Electrolux E23CS78EPS User manual

241540102 (0408)
Dishwasher
Use & Care Guide
Side-By-Side Refrigerator

2Finding Information
PLEASE READ AND SAVE THIS GUIDE
Thank you for choosing Electrolux, the new premium brand in home appliances.
This Use & Care Guide is part of our commitment to customer satisfaction and
product quality throughout the service life of your new refrigerator.
We view your purchase as the beginning of a relationship. To ensure our ability to
continue serving you, please use this page to record key product information.
MAKE A RECORD FOR QUICK REFERENCE
________________________________________________
Purchase Date
________________________________________________
Electrolux Model Number
________________________________________________
Electrolux Serial Number (see picture for location)
QUESTIONS?
For toll-free telephone support in the U.S. and Canada:
1-877- 4ELECTROLUX (1-877-435-3287)
For online support and Internet product information:
www.electroluxusa.com
©2003 Electrolux Home Products, Inc.
Post Office Box 212378, Augusta, Georgia 30917, USA
All rights reserved. Printed in the USA
NONO
NONO
NOTETE
TETE
TE
Registering your product with Electrolux enhances our ability to
serve you. You can register online (at the Internet address below)
or by dropping your Product Registration Card in the mail.
Attach your sales
receipt to this
page for future
reference.

3
Finding Information
TABLE OF CONTENTS
Finding Information ............................................ 2
Please ReadAnd Save This Guide.................. 2
MakeARecord For Quick Reference............... 2
Questions? ....................................................... 2
Table Of Contents ............................................ 3
Safety ................................................................... 4
Important Safety Instructions ........................... 4
Electrical Information........................................ 5
Removing The Doors .......................................... 6
Getting Through Narrow Spaces...................... 6
Connecting The Water Supply ........................... 9
About Your Refrigerator’s Water Supply .......... 9
Feature Overview .............................................. 11
Understanding FeaturesAnd Terms................11
Controls & Settings .......................................... 12
Allowing Cooling Time Before Use................. 12
Setting Cooling Temperatures........................ 12
System-MonitoringAlarms ............................. 14
TurningThe Cooling System OnAnd Off....... 15
Storage Features............................................... 16
Cantilever Shelves ......................................... 16
Drawers.......................................................... 17
Doors.............................................................. 18
Accessories.................................................... 19
Automatic Ice & Water Dispenser ................... 20
Using The Dispenser...................................... 20
Using The Dispenser Control Panel............... 21
Priming The Water Supply System ................ 22
Ice Dispenser Operation & Care .................... 23
Changing The Filter .......................................... 26
Locating The Water Filter ............................... 26
Ordering Replacement Filters ........................ 26
Replacing The Water Filter............................. 26
Storing Food & Saving Energy ........................ 29
Ideas For Storing Foods................................. 29
Ideas For Saving Energy................................ 30
Normal Operating Sounds & Sights ............... 31
Understanding The SoundsYou May Hear.... 31
Care & Cleaning ................................................ 32
Protecting Your Investment ............................ 32
Care & Cleaning Tips ..................................... 33
Vacation & Moving Tips.................................. 33
Replacing Light Bulbs .................................... 34
Warranty Information ........................................ 35
Solutions To Common Problems .................... 36
Before You Call .............................................. 36

4Safety
IMPORTANT SAFETY INSTRUCTIONS
General Safety
• Do not store or use gasoline, or other flammable liquids, near this or any
other appliance. Read product labels for warnings regarding flammability and
other hazards.
• Do not operate the refrigerator in the presence of explosive fumes.
• Avoid contact with any moving parts of the automatic ice maker.
• Remove all staples from the carton to avoid cut injuries. Staples can also
damage finishes if they come in contact with other appliances or furniture.
Child Safety
Packing Materials:
• Packing cartons covered with rugs, bedspreads, plastic sheets or stretch
wrap may become airtight chambers and can quickly cause suffocation.
• Destroy or recycle the product’s carton, plastic bags, and any other exterior
wrapping material immediately after the refrigerator is unpacked. Children
should never play with these items.
Child Entrapment And Suffocation:
• These problems are not limited to the past. Whether
junked, abandoned or temporarily stored (even for a
few hours), unattended refrigerators and freezers are
dangerous. Please take the precautions listed below.
Proper Disposal Of Refrigerators And Freezers
Before you throw away your old refrigerator/freezer:
• Remove the doors.
• Leave the shelves in place so children may not easily
climb inside.
• Have refrigerant removed by a qualified service
technician.
!
WARNINGWARNING
WARNINGWARNING
WARNING
Please read all safety instructions before using your new Electrolux refrigerator.

