Electrolux 253.72242201 Manual

REPAIR
PARTS
LIST
253.72242201
253.72243201
253.72244201
253.72249201
To Call Toll Free
For Parts:
1-800-366-PART
(1-800-366-7278)
For Service:
1-800-4-MY-HOMESM
(1-800-469-4663)
Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A.
P/N 240535601 Publication number 5995368510
TOP MOUNT
REFRIGERATOR
On all orders or correspondence, avoid delays and misunder-
standings by always giving the complete model number
shown on the serial plate on the top left side of the refrigerator
compartment.
All repair parts listed are available for immediate purchase or
special order when you visit your nearest Sears Service Cen-
ter, or the Service Department at most Sears stores. To order
partsbyphone,callthetollfreepartsnumberlistedtotheleft.
Whenrequestingserviceororderingparts,alwaysprovidethe
following information:
•Product Type •Part Number
•Model Number •Part Description

03/02 2
7224
CAUTION: Use the Kenmore part number to order part, not the illustration number.
DOOR

# = Functional Parts 3 03/02
* = Non-Illustrated Parts
7224
CAUTION: Use the Kenmore part number to order part, not the illustration number.
DOOR
A = 7224 (25372242201)
B = 7224 (25372243201)
C = 7224 (25372244201)
D = 7224 (25372249201)
POS. NO PART NO DESCRIPTION
1 # 240514607 A - C - Gasket-frzr door,white ,magnetic
1 # 240514611 - B - D Gasket-frzr door,black ,magnetic
2 # 240514608 A - C - Gasket-refr door,white ,magnetic
2 # 240514612 - B - D Gasket-refr door,black ,magnetic
7 240338307 A B C D Door-dairy,clear
10 240381301 A - - - Plug-button,white, hinge brg hole ,(2)
10 240381303 - B - D Plug-button,black, hinge brg hole
10 240381302 - - C - Plug-button,bisque, hinge brg hole ,(2)
11 240450309 A - - - Panel-frzr door,white, complete assy
11 240450328 - B - - Door-frzr,stainless steel, complete assy
11 240450310 - - C - Panel-frzr door,bisque ,complete assy
11 240450311 ---D Panel-frzr door,black ,complete assy
13 240312403 A - - - Door Stop,white ,ref
13 240312405 - B - D Door Stop,black ,ref
13 240312407 - - C - Door Stop,bisque ,ref
13A 240312404 A - - - Door Stop,white ,frzr
13A 240312406 - B - D Door Stop,black ,frzr
13A 240312408 - - C - Door Stop,bisque ,frzr
14 240494001 A - - - Plug-button,white
14 240494003 - B - D Plug-button,black
14 240494002 - - C - Plug-button,bisque
15 240450409 A - - - Panel-refr door,white ,complete assy
15 240450434 - B - - Door-refr,stainless steel, complete assy
15 240450410 - - C - Panel-refr door, bisque, complete assy
15 240450411 ---D Panel-refr door, black, complete assy
18 218779901 A - - - Handle-door, white, refr, w/block & screw
18 218779903 - B - D Handle-door,charcoal gray, refr, w/block & screw
18 218779904 - - C - Handle-door, bisque, refr, w/block & screw
18A 218779812 A - - - Handle-frzr door,white
18A 218779814 - B - D Handle-door,charcoal gray ,frzr
18A 218779813 - - C - Handle-door,bisque ,frzr ,w/nameplate, blk & screw
21 240383402 A - - - Screw,truss hd quad, #10-16 x .500, white
21 240383403 - B - D Screw,truss hd quad, #10-16 x .500, black
21 240383404 - - C - Screw,truss hd quad, #10-16 x .500, bisque
21A 240521301 A B C D Screw,#10-16 x 1/2
21C 218252200 A B C D Screw,#8 truss hd ,10-32CA x 0.500
22 240311201 A - C - Bearing-hinge,natural color ,(8)
22 240311202 - B - D Bearing-hinge,black ,(8)
37A 218779310 A - - - Trim-handle,28.18", white, lower, w/mtg locks
37A 218779312 - B - D Trim-handle,28.18", gray, lower, w/mtg locks
37A 218779316 - - C - Trim-handle,28.18", bisque, lower, w/mtg locks
37A* 218074001 A - - - Plug-button,white, refr door front, lower
37A* 218074003 - B - D Plug-button, black, refr door front, lower
37A* 218074004 - - C - Plug-button, bisque, refr door front, lower
37A* 218776501 A B C D Lock-handle trim,stick-on
37A* 218776600 A B C D Lock-handle trim,snap-in
48 240338101 A B C D Bin-door,pseudo ,bottom
48A 240338201 A B C D Bin-door,gallon
49 240495801 A B C D Bin-door,pseudo ,frzr
73 218396700 A B C D Block-handle mtg,dovetail
74 215503200 A B C D Screw,cr pan hd ,10-16 x 0.500
96 240345505 A - C - Plug,door foam hole ,white
96 240345506 - B - D Plug,door foam hole ,black
* 218490900 - B - - Cleaner,stainless steel

