
of the power level you wanted.
(4) Press " START/+30S
Keep WARM once 00:00
warming
7. KEEP WARM
EC." to start cooking.
EC. " to start defrosting and the cooking time remained will be
EC." to start defrosting. The remained cooking time will be
EC." to start . The remained cooking time will be displayed.

EN-12
8.WARM
10.MELT
" repeatedly until the number you wish appears in the
display, "150","250","350","400" grams will display in order.
For example, press " " once , "150" appears.
" START/+30 SEC. " to cook, buzzer sounds once.When cooking finish,buzzer
sounds five times and then turn back to waiting state.
WARM
WARM
(1) Press "
(2) Press
B " repeatedly until the number you wish appears in the
display, "1","2","3" will display in order.
" START/+30 SEC. " to cook, buzzer sounds once.When cooking finish,buzzer
sounds five times and then turn back to waiting state.
AKE(1) Press "
(2) Press
Function
BAKEx1
BAKEx2
chocolate
candy
Menu Weight Display
1 (about 400g) 1
pancake 1(about 30ml)
BAKEx3
BAKEx4
2
3
4
flan
cake
" repeatedly until the number you wish appears in the
display, "1","2","3" will display in order.
(1) Press "
(2)
Function
chocolate
Menu Weight Display
Melt
Select the menu you want,then press number buttons to choose the weight.
" START/+30 SEC. " to cook, buzzer sounds once.When cooking finish,buzzer
sounds five times and then turn back to waiting state.
(3) Press
MELTx1
MELTx2
MELTx3
For example, the chocolate 300g for melt :
" once , select chocolate, "1" appears.a. Press "Melt
b. Press "
select
1" .
START/+30 SEC.
c. Press " " to start.
Note:
the chocolate.
The oven will sounds to remind you turn the food over when you melting
butter
cheese
200
300
200g
300g
0g
000g
100g
20 100
200
50g 50
10 1
1-3 repeatedly
twice to s lect 300ge
,"4"
1 (about 900g)
1 (about1100g)
9.BAKE

EN-13
.
a) Press " " repeatedly until the number you wish appears in the
display, "1","2","3" will display in order.
For example, press " " once ,
"1" appears.
b) Press " START/+30 SEC. " to cook, buzzer sounds once.When cooking finish,buzzer
sounds five times and then turn back to waiting state.
12. PIZZA
a) Press " PIZZA " repeatedly until the number you wish appears in the display,
" "," "," " will display in order.
For example, press "PIZZA" once , " " appears.
b) Press " START/+30SEC. " to cook, buzzer sounds once.When cooking finish,buzzer
sounds five times and then turn back to waiting state.
100
100 200 400 g
NUGGETS
NUGGETS
piece NUGGETS
13
a)Press " POPCORN " repeatedly until the number you wish appears in the display,
"50","100"g will display in order.
For example, press "POPCORN" once , "50" appears.
b) Press " START/+30 SEC. " to cook, buzzer sounds once.When cooking finish,buzzer
sounds five times and then turn back to waiting state.
11.POPCORN
1. When selecting 100 g of popcorn, it is
suggested that you fold down a triangle on each
corner of the bag before cooking. Refer to the
picture at right.
Important Information About Microwave Popcorn Feature:
2. If/When the popcorn bag expands and no longer
rotates properly, please press
button onceand open the oven door and adjust the
to ensure even cooking.
STOP/CANCEL
bag position
14. P
a) Press " POTATO " repeatedly until the number you wish appears in the display,
"1","2","3" will display in order.
"1"SET : 1 potato (approximate 230 gram)
"2"SETS: 2 potatoes (approximate 460 gram)
"3"SETS: 3 potatoes (approximate 690 gram)
For example, press "POTAT " once , "1" appears.
b) Press " to cook, buzzer sounds once.When cooking finish,buzzer
sounds five times and then turn back to waiting state.
ES
" START/+30SEC. OES
OTATOES