5
Safety
ELECTRICAL INFORMATION
•The refrigerator must be plugged into its own dedicated 115 Volt, 60 Hz.,
AC-only electric outlet. The power cord of the appliance is equipped with a
three-prong grounding plug for your protection against electrical shock
hazards. It must be plugged directly into a properly grounded three-prong
receptacle. The receptacle must be installed in accordance with local codes
and ordinances. Consult a qualified electrician. Do not use an extension
cord or adapter plug.
• If the power cord is damaged, it should be replaced by
the manufacturer, service technician or a qualified
person to prevent any risk.
• Never unplug the refrigerator by pulling on the power
cord. Always grip the plug firmly, and pull straight out
from the receptacle to prevent damaging the power
cord.
• Unplug the refrigerator before cleaning and before
replacing a light bulb to avoid electrical shock.
• Performance may be affected if the voltage varies by
10% or more. Operating the refrigerator with
insufficient power can damage the compressor. Such
damage is not covered under your warranty.
• Do not plug the unit into an outlet controlled by a wall
switch or pull cord to prevent the refrigerator from being turned off
accidentally.
• Avoid connecting refrigerator to a Ground Fault Interruptor (GFI) circuit.
IMPORIMPOR
IMPORIMPOR
IMPORTT
TT
TANTANT
ANTANT
ANT
To turn off power to your refrigerator, unplug the power cord from the wall outlet.
!
WARNINGWARNING
WARNINGWARNING
WARNING
You must follow these guidelines to ensure that your refrigerator’s safety mechanisms are
operating correctly.

6Removing The Doors
GETTING THROUGH NARROW SPACES
If your refrigerator will not fit through an entrance area, you can reduce its size by
removing the doors. Check first by measuring the entrance.
Required Tools
You will need the following tools:
To prepare for removing the doors:
1Make sure the electrical power cord is unplugged from the wall outlet.
2Open both doors and remove the toe grille (as explained in the Installation
Instructions that came with your appliance).
3Remove any food from the door shelves.
4Close the doors.
NONO
NONO
NOTETE
TETE
TE
For more information on removing the toe grille, please refer to the Installation Instructions.
Adjustable
Wrench
Socket
Wrench Set
OR
Phillips Head
™
Tools Necessary:
3/8” Fixed
Wrench
AND OR

7
Removing The Doors
To remove the top hinge cover:
1Remove the three screws from
the cover over the top door
hinges.
2Pull the cover forward about a
half-inch and lift it off.
To remove the refrigerator door:
1Trace lightly around the door’s top hinge with a pencil. This makes
reinstallation easier.
2Remove the two screws from the top hinge. Lift the door off of the
bottom hinge and and set it aside.
3Remove the three bottom hinge screws and hinge if necessary.
To reinstall the refrigerator door, reverse the above steps. Once both doors
are in place, also replace the top hinge cover.
!
CACA
CACA
CAUTIONUTION
UTIONUTION
UTION
Be sure doors are set aside in a secure position where they cannot fall and cause
personal injury.

8Removing The Doors
To remove the freezer door:
1Detach the multi-wire cable connector located above the top hinge.
Grasp both sides of the connector firmly and pull apart.
2Trace lightly around the hinge with a pencil.
This makes reinstallation easier.
3Detach the water tube from the connector located below the freezer
door. The connector releases when you press its outer sleeve inward.
4Remove the screws from the top hinge and
pull the multi-wire cable through it. Lift the
door off of the bottom hinge.
5Remove the three bottom hinge screws and hinge if necessary.
6Lay the door on its side to avoid damage to the water tube extending
from the bottom hinge.
To reinstall the freezer door, reverse the above steps. Once both doors
are in place, also replace the top hinge cover (see Page 7).

