Electrolux ERC 3025 X User manual

fridge
INSTRUCTION BOOK
2223 384-31
ERC 3025 X
© Electrolux plc 2005

2
IMPORTANT SAFETY INFORMATION
It is most important that this instruction book should be retained with the appliance or uture
re erence. Should the appliance be sold or trans erred to another owner, or should you move house and
leave the appliance, always ensure that the book is le t with the appliance in order that the new owner
can get to know the unctioning o the appliance and the relevant sa ety in ormation.
This in ormation has been provided in the interest o sa ety.You MUST read it care ully be ore installing
or using the appliance.
Installation
• This appliance is heavy. Care should be taken when
movin it.
• It is dan erous to alter the specifications or attempt
to modify this product in any way.
• Care must be taken to ensure that the appliance
does not stand on the electrical supply cable.
Important: if the supply cable is dama ed, it must
be replaced by a special cable available from the
manufacturer or its service a ent.
• Any electrical work required to install this appliance
should be carried out by a qualified electrician or
competent person.
• Parts which heat up should not be exposed.
Whenever possible, the back of the appliance
should be close to a wall but leavin the required
distance for ventilation as stated in the installation
instructions.
• The appliance should be left for 2 hours after
installation before it is turned on, in order to allow
the refri erant to settle.
Child Sa ety
• Do not allow children to tamper with the controls or
play with the product.
• Keep all packa in well away from children.
General Sa ety
•Take utmost care when handling your appliance
so as not to cause any damages to the cooling
unit with consequent possible luid leakages.
•The appliance must not be located close to
radiators or boilers.
•Avoid prolonged exposure o the appliance to
direct sunlight.
•Do not use other electrical appliances (such as
ice cream makers) inside o re rigerating
appliances, unless they are approved or this
purpose by the manu acturer.
During Use
• This appliance is desi ned for domestic use only,
specifically for the stora e of edible foodstuffs only.
• Frozen food must NOT be re-frozen once it has
thawed out.
• Do not place carbonated or fizzy drinks in the
freezer.
• Do not remove items from the freezer if your
hands are damp/wet, as this could cause skin
abrasions or frost/freezer burns.
• Ice lollies can cause ‘frost/freezer burns’ if
consumed strai ht from the freezer.
• Manufacturers’ stora e recommendations should
be strictly adhered to. Refer to relevant
instructions.
• The coolin plate or refri erated freezer shelves
in this appliance contain channels throu h which
the refri erant passes. If these are punctured this
will cause substantial dama e to the appliance
and result in food loss. DO NOT USE SHARP
INSTRUMENTS to scrape off frost or ice. Under
NO circumstances should solid ice be forced off
the linin or shelves. Solid ice should be allowed
to thaw, when defrostin the appliance. See
Defrost Instructions.
Maintenance and Cleaning
• Switch off and unplu the appliance before
carryin out any cleanin or maintenance work.
Servicing
• This product should be serviced by an authorised
en ineer and only enuine spare parts should be
used.
• Under no circumstances should you attempt to
repair the machine yourself. Repairs carried out
by inexperienced persons may cause injury or
serious malfunctionin . Refer to your local
Electrolux Service Force Centre and always insist
on enuine spare parts.
At the end o the Appliance
Li e
• When disposin of your appliance, use an
authorised disposal site.
• Remove the plu and ensure that any locks or
catches are removed, to prevent youn children
bein trapped inside.

3
CONTENTS
Instructions or the User
Important Sa ety In ormation 2
Operation 4
Before use 4
Settin the temperature 4
Fresh food refri eration 4
Normal operatin sounds 4
Positionin the inner shelves 5
Positionin the door shelves 5
Health and Sa ety Guidelines 5
Maintenance and Cleaning 6
Internal cleanin 6
External cleanin 6
When the appliance is not in use 6
Chan in the li ht bulb 6
Defrostin 6
Something not working 7
Service and Spare Parts 8
Customer Care 8
Guarantee Conditions 9
Instructions or the
Installer
Technical Speci ication 10
Installation 11
Positionin 11
Shelf holders 11
Electrical Connection 12
Rear Spacers 13
Door Reversal 13
Disposal o old Appliances
The symbol on the product or on its packa in
indicates that this product may not be treated as
household waste. Instead it shall be handed over to
the applicable collection point for the recyclin of
electrical and electronic equipment. By ensurin this
product is disposed of correctly, you will help prevent
potential ne ative consequences for the environment
and human health, which could otherwise be caused
by inappropriate waste handlin of this product. For
more detailed information about recyclin of this
product, please contact your local city office, your
household waste disposal service or the shop where
you purchased the product.

4
OPERATION
Be ore using
Remove all securin tapes. Wash inside the
appliance with lukewarm water and bicarbonate of
soda (5 ml to 0.5 litre of water).
Setting the temperature
The temperature within the appliance is controlled by
the thermostat control knob situated at the top of the
appliance.
To operate the appliance proceed as follows:
Turn the thermostat control beyond the «■» position.
Position min = minimum coldness
Position max = maximum coldness
Turn the thermostat dial to the required position.
The intermediate position is usually the most
suitable.
