Built-In Microwave
EW27SO60L S
Featuring Wave-Touch®Electronic Controls
Auto-Cook Functions
Features four Auto-Cook options, one Auto-
Reheat option and six Auto-Defrost options
for amazing flexibility.
Wave-Touch®Controls
One simple touch and the control panel
activates, showing the virtually endless cooking
options. After you make your choices, all but
the options selected will fade away, returning
to an elegant display.
Premium Sensor-Cook Options
Eight Sensor-Cook options available to
determine exact cooking time for many
commonly prepared dishes.
Convection Cooking
Circulates hot air through your microwave to cook
foods evenly.
27" BUILT-IN MICROWAVE WITH DROP-DOWN DOOR
Oven Cavity
Watts
Oven Interior
Interior Krypton Light
Porcelain Enamel Turntable
Control Panel Features
Wave-Touch®Electronic Controls
VFD Front Display with Blue Indicators
Electronic Clock & Timer
Humidity Sensor
Convection Bake
Power Levels
Touch Pad Controls
Auto-Defrost Options
Auto-Cook Options
Auto-Reheat Options
Sensor-Cook Options
Multi-Stage Cooking Options
Shortcut Options
Add 30 Seconds
Custom Help Options
Panel Lock
Demo Mode
Adjustable Sound Level For Timers / Reminders
More / Less Function
Power Failure Indicator
Additional Features
Signature Soft-Arc Oven Door and Handle Design
Adjustable Metal Racks
Glass Window
Specifications
Color –
Stainless Steel
Oven Cavity Dimensions –
Height
Width
Depth
Product Dimensions –
Height
Width
Depth (to Front Door Corner)
Approved for Under-Counter Installation
Approved for Electric Single Oven Combination Installation*
Power Supply Connection Location
Voltage Rating
Connected Load (kW Rating) @ 120 Volts‡
Amps @ 120 Volts
60" Electrical Cable
Microwave – Watts @ 120 Volt input
Convection – Watts @ 120 Volt input
Frequency (MHz)
Shipping Weight (Approx.)
‡For use on adequately wired 120V, dedicated circuit having 2-wire service with a separate
ground wire. Appliance must be grounded for safe operation.
* Approved to be used in combination with any Electrolux Electric Single Wall Oven
and/or Warmer Drawer.
NOTE: Always consult local and national electric codes. Refer to Product Installation Guide
for detailed installation instructions on the web at electroluxappliances.com.
Specifications subject to change.
1.5 Cu. Ft.
900
Stainless Steel
Yes
Cobalt Blue
Yes
Yes
Yes
Yes
Yes (100°-450° F)
10
36
6
4
1
8
4
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
S
9-5/8"
16-1/8"
16-1/8"
22-1/4"
27"
21-11/16"
No
Yes
Left Bottom Rear
120V / 60Hz / 15A
1.6
13.7
Included
1600
1500
2450
84

High standards of quality at Electrolux Home Products, Inc. mean
we are constantly working to improve our products. We reserve the right
to change specifications or discontinue models without notice.
27" Built-In Convection Microwave Oven
w/Drop-Down Door
EW27SO60L
27" Built-In Microwave Specifications
•
Product Weight – 79 Lbs.
•
Voltage Rating – 120V / 60 Hz / 15 Amps
•
Connected Load (kW Rating) @120 Volts = 1.6kW (For use on
adequately wired 120V, dedicated circuit having 2-wire service with a
separate ground wire. Appliance must be grounded for safe operation.)
•
Amps @120 Volts = 13.7 Amps
•
Always consult local and national electric codes.
•
Allow at least 15" clearance for oven door depth when open.
•
Minimum required distance from floor is 36".
•
Minimum 20-1/8" deep oven cutout dimension is critical for proper
installation for oven and faceplate to fit flush against cabinet front.
•
Full oven base of solid plywood or similar material required, capable
of supporting 150 Lbs.
•
Base must be level and cabinet front must be square.
•
Grounded outlet should NOT be located in shaded area, as indicated,
unless cabinet depth is greater than 21-1/8".
•
Built-In Microwave is NOT approved to be used under counter.
•
Built-In Microwave can be built in alone or is approved to be used in
combination with any Electrolux Electric Single Wall Oven and / or Warmer
Drawer. (Refer to model-specific Combination Installation Specification
pages on web.)
•
When used in combination with another Electrolux built-in product, a
minimum clearance of 2-1/8" required from bottom of Built-In Microwave
cutout to top edge of companion product’s faceplate, leaving a 2" visible
gap between both product faceplates.
Note: For planning purposes only. Refer to Product Installation Guide
on the web at electroluxappliances.com for detailed instructions.
Electrolux Major Appliances, N.A.
USA •10200 David Taylor Drive •Charlotte, NC 28262 •1-877-4electrolux (1-877-435-3287) •electroluxappliances.com
CANADA •5855 Terry Fox Way •Mississauga, ON L5V 3E4 •1-800-265-8352 •electroluxappliances.ca
EW27SO60L 02/12 © 2012 Electrolux Home Products, Inc.
Built-In Microwave
EW27SO60L S

