Electrolux ENB 38607 W User manual

GB
User manual
ENB 38607 W
ENB 38607 W8
ENB 38607 X
fridge - freezer

We were thinking of you
when we made this product

electrolux 3
GB
WWeellccoommeettootthheewwoorrllddooffEElleeccttrroolluuxx
Thank you for choosing a first class product from Electrolux, which hopefully will
provide you with lots of pleasure in the future. The Electrolux ambition is to offer a
wide variety of quality products that make your life more comfortable. You find some
examples on the cover in this manual. Please take a few minutes to study this
manual so that you can take advantage of the benefits of your new machine. We
promise that it will provide a superior User Experience delivering Ease-of-Mind.
Good luck!

4electrolux GB
Before installing and using the appliance read this user's instruction book
carefully. It contains safety precautions, hints, information and ideas. If the
refrigerator is used in compliance with these instructions, it will operate
properly and provide you with the greatest satisfaction.
The symbols below help you to find things more easily:
Safety precautions
Warnings and information at this symbol serve safety for you and your appliance.
Hints, useful information
Environmental information
Symbol for ideas
At this symbol ideas can be found according to food and its storing.
The symbol on the product or on its packaging indicates that this
product may not be treated as household waste. Instead it should be
taken to the appropriate collection point for the recycling of electrical
and electronic equipment. By ensuring this product is disposed of
correctly, you will help prevent potential negative consequences for
the environment and human health, which could otherwise be caused
by inappropriate waste handling of this product. For more detailed
information about recycling of this product, please contact your local
council; your household waste disposal service or the shop where you
purchased the product.

electrolux 5
service agent or qualified service
personnel.
If the power plug socket is loose,
do not insert the power plug.
- There is a risk of electric shock or
fire.
Any electrical work required to install
this appliance should be carried out
by a qualified electrician or
competent person.
Parts which heat up should not be
exposed. Whenever possible, the
back of the appliance should be
close to a wall, but leaving the
required distance for ventilation, as
stated in the installation instructions.
The appliance should be left for 2
hours after installation before it is
turned on, in order to allow the
refrigerant to settle.
Child Safety
Do not allow children to tamper with
the controls or play with the product.
Keep packaging materials away from
children, to prevent the risk of
suffocation!
This appliance is not intended for use
by persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience
and knowledge, unless they have
been given supervision or instruction
concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to
ensure that they do not play with the
appliance.
GB
IMPOR
IMPORT TANT S ANT SAFET AFETY INS Y INSTR TRUCTIONS UCTIONS
These warnings are provided in the interests of your safety. Ensure that you
understand them all before installing or using this appliance. Your safety is of
paramount importance. If you are unsure about any of the meanings or these
warnings contact the Customer Care Department.
Prior to installation
Check the appliance for transport
damage. Under no circumstances
should a damaged appliance be
installed. In the event of damage
please contact your retailer.
Installation
This appliance is heavy. Care should
be taken when moving it.
It is dangerous to alter the
specifications or attempt to modify
this product in any way.
Ensure that the appliance does not
stand on the electrical supply cable.
If the supply cable is damaged, it
must be replaced by a cable
available from your local Service
Force Centre.
Make sure that the power plug
has not been squashed or
damaged during transit.
- A damaged power plug may
overheat and cause a fire.
As you unpack the appliance,
check carefully for any signs of
transit damage.
Do not place heavy articles or the
fridge/freezer itself on the power
cord.
- There is a risk of a short circuit and
fire.
Do not remove the power cord by
pulling on its lead, particularly
when the fridge/freezer is being
pulled out of its niche.
- Damage to the cord may cause a
short-circuit, fire and/or electric
shock.
- If the power cord is damaged, it
must be replaced by a certified