The thermostat settin can vary as the temperature
inside the refri eration compartment depends on the
followin factors:
– room temperature
– how often the door is opened
– how much food is stored
– position of the appliance
Fresh ood re rigeration
To obtain the best performance, do not store warm
food or evaporatin liquids in the refri erator; do
cover or wrap the food, particularly if it has a stron
flavour.
Do not cover the shelves with any protective
material, such as paper, cardboard or plastic, which
may obstruct the air circulation throu h them.
To help you use your refri erator correctly, here are
some more useful hints:
Raw meat (beef, pork, lamb & poultry or chicken):
wrap in polythene ba s and place on the lass shelf
above the salad crispers.
Meat can only be stored sa ely in this way or
one or two days at the most.
Fruit & ve etables: these should be thorou hly
cleaned and placed in the bottom salad crisper(s).
Butter & cheese: these should be placed in special
airti ht containers or wrapped in aluminium foil or
polythene ba s to exclude as much air as possible.
Milk bottles: these should have a cap and should be
stored in the bottle rack on the door.
Control panel
A - Pilot li ht
B - Thermostat control
To Start the Appliance
Allow the appliance to stand for 2 hours after
installation.
Plu in the appliance and switch on at the mains
supply. Turn the thermostat control knob (B) to a
medium settin . The pilot li ht (A) will illuminate.
Leave the appliance for approximately 4 hours to
allow the correct temperature to be reached before
placin food inside.
To switch off the appliance turn the thermostat
control knob to position “O” .
Important
Durin prolon ed periods of abnormally hot weather,
if the thermostat is set on too hi h a number, the
coolin system may operate continuously and the
frid e coolin plate may not defrost. Turnin the knob
to a lower number will cause the automatic
defrostin to resume.
B
ON
minMAX
A
Do not use soap or detergent as the smell may
linger. Dry thoroughly.
13
Door reversal directions
1. Disconnect from the electricity supply.
2. Gently lay the frid e on its back with the top held
away from the floor by 5-8 cm (2-3 inches) of
packin ;
3. Remove the ventilation rill (D).
4. remove the bottom hin e (E) by unscrewin its
three fixin screws;
5. Slide out the frid e door from pin (G), unscrew
the latter and then refit it on the opposite side;
6. remove the two plu s of the door (where
available), discoverin the holes for the hin e
pins, assemble them on the opposite side;
7. reassemble the door;
8. usin a 10 mm spanner, unscrew the hin e pin
(E) and reassemble it on the opposite side of the
hin e;
9. reassemble the lower hin e (E) on the opposite
side, usin the screws previously removed. Slide
the hole cover (F) out of the ventilation rille (D)
by pushin it in the direction of the arrow and
reassemble it on the opposite side;
10.refit the ventilation rille (D), clippin it into place;
11. Unscrew the handle. Refit it on the opposite side
after havin pierced the plu s with a punch.
Cover the holes left open with the plu s supplied
in the documentation pack.
Important
After completion of the door reversin operation,
check that the door asket adheres to the cabinet. If
the ambient temperature is cold (i.e. in Winter), the
asket may not fit perfectly to the cabinet. In that
case, wait for the natural fittin of the asket or
accelerate this process by heatin up the part
involved with a normal hairdryer on a low settin .
F
F
D
FF
E
E
G
D594
Rear spacers
In the ba with the documentation, there are two
spacers which must be fitted as shown in the fi ure.
Slacken the screws and insert the spacer under the
screw head, then re-ti hten the screws.

5
Positioning the inner shelves
The walls of the refri erator have runners so that
shelves can be positioned as desired.
• Keep the time between buyin chilled food and
placin it in your frid e as short as possible. Tests
showed that the temperature of 1 litre of oran e
juice rose to 22°C in an hour between the
supermarket and home. It then took 11 hours to
et down to 7°C in the refri erator.
• Keep the refri erator door closed as much as
possible.
• Do not push food to ether too much, try to allow
air to circulate around each item.
• Cool cooked food as quickly as possible but do
NOT place in the refri erator until cool. (Leave
food in a place as cool as possible in order that it
can then be placed in the refri erator as soon as
possible).
• Do NOT mix raw and cooked meat, they must be
in separate containers. Take care not to let the
meat juices drip onto other food. If the meat does
drip, remove everythin and clean thorou hly.
• Do not store food uncovered.
• Remove suspect food from your refri erator and
clean (refer to “Maintenance and Cleanin ).
• Never allow spilla es to dry and harden.
• Store e s in the e rack provided in the
refri erator door. Discard any broken or chipped
e s.
• Re ularly check the refri erator door seal to
ensure that it is clean and free from debris.
• Always wash your hands with soapy water and
dry them with a clean towel before handlin food.
• Keep work surfaces clean and avoid cross
contamination by not usin the same work
surface or knife, without washin them thorou hly
in between.
HEALTH AND SAFETY GUIDELINES
Positioning the door shelves
To permit stora e of food packa es of various sizes,
the door shelves can be adjusted in hei ht.
To do this proceed as shown in the dia ram.
Because o consumer demand, preservatives have been removed rom many pre-prepared oods. This
together with the changes in shopping habits to a once-a-week shop, mean that sa e handling and
storage o ood is even more important than ever.
The ollowing tips should help you to ensure that the ood in your home is in as per ect condition as
possible.