03/02 4
7224
CAUTION: Use the Kenmore part number to order part, not the illustration number.
CABINET

# = Functional Parts 5 03/02
* = Non-Illustrated Parts
7224
CAUTION: Use the Kenmore part number to order part, not the illustration number.
CABINET
A = 7224 (25372242201)
B = 7224 (25372243201)
C = 7224 (25372244201)
D = 7224 (25372249201)
POS. NO PART NO DESCRIPTION
1 240355402 A B C D Cover-fan
2 240367001 A B C D Knob-damper control
3 5303001028 A B C D Nut,push-on
4 240367401 A B C D Damper-fan cover
5 # 5308000010 A B C D Fan Blade,red ,evaporator fan
8 5300157666 A B C D Bushing-motor mtg,(2)
9 5303292396 A B C D Bracket-motor mtg,front
10 240313606 A B C D Cover-evap coil
10* 240371303 A B C D Seal,insulation ,53.23 in. long ,foam, coil cover
10*# 240385402 A B C D Wiring Harness,freezer section
11 5303208309 A B C D Plug-hole,factory test
13 # 240369701 A B C D Motor-evap fan
13* 218931001 A B C D Clamp-motor wiring,nylon, w/adhesive tape
14 5303292397 A B C D Bracket-motor mtg,rear
14* 240433201 A B C D Screw,hex washer head ,8-18 x 0.375
18 240411901 A B C D Support-evap cover,(2)
21C 218252200 A B C D Screw,#8 truss hd ,10-32CA x 0.500
22 215774901 A - - - Plug-button,white ,upr hinge holes
22 215774918 - B - D Plug-button,black ,upr hinge holes
22 215774919 - - C - Plug-button,bisque ,upr hinge holes
28 240335501 A B C D Bolt-roller adj,hex washer head, 1/4-20 x 4.020,(2),special
30 240314002 A - - - Bracket-lower hinge,white
30 240314003 - B - D Bracket-lower hinge,black
30 240314004 - - C - Bracket-lower hinge,bisque
34 240311301 A B C D Washer,hinge ,nylon ,(2)
35 240313802 A - - - Bracket-ctr hinge,white
35 240313803 - B - D Bracket-ctr hinge,black
35 240313804 - - C - Bracket-ctr hinge,bisque
35A 240336801 A B C D Spacer-hinge,center
36 240516401 A B C D Pin-center hinge
37 240337601 A - - - Trim-cabinet corner,white ,(2)
37 240337603 - B - D Trim-cabinet corner,black
37 240337604 - - C - Trim-cabinet corner,bisque ,(2)
38 240313701 A B C D Bracket-upper hinge
40 240354401 A - - - Cover-upper hinge,white
40 240354404 - B - D Cover-upper hinge,black
40 240354403 - - C - Cover-upper hinge,bisque
41 5303001609 A B C D Grommet,shelf mtg ,0.69" ,RH
41* 5308009759 A B C D Grommet,shelf mtg ,1.25" ,LH
42 240315301 A B C D Screw-hinge mtg,hex head ,1/4-20 x 0.75
43 240335003 A B C D Roller Assy,front ,(2)
47 218233300 A B C D Channel-shelf mtg,side ,(2)
48 5303292395 A B C D Channel-shelf mtg,center
49 218362500 A B C D Screw,hex washer head, 8-18AB x 1.250
56 240516501 A B C D Pin-lower hinge
58 5303274237 A B C D Screw,hex washer head, 8-32CA x 0.500, motor bracket
59 240442702 A - - - Screw-#10-32 X 3/4,white
59 240442703 - B - D Screw-#10-32 X 3/4,black
59 240442704 - - C - Screw-#10-32 X 3/4,bisque