27" Combination Installation Specifications
•
Always consult local and national electric codes.
(Refer to product-specific electrical specifications on this page.)
•
Minimum 23-1/2" deep cutout dimension is critical for proper
combination installation, to ensure that each built-in product’s faceplate
will fit flush against cabinet front.
•
Bases must be level and cabinet front must be square.
•
Minimum 4-1/2"required distance from bottom of Wall Oven cutout
to floor, 31"suggested.
•
Respect critical dimensions as noted for proper installation of built-In
products.
•
Minimum 21" clearance needed for Wall Oven door depth when open.
27" Built-In Microwave Specifications
•
Product Weight – 79 Lbs.
•
Voltage Rating –120V/60Hz/15 Amps
•
Connected Load (kW Rating) @120 Volts = 1.6kW
(For use on adequately wired 120V, dedicated circuit having 2-wire
service with a separate ground wire. Appliance must be grounded
for safe operation.)
•
Amps @120 Volts =13.7 Amps
•
Full oven base of solid plywood or similar material required, capable of
supporting 150 Lbs.
•
Minimum 2-1/8" clearance required from bottom of Built-In Microwave
cutout to top edge of Wall Oven’s faceplate, leaving a 2" visible gap
between both product faceplates.
27" Electric Single Wall Oven Specifications
•
Product Weight – 150 Lbs.
•
Single phase 3- or 4-wire cable, 120/240 or 120/208 Volt, 60 Hertz
AC only electrical supply with ground required on separate circuit fused
on both sides of line.
•
Connected Load (kW Rating) @ 240/208 Volts =
(EW27EW55G) 3.4/2.6kW / (EI27EW35J/EI27EW35K) 3.6/2.7kW
•
Amps @ 240/208 Volts = (EW27EW55G) 14.2/12.5 Amps /
(EI27EW35J/EI27EW35K) 15.0/13.0 Amps
•
Full oven base of solid plywood or similar material required, capable of
supporting 150 Lbs.
•
To adapt oven to fit cutout height between 27-5/8" and 28-1/4", add
one 2"-wide wood shim of appropriate height to each side of opening
under oven side rails. Lifting oven will hide larger cutout opening at
top and oven’s 1"-high bottom trim will hide shims at bottom.
(Standard 1"-High Bottom Trim included.)
•
To adapt oven to fit cutout height between 28-1/4" and 30", optional
3"-High Bottom Trim available.
Note: For planning purposes only. Refer to Product Installation Guide
on the web at electroluxappliances.com for detailed instructions.
27" Combination Installation –
Built-In Microwave/Single Wall Oven
High standards of quality at Electrolux Home Products, Inc. mean
we are constantly working to improve our products. We reserve the right
to change specifications or discontinue models without notice.
Electrolux Major Appliances, N.A.
USA
•10200 David Taylor Drive •Charlotte, NC 28262 •1-877-4electrolux (1-877-435-3287) •
electroluxappliances.com
CANADA
•5855 Terry Fox Way •Mississauga, ON L5V 3E4 •1-800-265-8352 •
electroluxappliances.ca
SODD_EW 27INST EL 02/12 © 2012 Electrolux Major Appliances, NA