D338
12
Electrical connections
Any electrical work required to install this appliance
should be carried out by a qualified electrician or
competent person.
WARNING: THIS APPLIANCE MUST BE
EARTHED.
The manu acturer declines any liability should
this sa ety measure not be observed.
If the plu that is fitted to your appliance is not
suitable for your socket outlet, it must be cut off and
the appropriate plu fitted.
Remove the fuse from the cut off plu .
The cut off plu should then be disposed of to
prevent the hazard of shocks in case it should be
plu ed into a 13amp socket in another part of your
home.
Important
The wires in the mains lead are coloured in
accordance with the followin code:
Green and Yellow - Earth
Blue - Neutral
Brown - Live
If you fit your own plu , the colours of the wires in
the mains lead of your appliance may not correspond
with the markin s identifyin the terminals in your
plu , proceed as follows:
Connect the Green and Yellow (earth) wire to the
terminal in the plu which is marked with the letter
«E» or the earth symbol or coloured reen and
yellow.
Connect the blue (neutral) wire to the terminal in the
plu which is marked with the letter «N» or coloured
black.
Connect the brown (live) wire to the terminal in the
plu which is marked with the letter «L» or coloured
red.
The plu moulded onto the lead incorporates a fuse.
D207
GREEN & YELLOW 13 AMP. FUSE
BROWN
CORD CLAMP
BLUE
13 AMP
For replacement, use a 13amp BSI362 fuse. Only
ASTA or BSI approved fuses should be used.
The plu must not be used if the fuse cover/carrier is
lost. The cover/carrier is indicated by the coloured
insert at the base of the plu .
A replacement cover/carrier must be obtained from
your local Electrolux Service Force Centre .
This appliance complies with the E.E.C. Directive
No. 87/308 o 2.6.87 relative to radio inter erence
suppression.
This appliance complies with the followin
E.E.C. Directives:
- 73/23 EEC o 19.2.73 (Low Volta e Directive)
and subsequent modifications;
- 89/336 EEC o 3.5.89 (Electroma netic
Compatibility Directive) and subsequent
modifications.
Please ensure that when the appliance is
installed it is easily accessible or the engineer in
the event o a breakdown.

De rosting
The refri erator automatically defrosts every time the
compressor stops. The water is dischar ed, via the
pipe, into a tray located at the back of the appliance
above the compressor, where it evaporates.
Important
To avoid defrost water overflowin into the frid e,
periodically clean the water dischar e hole in the centre
of the V shaped drip collector at the back of the
refri erator compartment behind the fruit and ve etable
drawer. Use the defrost cleaner provided which you will
find already inserted into the dischar e hole.
Remember to wash the defrost cleaner in hot soapy
water at re ular intervals. Dry throu hly before
replacin .
D037
MAINTENANCE AND CLEANING
External cleaning
Many proprietary kitchen sur ace cleaners
contain chemicals that can attack/damage the
plastics used in this appliance. For this reason it
is recommended that the outer casing o this
appliance is only cleaned with warm water with a
little washing-up liquid added.
An accumulation of dust will affect the performance
of the appliance and cause excessive electricity
consumption.
You MUST ensure that the appliance is switched
OFF.
Once or twice a year dust the condenser (black rill)
and the compressor at the back of the appliance,
with a brush or vacuum cleaner, see dia ram.
PR259
Before any maintenance or cleanin work is carried
out, DISCONNECT the appliance from the
ELECTRICITY supply.
Internal cleaning
Clean the inside and accessories with warm water
and bicarbonate of soda (5ml to 0.5 litre of water).
Rinse and dry thorou hly.
NEVER USE DETERGENTS, ABRASIVE
POWDERS, HIGHLY PERFUMED CLEANING
PRODUCTS OR WAX POLISHES, TO CLEAN
THE INTERIOR AS THESE WILL DAMAGE THE
SURFACE AND LEAVE A STRONG ODOUR.
Clean the drain hole of the water trou h at re ular
intervals and make sure that the drain hole is never
obstructed, so that the defrost water may flow freely.
Changing the light bulb
Should the interior li ht fail to work, first switch off
the appliance and disconnect from the electricity
supply, then replace the bulb as follows;
press on the rear hook and at the same time slide the
cover in the direction indicated by the arrow.
Unscrew the bulb and replace it with one of the same
power (the maximum power is shown on the li ht
diffuser) available from your nearest Service Force
Centre.
Replace the li ht cover by slidin it into its ori inal
position.
When the appliance is not in use
When the appliance is not in use for lon periods,
disconnect from the electricity supply, empty all
foods and clean the appliance, leavin the doors ajar
to prevent unpleasant smells.
6
11
INSTALLATION
Positioning
This appliance should only be installed at a location
where the ambient temperature corresponds to the
climate classification indicated on the ratin plate, which
is located at the left on the inside of the appliance.
The followin table shows which ambient temperature is
correct for each climate classification:
SN +10°C to + 32°C
N +16°C to + 32°C
ST +18°C to + 38°C
T +18°C to + 43°C
It should be located in a dry atmosphere, out of direct
sunli ht and away from extreme temperature e. . not next
to a boiler or radiator, or in a very cold room e. . an
outhouse, where the temperatures may fall below 10°C
(50°F). If these temperatures are exceeded i.e. colder or
warmer, then the appliance may not operate correctly.
