Electrolux EN3855MFX User manual

EN3855MFX
EN Fridge Freezer User Manual

CONTENTS
1. SAFETY INFORMATION....................................................................................2
2. SAFETY INSTRUCTIONS..................................................................................4
3. CONTROL PANEL............................................................................................. 6
4. DAILY USE......................................................................................................... 7
5. CARE AND CLEANING......................................................................................8
6. TROUBLESHOOTING........................................................................................9
7. INSTALLATION................................................................................................ 11
8. TECHNICAL DATA...........................................................................................12
WE’RE THINKING OF YOU
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that
brings with it decades of professional experience and innovation. Ingenious and
stylish, it has been designed with you in mind. So whenever you use it, you can
be safe in the knowledge that you’ll get great results every time.
Welcome to Electrolux.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.electrolux.com/webselfservice
Register your product for better service:
www.registerelectrolux.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.electrolux.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
responsible for any injuries or damages that are the
result of incorrect installation or usage. Always keep the
www.electrolux.com2

instructions in a safe and accessible location for future
reference.
1.1 Children and vulnerable people safety
•This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a
safe way and understand the hazards involved.
•Do not let children play with the appliance.
•Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
•Keep all packaging away from children and dispose of
it appropriately.
1.2 General Safety
•This appliance is intended to be used in household
and similar applications such as:
–Farm houses; staff kitchen areas in shops, offices
and other working environments
–By clients in hotels, motels, bed and breakfast and
other residential type environments
•Keep ventilation openings, in the appliance enclosure
or in the built-in structure, clear of obstruction.
•Do not use mechanical devices or other means to
accelerate the defrosting process, other than those
recommended by the manufacturer.
•Do not damage the refrigerant circuit.
•Do not use electrical appliances inside the food
storage compartments of the appliance, unless they
are of the type recommended by the manufacturer.
•Do not use water spray and steam to clean the
appliance.
•Clean the appliance with a moist soft cloth. Only use
neutral detergents. Do not use abrasive products,
abrasive cleaning pads, solvents or metal objects.
ENGLISH 3

•Do not store explosive substances such as aerosol
cans with a flammable propellant in this appliance.
•If the supply cord is damaged, it must be replaced by
the manufacturer, its Authorised Service Centre or
similarly qualified persons in order to avoid a hazard.
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must
install this appliance.
• Remove all the packaging and the
transit bolts.
• Do not install or use a damaged
appliance.
• Follow the installation instruction
supplied with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Make sure the air can circulate
around the appliance.
• At first installation or after reversing
the door wait at least 4 hours before
connecting the appliance to the power
supply. This is to allow the oil to flow
back in the compressor.
• Before carrying out any operations on
the appliance (e.g. reversing the
door), remove the plug from the
power socket.
• Do not install the appliance close to
radiators or cookers, ovens or hobs.
• Do not install the appliance where
there is direct sunlight.
• Do not install this appliance in areas
that are too humid or too cold, such
as the construction appendices,
garages or wine cellars.
• When you move the appliance, lift it
by the front edge to avoid scratching
the floor.
2.2 Electrical connection
WARNING!
Risk of fire and electrical
shock.
• The appliance must be earthed.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to
the electrical components (e.g. mains
plug, mains cable, compressor).
Contact the Authorised Service
Centre or an electrician to change the
electrical components.
• The mains cable must stay below the
level of the mains plug.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
2.3 Use
WARNING!
Risk of injury, burns,
electrical shock or fire.
• Do not change the specification of this
appliance.
• Do not put electrical appliances (e.g.
ice cream makers) in the appliance
unless they are stated applicable by
the manufacturer.
• Be careful not to cause damage to the
refrigerant circuit. It contains
isobutane (R600a), a natural gas with
a high level of environmental
compatibility. This gas is flammable.
• If damage occurs to the refrigerant
circuit, make sure that there are no
www.electrolux.com4