EN-14
(1) Press " " to choose memory 1-3 procedure The D will display 1, 2,3LE .
(2) If the procedure has been set, press " START/ +30S
set the procedure. Only one or two stages can be set.
(3) After finishing the setting, press "START/ +30S
turn back to the waiting states.If press " START/ +30S
Example: to set the following procedure as the second memory, that is memory 2.
to cook the food with 80% microwave power for 3 minutes and 20 seconds.
The steps are as follow:
a. In waiting states, press "FAVORITES" twice,stop pressing until the screen displays "2".
b.Press "COOK" once,then press "3","2","0" in order.
c. Press "POWER" once,"PL10" display,then press "8" and "PL8" displays.
d. Press "START/ +30S
waiting states. If you press "START/+30S
memory 1 and operated.
e. If the electricity is not cut off, the procedure will be saved all the time. If it is, the
procedure need to reset.
f. If you want to run the saved procedure, in waiting state, press " " twice,
screen displays "2", then press "START/+30SEC." to run.
FAVORITES
FAVORITTES
1 . MEMORY FUNCTION
7
.
a) Press " " repeatedly until the number you wish appears in the
display, "1","2" will display in order.
For example, press " " once , "1" appears.
b) Press " START/+30S
sounds five times and then turn back to waiting state.
RRICE RICE
a) Press " VEGETABLES " repeatedly until the number you wish appears in the
display, "150","350","500" grams will display in order.
For example, press "VEGETABLE
b) Press " START/+30 SEC. " to cook, buzzer sounds once.When cooking finish,buzzer
sounds five times and then turn back to waiting state.
VEGETABLES1 .
15
6
Press "1" appear 17mins (for 170g Rice and 340g water)
Press "2" appear 22 mins (for 340g Rice and 680g water)
TIPS:This is for FrozenVegetable
ICE
EC." to cook, buzzer sounds once.When cooking finish,buzzer
S" once , "150" appears.
EC." to use it. If not, continue to
EC." once to save the procedure and
EC." again,it will start cooking.
EC." to save the setting. Buzzer sounds once then turn back to
EC." again, the procedure will be saved as the

EN-15
Lock: In waiting state, press " STOP/CANCEL " for 3 seconds, there will be a long "beep"
denoting the entering into the children-lock state; meanwhile, LED will display " "
Lock quitting: In locked state, press " STOP/CANCEL " for 3 seconds, there will be a long
"beep" denoting that lock is released.
the current microwave power will be displayed. After three seconds, the oven will turn back
21. INQUIRING FUNCTION
(1) In cooking state, press " TIMER/CLOCK
(2) In the microwave cooking state, press " POWER " to inquire microwave power level, and
to the previous state. In multi-stage state, the inquiring way can be done by the
same way as above.
2. OTHER SPECIFICATIONS
(1) In standby state , if the set clock digital tube displays current time, the icon " : " would
flash; otherwise, it shows " 0:00 ".
(2) In setting function state, LED displays corresponding setting.
(3) In working or pause state, LED displays surplus cooking time.
When the cooking is over, the buzzer will sound 5 "beep" to alert user the cooking is finished.
22. COOKING END REMINDING FUNCTION
20. LOCK FUNCTION FOR CHILDREN
3
1. MULTI_STAGE COOKING
At most 2 stages can be set for cooking. In multi-stage cooking, if one stage is
defrosting, then defrosting shall be placed at the first stage automatically.
Note: Auto cooking cannot work in the multi-stage cooking.
Example: if you want to cook with 80% microwave power for 5 minutes + 60% microwave
power for 10 minutes. The cooking steps are as following:
(1) Press "COOK" once,then press "5","0","0" to set the cooking time;
(2) Press "POWER" once,then press "8" to select 80% microwave power.
(3) Press "COOK" once,then press "1","0","0","0" to set the cooking time;
(4) Press "POWER" once,then press "6" to select 60% microwave power.
(5) Press "START/ +30S
Note: during microwave cooking and time defrost,time can be added by pressing
"START/30S" button.
( ) In waiting state, instant cooking at 100% power level with 30 seconds' cooking time can
be started by pressing " START/+30S
cooking time by 30 seconds. the maximum cooking time is 9 minutes
. SPEEDY COOKING
1
1
5 .
8
9
", the LED will display clock for three seconds.
EC." to start cooking.
EC. ". Each press on the same button will increase

EN-16
Model
EME20
Rated Voltage:
Rated Input Power (Microwave):
700W
Rated Output Power
(Microwave): 1050W
Oven Capacity:
20L
Turntable Diameter:
Ø 255mm
External Dimmensions (wxdxh):
440*355*259mm
Net Weight:
10.4kg
220V~ 50H z
24MW