03/02 6
7224
CAUTION: Use the Kenmore part number to order part, not the illustration number.
CABINET

# = Functional Parts 7 03/02
* = Non-Illustrated Parts
7224
CAUTION: Use the Kenmore part number to order part, not the illustration number.
A = 7224 (25372242201)
B = 7224 (25372243201)
C = 7224 (25372244201)
D = 7224 (25372249201)
POS. NO PART NO DESCRIPTION
72 240368201 A - - - Grille/Kickplate,white
72 240368203 - B - D Grille/Kickplate,black
72 240368202 - - C - Grille/Kickplate,bisque
81 5308016566 A B C D Screw,hex washer head ,8-15A x 0.625, low profile
82 5304418225 A B C D Roller,compressor base ,rear ,(2)
83 5303316859 A B C D Rivet,flat head, 1/4 OD x 1-3/4, roller pin
89 240326115 A B C D Cover-access,with label
89* 241500301 A B C D Screw,hex washer head ,8-18AB x 0.500
92 5303001479 A B C D Screw-hinge mtg,hex hd ,1/4-20 x 0.875
* 218990901 A B C D Clip-wire
* 5303305324 A - - - Paint,touch-up ,white
* 5303305345 - B - D Paint,touch-up ,black
* 5304414035 - - C - Paint,touch-up ,bisque
CABINET

03/02 8
7224
CAUTION: Use the Kenmore part number to order part, not the illustration number.
SHELVES

# = Functional Parts 9 03/02
* = Non-Illustrated Parts
7224
CAUTION: Use the Kenmore part number to order part, not the illustration number.
SHELVES
A = 7224 (25372242201)
B = 7224 (25372243201)
C = 7224 (25372244201)
D = 7224 (25372249201)
POS. NO PART NO DESCRIPTION
11 240358003 A B C D Shelf-freezer
11* 5303299664 A B C D Spacer-shelf
12 240380202 A B C D Diffuser-air,top
13 240362601 A B C D Diffuser-air,bottom
13* 240392601 A B C D Seal-diffuser
14 # 240413601 A B C D Switch,light/lamp ,rocker
15 240436701 A B C D Light Bulb/Lamp, A-15, 40 W, 120 V, miniature
16 241500701 A B C D Socket-light/lamp
17 240368101 A B C D Control Box
17*# 240375501 A B C D Wiring Harness,control box
18 240360801 A B C D Knob-control
21 # 5304421256 A B C D Control-temperature
22A 240468201 A B C D Tube,sensor sleeve, 31 inch, plastic, white
23 # 240375801 A B C D Control-defrost,adaptive timer, PC board
23* 5303001259 A B C D Screw-timer mtg, pan hd, 6-20 x 0.438, (2)
24 240355231 A B C D Shelf-"Spill-Safe",cantilever, half width,fixed
25 240364729 A B C D Cover-crisper pan
25B 240361204 A B C D Knob-humidity control
25C 240361301 A B C D Damper-humidity control
26 240343803 A B C D Pan-crisper,(2)
28 3201150 A B C D End Cap,freezer shelf ,protector
31 240530903 A B C D Pan-meat,w/o graphics ,clear
34 240385201 A B C D Container-ice
42 240356501 A B C D Hanger-meat pan,RH
42 240365401 A B C D Hanger-meat pan,LH
47 240350689 A B C D Insert-pan cover,glass
81 5308016566 A B C D Screw,hex washer head, 8-15A x 0.625, low profile
123 215005100 A B C D Screw-roller/hanger,8-10 x 0.438
* 3205266 A B C D Edge Protector,wiring harness
* 240432303 A B C D Owner’s Manual
* 240379009 A B C D Service Data Sheet
* 240465002 A B C D Label-Energy Guide
* 5303270944 A B C D Label-Use & Care
* 5995368510 A B C D Repair Parts List