flames and sources of ignition in the
room. Ventilate the room.
• Do not let hot items to touch the
plastic parts of the appliance.
• Do not put soft drinks in the freezer
compartment. This will create
pressure on the drink container.
• Do not store flammable gas and liquid
in the appliance.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
• Do not touch the compressor or the
condenser. They are hot.
• Do not remove or touch items from
the freezer compartment if your hands
are wet or damp.
• Do not freeze again food that has
been thawed.
• Obey the storage instructions on the
packaging of frozen food.
2.4 Internal light
• The type of lamp used for this
appliance is not suitable for
household room illumination
2.5 Care and cleaning
WARNING!
Risk of injury or damage to
the appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains
plug from the mains socket.
• This appliance contains hydrocarbons
in the cooling unit. Only a qualified
person must do the maintenance and
the recharging of the unit.
• Regularly examine the drain of the
appliance and if necessary, clean it. If
the drain is blocked, defrosted water
collects in the bottom of the
appliance.
2.6 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains cable and discard it.
• Remove the door to prevent children
and pets to be closed inside of the
appliance.
• The refrigerant circuit and the
insulation materials of this appliance
are ozone-friendly.
• The insulation foam contains
flammable gas. Contact your
municipal authority for information on
how to discard the appliance
correctly.
• Do not cause damage to the part of
the cooling unit that is near the heat
exchanger.
ENGLISH 5

3. CONTROL PANEL
5°
8°
2°
1
2
3
4
1Temperature scale
2EcoMode icon
3FastFreeze icon
4Temperature key
3.1 Switching on
1. Plug the appliance into electrical
mains socket.
2. To turn on the appliance, touch the
temperature key until all LED
indicators light up.
After approximately 3
seconds LED indicators fade
and the temperature is set to
the default setting
(EcoMode). LED indicator
next to EcoMode icon
illuminates.
3.2 Switching off
1. To switch off the appliance press the
temperature key for 3 seconds.
All LED indicators turn off.
2. To disconnect the appliance from the
electrical supply, remove the mains
plug from the power socket.
3.3 Temperature regulation
To regulate the temperature, press the
temperature key. Every time the key is
pressed, the set temperature moves by 1
position and corresponding LED indicator
lights up. Press the temperature key
repeatedly until the required temperature
is selected. The setting will be fixed.
Selection is progressive,
varying from +2°C to +8°C.
Coldest setting: +2°C.
Warmest setting: +8°C
Most suitable setting:
EcoMode (+3 to +4°C).
Choose the setting keeping in mind that
the temperature inside the appliance
depends on:
• room temperature
• frequency of opening the door
• quantity of food stored
• appliance location.
3.4 Sleep mode of the display
After 30 seconds of no interaction with
the appliance, the display goes into the
sleep mode. Only LED indicator
corresponding to currently set
temperature illuminates in low light. All
other LED indicators are off. To
deactivate this mode press the
temperature key.
www.electrolux.com6

3.5 ECO mode
Use this function for the best food
preservation results with minimal energy
consumption.
To switch on ECO mode, touch the
temperature key repeatedly until LED
indicator next to the ECO mode icon
lights up.
In this mode, the temperature stays
between +3° C and +4° C.
3.6 FastFreeze function
If you need to insert a large amount of
warm food into fridge compartment (for
example after doing the grocery
shopping) or rapidly decrease the
temperature in the freezer compartment
to freeze fresh food quickly, we suggest
activating FastFreeze function for proper
food storage.
To activate this function press the
temperature key repeatedly until the LED
indicator next to FastFreeze icon lights
up. Also LED indicator corresponding to
+2°C illuminates.
This function stops
automatically after 52 hours.
When the function
deactivates, the previous
temperature setting is
restored.
You can deactivate this
function at any time by
pressing the temperature
key and choosing a new
temperature setting.
This function corresponds
both to fridge and freezer
compartment.
4. DAILY USE
4.1 Freezing fresh food
The freezer compartment is suitable for
freezing fresh food and storing frozen
and deep-frozen food for a long time.
To freeze fresh food activate the
FastFreeze function at least 24 hours
before placing the food to be frozen in
the freezer compartment.
Place the fresh food to be frozen in the
top compartment.
The maximum amount of food that can
be frozen in 24 hours is specified on the
rating plate, a label located on the
inside of the appliance.
The freezing process lasts 24 hours:
during this period do not add other food
to be frozen.
When the freezing process is completed,
return to the required temperature (see
"FastFreeze Function").
In this condition, the
refrigerator compartment
temperature might drop
below 0°C. If this occurs
reset the temperature
regulator to a warmer
setting.
4.2 Storage of frozen food
When first starting-up or after a period
out of use, before putting the products in
the compartment let the appliance run at
least 2 hours with the FastFreeze
function turned on.
If large quantities of food are to be
stored, remove all drawers from
appliance and place food on glass shelf
to obtain the best performance.
ENGLISH 7

