Electrolux NEXT GEN User manual

1
White-Westinghouse
ELECTROLUX HOME PRODUCTS NORTH AMERICA
SERVICE MANUAL
NEXT GEN
30” ELECTRIC
FREESTANDING RANGES
5995361523 December 2001
1111111

2
ATTENTION!!!
Thisservicemanualisintendedforusebypersonshavingelectricalandmechanicaltraining
andalevelofknowledgeofthesesubjectsgenerallyconsideredacceptableintheappliance
repairtrade.ElectroluxHomeProductscannotberesponsible,norassumeanyliability,for
injury or damage of any kind arising from the use of this manual.
©2001WhiteConsolidatedIndustries
SAFE SERVICING PRACTICES - ALL APPLIANCES
Toavoid personalinjuryand/or propertydamage, it isimportant thatSafeServicing
Practicesbe observed. The following are somelimited examplesof safe practices:
1. DO NOT attempt a product repair if you have any doubts as to your ability to
complete it in a safe and satisfactory manner.
2. Before servicing or moving an appliance:
• Removethepower cordfromthe electricaloutlet,trip thecircuitbreaker tothe
OFF position, or remove the fuse.
• Turnoff the gassupply.
• Turnoffthe watersupply.
3. Never interfere with the proper operation of any safety device.
4. USE ONLY REPLACEMENT PARTS CATALOGED FOR THIS APPLIANCE.
SUBSTITUTIONS MAY DEFEAT COMPLIANCE WITH SAFETY
STANDARDS SET FOR HOME APPLIANCES.
5. GROUNDING: The standard color coding for safety ground wires is GREEN, or
GREEN with YELLOW STRIPES. Ground leads are not to be used as current
carrying conductors. It is EXTREMELY important that the service technician
reestablish all safety grounds prior to completion of service. Failure to do so will
create a hazard.
6. Prior to returning the product to service, ensure that:
• All electrical connections are correct and secure
• Allelectricalleads areproperlydressed andsecuredaway fromsharpedges,
high-temperaturecomponents,and movingparts
• Allnon-insulatedelectricalterminals,connectors,heaters,etc.areadequately
spaced away from all metal parts and panels
• All safety grounds (both internal and external) are correctly and securely
connected
• All panels are properly and securely reassembled

3
TABLE OF CONTENTS
Safe servicing practices 2
Quick reference sheet 10
Maximum allowable surface temperatures 11
SECTION A - INSTALLATION 12 - 17
Clearances and dimensions 12
Important safety instructions 13
Tools you will need 13
Normal installation steps 13
Anti-tip bracket installation instructions 13
Electrical connection requirements 14
Grounding instructions 16
Model and serial number location 17
SECTION B - SURFACE ELEMENT CONTROL SYSTEM 18 - 23
Standard Infinite Switch 18 - 19
Troubleshooting 18 - 19
Element does not heat 18
Element does not cycle 19
Indicator light does not glow 19
Indicator light glows full brilliance with all switches off 19
Dual Infinite Switch 19 - 20
Troubleshooting 19 - 20
Both elements do not heat 20
Outer element doesn’t heat, but inner element does 20
Inner element doesn’t heat, but outer element does 20
Elements do not cycle 20
Indicator light does not glow 20
Indicator light glows full brilliance with all switches off 20
Top Element Electronic Control System 21 - 24
Components of the system 21
How it operates 22
Troubleshooting 22 - 24
F5 code 22
F6 code 23
F7 code 23
Blank display 23
Element not heating 23
Warm and Serve Zone 24
Troubleshooting 24
Element does not heat 24
Element does not cycle 25
Indicator light does not glow 25
Indicator light glows full brilliance with switch turned off 25
SECTION C - ELECTRONIC OVEN CONTROL SYSTEMS 26 - 66
The ES 100 Electronic Oven Control System 26 - 29
How to program the ES 100 26 - 27
To set the clock 26
To set the minute timer 26
To change the minute timer while it is in use 26
To cancel the minute timer before the set time has run out 26
To set the controls for baking 26
To change the oven temperature after baking has started 27

4
To broil 27
How the ES 100 operates 27
Bake 27
Broil 27
Calibration 28
The control cannot be calibrated 28
Troubleshooting 28 - 29
F1 code 28
F3 code 28
Control will not program 28
Control will not program 28
Blank Display 28
No heat 28
Bake element does not heat 28
Broil element does not heat 28
Sample schematic for ES100 control system 30
The ES 200 Electronic Oven Control System 31 - 36
How to program the ES 200 31 - 33
Temperature conversion 31
To change the temperature from °F to °C or from °C to °F 31
To set the clock 31
To set the minute timer 31
To change the minute timer while it is in use 32
To cancel the minute timer before the set time has run out 32
To set the controls for baking 32
To change the oven temperature after baking has started 32
To set control for continuous baking 32
To set control for oven lockout feature 32
To broil 32
To set the controls for a self-clean cycle 33
When the self-clean cycle is completed 33
Stopping or interrupting a self-cleaning cycle 33
How the ES 200 operates 33 - 34
Bake 33
Broil 34
Clean 34
Calibration 34
To change the calibration 34
Troubleshooting 34 - 36
F1 code 34
F3 code 34
F9 code 35
Control will not program 35
Blank display 35
Bake element does not heat 35
Broil element does not heat 35
Oven door does not lock when the oven is programmed for clean 35
Oven door locks but the oven does not heat 36
Lock motor runs continuously 36
Door latch is partly closed with door open 36
Sample schematic for ES200 control system 37
The ES 300 Electronic Oven Control System 38 - 45
How to program the ES 300 38 - 45
For a silent control panel 38
To change the temperature from °F to °C or from °C to °F 38
To set the clock 38
To set the minute timer 38