03/02 10
7224
CAUTION: Use the Kenmore part number to order part, not the illustration number.
SYSTEM

# = Functional Parts 11 03/02
* = Non-Illustrated Parts
7224
CAUTION: Use the Kenmore part number to order part, not the illustration number.
SYSTEM
A = 7224 (25372242201)
B = 7224 (25372243201)
C = 7224 (25372244201)
D = 7224 (25372249201)
POS. NO PART NO DESCRIPTION
1 240444401 A B C D Condenser,dynamic
4 # 218944001 A B C D Drier-filter,R134a System
6 240496101 A B C D Wiring Harness,machine compt, w/electric cord
6* # 240375501 A B C D Wiring Harness,control box
6* # 240385402 A B C D Wiring Harness,freezer section
14 # 5303918247 A B C D Defrost Heater Kit
15 # 5303918250 A B C D Evaporator Kit
16 5308000110 A B C D Strap-evap/heater,aluminum ,(2)
17 240434002 A B C D Trough-drain
18 240362301 A B C D Insulation Block,RH
20 240362401 A B C D Insulation Block,LH
21 # 5303918202 A B C D Thermostat-defrost,kit
22 240330006 A B C D Plate-compr mtg
22* 218252200 A B C D Screw,#8 truss hd ,10-32CA x 0.500
23 218513300 A B C D Grommet-compr mtg,(4)
25 240491501 A B C D Screw-compressor mtg, 1/4-28 x 1.16,shoulder,typ CF
26 240332602 A B C D Pan-defrost drain
29 # 5303918251 A B C D Compressor,w/electricals
30 # 218721119 A B C D Starter,PTC
32 218973501 A B C D Clamp,elec cont mtg ,compressor
34 240405201 A B C D Grommet,rubber ,black ,cond tube/wire
41 218897001 A B C D Screw,hex washer head ,8-32 x 1/4
44 215174700 A B C D Clamp-service cord,strain relief, galv steel
45 5308016566 A B C D Screw, hex washer head, 8-15A x 0.625, low profile
55 # 216787800 A B C D Capacitor-run
57 240403601 A B C D Clip-wiring harness
58 215004600 A B C D Screw,hx serr wshr hd ,8-36 x 7/16, cond fan motor,(2)
59 240315501 A B C D Shroud-cond fan
59* 240346701 A B C D Tape-foam seal,shroud
59* 240359401 A B C D Screw-fan shroud,(2)
59A 240346501 A B C D Bracket-support,cond mtr ,(3)
59B 240346601 A B C D Grommet-bracket,(3)
60 # 240334001 A B C D Motor,condenser fan
61 # 240315401 A B C D Fan Blade,galv steel ,condenser fan
61A 215004700 A B C D Nut,speed
61B 215004800 A B C D Grommet-silencer
82 5304418225 A B C D Roller,compressor base ,rear ,(2)
83 5303316859 A B C D Rivet,flat head ,1/4 OD x 1-3/4, roller pin
84 240500801 A B C D Tube-drain,lower
85 240346201 A B C D Tube-connector,suction
86 240409302 A B C D Spacer-cond tube,black
* 218843800 A B C D Screw,hex wshr hd ,8-15A x 0.500
* 240396801 A B C D Clamp,tube/wiring ,nylon ,black/natural
* # 5303918210 A B C D Heat Exchanger Kit,suction line
* 5304421289 A B C D Hot Tube Repair Kit,Service