In the event of accidental
defrosting, for example due
to a power failure, if the
power has been off for
longer that the value shown
in the technical data chart
under "Rising time", the
defrosted food must be
consumed quickly or cooked
immediately and then re-
frozen (after cooling).
4.3 Storage of the food in a
fridge compartment
Cover or wrap the food, particularly if it
has a strong flavour.
Position the food so that air can circulate
freely around it.
Keep the food on all shelves no closer
than 20 mm from the rear wall and 15
mm from the door.
4.4 FREESTORE
The FREESTORE function lets the food
cool quickly and keeps a more uniform
temperature in the compartment. It is
recommended to switch on the
FREESTORE function when the ambient
temperature exceeds 25°C.
To activate FREESTORE device press
the button on it.
The green light comes up.
When you switch off the
appliance remember to turn
off the fan by pressing
button again.
The green light comes off.
5. CARE AND CLEANING
WARNING!
Refer to Safety chapters.
5.1 Cleaning the interior
Before using the appliance for the first
time, the interior and all internal
accessories should be washed with
lukewarm water and some neutral soap
to remove the typical smell of a brand-
new product, then dried thoroughly.
CAUTION!
Do not use detergents,
abrasive powders, chlorine
or oil-based cleaners as they
will damage the finish.
5.2 Periodic cleaning
CAUTION!
Do not pull, move or damage
any pipes and/or cables
inside the cabinet.
CAUTION!
Take care of not to damage
the cooling system.
CAUTION!
When moving the cabinet, lift
it by the front edge to avoid
scratching the floor.
The equipment has to be cleaned
regularly:
1. Clean the inside and accessories
with lukewarm water and some
neutral soap.
2. Regularly check the door seals and
wipe clean to ensure they are clean
and free from debris.
3. Rinse and dry thoroughly.
4. If accessible, clean the condenser
and the compressor at the back of
the appliance with a brush.
This operation will improve the
performance of the appliance and
save electricity consumption.
www.electrolux.com8

5.3 Defrosting of the
refrigerator
Frost is automatically eliminated from the
evaporator of the refrigerator
compartment every time the motor
compressor stops, during normal use.
The defrost water drains out through a
trough into a special container at the
back of the appliance, over the motor
compressor, where it evaporates.
It is important to periodically clean the
defrost water drain hole in the middle of
the refrigerator compartment channel to
prevent the water overflowing and
dripping onto the food inside.
5.4 Periods of non-operation
When the appliance is not in use for long
periods, take the following precautions:
1. Disconnect the appliance from
electricity supply.
2. Remove all food.
3. Clean the appliance and all
accessories.
4. Leave the door/doors open to
prevent unpleasant smells.
6. TROUBLESHOOTING
WARNING!
Refer to Safety chapters.
6.1 What to do if...
Problem Possible cause Solution
The appliance is noisy. The appliance is not sup‐
ported properly.
Check if the appliance
stands stable.
The lamp does not work. The lamp is in stand-by
mode.
Close and open the door.
The lamp does not work. The lamp is defective. Contact the nearest Author‐
ised Service Centre.
The compressor operates
continually.
Temperature is set incor‐
rectly.
Refer to "Operation"/"Control
panel" chapter.
Many food products were
put in at the same time.
Wait a few hours and then
check the temperature
again.
The room temperature is
too high.
Refer to climate class chart
on the rating plate.
ENGLISH 9

Problem Possible cause Solution
Food products placed in
the appliance were too
warm.
Allow food products to cool
to room temperature before
storing.
The FastFreeze function
is switched on.
Refer to "FastFreeze func‐
tion".
The compressor does not
start immediately after
pressing the FastFreeze
or after changing the tem‐
perature.
This is normal, no error
has occurred.
The compressor starts after
some time.
Water flows inside the re‐
frigerator.
The water outlet is clog‐
ged.
Clean the water outlet.
Food products prevent
water from flowing into
the water collector.
Make sure that food prod‐
ucts do not touch the rear
plate.
Water flows on the floor. The melting water outlet
is not connected to the
evaporative tray above
the compressor.
Attach the melting water out‐
let to the evaporative tray.
Temperature cannot be
set.
The FastFreeze or Shop‐
pingMode function is
switched on.
Switch off FastFreeze or
ShoppingMode manually, or
wait until the function resets
automatically to set the tem‐
perature. Refer to "Fast‐
Freeze or ShoppingMode
function".
The temperature in the
appliance is too low/too
high.
The temperature regulator
is not set correctly.
Set a higher/lower tempera‐
ture.
The food products tem‐
perature is too high.
Let the food products tem‐
perature decrease to room
temperature before storage.
Many food products were
stored at the same time.
Store less food products at
the same time.
The FastFreeze function
is switched on.
Refer to "FastFreeze func‐
tion".
Side panels of the appli‐
ance are warm.
This is a normal state
caused by operation of
the heat exchanger.
Make sure that there is at
least 30 mm of space be‐
tween each side of the appli‐
ance and the surrounding
furniture when the ambient
temperature exceeds 38°C.
www.electrolux.com10