5
To change the minute timer while it is in use 39
To cancel the minute timer before the set time has run out 39
To set the controls for baking 39
To change the oven temperature after baking has started 39
To set control for continuous baking 39
To set control for oven lockout feature 39
To program the oven to begin baking immediately
and to shut off automatically 39
To program oven for a delayed start time
and to shut-off automatically 40
When the set bake time runs out 40
To change the oven temperature or bake
time after baking has started 40
Speed Bake™ 40
To set speed bake cooking system 41
To broil 41
To set the controls for a self-clean cycle 41
When the self-clean cycle is completed 42
Stopping or interrupting a self-cleaning cycle 42
How the ES 300 operates 42 - 45
Bake 42
Time bake 43
Speed bake 43
Broil 43
Clean 43
Calibration 43
To change the calibration 43
Troubleshooting 44 - 45
F1 code 44
F3 code 44
F9 code 44
Control will not program 44
Time bake does not operate 44
Blank display 44
Bake element does not heat 44
Broil element does not heat 45
Oven door does not lock when the oven is programmed for clean 45
Oven door locks but the oven does not heat 45
Lock motor runs continuously 45
Door latch is partly closed with door open 45
Fan in oven does not run when speed bake switch is turned on 45
Sample schematic for ES300 control system 46
The ES 400 Electronic Oven Control System 47 - 55
How to program the ES 400 47 - 52
Clock 47
To set the clock 47
Changing between 12 or 24 hour time of day display 47
Continuous bake or 12 hour energy saving 47
To set the control for continuous bake or 12 hour energy saving 47
Minute timer 48
To set the minute timer 48
To change the minute timer while it is in use 48
To cancel the minute timer before the set time has run out 48
Oven lockout feature 48
To activate the oven lockout 48
To reactivate oven operation 48
Temperature display - Fahrenheit or Celsius 48

6
To change the temperature from °F to °C or from °C to °F 48
Silent control operation 48
To change control from normal sound
operation to silent control operation 48
Preheat 49
48 To set preheat temperature 49
To change the preheat temperature while the oven is preheating 49
Bake 49
To set the bake temperature 49
To change the bake temperature 49
Timed bake 49
To program the oven to begin baking immediately
and to shut off automatically 49
Delay timed bake- cook time and stop time 50
To program oven for a delayed start time and
toshut-off automatically 50
To broil 50
To set the oven to broil 50
Convection bake 51
To set the convection bake feature 51
Convection roast 51
To set the convection roast feature 51
Self-clean cycle 51
To set the controls for the self-cleaning cycle
to start immediately and shut off automatically 51
When the self-clean cycle is completed 52
Stopping or interrupting a self-cleaning cycle 52
How the ES 400 operates 52 - 53
Preheat 52
Bake 52
Time bake 52
Convection bake 52
Convection roast 53
Broil 53
Clean 53
Calibration 53
To change the calibration 53
To adjust the oven temperature higher 53
To adjust the oven temperature lower 53
Troubleshooting 53 - 55
F1 code 53
F3 code 53
F9 code 54
Control will not program 54
Time bake does not operate 54
Convection bake and convection roast 54
Neither the fan motor or the assist element operates 54
If either the convection bake or roast operates
normal but the other does not 54
Fan motor does not operate 54
Assist element does not operate 54
Control does not operate in preheat 54
Blank Display 54
Bake element does not heat 54
Broil element does not heat 55
Oven door does not lock when the oven is programmed for clean 55
Lock motor runs continuously 55

7
Oven door locks but the oven does not heat 55
Door latch is partly closed with door open 55
Sample schematic for ES400 control system 56
The ES 450 Electronic Oven Control System 57 - 66
How to program the ES 450 57 - 62
Clock 57
To set the clock 57
Changing between 12 or 24 hour time of day display 57
Continuous bake or 12 hour energy saving 57
To set the control for continuous bake or 12 hour energy saving 57
Minute timer 58
To set the minute timer 58
To change the minute timer while it is in use 58
To cancel the minute timer before the set time has run out 58
Oven lockout feature 58
To activate the oven lockout 58
To reactivate oven operation 58
Temperature display - Fahrenheit or Celsius 58
To change the temperature from °F to °C or from °C to °F 58
Silent control operation 58
To change control from normal sound
operation to silent control operation 58
Preheat 59
58 To set preheat temperature 59
To change the preheat temperature while the oven is preheating 59
Bake 59
To set the bake temperature 59
To change the bake temperature 59
Timed bake 59
To program the oven to begin baking immediately
and to shut off automatically 59
Delay timed bake- cook time and stop time 60
To program oven for a delayed start time and
toshut-off automatically 60
To broil 60
To set the oven to broil 60
Convection bake 61
To set the convection bake feature 61
Setting food categories feature 61
To set the food categories feature 61
Self-clean cycle 61
To set the controls for the self-cleaning cycle
to start immediately and shut off automatically 62
When the self-clean cycle is completed 62
Stopping or interrupting a self-cleaning cycle 62
How the ES 450 operates 62 - 64
Preheat 62
Bake 62
Time bake 62
Convection bake 63
Fixed settings 63
Meats 63
Cakes 63
Breads 63
Broil 63
Clean 63
Calibration 63

