Luxury-Glide®Crispers
Drawers smoothly glide out and keep produce
fresh with adjustable humidity control and minimal
temperature variation.
IQ-Touch™Controls
For those who like to have their options always
visible, the IQ-Touch™control panel displays your
options at all times.
9"-Tall Water / Ice Dispenser
Our tall water and ice dispenser is specially
designed to accommodate a variety of large
containers, from a 16-ounce tumbler to a pitcher
or a coffee carafe.
PureAdvantage®Air Filter
Keeps clean, filtered air circulated throughout to
prevent odour transfer.
23 CU. FT. COUNTER-DEPTH REFRIGERATORS
Capacities
Total Capacity
Fresh Food Volume
Freezer Volume
Total Shelf Area
Fresh Food Shelf Area
Freezer Shelf Area
Exterior
Signature Soft-Arc Door and Handle Design
Electronic Controls
Hidden Hinge Door Design
Ice / Water Dispenser
Perfect Set®Temperature Control System and Display
Crushed / Cubes / Water
Air and Water Filter Indicator / Reset
Fast Ice™/ Fast Freeze™
Lock / Dispenser Light Control
Fresh Food Conveniences
PureAdvantage®Water & Ice
PureAdvantage®Air Filtration
Water Filter Location
Temp Alarm System
Door Ajar Alarm / Power Failure Alarm
Glass Shelves
Dual Humidity-Controlled Upper Crisper
Humidity-Controlled Lower Crisper
Perfect Temp®Drawer
Chill Zone™Drawer
Wine and Beverage Mat
Clear Gallon Door Bins
Clear 2-Litre Door Bins
Condiment Bin
Perfect Bin™Door Storage
Dairy Compartment with Clear Cover
Tall Bottle Retainers
Clear In-Door Can Racks (Holds 6 Cans Each)
Luxury-Design®LED Ramp-Up Multilevel
Freezer Conveniences
Automatic Ice Maker with Ice Server
Glass Shelves
Sliding Full-Width Freezer Baskets
Sliding Half-Width Freezer Baskets
Clear Fixed Door Bins
Tilt-Out Wire Door Racks
Ice Cream Shelf
Soft Freeze™Bin
Pizza Shelf
Luxury-Design®LED Ramp-Up Multilevel
Additional Features
ENERGY STAR®
Sabbath Mode (Star-K®Certified)
Specifications
Colour –
Stainless Steel
Product Dimensions –
Height (with Hinges and 3/8" Rollers)
Cabinet Width / Door Width
Depth (to Center of Arc)
Depth (to Center of Arc)
Power Supply Connection Location
Water Inlet Location
Voltage Rating
Connected Load (kW Rating) @ 120 Volts‡
Minimum Circuit Required (Amps)
Shipping Weight (Approx.)
‡An electrical supply with grounded three-prong receptacle is required. The power supply circuit must
be installed in accordance with current edition of National Electrical Code (NFPA 70) and local codes
& ordinances.
NOTE: Always consult local and national electric & plumbing codes. Refer to Product Installation Guide
for detailed installation instructions on the web at electroluxappliances.ca.
Specifications subject to change.
22.7 Cu. Ft.
14.08 Cu. Ft.
8.59 Cu. Ft.
22.31 Sq. Ft.
16.69 Sq. Ft.
5.62 Sq. Ft.
Yes
IQ-Touch™
Yes
Yes
Yes
Yes / Yes / Yes
Yes
Yes / Yes
Yes / Yes
Yes
Yes
Right Rear
Yes
Yes / Yes
3 SpillSafe®Sliding
Luxury-Glide®
Luxury-Glide®
Luxury-Glide®
1 Removable
2 Adjustable
1
2
Yes
Yes
2
1 Luxury-Glide®/ 1 Standard
1
4
Yes
Yes
Yes
Yes
S
69-1/2"
35-5/8" / 36"
28-3/16"
45"
Right Bottom Rear
Left Bottom Rear
120V / 60 Hz / 15 or 20A
1.02
15
325 Lbs.
Counter-Depth Refrigerators
EI23CS35KS
Featuring IQ-Touch™Electronic Controls

High standards of quality at Electrolux Home Products, Inc. mean
we are constantly working to improve our products. We reserve the right
to change specifications or discontinue models without notice.
Counter-Depth Refrigerator Specifications
•
ProductWeight–315Lbs.
•
Anelectricalsupplywithgroundedthree-prongreceptacleisrequired.The
powersupplycircuitmustbeinstalledinaccordancewithcurrentedition
ofNationalElectricalCode(NFPA70)andlocalcodes&ordinances.
•
VoltageRating–120V/60Hz/15or20Amps
•
ConnectedLoad(kWRating)@120Volts=1.02kW
•
Amps@120Volts=8.5Amps
•
Alwaysconsultlocalandnationalelectric&plumbingcodes.
•
Floorshouldbelevelsurfaceofhardmaterial,capableofsupportingfully
loadedrefrigerator.
•
Wheninstallingrefrigeratoradjacenttowall,cabinetorotherappliance
thatextendsbeyondfrontedgeofunit,20"minimumclearance
recommendedtoallowforoptimum120°to180°doorswing,providing
completedrawer/crisperaccessandremoval.(Absolute 4-1/2"
minimum clearance will ONLY allow for 90° door swing which will provide
drawer / crisper access with restricted removal.)
•
Toensureoptimumperformance,avoidinstallingindirectsunlightorclose
proximitytorange,dishwasherorotherheatsource.
•
Forproperventilation,frontgrilleMUSTremainunobstructed.
•
Recesselectricaloutletwhenpossible.
•
Waterrecessonrearwallrecommendedtopreventwaterlinedamage.
•
WaterPressure–Coldwaterlinemustprovidebetween30and100
poundspersquareinch(psi).
•
Coppertubingwith1/4"O.D.recommendedforwatersupplylinewith
lengthequaltodistancefromrearofunittohouseholdwatersupplyline
plus7additionalfeet.OptionalWaterSupplyInstallationKitsavailable.
•
Adjustablefrontrollerstoassistwithdooralignment.
“Built-In Look” Specifications
•
Minimumopeningof70-1/4"Hx36"Wx25"Drequiredtoallowforease
ofinstallation,properaircirculation,andplumbing/electricalconnections.
•
Removeallwall/floormoldingpriortoinstallation.
Note: For planning purposes only. Refer to Product Installation Guide
on the web at electroluxappliances.ca for detailed instructions.
Counterdepth Refrigerator
EI23CS35K