9
Connecting The Water Supply
ABOUT YOUR REFRIGERATOR’S WATER SUPPLY
The automatic ice & water dispenser on your refrigerator requires a permanent
water supply to function correctly. During installation, you (or a service
professional) establish this water supply by connecting a copper tube from your
household water system to a valve at the rear of the refrigerator.
You may have already followed the directions in the Installation Instructions to
connect the water supply. This information is repeated here for future reference if
you need to relocate your refrigerator.
What you will need:
• Access to a cold water line with pressure of 20-100 psi.
• Copper tubing with ¼-inch (6.4mm) OD. Length for this tubing is the distance
from the rear of the refrigerator to your household water supply line plus 7
feet (2.1 meters).
• A shut-off valve for the connection between your household water line and
the refrigerator supply line.
Do not use a self-piercing shut-off valve.
• A compression nut and ferrule (sleeve) for the water supply connection at the
rear of your refrigerator.
!
CACA
CACA
CAUTIONUTION
UTIONUTION
UTION
To avoid property damage:
• Use copper tubing for the water supply line (plastic tubing is more
likely to leak). Manufacturer is not responsible for any damage if
plastic tubing is used for supply line.
• Ensure water supply complies with local plumbing codes.
• For proper dispenser operation, recommended water supply pressure
should fall between 20 psi and 100 psi. Excessive pressure may cause
water filter to malfunction.
NONO
NONO
NOTETE
TETE
TE
Electrolux Kit #53039117950, available from your dealer, provides all materials for a water
supply installation, including 25 feet of copper tubing and full instructions.

10 Connecting The Water Supply
To connect the water supply to the rear of your refrigerator:
1Ensure that the refrigerator is not plugged in.
2Flush the supply line until water is clear by placing the end of the copper tube
in a sink or bucket and opening the shut-off valve.
3Unscrew the plastic cap from the water valve inlet at
the rear of your refrigerator. Discard the cap.
4Slide the brass compression nut, then the ferrule
(sleeve) onto copper tube.
5Push the copper tube into water valve inlet as far as it
will go (1/4 inch).
6Slide the ferrule (sleeve) into valve and finger-tighten
the compression nut onto valve. Tighten another half
turn with a wrench. Do not over-tighten.
7Secure the copper tube to your refrigerator’s rear panel
with a steel clamp and screw (see illustration).
8Coil the excess copper tubing (about 2½ turns) behind
your refrigerator as shown. Arrange coiled tubing to
avoid vibration or wear against other surfaces.
9Open water supply shut-off valve and tighten any
connections that leak.
NONO
NONO
NOTETE
TETE
TE
After connecting the water supply, see page 22 for information about priming an empty
water supply system. Also read all topics in the “Automatic Ice & Water Dispenser” section
to learn about normal operating procedures.

11
Feature Overview
UNDERSTANDING FEATURES AND TERMS
Your Electrolux refrigerator is designed for optimal convenience and storage
flexibility. Use the illustration below to familiarize yourself with product features and
terminology.
NONO
NONO
NOTETE
TETE
TE
Features may vary according to model.

12 Controls & Settings
ALLOWING COOLING TIME BEFORE USE
To ensure reliable food storage, allow your refrigerator and freezer to operate with
the doors closed for 8 to 12 hours before placing food inside. During this cooling
period, you do not need to adjust the controls, which are preset at the factory.
SETTING COOLING TEMPERATURES
Your refrigerator comes with a state-of-the-art electronic digital control system. The
system’s control panel is located at the top of the the fresh food compartment.
The two digital displays on the left half of the control panel
indicate the current temperatures of your freezer and fresh
food compartments.
To adjust the temperature to a higher or lower setting, press the Up or Down
Arrow button closest to the display. The first time you press the button, the display
shows the last setting you entered. Each press of the button after that increments
the setting by one degree.
The display shows your new setting momentarily, then changes back to the current
temperature. (Refer to page 13 for more about temperature settings.)
NONO
NONO
NOTETE
TETE
TE
The advanced electronic control system in your refrigerator includes additional display
modes that service professionals can use to rapidly diagnose performance issues.

13
Controls & Settings
Choosing Fahrenheit or Centigrade
Depending on which temperature standard you
prefer to use, you can set your control panel to
display in fahrenheit or centigrade. To change
between fahrenheit and centigrade, press the
Mode button (located between the two digital
temperature displays).
Making Temperature Adjustments
After running your refrigerator for 24 hours, you can adjust temperatures as
needed. Make your adjustments small and gradual, allowing time for temperatures
to change and stabilize. Refer to the following guidelines for temperature settings.
What To Do If The Temperature Displays Flash
If ever you you see both temperature displays continuously flashing, it may indicate
that the control system has detected a performance problem. Call your Electrolux
service representative, who can interpret the flashing message.
Temperature Control Range
Freezer Fresh Food
Fahrenheit Centigrade Fahrenheit Centigrade
Warmest 6°-14°47°8°
Warmer
Factory Setting Midpoint 0°-18°37°3°
Coldest -6°-21°33°1°
Colder
Press to alternate between
Fahrenheit and Centigrade
Temperature Adjustment Guide
If Fresh Food compartment is too warm
Adjust Fresh Food control one degree
colder by pressing Down Arrow button.
If Fresh Food compartment is too cold
Adjust Fresh Food control one degree
warmer by pressing the Up Arrow button.
If Freezer compartment is too warm
Adjust Freezer control one degree colder
by pressing Down Arrow button.
If Freezer compartment is too cold
Adjust Freezer control one degree warmer
by pressing the Up Arrow button.