EN-17
Troubleshooting
Check your problem by using the chart below and try the solutions for each problem. If the
microwave oven still does not work properly, contact the nearest authorized service center.
TROUBLE
Oven will not start
POSSIBLE CAUSE POSSIBLE REMEDY
a. Electrical cord for oven is
not plugged in.
b. Door is open.
c. Wrong operation is set.
a. Plug into the outlet.
b. Close the door and try
again.
c. Check instructions.
Arcing or sparking
a. Materials to be avoided in
microwave oven were
used.
b. The oven is operated when
empty.
c. Spilled food remains in the
cavity.
a. Use microwave-safe
cookware only.
b. Do not operate with oven
empty.
c. Clean cavity with wet towel.
Unevenly cooked
foods
a. Materials to be avoided in
microwave oven were
used.
b. Food is not defrosted
completely.
c. Cooking time, power level
is not suitble.
d. Food is not turned or stirred.
a. Use microwave-safe
cookware only.
b. Completely defrost food.
c. Use correct cooking time,
power level.
d. Turn or stir food.
Overcooked foods Cooking time, power level is
not suitable. Use correct cooking time,
power level.
Undercooked foods
a. Materials to be avoided in
microwave oven were used.
b. Food is not defrosted
completely.
c. Oven ventilation ports are
restricted.
d. Cooking time, power level is
not suitable.
a. Use microwave-safe
cookware only.
b. Completely defrost food.
c. Check to see that oven venti-
lation ports are not restricted.
d. Use correct cooking time,
power level.
Improper defrosting
a. Materials to be avoided in
microwave oven were used.
b. Cooking time, power level is
not suitable.
c. Food is not turned or stirred.
a. Use microwave-safe
cookware only.
b. Use correct cooking time,
power level.
c. Turn or stir food.
Maintenance

EN-18
CONSUMER CARE CENTER
Indonesia
Consumer Care Center Tel : [phone]
PT. Electrolux Indonesia
Gedung Plaza Kuningan
Menara Utara 2nd Floor,
Suite 201, Jl. HR Rasuna Said
kav C 11-14, Karet Setiabudi
Jakarta Selatan 12940
Office Tel: [phone]
Office Fax: [phone]
Email : [email protected]
Malaysia
Consumer Care Center Tel: 1300-88-11-22
Electrolux Home Appliances Sdn. Bhd.
Corporate Office Address: Unit T2-7, 7th Floor, Tower 2 ,
Jaya33 Hyperoffice, No. 3, Jalan Semangat, Seksyen 13,
46100 Petaling Jaya, Selangor
Office Tel : [phone]
Office Fax : [phone]
Consumer Care Center Address: Lot C6, No. 28,
Jalan 15/22, Taman Perindustrain Tiong Nam,
40200 Shah Alam, Selangor
Consumer Care Center Fax : [phone]
Email : [e-mail]
Philippines
Consumer Care Center Toll Free : 1-800-10-845-CARE 2273
Consumer Care Hotline : (+63 2) 845 CARE 2273
Electrolux Philippines, Inc.
10th Floor. W5th Avenue Building
5th Avenue Corner 32nd Street
Bonifacio Global City,
Taguig Philippines 1634
Trunkline: [phone]
Website : www.electrolux.com.ph
Email : w[email protected]
Singapore
Consumer Care Center Tel: [phone]
Electrolux S.E.A. Pte Ltd.
1 Fusionopolis Place,
#07-10 Galaxis, West Lobby
Singapore 138522.
Office Fax : [phone]
Email : [email protected]
Thailand
Consumer Care Tel : [phone]
Electrolux Thailand Co., Ltd.
Electrolux Building 14th Floor
1910 New Phetchaburi Road,
Bangkapi, Huai Khwang, Bangkok 10310
Office Tel : [phone]
Office Fax : [phone]
Email : [e-mail]
Vietnam
Consumer Care Center Toll Free : 1800-58-88-99
Tel : [phone]
Electrolux Vietnam Ltd.
Floor 9th, A&B Tower
76 Le Lai street - Ben Thanh Ward - District 1
Ho Chi Minh City ，Vietnam
Office Tel : [phone]
Office Fax : [phone]
Email : [e-mail]
Hongkong
Tel: [phone]
Dah Chong Hong, Ltd. - Service Centre
8/F., Yee Lim Godown Block C
2-28 Kwai Lok Street, Kwai Chung, N.T.

EN-19