6electrolux
Safety precautions for isobutane
Warning
The refrigerant isobutane (R 600a) is
contained within the refrigerant
circuit of the appliance, a natural gas
with a high level of environmental
compatibility, which is nevertheless
flammable.
Keep ventilation openings, in the
appliance enclosure or in the built-in
structure, clear of obstruction.
Do not use mechanical devices or
other means to accelerate the
defrosting process, other than those
recommended by the manufacturer.
Do not damage the refrigerant
circuit.
Do not use electrical appliances
inside the food storage
compartments of the appliance.
During Use
This appliance is designed for
domestic use only, specifically for
the storage of edible foodstuffs. It is
not intended for commercial or
industrial use.
Containers with flammable gases or
liquids can leak at low temperatures.
Do not store any containers with
flammable materials, such as spray
cans, fire extinguisher refill
cartridges etc. in the appliance.
Frozen food should not be refrozen
once it has thawed out.
Do not place carbonated or fizzy
drinks in the freezer compartment.
Ice lollies can cause 'frost/freezer
burns' if consumed straight from the
freezer.
Do not remove items from the freezer
compartment if your hands are
damp/wet, as this could cause skin
abrasions or frost/freezer burns.
Bottles and cans must not be placed
in the freezer compartment they can
burst when the contents freeze.
Manufacturers' recommended
storage times should be adhered to.
Refer to relevant instructions.
Maintenance and Cleaning
Before cleaning, always switch off
the appliance and disconnect from
the electrical supply.
When unplugging always pull the
plug from the mains socket, do not
pull on the cable.
Servicing
This product should be serviced by
an authorised engineer and only
genuine spare parts should be used.
Under no circumstances should you
attempt to repair the appliance
yourself. Repairs carried out by
inexperienced persons may cause
injury or serious malfunctioning.
Contact your local Service Force
Centre.
At the end of the Appliance Life
When disposing of your appliance
use an authorised disposal site.
Remove the plug and ensure that any
locks or catches are removed, to
prevent young children being
trapped inside.
The Appliance and the
Environment
This appliance does not contain gases
which could damage the ozone layer.
Avoid damaging the cooling unit.
The packaging used on this appliance
marked with the symbol is
recyclable.
Keep this instruction book for
future reference and ensure it is
passed on to any new owner.
GB

electrolux 7
GB
Contents
Instructions for the User
Important safety information......................................................................5
Instructions for the User ............................................................................9
General information.................................................................................9
Use ......................................................................................................9
Control panel ....................................................................................9
Display .............................................................................................9
First switch on ...................................................................................9
Switching off ...................................................................................10
Functions Menu ...............................................................................10
Select / Switch off / Switch on each compartment ....................................10
Temperature selection.......................................................................10
Switching off on compartment ............................................................11
Ambient Temperature Function ...........................................................11
Child lock Function...........................................................................11
Use of the fridge compartment ................................................................11
How to use the refrigerator.................................................................11
Temperature regulation......................................................................11
Holiday Function ..............................................................................11
Shopping Function ...........................................................................12
Eco mode Function ..........................................................................12
The Refrigerator ...............................................................................12
Fresh Box .......................................................................................12
Storage Shelves...............................................................................12
Storage Times .................................................................................12
DrinksExpress device ............................................................................13
How to chill down drinks?..................................................................13
The DrinksExpress device in stand-by mode.........................................14
Cleaning the device ..........................................................................14
Use of the freezer compartment ..............................................................15
Temperature regulation......................................................................15
Excessive temperature alarm..............................................................15
Door open acoustic alarm..................................................................15
Freezing fresh food...........................................................................15
Frozen Food Storage ........................................................................16
Removal of freezing baskets from the freezer........................................16
Thawing ..........................................................................................17
To Make Ice Cubes...........................................................................17
Hints & Tips.....................................................................................17
Normal Operating Sounds .................................................................17
Food Storage ..................................................................................17
Energy Saving Advice .......................................................................18
In the Event of a Power Failure ...........................................................18

8electrolux GB
Maintenance and Cleaning ................................................................19
External Cleaning .............................................................................19
When the Appliance is not in Use........................................................19
Defrosting .......................................................................................19
To Change the Light Bulb ..................................................................20
Something Not Working .........................................................................21
Service and Spare Parts ..........................................................................22
Customer Care Department.....................................................................22
Guarantee Conditions .............................................................................23
Instructions for the Installer .....................................................................25
Technical data ......................................................................................25
Installing the appliance ..........................................................................25
Transportation, unpacking .................................................................25
Cleaning.........................................................................................25
Location .........................................................................................25
Levelling the Appliance .....................................................................26
Ventilation Requirements ...................................................................26
Removal of glass shelf blockers from the product..................................27
Door reversal...................................................................................27
Electrical Connection........................................................................30
Storage time chart .................................................................................31