You should also ensure that air can circulate freely around
the back and the top of the cabinet. There must also be at
least 100 mm (4”) distance between the top of the cabinet
and any overhan in kitchen furniture (A). Ideally, the
appliance should not be positioned beneath overhan in
furniture (B).
There should also be a ap of 25 mm either side of the
appliance. Do not obstruct the space underneath. The
back of the cabinet may be placed close to the wall but
must not touch it. DO NOT install in places with restricted
ventilation.
Adjust the level of the appliance by screwin out the
adjustable foot, or feet, at the bottom of the cabinet usin
your fin ers or a spanner (see fi ure).
D200
100 mm10 mm
10 mm
AB
NP007
Warning
IF YOU ARE DISCARDING AN OLD APPLIANCE
THAT HAS A LOCK OR CATCH ON THE DOOR,
YOU MUST ENSURE THAT IT IS MADE
UNUSABLE TO PREVENT YOUNG CHILDREN
BEING TRAPPED INSIDE.
Dependin upon the position which you choose for
your appliance, you may wish to reverse the way in
which the door opens. To do this, refer to instructions
on “Door reversal directions”.
Important
It must be possible to disconnect the appliance from
the mains power supply; the plu must therefore be
easily accessible after installation.
A
C
B
Shel holders
Your appliance is equipped with shelf retainers that
make it possible to secure the shelves durin
transportation.
To remove them proceed as follows:
Move the shelf retainers in the direction of the arrow,
raise the shelf from the rear and push it forward until
it is freed and remove the retainers.

7
SOMETHING NOT WORKING
Important: If you call out an en ineer to a fault listed below, or to repair a fault caused by incorrect use or
installation a char e will be made, even if the appliance is under uarantee.
Be ore contactin your local Electrolux Service Force Centre, check the followin points:
If, after the above checks, there is still a fault, call your local Service Force Centre.
In uarantee customers should ensure that the above checks have been made as the en ineer will make a
char e if the fault is not a mechanical or electrical breakdown.
Please note that proof of purchase is required for any in- uarantee service calls.
Symptom
No power to the appliance
The li ht does not come on
The temperature in the frid e is too hi h
The compressor runs continuously
Noise
Water under the salad crispers
Solution
Check there is power at the socket.
Check there is not a power cut by checkin the
household li hts.
Check the fuse has not blown.
Ensure that the bulb is correctly fitted.
Replace the bulb if it has blown.
Check the door li ht switch is not jammed.
Check the thermostat control knob on the front panel
is turned to the correct settin relative to ambient
conditions.
Check the ambient temperature is within the
appliance’s operatin limits, please refer to the
installation section in this instruction book.
Relocate the appliance if necessary.
Adjust the thermostat control knob to ive correct
temperature control. See “Settin the temperature”.
Check that the door is closed.
Lar e quantities of food have recently been placed in
the cabinet and/or door is frequently opened.
Check that air ventilation is not obstructed.
Refer to normal operatin sounds.
Check the drain hole is not blocked. (see
Maintenance and Cleanin ).
10
TECHNICAL SPECIFICATIONS
DIMENSIONS
Hei ht 160 cm
Width 60 cm
Depth 62,5 cm
POWER SUPPLY VOLTAGE AND FREQUENCY 220-240 V / 50 Hz
TOTAL POWER ABSORBED 110 W
AVERAGE DAILY UNITS ELECTRICITY * 0.47 kWh
GROSS CAPACITY
Frid e 294 l
NET CAPACITY
Frid e 291 l
* This fi ure is based on standard test results in accordance with European Standard EN 153.
Actual consumption will depend on how the appliance is used and where it is located.

8
CUSTOMER CARE DEPARTMENT
In the event of your appliance requirin service, or if you wish to purchase spare parts, please contact your local
Electrolux Service Force Centre by telephonin :-
0870 5 929929
Your telephone call will be automatically routed to the Service Force Centre coverin your post code area.
For the address of your local Service Force Centre and further information about Service Force, please visit the
website at www.serviceforce.co.uk
For Customer Service in Ireland please
contact us at the address below:
Electrolux Group (Irl) Ltd
Lon Mile Road
Dublin 12
Republic of Ireland
Telephone : [phone]
Email: ser[email protected]
Before callin out an en ineer, please ensure you have read the details under the headin ‘Somethin Not
Workin .’
When you contact the Service Force Centre you will need to ive the followin details:
1. Your name, address and post code
2. Your telephone number
3. Clear and concise details of the fault
4. The model and serial number of the appliance (found on the ratin plate)
5. The purchase date
Please note that a valid purchase receipt or guarantee documentation is required or in-guarantee
service calls.
or eneral enquiries concernin your Electrolux appliance or for further information on Electrolux products,
please contact our Customer Care Department by letter or telephone at the address below or visit our website
at www.electrolux.co.uk
Customer Care Department
Electrolux Major Appliances
Addin ton Way
Luton
Bedfordshire
LU4 9QQ
08705 950 950 *
* calls to this number may be recorded for trainin purposes.