8
To change the calibration 63
To adjust the oven temperature higher 63
To adjust the oven temperature lower 63
Troubleshooting 64 - 65
F1 code 64
F3 code 64
F9 code 64
Control will not program 64
Time bake does not operate 64
Convection bake 64
Neither the fan motor or the assist element operates 64
Fan motor does not operate 64
Assist element does not operate 64
Control does not operate in preheat 64
Blank Display 65
Bake element does not heat 65
Broil element does not heat 65
Oven door does not lock when the oven is programmed for clean 65
Lock motor runs continuously 65
Oven door locks but the oven does not heat 65
Door latch is partly closed with door open 65
Sample schematic for ES450 control system 66
Warmer drawer 67 - 68
To set the warmer drawer thermostat control 67
How the warmer drawer circuit works 67
Troubleshooting 67 - 68
Element does not heat 67
If the element heats during preheat, then stays off
until the temperature drops to about 130° F 68
If the element does not cycle off 68
If the warmer drawer is slow preheating 68
If the warmer drawer heats, but the indicator
light does not glow 68
SECTION D - DISASSEMBLY AND REPLACEMENT OF PARTS 69 - 86
Backguard 69 - 73
To remove the backguard back panel 69
To remove the infinite switches 69
To remove the knobs 69
To remove the potentiometers 69
To remove the user interface board 70
To remove the display window 70
To remove the top elements indicator light 71
To remove the electronic oven control 71
To remove the oven light switch 71
To remove the control panel 71
To remove the end caps 71
To remove the splasher panel 72
Main Top Area 73 - 76
To remove the main top with coil elements 73
To remove the main top on smooth top ranges 74
To remove the main top hinges 75
Top elements 75
To remove coil elements 75
To remove smooth top elements 75
To remove and replace terminal blocks for coil elements 76
To remove the lift and lock rods 76

9
To remove burner pan (coil element ranges only) 76
Oven door 76 - 78
To remove oven door seal 76
To remove oven door 77
Door hinge adjustment 77
Removal of the hinge opening cover 77
Door hinge removal 77
Oven door disassembly 77 - 78
Removing the upper door trim 77
Door handle 78
Outer door glass and trim 78
Center glass 78
Wool shield 78
Glass package and inner door liner 78
Components inside the oven 78 - 80
Bake element 78
Broil element 79
Fan blade (convection/speed bake models) 79
Convection assist element removal 79
Oven vent (coil element models) 79
Oven vent (smooth top models) 80
Removing the oven light cover (self-clean models) 80
Door latch removal (self-clean) 81
Door switch and rod removal (self-clean) 81
Components mounted to the back of the range 81 - 83
Removing the back cover 81
Removing lock motor assembly 81
Removing convection and speed bake motor assemblies 82
Removing oven sensor 82
Removing oven light socket 83
Removing mother board 83
Removing the bodyside panels 83
Storage drawer 84
Removing the storage drawer front panel 84
Removing inside drawer panel 84
Removing storage drawer glides 84
Removing the bottom heat shield 85
Removing bottom wool shield 85
Warmer drawer area 85
Removing the warmer drawer 85
Removing the warmer drawer side rail 85
Removing drawer rail from range frame 86
Removing warmer drawer low limit thermostat 86
Removing the warmer drawer element 86

10
Quick reference sheet
1. Serial number breakdown:
2. Oven sensor resistance chart:
3. Element resistance
RTD SCALE
Temperature Degrees F. Resistance (Ohms)
32 +/- 1.9 1000 +/- 4.0
75 +/- 2.5 1091 +/- 5.3
250 +/- 4.4 1453 +/- 8.9
350 +/- 5.4 1654 +/- 10.8
450 +/- 6.9 1852 +/- 13.5
550 +/- 8.2 2047 +/- 15.8
650 +/- 9.6 2237 +/- 18.5
900 +/- 13.6 2697 +/- 24.4
The wattage rating is stamped on the element. To deter-
mine the resistance divide the wattage by the voltage
rating on the element (either 250 or 120) to obtain the
amperage. Then divide the amperage into the voltage
rating to obtain the resistance. If for some reason you
cannot find the wattage rating, as a general rule most
element’s resistance will be between 15 and 45 Ohms.
N F 1 2 3 1 8 4 7 5
Incremented unit number
Production week
Last digit of production year
Product identification
Manufacturing Facility