electrolux 9
GB
General information
The official designation of the appliance
is "partial frostfree refrigerator-freezer
combination with one motor compressor
and freezer placed in the lower part". The
appliance has - besides the general
services - a freezer with its own door and
is completely separated from the other
unit.
According to this the appliance is suitable
for storing frozen and deep-frozen food,
freezing products in quantity given in the
user's instructions at home and making
ice. The appliance can meet the
requirements of standards between
different temperature limits according to
the climate class.
The letter symbol for climate class can be
found on the data label.
Instructions for the User
Use
Control panel
A - Appliance button ON/OFF
B - Temperature regulation button
C - Temperature and function indicator
D - Function button
E - Confirmation button
DISPLAY
if on the indicated compartment is on;
if on the indicated temperature is that
of the relative compartment
if it flashes the operations corresponds to
the relative compartment
Excessive temperature alarm
If on the temperature indicated is the
ambient temperature
Positive or negative Temperature
indicator
Temperature indicator
If on the child lock function is on
If on the time function is on
If on the shopping function is on
If on the DrinksExpress function is on
If on the fast freeze function is on
If on the Eco mode function is on
First switch on
After plugging the plug into the power
outlet, if the display is not illuminated,
press key (A), to turn the appliance on.
As soon as the appliance is turned on, it
is in alarm mode, the temperature flashes
and you will hear a buzzer.
Press key (E) and the buzzer will go off
(also see the section on "excessive
temperature alarm") The icon still
flashes and the warmest temperature
reached will appear on the display.

10 electrolux GB
Ambient Temperature Function
The ambient temperature function is
activated by pressing key D (several times
if necessary) until the corresponding icon
appears .
In this condition the selected temperature
is the ambient temperature.
You must confirm the choice by pressing
key E within few seconds. You will hear
the buzzer and the icon remains lit.
It is possible to de-activate the function at
any time by pressing key D until the
corresponding icon will flash and then
key E.
Child lock Function
The child lock function is activated by
pressing key D (several times if
Switching off
The appliance is shut off by pressing key
(A) for more than 1 second. After this, a
countdown of the temperature from -3 -2
-1 will be shown.
When the appliance is shut off, the
ambient temperature is shown and the
corresponding icon is lit.
Functions Menu
The functions menu is accessed by
pressing the key (D). Each function could
be confirmed by pressing button E. If
there is no confirmation after some
seconds the display will go out from the
menu and return in normal condition.
The following functions are indicated:
Select/Switch off/Switch on
fridge compartment
Select/Switch off/Switch on
freezer compartment
Ambient Temperature
Child lock function
Shopping function
Eco mode function
Fast freeze function
DrinksExpress function
Select /Switch off /Switch on
each compartment
Temperature selection
The temperature may be regulated by
pressing the key (D) to select the
compartment and than the key (B) to set
the desired temperature.
By pressing the key (B) the current
temperature setting flashes on the
indicator. To confirm the choice of the
temperature press the key (E).
You will hear the buzzer for few seconds
and the indicator displays the newly
selected temperature for a few seconds,
then shows again the inside
compartment temperature.
The newly selected-temperature must be
reached after 24 hours.
After a long period out of use it is not
necessary to set the temperature again
because it remains stored.
For the correct storage of the food select
the Eco mode function that guarantee the
following temperatures are set:
+5°C in the fridge
-18°C in the freezer
Wait until the inside temperature
reaches -18°C, before putting food in
the freezer compartment.
To select a different temperature see
"Temperature regulation".