SERVICE AND SPARE PARTS
9
Standard guarantee conditions
We, Electrolux, undertake that if within 12 months of the date of the purchase this Electrolux appliance or any
part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option
repair or replace the same FREE OF CHARGE for labour, materials or carria e on condition that:
The appliance has been correctly installed and used only on the electricity supply stated on the ratin plate.
The appliance has been used for normal domestic purposes only, and in accordance with the manufacturer’s
instructions.
The appliance has not been serviced, maintained, repaired, taken apart or tampered with by any person not
authorised by us.
All service work under this uarantee must be undertaken by an Electrolux Service Force Centre. Any appliance
or defective part replaced shall become the Company’s property.
This uarantee is in addition to your statutory and other le al ri hts.
Home visits are made between 8.30am and 5.30pm Monday to Friday. Visits may be available outside these
hours in which case a premium will be char ed.
Exclusions
This guarantee does not cover:
Dama e or calls resultin from transportation, improper use or ne lect, the replacement of any li ht bulbs or
removable parts of lass or plastic.
Costs incurred for calls to put ri ht an appliance which is improperly installed or calls to appliances outside the
European Community (EC) or European Free Trade Area.
Appliances found to be in use within a commercial environment, plus those which are subject to rental
a reements.
Products of Electrolux manufacture which are not marketed by Electrolux.
European Guarantee
If you should move to another country within Europe then your uarantee moves with you to your new home
subject to the followin qualifications:
The uarantee starts from the date you first purchased your product.
The uarantee is for the same period and to the same extent for labour and parts as exists in the new country of
use for this brand or ran e of products.
This uarantee relates to you and cannot be transferred to another user.
Your new home is within the European Community (EC) or European Free Trade Area.
The product is installed and used in accordance with our instructions and is only used domestically, i.e. a
normal household.
The product is installed takin into account re ulations in your new country.
Before you move please contact your nearest Customer Care centre, listed below, to ive them details of your
new home. They will then ensure that the local Service Or anisation is aware of your move and able to look
after you and your appliances.
France Senlis [phone]
Germany Nürnber [phone]
Italy Pordenone [phone]
Sweden Stockholm [phone]
UK Luton [phone]
Ireland Dublin [phone]
GUARANTEE CONDITIONS

8
CUSTOMER CARE DEPARTMENT
In the event of your appliance requirin service, or if you wish to purchase spare parts, please contact your local
Electrolux Service Force Centre by telephonin :-
0870 5 929929
Your telephone call will be automatically routed to the Service Force Centre coverin your post code area.
For the address of your local Service Force Centre and further information about Service Force, please visit the
website at www.serviceforce.co.uk
For Customer Service in Ireland please
contact us at the address below:
Electrolux Group (Irl) Ltd
Lon Mile Road
Dublin 12
Republic of Ireland
Telephone : [phone]
Email: ser[email protected]
Before callin out an en ineer, please ensure you have read the details under the headin ‘Somethin Not
Workin .’
When you contact the Service Force Centre you will need to ive the followin details:
1. Your name, address and post code
2. Your telephone number
3. Clear and concise details of the fault
4. The model and serial number of the appliance (found on the ratin plate)
5. The purchase date
Please note that a valid purchase receipt or guarantee documentation is required or in-guarantee
service calls.
or eneral enquiries concernin your Electrolux appliance or for further information on Electrolux products,
please contact our Customer Care Department by letter or telephone at the address below or visit our website
at www.electrolux.co.uk
Customer Care Department
Electrolux Major Appliances
Addin ton Way
Luton
Bedfordshire
LU4 9QQ
08705 950 950 *
* calls to this number may be recorded for trainin purposes.
SERVICE AND SPARE PARTS
9
Standard guarantee conditions
We, Electrolux, undertake that if within 12 months of the date of the purchase this Electrolux appliance or any
part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option
repair or replace the same FREE OF CHARGE for labour, materials or carria e on condition that:
The appliance has been correctly installed and used only on the electricity supply stated on the ratin plate.
The appliance has been used for normal domestic purposes only, and in accordance with the manufacturer’s
instructions.
The appliance has not been serviced, maintained, repaired, taken apart or tampered with by any person not
authorised by us.
All service work under this uarantee must be undertaken by an Electrolux Service Force Centre. Any appliance
or defective part replaced shall become the Company’s property.
This uarantee is in addition to your statutory and other le al ri hts.
Home visits are made between 8.30am and 5.30pm Monday to Friday. Visits may be available outside these
hours in which case a premium will be char ed.
Exclusions
This guarantee does not cover:
Dama e or calls resultin from transportation, improper use or ne lect, the replacement of any li ht bulbs or
removable parts of lass or plastic.
Costs incurred for calls to put ri ht an appliance which is improperly installed or calls to appliances outside the
European Community (EC) or European Free Trade Area.
Appliances found to be in use within a commercial environment, plus those which are subject to rental
a reements.
Products of Electrolux manufacture which are not marketed by Electrolux.
European Guarantee
If you should move to another country within Europe then your uarantee moves with you to your new home
subject to the followin qualifications:
The uarantee starts from the date you first purchased your product.
The uarantee is for the same period and to the same extent for labour and parts as exists in the new country of
use for this brand or ran e of products.