Problem Possible cause Solution
There is too much con‐
densed water on the rear
wall of the refrigerator.
Door was opened too fre‐
quently.
Open the door only when
necessary.
Door was not closed com‐
pletely.
Make sure the door is closed
completely.
Stored food was not
wrapped.
Wrap food in suitable pack‐
aging before storing it in the
appliance.
Door does not open easi‐
ly.
You attempted to re-open
the door immediately after
closing.
Wait a few seconds between
closing and re-opening of the
door.
If the advice does not lead to
the desired result, contact
the nearest Authorised
Service Centre.
6.2 Replacing the lamp
The appliance is equipped with a longlife
LED interior light.
Only service is allowed to replace the
lighting device. Contact your Authorised
Service Centre.
7. INSTALLATION
WARNING!
Refer to Safety chapters.
7.1 Positioning
This appliance can be installed in a dry,
well ventilated indoor where the ambient
temperature corresponds to the climate
class indicated on the rating plate of the
appliance:
Climate
class
Ambient temperature
SN +10°C to + 32°C
N +16°C to + 32°C
ST +16°C to + 38°C
T +16°C to + 43°C
7.2 Location
It must be possible to
disconnect the appliance
from the mains power
supply. The plug must
therefore be easily
accessible after installation.
The appliance should be installed well
away from sources of heat such as
radiators, boilers, direct sunlight etc.
Ensure that air can circulate freely
around the back of the cabinet. To
ensure best performance, if the
appliance is positioned below an
overhanging wall unit, the minimum
distance between the top of the cabinet
and the wall unit must be at least
100mm. Ideally, however, the appliance
should not be positioned below
overhanging wall units. One or more
adjustable feet at the base of the cabinet
ensure that the appliance stands level.
ENGLISH 11

AB
100 mm min
20 mm
CAUTION!
In order to guarantee proper
functioning in ambient
temperature above 38°C, it
is advised to have a 30mm
separation between the
sides of the appliance and
surrounding furniture.
7.3 Levelling
When placing the appliance ensure that
it stands level. This can be achieved by
two adjustable feet at the bottom in front.
7.4 Electrical connection
• Before plugging in, ensure that the
voltage and frequency shown on the
rating plate correspond to your
domestic power supply.
• The appliance must be earthed. The
power supply cable plug is provided
with a contact for this purpose. If the
domestic power supply socket is not
earthed, connect the appliance to a
separate earth in compliance with
current regulations, consulting a
qualified electrician.
• The manufacturer declines all
responsibility if the above safety
precautions are not observed.
• This appliance complies with the
E.E.C. Directives.
7.5 Door reversibility
In case you want to change the opening
direction of the door, contact the nearest
Authorised Service Centre. The
Authorised Service specialist will carry
out the reversibility of the doors at your
cost.
8. TECHNICAL DATA
According to 1/1998. (I. 12.) IKIM
ministerial decree
Producer Electrolux
Product category Refrigerator -
Freezer
Height 2010 mm
Width 595 mm
Depth 647 mm
Fridge net capacity 258 l
Freezer net capacity 91 l
www.electrolux.com12

Energy class (from A++
to G, where A++ is the
most efficient, G is the
least efficient )
A++
Energy consumption
(depending on the us‐
age and the placement)
251 kWh/y
Star rating ****
Rising time 18 h
Freezing capacity 4 kg/24h
Climatic class SN-N-ST-T
Voltage 230 - 240 V
Frequency 50 Hz
Noise level 43 dB/A
Built-in No
The technical information is situated in
the rating plate, on the external or
internal side of the appliance and in the
energy label.
9. ENVIRONMENTAL CONCERNS
Recycle the materials with the symbol
. Put the packaging in applicable
containers to recycle it. Help protect the
environment and human health and to
recycle waste of electrical and electronic
appliances. Do not dispose appliances
marked with the symbol with the
household waste. Return the product to
your local recycling facility or contact
your municipal office.
*
ENGLISH 13

www.electrolux.com14

ENGLISH 15

www.electrolux.com/shop
280156927-B-222017