electrolux 11
Attention!
A difference between the temperature
displayed and temperature setting is
normal. Especially when:
- a new setting has recently been
selected
- the door has been left open for a long
time
- warm food has been placed in the
compartment.
Holiday Function "H"
The holiday function sets the temperature
at + 15°C.
This function allows you to keep the
refrigerator shut and empty during a long
holiday period ( e. g. the summer
holidays) without the formation of
unpleasant smells.
1. To turn on the holiday function modify
the selected temperature. The
temperature indicator can change the
displayed temperature up to + 8 °C, 1 °at
a time. + 2 °C will be followed by the
letter "H ". Press key E to confirm.
Now the refrigerator is in the "holiday
"function in the energy- saving mode.
Attention!
The fridge compartment must be empty
with holiday function on.
Shopping Function
If you need to insert a large amount of
warm food, for example after doing the
grocery shopping, we suggest activating
the Shopping function to chill the
products more rapidly and to avoid
GB
necessary) until the corresponding icon
appears .
You must confirm the choice by pressing
key E within few seconds. You will hear
the buzzer and the icon remains lit.
In this condition any possible operation
through the keys does not cause any
change as long as this function is
activated.
It is possible to de-activate the function at
any time by pressing key D until the
corresponding icon flashes and then key
E.
Use of the fridge compartment
How to use the refrigerator
Sufficient air circulation is required
for the proper operation of this
appliance. For this reason you are asked
not to cover the air circulation gaps
behind the shelves (e.g. with tray etc.).
Do not put hot food into the
refrigerator. Allow it to reach
room temperature naturally. In this
way the unnnecessary frost building
up can be avoided.
Food odours can be
transferable, so it is essential to
put foods in closed dishes or wrap
them in cellophane, aluminium foil,
grease-proof paper or cling film
before placing them into the
refrigerator. This way foods will keep
their moisture e.g. vegetables will not
dry out after some days.
Temperature regulation
The temperature of this compartment
may be regulated between +2°C and
+8°C.
During normal functioning the indicator
shows the temperature inside the fridge.

12 electrolux GB
The Refrigerator
Below is the recommended storage
positions for various food types:
1. Ready-cooked foods, fresh meat, cold
cuts.
2. Milk, dairy products.
3. Fruits, vegetables, salads.
4. Cheese, butter.
5. Eggs.
6. Yoghurt, sour cream.
7. Small bottles, drinks.
8. Large bottles, drinks.
Eco mode Function
The Eco mode function is activated by
pressing key D (several times if
necessary) until the corresponding icon
appears .
You must confirm the choice by pressing
key E within few seconds. You will hear
the buzzer and the icon remains lighted.
In this condition the chosen temperatures
are automatically set (+ 5°C e - 18°C), in
the best conditions for storing food It is
possible to de-activate the function at any
time by changing the selected
temperature in one of the compartment.
Shopping Function
If you need to insert a large amount of
warm food, for example after doing the
grocery shopping, we suggest activating
the Shopping function to chill the
products more rapidly and to avoid
warming the other food which is already
in the refrigerator.
The shopping function is activated by
pressing key D (several times if
necessary) until the corresponding icon
appears .
You must confirm the choice by pressing
key E within few seconds. You will hear
the buzzer and the icon remains lit.
The shopping function shuts off
automatically after approximately 6
hours.
It is possible to de-activate the function at
any time by pressing key D until the
corresponding icon will flash and then
key E.
Storage Shelves
The shelves in the refrigerator
compartment are adjustable to allow for
the storage of large items.
To re-arrange the shelves, open the door
to 90°.
Storage Times
The storage chart at the end of the
instruction book gives information on
storage times in the refrigerator
compartment. The storage times quoted
are intended as a guide only.
Do not cover the shelves with paper or
trays etc. as this will affect the air
circulation within the refrigerator

electrolux 13
GB
compartment.
Do not put hot foods in the
refrigerator, allow hot foods to reach
room temperature naturally before
placing in the refrigerator.
Cover foods, or place in closed dishes
before placing them in the refrigerator,
this prevents any transference of food
smells.
DrinksExpress device
This DrinksExpress device can rapidly
chill a variety of packaged beverages
faster than in the fridge and in the freezer.
The capacity is large enough for
beverages from 330ml up to 2l.
If properly used, risk of bottle freezing is
avoided.
Main parts of the device
1 - User interface (UI)
2 - Control button On/Off & selection
3 - Tray
4 - Door
The DrinksExpress device
The DrinksExpress user interface
How to chill down drinks?
(See the pictures in chapter "Main parts
of the device)
Open the DrinksExpress door and place
the vessel inside on the tray.
Close the door.