This uarantee relates to you and cannot be transferred to another user.
Your new home is within the European Community (EC) or European Free Trade Area.
The product is installed and used in accordance with our instructions and is only used domestically, i.e. a
normal household.
The product is installed takin into account re ulations in your new country.
Before you move please contact your nearest Customer Care centre, listed below, to ive them details of your
new home. They will then ensure that the local Service Or anisation is aware of your move and able to look
after you and your appliances.
France Senlis [phone]
Germany Nürnber [phone]
Italy Pordenone [phone]
Sweden Stockholm [phone]
UK Luton [phone]
Ireland Dublin [phone]
GUARANTEE CONDITIONS

7
SOMETHING NOT WORKING
Important: If you call out an en ineer to a fault listed below, or to repair a fault caused by incorrect use or
installation a char e will be made, even if the appliance is under uarantee.
Be ore contactin your local Electrolux Service Force Centre, check the followin points:
If, after the above checks, there is still a fault, call your local Service Force Centre.
In uarantee customers should ensure that the above checks have been made as the en ineer will make a
char e if the fault is not a mechanical or electrical breakdown.
Please note that proof of purchase is required for any in- uarantee service calls.
Symptom
No power to the appliance
The li ht does not come on
The temperature in the frid e is too hi h
The compressor runs continuously
Noise
Water under the salad crispers
Solution
Check there is power at the socket.
Check there is not a power cut by checkin the
household li hts.
Check the fuse has not blown.
Ensure that the bulb is correctly fitted.
Replace the bulb if it has blown.
Check the door li ht switch is not jammed.
Check the thermostat control knob on the front panel
is turned to the correct settin relative to ambient
conditions.
Check the ambient temperature is within the
appliance’s operatin limits, please refer to the
installation section in this instruction book.
Relocate the appliance if necessary.
Adjust the thermostat control knob to ive correct
temperature control. See “Settin the temperature”.
Check that the door is closed.
Lar e quantities of food have recently been placed in
the cabinet and/or door is frequently opened.
Check that air ventilation is not obstructed.
Refer to normal operatin sounds.
Check the drain hole is not blocked. (see
Maintenance and Cleanin ).
10
TECHNICAL SPECIFICATIONS
DIMENSIONS
Hei ht 160 cm
Width 60 cm
Depth 62,5 cm
POWER SUPPLY VOLTAGE AND FREQUENCY 220-240 V / 50 Hz
TOTAL POWER ABSORBED 110 W
AVERAGE DAILY UNITS ELECTRICITY * 0.47 kWh
GROSS CAPACITY
Frid e 294 l
NET CAPACITY
Frid e 291 l
* This fi ure is based on standard test results in accordance with European Standard EN 153.
Actual consumption will depend on how the appliance is used and where it is located.

De rosting
The refri erator automatically defrosts every time the
compressor stops. The water is dischar ed, via the
pipe, into a tray located at the back of the appliance
above the compressor, where it evaporates.
Important
To avoid defrost water overflowin into the frid e,
periodically clean the water dischar e hole in the centre
of the V shaped drip collector at the back of the
refri erator compartment behind the fruit and ve etable
drawer. Use the defrost cleaner provided which you will
find already inserted into the dischar e hole.
Remember to wash the defrost cleaner in hot soapy
water at re ular intervals. Dry throu hly before
replacin .
D037
MAINTENANCE AND CLEANING
External cleaning
Many proprietary kitchen sur ace cleaners
contain chemicals that can attack/damage the
plastics used in this appliance. For this reason it
is recommended that the outer casing o this
appliance is only cleaned with warm water with a
little washing-up liquid added.
An accumulation of dust will affect the performance
of the appliance and cause excessive electricity
consumption.
You MUST ensure that the appliance is switched
OFF.
Once or twice a year dust the condenser (black rill)
and the compressor at the back of the appliance,
with a brush or vacuum cleaner, see dia ram.
PR259
Before any maintenance or cleanin work is carried
out, DISCONNECT the appliance from the
ELECTRICITY supply.
Internal cleaning
Clean the inside and accessories with warm water
and bicarbonate of soda (5ml to 0.5 litre of water).
Rinse and dry thorou hly.
NEVER USE DETERGENTS, ABRASIVE
POWDERS, HIGHLY PERFUMED CLEANING
PRODUCTS OR WAX POLISHES, TO CLEAN
THE INTERIOR AS THESE WILL DAMAGE THE
SURFACE AND LEAVE A STRONG ODOUR.
Clean the drain hole of the water trou h at re ular
intervals and make sure that the drain hole is never
obstructed, so that the defrost water may flow freely.
Changing the light bulb
Should the interior li ht fail to work, first switch off
the appliance and disconnect from the electricity
supply, then replace the bulb as follows;
press on the rear hook and at the same time slide the
cover in the direction indicated by the arrow.
Unscrew the bulb and replace it with one of the same
power (the maximum power is shown on the li ht
diffuser) available from your nearest Service Force
Centre.
Replace the li ht cover by slidin it into its ori inal
position.
When the appliance is not in use
When the appliance is not in use for lon periods,
disconnect from the electricity supply, empty all
foods and clean the appliance, leavin the doors ajar
to prevent unpleasant smells.