03/02 12
7224
CAUTION: Use the Kenmore part number to order part, not the illustration number.
ICE MAKER

# = Functional Parts 13 03/02
* = Non-Illustrated Parts
7224
CAUTION: Use the Kenmore part number to order part, not the illustration number.
A = 7224 (25372242201)
B = 7224 (25372243201)
C = 7224 (25372244201)
D = 7224 (25372249201)
POS. NO PART NO DESCRIPTION
1 218976901 A B C D Tube-water inlet,inlet valve to ice maker
2 5304420650 A B C D Spring,shut-off arm
2* 5308000039 A B C D Screw,hex washer hd, 8-32CA x 0.500, serrated head
3 3206299 A B C D Label,ID plate
4 3206301 A B C D Gear
5 3206303 A B C D Plate-mounting
6 3206305 A B C D Screw-ground wire,8-32 x 0.250
7 # 3206306 A B C D Motor-ice maker
8 3206312 A B C D Spacer-hold switch
9 3206313 A B C D Cam
10 3206315 A B C D Clamp
11 # 3206319 A B C D Thermal Cutoff,ice maker ,complete assy
12 # 5304420651 A B C D Wiring Harness,ice maker ,internal, with plug
13 # 3206322 A B C D Thermostat Assy,ice maker
14 5304420652 A B C D Screw,4 x 0.750 ,switch mtg.
15 # 3206324 A B C D Switch,(3)
16 5304420653 A B C D Support,phenolic
17 # 5303320545 A B C D Mold-ice maker,Radius Cube ,with heater
18 3206328 A B C D Ejector-ice
19 3206330 A B C D Bearing & Inlet
20 5304408581 A B C D Screw, 8-32 x 0.375
21 3206332 A B C D Ice Stripper
22 3206333 A B C D Shut-off Arm
23 5304408582 A B C D Screw, 8-32 x 0.875, mold-to-support, (3)
24 3206335 A B C D Lever Arm
25 3206336 A B C D Screw, 8-18 x 0.562, lever arm/sprt
26 5304420654 A B C D Screw-thermo/sprt,4-24 x 0.375 ,(4)
27 3206338 A B C D Screw, 4-40 x 1.000, hold switch mtg, (2)
28 3206339 A B C D Screw-timing stop,4-40 x 0.375
29 3206323 A B C D Screw,4-24 x 0.750 ,(6)
30 3206341 A B C D Screw-timing adj,8-32 x 1.000
31 3206342 A B C D Insulator
32 3206343 A B C D Plate-valve switch
33 5304408583 A B C D Spring-timing adj
34 5304420655 A B C D Screw,plazscrew ,8-10 ,(3)
35 5304408585 A B C D Screw
36 3206347 A B C D Cover-ice maker
45 5308016566 A B C D Screw,hex washer head, 8-15A x 0.625, low profile
45* 218843800 A B C D Screw,hex wshr hd ,8-15A x 0.500
51 240387101 A B C D Tube-water, ice mold fill, extension
55 # 240519601 A B C D Valve-water, single solenoid, 60 Hz, 105/120 V
60 218362500 A B C D Screw,hex washer head ,8-18AB x 1.250
61 218721500 A B C D Bracket-leveling,ice maker
62 218737900 A B C D Screw-IM brkt mtg, hex washer head, 8-32D x 0.375
64 5303001549 A B C D Clamp,0.31 ID ,steel ,copper wtr line
* 218888001 A B C D Adapter-water supply, nut & sleeve, compression ftg
* 240352403 A B C D Ice Maker, Radius Cube,115 V, no instl parts
ICE MAKER

03/02 14
7224
CAUTION: Use the Kenmore part number to order part, not the illustration number.
WIRING SCHEMATIC

# = Functional Parts 15 03/02
* = Non-Illustrated Parts
7224
CAUTION: Use the Kenmore part number to order part, not the illustration number.
WIRING DIAGRAM