14 electrolux
Hold down the control button for 1sec to
turn ON the system / device.
Set the type of beverage and start the
cooling with the control button on the
device user interface (UI).
If you push the button once then the LED
on the DrinksExpress display lights up to
the first beverage type (Type A).
If you push it once again within the next 3
seconds then the vessel Type B will be
preselected. Continuing pressing it and
you will move on the next Type of vessel
until you arrive at the last Type (Type F).
Pressing on more time and you will turn
off the unit.
Once you have selected the type of
vessel, following the previous guidelines,
just leave the unit as it is (LED blinking),
and after 3 seconds it will initiate the
cooling automatically.
Immediately you will see on the external
display on top of the refrigerator an icon
being activated (bottle icon as on the
figure below).
GB
Activating icons for DrinksExpress function on the
topdisplay
Once the cooling cycle is finished, you
will receive an acoustic signal as the
bottle icon on the external display is
blinking.
This acoustic signal will be repeated
every 10 seconds during a period of 30
minutes after which the DrinksExpress
unit will automatically switch off. You can
manually deactivate the acoustic signal
and switch off the DrinksExpress unit by
pressing the control button.
Vessel capacity of the DrinksExpress
unit:
Inside DrinksExpress unit you can chill
down up to:
8 cans of 0.33 cl or 0.5 cl
4 PET bottles of 0.5 cl
2 wine bottles 0.75 lt
a 2lt Tetrapak
a 1.5 lt PET bottle or even a Magnum
bottle
The DrinksExpress device in
stand-by mode
In stand-by mode this specific
compartment is a refrigerated zone that
can be used as extension of the fresh
food compartment for storing food or
beverages.
The temperature inside the
DrinksExpress device when not in use
is at the same level as the crisper bin
beside.
Cleaning the device
DrinksExpress device is easy to clean
because it has a flat surface inside that
can be easily cleaned with a damp
cloth.
A removable plate on the bottom
collects any possible drink spillage and
condensation water: it can be removed
for cleaning even under hot water (but it
is not recommended to put it into a
dishwasher).

electrolux 15
GB
Use of the freezer compartment
The freezer is provided with the
symbol which means that it is
suitable for freezing fresh food and
for long term storage of frozen and
deep-frozen food.
Temperature regulation
The temperature may be regulated
between -16°C and -22°C.
We suggest setting the internal
temperature of approximately -18°C,
which guarantees proper freezing and
conservation of the frozen foods.
Attention!
A difference between the temperature
displayed and temperature setting is
normal. Especially when:
- a new setting has recently been
selected
- the door has been left open for a long
time
- warm food has been placed in the
compartment
A difference up to 5°C inside the
compartment is normal.
During normal functioning the indicator
shows the warmest temperature inside
the compartment.
Important
In the event of accidental defrosting,
for example due to a power failure, if
the power has been off for longer
than the value shown in the technical
characteristics chart under "rising
time", the defrosted food must be
consumed quickly or cooked
immediately and then refrozen (after
cooling).
Excessive temperature alarm
An increase in the temperature in the
freezer compartment (for example due to
an power failure) is indicated by:
- flashing temperature;
- freezer compartment flashing ;
- flashing of the icon ;
- sounding of buzzer.
When normal conditions are restored:
- the acoustic signal shuts off;
- the temperature value continues to
flash;
When you press key "E" to deactivate the
alarm, the highest temperature reached
in the compartment appears on the
display for some seconds. Then it returns
to normal operation showing the
temperature of the selected
compartment.
During the alarm phase, the buzzer can
be switched off by pressing key E.
Door open acoustic alarm
An acoustic alarm will sound when the
door is left open for around 5 minutes.
The door open alarm conditions are
indicated by:
- flashing symbol of the relative
compartment
- sounding of buzzer.
Press the key (E) to stop the acoustic
alarm.
When normal conditions are restored
(door closed):
- the acoustic alarm will stop.
Freezing fresh food
The freezer compartment is suitable for
long term storage of commercially frozen
and deep-frezen food, and for freezing
fresh food.