6
11
INSTALLATION
Positioning
This appliance should only be installed at a location
where the ambient temperature corresponds to the
climate classification indicated on the ratin plate, which
is located at the left on the inside of the appliance.
The followin table shows which ambient temperature is
correct for each climate classification:
SN +10°C to + 32°C
N +16°C to + 32°C
ST +18°C to + 38°C
T +18°C to + 43°C
It should be located in a dry atmosphere, out of direct
sunli ht and away from extreme temperature e. . not next
to a boiler or radiator, or in a very cold room e. . an
outhouse, where the temperatures may fall below 10°C
(50°F). If these temperatures are exceeded i.e. colder or
warmer, then the appliance may not operate correctly.
You should also ensure that air can circulate freely around
the back and the top of the cabinet. There must also be at
least 100 mm (4”) distance between the top of the cabinet
and any overhan in kitchen furniture (A). Ideally, the
appliance should not be positioned beneath overhan in
furniture (B).
There should also be a ap of 25 mm either side of the
appliance. Do not obstruct the space underneath. The
back of the cabinet may be placed close to the wall but
must not touch it. DO NOT install in places with restricted
ventilation.
Adjust the level of the appliance by screwin out the
adjustable foot, or feet, at the bottom of the cabinet usin
your fin ers or a spanner (see fi ure).
D200
100 mm10 mm
10 mm
AB
NP007
Warning
IF YOU ARE DISCARDING AN OLD APPLIANCE
THAT HAS A LOCK OR CATCH ON THE DOOR,
YOU MUST ENSURE THAT IT IS MADE
UNUSABLE TO PREVENT YOUNG CHILDREN
BEING TRAPPED INSIDE.
Dependin upon the position which you choose for
your appliance, you may wish to reverse the way in
which the door opens. To do this, refer to instructions
on “Door reversal directions”.
Important
It must be possible to disconnect the appliance from
the mains power supply; the plu must therefore be
easily accessible after installation.
A
C
B
Shel holders
Your appliance is equipped with shelf retainers that
make it possible to secure the shelves durin
transportation.
To remove them proceed as follows:
Move the shelf retainers in the direction of the arrow,
raise the shelf from the rear and push it forward until
it is freed and remove the retainers.

5
Positioning the inner shelves
The walls of the refri erator have runners so that
shelves can be positioned as desired.
• Keep the time between buyin chilled food and
placin it in your frid e as short as possible. Tests
showed that the temperature of 1 litre of oran e
juice rose to 22°C in an hour between the
supermarket and home. It then took 11 hours to
et down to 7°C in the refri erator.
• Keep the refri erator door closed as much as
possible.
• Do not push food to ether too much, try to allow
air to circulate around each item.
• Cool cooked food as quickly as possible but do
NOT place in the refri erator until cool. (Leave
food in a place as cool as possible in order that it
can then be placed in the refri erator as soon as
possible).
• Do NOT mix raw and cooked meat, they must be
in separate containers. Take care not to let the
meat juices drip onto other food. If the meat does
drip, remove everythin and clean thorou hly.
• Do not store food uncovered.
• Remove suspect food from your refri erator and
clean (refer to “Maintenance and Cleanin ).
• Never allow spilla es to dry and harden.
• Store e s in the e rack provided in the
refri erator door. Discard any broken or chipped
e s.
• Re ularly check the refri erator door seal to
ensure that it is clean and free from debris.
• Always wash your hands with soapy water and
dry them with a clean towel before handlin food.
• Keep work surfaces clean and avoid cross
contamination by not usin the same work
surface or knife, without washin them thorou hly
in between.
HEALTH AND SAFETY GUIDELINES
Positioning the door shelves
To permit stora e of food packa es of various sizes,
the door shelves can be adjusted in hei ht.
To do this proceed as shown in the dia ram.
Because o consumer demand, preservatives have been removed rom many pre-prepared oods. This
together with the changes in shopping habits to a once-a-week shop, mean that sa e handling and
storage o ood is even more important than ever.
The ollowing tips should help you to ensure that the ood in your home is in as per ect condition as
possible.
D338
12
Electrical connections
Any electrical work required to install this appliance
should be carried out by a qualified electrician or
competent person.
WARNING: THIS APPLIANCE MUST BE
EARTHED.
The manu acturer declines any liability should
this sa ety measure not be observed.
If the plu that is fitted to your appliance is not
suitable for your socket outlet, it must be cut off and
the appropriate plu fitted.
Remove the fuse from the cut off plu .
The cut off plu should then be disposed of to
prevent the hazard of shocks in case it should be
plu ed into a 13amp socket in another part of your
home.
Important
The wires in the mains lead are coloured in
accordance with the followin code:
Green and Yellow - Earth
Blue - Neutral
Brown - Live
If you fit your own plu , the colours of the wires in
the mains lead of your appliance may not correspond
with the markin s identifyin the terminals in your
plu , proceed as follows:
Connect the Green and Yellow (earth) wire to the
terminal in the plu which is marked with the letter
«E» or the earth symbol or coloured reen and
yellow.
Connect the blue (neutral) wire to the terminal in the
plu which is marked with the letter «N» or coloured
black.
Connect the brown (live) wire to the terminal in the
plu which is marked with the letter «L» or coloured
red.