14 Controls & Settings
SYSTEM-MONITORING ALARMS
The electronic control system continuously
monitors your refrigerator/freezer for temperature
consistency, doors left ajar, and power failures.
Variances from normal operating conditions are
communicated by audible tones and a set of four
status indicator lights.
Responding to Alarms (Audible Tones & Indicator Lights)
Your refrigerator’s control system can convey the following information through
audible tones and the alarm indicator lights.
Alarm
Name
Indicator
Light
Audible
Tones Condition How To Respond
On (light is
off)
Alarm system is not active
while Freezer and Fresh
Food compartments are
cooling toward the current
temperature settings.
If Freezer and Fresh Food
compartments do not match your
temperature settings in three hours,
expect the control system to signal
other conditions. If cooling does not
stabilize toward your current settings,
call 1-877-435-3267 for assistance.
Steady
Green
Alarm system is active. No response required.
Door
Ajar
Flashing
Green 9Freezer or Fresh Food
door has been open for
over five minutes.
Close door to disable and reset alarm.
High
Temp
Flashing
Amber 9Freezer or Fresh Food
compartment has been too
warm (45°F or higher) for
over an hour.
Press Alarm Reset button to turn off
alarm. If temperatures do not improve,
call 1-877-435-3267 for assistance.
Power
Failure
Flashing
Amber
A power outage was
detected.
Press Alarm Reset button to turn off
alarm and again to reset. Check if the
power failure lasted long enough to
affect stored food temperatures.
NONO
NONO
NOTETE
TETE
TE
Each time you make settings on the control panel, a
single audible tone acknowledges your input.
Alarm Reset Button
Indicator Lights

15
Controls & Settings
Using The Alarm Reset Button
You can disable or activate the alarm system by pressing and holding the Alarm
Reset button for three seconds. Use it, for example, to turn off audible tones and/
or flashing indicator lights.
Once you disable the alarm system, you must again press and hold the Alarm
Reset button for three more seconds to reset (activate) the alarm system. The On
indicator light remains off while the Freezer and Fresh Food compartments cool
toward the current temperature settings. When temperature settings are reached,
the On light displays green to indicate an active alarm system.
TURNING THE COOLING SYSTEM ON AND OFF
You can disable the cooling system in your
refrigerator by pressing the On/Off button
located on the left side of the temperature
control panel.
To ensure that you do not accidentally turn
off the cooling system, the button does not
work unless you press and hold it for three
seconds.
Once you disable the cooling system, all
refrigeration to the freezer and fresh food
compartments stops.
To turn the cooling system back on, you must again press and hold the On/Off
button for three more seconds.
!
CACA
CACA
CAUTIONUTION
UTIONUTION
UTION
The alarm system does not automatically reset if you disconnect and reconnect your
refrigerator’s power cord. It can only be reactivated by pressing the Alarm Reset button.
IMPORIMPOR
IMPORIMPOR
IMPORTT
TT
TANTANT
ANTANT
ANT
The On/Off button only controls your refrigerator’s cooling system. Power to lights and
other electrical components continues unless you unplug the power cord.
Cooling System On/Off Button

16 Storage Features
CANTILEVER SHELVES
You can easily adjust shelf positions in the freezer and fresh food compartments to
suit your needs. The shelves have mounting brackets, which attach to slotted
supports at the rear of each compartment.
To change the position of a shelf:
1Before adjusting a shelf, remove all food.
2Lift the front edge up.
3Pull the shelf out.
4Replace by inserting the mounting bracket hooks into
the desired support slots.
5Lower the shelf and lock into position.
Shelf Features
Your refrigerator includes SpillSafeTM glass shelves, which
are designed to catch and hold accidental spills. These
shelves slide out for easy access to food and faster
cleaning.
Sliding shelves can be pulled forward as far as their built-in
stops allow. Sliding shelves cannot be separated from their
mounting brackets.
!
CACA
CACA
CAUTIONUTION
UTIONUTION
UTION
To avoid injury from breakage, handle tempered glass shelves carefully.
Cantilever Aspect
Glass Shelf
Cantilever
Glass Shelf
Cantilever
Sliding Glass
Shelf