16 electrolux GB
Frozen Food Storage
When using for the first time or if the
freezer has been out of use for some
time, we advise you to run your appliance
for at least 2 hours before storing frozen
food.
Do not exceed the storage period
indicated by the manufacturer.
Do not open the door frequently or leave
it open longer than is necessary.
It is practical to replace frozen products
into the basket(s) after freezing has
finished. Doing this you could make room
in the freezing compartment for furtner
freezing. Intermediate freezing does not
deteriorate foods already stored.
If large quantities of food are to be
stored, remove the baskets except the
lowest one from appliance and place
food on the shelves.
Removal of freezing baskets from
the freezer
The freezing baskets have a limit stop to
prevent their accidental removal or falling
out. To remove from the freezer, pull the
basket towards yourself and, upon
reaching the end point, remove the
basket by tilting its front upwards.
To put it back, slightly lift the front of the
basket to insert it into the freezer. Once
you are over the end points, push the
baskets back in their position.
The maximum quantity of foods to freeze
in 24 hours is shown on the rating
To freeze the amount of food indicated on
the rating plate, place the food directly
onto the cooling surface (remove the
drawer or basket).
In case the food is frozen inside the
drawers or baskets, the maximum
quantity is slightly reduced.
Place the food to be frozen in the
compartment, as this is the coldest point.
To freeze fresh foods, you will need to
activate the fast freeze function. Press
key D (several times if necessary) until
the corresponding icon appears
You must confirm the choice by pressing
key E within few seconds. You will hear
the buzzer and on the display will appear
some animation with lines.
After a pre-cooling period of 24 hours,
place the foods in the freezer.
The freezing process takes 24 hours.
During this period do not put other foods
in the freezer.
This function stops automatically after 52
hours.
It is possible to de-activate the function at
any time by pressing key D until the
corresponding icon flashes and then key
E.

electrolux 17
GB
Important
Do not put carbonated liquids in the
freezer.
Ice lollies, if consumed immediately after
removal from the freezer can cause a low
temperature skin burn.
In the event of a power cut the food in the
freezer will not be affected if the power
cut is short and the freezer is full. Do not
open the door. Should the food begin to
thaw it must be consumed quickly and
must not be re-frozen. (See Hints and
Tips)
Do not remove items from the freezer if
your hands are damp/wet, as this could
cause skin abrasions or frost/freezer
burns.
Thawing
Deep frozen or frozen food, prior to being
used, can be thawed in the fridge or at
room temperature, depending on the
time available. Small food items may even
be cooked from frozen, in this case
cooking will take longer.
Any frozen food which is thawed
accidentally should either be eaten as
soon as possible, or thrown away.
Alternatively, if the food is uncooked and
has not been completely defrosted it can
be cooked and then refrozen.
Defrosted cooked food must
never be refrozen.
)To Make Ice Cubes
1. Fill the ice cube tray ¾full with cold
water, place in the freezing
compartment and leave to freeze.
2. To remove the cubes twist the tray or
hold it under running water for a few
seconds.
Never try to free an ice tray that is
frozen to the freezer compartment by
using pointed or sharp edged objects.
Hints & T
Hints & Tips ips
Normal Operating Sounds
You may hear faint gurgling or
bubbling sounds when the refrigerant
is pumped through the coils or tubing.
When the compressor is on, the
refrigerant is being pumped round and
you will hear a whirring sound or
pulsating noise from the compressor.
A thermostat controls the compressor
and you will hear a faint 'click' when
the thermostat cuts in and out.
Food Storage
To obtain the best performance from your
freezer:

18 electrolux GB
Do not store warm food or evaporating
liquid.
Avoid buying frozen food if you cannot
store it straight away. The use of an
insulated container is advisable. When
you arrive home, place the frozen food
in the freezer immediately.
Do not push food together too much,
try to allow air to circulate around each
item.
Do not store food uncovered.
Ensure that food placed in the freezer
is dated and labelled and used in date
order to ensure that food is consumed
at its best.
Lean food keeps better and longer
than fatty food, salt reduces the
storage time.
Wrap the food in polythene or
aluminium freezing bags or foil so that
they adhere to the food and provide an
airtight seal.
Packaging which is swollen or has
traces of refrozen water droplets on
the pack could indicate that the
product has not been kept at a
suitable temperature and that it may
have lost its original quality. Partially
thawed food must not be refrozen, it
must be consumed within 24 hours.
Never exceed the storage times
indicated by the manufacturer.
Energy Saving Advice
Do not install the appliance close to
sources of heat, such as a boiler or
radiator.
Locate the appliance in a cool well
ventilated room and make sure that
the air openings of the appliance are
not obstructed.
Avoid unnecessary frosting in the
cabinet by packing all foodstuffs into
airtight packages before placing them
in the freezer.
Food which is to be frozen (when cool)
should be placed in the fridge before
being transferred to the freezer.
Try to avoid keeping the door open for
long periods or opening the door too
frequently as warm air will enter the
cabinet and cause the compressor to
switch on unnecessarily often.
Ensure there are no obstructions
preventing the door from closing
properly.
In the Event of a Power Failure
If there is a power failure during the
storage of frozen foods, keep the door
closed. If the temperature within your
freezer should rise, do not refreeze the
food without checking its condition. The
following guidelines should assist you:
Ice Cream: Once thawed should be
discarded.
Fruits & Vegetables: If soft should be
cooked and used up.
Breads & Cakes: Can be refrozen
without danger.
Shellfish: Should be refrigerated and
used up quickly.
Cooked Dishes: i.e. casseroles should
be refrigerated and used up.
Large Pieces of Meat: Can be refrozen
providing there are still ice crystals
remaining within them.
Small Joints: Should be cooked and can
then be refrozen as cooked dishes.

electrolux 19
GB
Chicken: Should also be cooked and
refrozen as a fresh dish.
Maintenance and Cleaning
Before any maintenance or
cleaning is carried out you must
DISCONNECT the appliance from the
electricity supply.
Internal Cleaning
Clean the inside and accessories with
warm water and bicarbonate of soda (5
ml to 0.5 litre of water).
Rinse and dry thoroughly.
NEVER use detergents,
abrasive powders, highly perfumed
cleaning products or wax polishes to
clean the interior as these will
damage the surface and leave a
strong odour.
External Cleaning
Wash the outer cabinet with warm soapy
water.
Once or twice a year dust the condenser
(black grille) and the compressor at the
back of the appliance with a brush or
vacuum cleaner, as an accumulation of
dust will affect the performance of the
appliance and cause excessive electricity
consumption.
When the Appliance is not in Use
When the appliance is not in use for long
periods, disconnect from the electricity
supply, empty all foods and clean the
appliance, leaving the door open to
prevent unpleasant smells.
Defrosting
Bleeding part of the moisture of cooling
chambers in form of frost and ice goes
with the operation of the appliance.
Thick frost and ice has an insulating
effect, so it reduces cooling efficiency as
the temperetaure increases in the
cooling chambers, they need more
energy.
This appliance defrosts the cooling
surface of the refrigerator without any
external intervention. The termostatic
control interrupts the operation of
compressor at regular intervals. During
this cooling is interrupted - the
temperature of the cooling surface goes
above 0°C due to interior heating load of
the compartment, so defrosting occurs.
When the surface temperature of the
cooling surface has reached +3 - +4 °C
the thermostatic control restarts
operation of the system.
Water flows through the defrost water
outlet through the back into the
evaporator tray which sits on the top of
compressor and evaporates due to its
warmth.
Check and clean the defrost
water outlet regularly - a label
inside the appliance warns you about
this. If it is blocked the defrost water
can cause damage to the insulation of
the appliance.
Clean the melting water outlet with the
supplied pipe scraper that can be seen in
the figure.
The pipe scraper should be stored in the
outlet.
Extra care should be taken when putting
wrapped food, especially in paper, in the
appliance. Blockages to the defrost
water outlet often occurs when wrapped
foods are placed in the back of the
refrigerator, and the wrapping contacts
the back plate of the fridge and sticks to
it.

20 electrolux GB
In case of increased demand e. g.
during heatwawes, the refrigerator
temporarily operates constantly - during
this the automatic defrosting does not
work.
Remaining small ice and frost stains on
back plate of the refrigerator after
defrosting period is normal.
Defrosting of the freezer is automatic in
this model.
How to change the bulb
Should the light fail to work you can
change it as below:
Break the circuit of the appliance.
Unscrew the screw holding the cover (1),
press the rear hook (2) and at the same
time slide the cover in the direction
indicated by arrow (3). So the bulb can
be replaced. (Bulb type: 230-240 V, 15
W, E 14 thread)
After changing the bulb replace the
cover, snap it in place, screw back the
screw and apply voltage to the appliance.