27" Combination Installation Specifications
•
Always consult local and national electric codes.
(Refer to product-specific electrical specifications on this page.)
•
Minimum 23-5/8" deep cutout dimension is critical for proper
combination installation, to ensure that each built-in product’s faceplate
will fit flush against cabinet front.
•
Bases must be level and cabinet front must be square.
•
Minimum 4-1/2"required distance from bottom of Warmer Drawer cutout
to floor.
•
Respect critical dimensions as noted for proper installation of built-In
products.
•
Minimum 21" clearance needed for Wall Oven door depth when open.
27" Built-In Microwave Specifications
•
Product Weight – 79 Lbs.
•
Voltage Rating –120V/60Hz/15 Amps
•
Connected Load (kW Rating) @120 Volts = 1.6kW
(For use on adequately wired 120V, dedicated circuit having 2-wire
service with a separate ground wire. Appliance must be grounded
for safe operation.)
•
Amps @120 Volts =13.7 Amps
•
Full oven base of solid plywood or similar material required, capable of
supporting 150 Lbs.
•
Minimum 2-1/8" clearance required from bottom of Built-In Microwave
cutout to top edge of Wall Oven’s faceplate, leaving a 2" visible gap
between both product faceplates.
27" Electric Single Wall Oven Specifications
•
Product Weight – 150 Lbs.
•
Single phase 3- or 4-wire cable, 120/240 or 120/208 Volt, 60 Hertz
AC only electrical supply with ground required on separate circuit fused
on both sides of line.
•
Connected Load (kW Rating) @ 240/208 Volts =
(EW27EW55G) 3.4/2.6kW / (EI27EW35J/EI27EW35K) 3.6/2.7kW
•
Amps @ 240/208 Volts = (EW27EW55G) 14.2/12.5 Amps /
(EI27EW35J/EI27EW35K) 15.0/13.0 Amps
•
To support Wall Oven, two 3"-wide x 3/4"-thick planks must be installed
as a base, capable of supporting 150 Lbs. Do NOT use full base, since
planks are necessary to allow for proper air displacement.
27" Warmer Drawer Specifications
•
Product Weight – 55 Lbs.
•
Voltage Rating –120V/450W/60Hz/15 Amps
•
Connected Load (kW Rating) @120 Volts = 0.45kW
(For use on adequately wired 120V, dedicated circuit having 2-wire
service with a separate ground wire. Appliance must be grounded
for safe operation.)
•
Amps @120V = 3.75 Amps
•
Full base of solid plywood or similar material required, capable of
supporting 100 Lbs.
Note: For planning purposes only. Refer to Product Installation Guide
on the web at electroluxappliances.com for detailed instructions.
27" Combination Installation –
Built-In Microwave/Single Wall Oven/Warmer Drawer
High standards of quality at Electrolux Home Products, Inc. mean
we are constantly working to improve our products. We reserve the right
to change specifications or discontinue models without notice.
Electrolux Major Appliances, N.A.
USA
•10200 David Taylor Drive •Charlotte, NC 28262 •1-877-4electrolux (1-877-435-3287) •
electroluxappliances.com
CANADA
•5855 Terry Fox Way •Mississauga, ON L5V 3E4 •1-800-265-8352 •
electroluxappliances.ca
SODD_EW_WD 27INST EL 02/12 © 2012 Electrolux Major Appliances, NA

General Installation Guidelines
For Installation with Side-by-Side Refrigerator
High standards of quality at Electrolux Home Products, Inc. mean
we are constantly working to improve our products. We reserve the right
to change specifications or discontinue models without notice.
Electrolux Major Appliances, N.A.
USA
•10200 David Taylor Drive •Charlotte, NC 28262 •1-877-4electrolux (1-877-435-3287) •
electroluxappliances.com
CANADA
•5855 Terry Fox Way •Mississauga, ON L5V 3E4 •1-800-265-8352 •
electroluxappliances.ca
INSTGDLNS_SSR EL 02/12 © 2012 Electrolux Home Products, Inc.
Use these dimensions and clearance instructions for planning purposes only. For detailed installation
instructions, refer to installation guide, packed with product, or on the web at electroluxappliances.com.
Top
Front
Front
Top

General Installation Guidelines
For Installation with French Door Refrigerator
High standards of quality at Electrolux Home Products, Inc. mean
we are constantly working to improve our products. We reserve the right
to change specifications or discontinue models without notice.
Electrolux Major Appliances, N.A.
USA
•10200 David Taylor Drive •Charlotte, NC 28262 •1-877-4electrolux (1-877-435-3287) •
electroluxappliances.com
CANADA
•5855 Terry Fox Way •Mississauga, ON L5V 3E4 •1-800-265-8352 •
electroluxappliances.ca
INSTGDLNS_FDR EL 02/12 © 2012 Electrolux Home Products, Inc.
Use these dimensions and clearance instructions for planning purposes only. For detailed installation
instructions, refer to installation guide, packed with product, or on the web at electroluxappliances.com.
Front
Front
Top
Top

General Installation Guidelines
For Installation with All Refrigerator or All Freezer
High standards of quality at Electrolux Home Products, Inc. mean
we are constantly working to improve our products. We reserve the right
to change specifications or discontinue models without notice.
Electrolux Major Appliances, N.A.
USA
•10200 David Taylor Drive •Charlotte, NC 28262 •1-877-4electrolux (1-877-435-3287) •
electroluxappliances.com
CANADA
•5855 Terry Fox Way •Mississauga, ON L5V 3E4 •1-800-265-8352 •
electroluxappliances.ca
INSTGDLNS_ARAF EL 02/12 © 2012 Electrolux Home Products, Inc.
Use these dimensions and clearance instructions for planning purposes only. For detailed installation
instructions, refer to installation guide, packed with product, or on the web at electroluxappliances.com.
Front
Front
Top
Top