17
Storage Features
DRAWERS
Your refrigerator includes a variety of storage drawers. These drawers usually are
located in fixed positions at the bottom of the fresh food compartment.
Crispers
Crisper drawers are designed for storing fruits, vegetables,
and other fresh produce. Before storing items in a crisper:
• Wash items in clear water and remove excess water.
• Wrap any items that have strong odors or high
moisture content.
Crisper Humidity Control
Crisper drawers include a sliding control for adjusting the
humidity inside the crisper. This feature can extend the life
of certain fresh vegetables that keep longer in high
humidity.
Meat Keeper
Some models are equipped with a meat keeper drawer for
short term storage of bulk meat items. This drawer includes
a sliding control for adjusting the temperature inside.
Any meat to be kept longer than two days should be frozen.
If you store fruits or vegetables in this drawer, set it to a
warmer temperature to prevent freezing.
NONO
NONO
NOTETE
TETE
TE
Leafy vegetables keep best when stored with the Humidity Control set on Higher Humidity,
or in a drawer without a Humidity Control. This keeps incoming air to a minimum and
maintains maximum moisture content.
Crisper
Meat Keeper

18 Storage Features
DOORS
Storage Bins
The doors to your freezer and fresh food compartments use a
system of modular storage bins. All of these bins are removable
for easy cleaning. Some of them have fixed positions, while
others can be adjusted to your needs.
Door bins are ideal for storing jars, bottles, cans, and large drink
containers. They also enable quick selection of frequently used
items.
To change the position of an adjustable door bin:
1Before adjusting a bin, remove all food.
2Grip the bin firmly with both hands and lift it upward.
3Remove the bin.
4Place the bin just above desired position.
5Lower the bin onto supports until locked in place.
Door Bin With
Tilt Shelf

19
Storage Features
ACCESSORIES
Tall Bottle Retainer
The tall bottle retainer keeps tall containers in the bin from falling forward
when opening or closing the refrigerator door. To install, snap the ends of
the retainer over the edge of the retainer wall as shown in the illustration.
Special Items Rack
The innovative design of the special items rack allows you to store a six-
pack of 12 ounce drink cans, a bottle of wine, a two-liter soft drink bottle,
or a carton of eggs. To install, slide the special item rack onto the left
side of any shelf as shown in the illustration.
Dairy Compartment
Use the dairy compartment, at the top of the fresh food compartment
door, for short term storage of cheese, spreads, or butter. The dairy
compartment, which includes a lift-up cover, is designed to be warmer
than the open storage area to accommodate these types of food.
Can Rack
The can rack allows you to efficiently and
securely store up to six twelve-ounce cans
of beverage drink.
Ice Cream Shelf
The ice cream shelf attaches to the top of
the ice dispenser container. It allows
storage of both round and rectangular
cartons of your favorite ice cream.
Tall Bottle
Retainer
Special Items
Rack
Can Rack
Dairy
Compartment
!
CACA
CACA
CAUTIONUTION
UTIONUTION
UTION
To avoid errors in your refrigerator’s control system, do not remove the magnet
that is mounted behind the dairy compartment.
Ice Cream
Shelf

20 Automatic Ice & Water Dispenser
USING THE DISPENSER
Your automatic ice & water dispenser includes a control panel, a
drinking glass bay, and two push-paddles for turning on the ice and
water supplies.
Using the dispenser control panel is necessary for the ice dispenser
but not the water dispenser. The control panel also includes options
for lighting, filter monitoring, and increasing the rates of ice making
and freezing.
Dispensing Ice
To operate the ice dispenser, press
an option for crushed or cubed ice
on the control panel. Press a
drinking glass against the
dispensing paddle (as far up as
possible to catch all the ice). To
stop, pull the glass away from the
dispensing paddle.
See details for operating the
dispenser controls on page 21.
Dispensing Water
To operate the water dispenser, press a drinking glass against the dispensing
paddle. To stop dispensing water, pull the glass away from the dispensing paddle.
The dispensed water is not cold. For colder water, first add crushed ice or cubes to
your drinking glass.
Drip Tray
A drip tray located at the base of the dispenser bay catches small spills and allows
them to evaporate. This drip tray is removable for easy cleaning.
NONO
NONO
NOTETE
TETE
TE
Please do not pour excess water and ice into the drip tray. It does not have a drain.