The plu moulded onto the lead incorporates a fuse.
D207
GREEN & YELLOW 13 AMP. FUSE
BROWN
CORD CLAMP
BLUE
13 AMP
For replacement, use a 13amp BSI362 fuse. Only
ASTA or BSI approved fuses should be used.
The plu must not be used if the fuse cover/carrier is
lost. The cover/carrier is indicated by the coloured
insert at the base of the plu .
A replacement cover/carrier must be obtained from
your local Electrolux Service Force Centre .
This appliance complies with the E.E.C. Directive
No. 87/308 o 2.6.87 relative to radio inter erence
suppression.
This appliance complies with the followin
E.E.C. Directives:
- 73/23 EEC o 19.2.73 (Low Volta e Directive)
and subsequent modifications;
- 89/336 EEC o 3.5.89 (Electroma netic
Compatibility Directive) and subsequent
modifications.
Please ensure that when the appliance is
installed it is easily accessible or the engineer in
the event o a breakdown.

4
OPERATION
Be ore using
Remove all securin tapes. Wash inside the
appliance with lukewarm water and bicarbonate of
soda (5 ml to 0.5 litre of water).
Setting the temperature
The temperature within the appliance is controlled by
the thermostat control knob situated at the top of the
appliance.
To operate the appliance proceed as follows:
Turn the thermostat control beyond the «■» position.
Position min = minimum coldness
Position max = maximum coldness
Turn the thermostat dial to the required position.
The intermediate position is usually the most
suitable.
The thermostat settin can vary as the temperature
inside the refri eration compartment depends on the
followin factors:
– room temperature
– how often the door is opened
– how much food is stored
– position of the appliance
Fresh ood re rigeration
To obtain the best performance, do not store warm
food or evaporatin liquids in the refri erator; do
cover or wrap the food, particularly if it has a stron
flavour.
Do not cover the shelves with any protective
material, such as paper, cardboard or plastic, which
may obstruct the air circulation throu h them.
To help you use your refri erator correctly, here are
some more useful hints:
Raw meat (beef, pork, lamb & poultry or chicken):
wrap in polythene ba s and place on the lass shelf
above the salad crispers.
Meat can only be stored sa ely in this way or
one or two days at the most.
Fruit & ve etables: these should be thorou hly
cleaned and placed in the bottom salad crisper(s).
Butter & cheese: these should be placed in special
airti ht containers or wrapped in aluminium foil or
polythene ba s to exclude as much air as possible.
Milk bottles: these should have a cap and should be
stored in the bottle rack on the door.
Control panel
A - Pilot li ht
B - Thermostat control
To Start the Appliance
Allow the appliance to stand for 2 hours after
installation.
Plu in the appliance and switch on at the mains
supply. Turn the thermostat control knob (B) to a
medium settin . The pilot li ht (A) will illuminate.
Leave the appliance for approximately 4 hours to
allow the correct temperature to be reached before
placin food inside.
To switch off the appliance turn the thermostat
control knob to position “O” .
Important
Durin prolon ed periods of abnormally hot weather,
if the thermostat is set on too hi h a number, the
coolin system may operate continuously and the
frid e coolin plate may not defrost. Turnin the knob
to a lower number will cause the automatic
defrostin to resume.
B
ON
minMAX
A
Do not use soap or detergent as the smell may
linger. Dry thoroughly.
13
Door reversal directions
1. Disconnect from the electricity supply.
2. Gently lay the frid e on its back with the top held
away from the floor by 5-8 cm (2-3 inches) of
packin ;
3. Remove the ventilation rill (D).
4. remove the bottom hin e (E) by unscrewin its
three fixin screws;
5. Slide out the frid e door from pin (G), unscrew
the latter and then refit it on the opposite side;
6. remove the two plu s of the door (where
available), discoverin the holes for the hin e
pins, assemble them on the opposite side;
7. reassemble the door;
8. usin a 10 mm spanner, unscrew the hin e pin
(E) and reassemble it on the opposite side of the
hin e;
9. reassemble the lower hin e (E) on the opposite
side, usin the screws previously removed. Slide
the hole cover (F) out of the ventilation rille (D)
by pushin it in the direction of the arrow and
reassemble it on the opposite side;
10.refit the ventilation rille (D), clippin it into place;
11. Unscrew the handle. Refit it on the opposite side
after havin pierced the plu s with a punch.
Cover the holes left open with the plu s supplied
in the documentation pack.
Important
After completion of the door reversin operation,
check that the door asket adheres to the cabinet. If
the ambient temperature is cold (i.e. in Winter), the
asket may not fit perfectly to the cabinet. In that
case, wait for the natural fittin of the asket or
accelerate this process by heatin up the part
involved with a normal hairdryer on a low settin .
F
F
D
FF
E
E
G
D594
Rear spacers
In the ba with the documentation, there are two
spacers which must be fitted as shown in the fi ure.
Slacken the screws and insert the spacer under the
screw head, then re-ti hten the screws.

3
CONTENTS
Instructions or the User
Important Sa ety In ormation 2
Operation 4
Before use 4
Settin the temperature 4
Fresh food refri eration 4
Normal operatin sounds 4
Positionin the inner shelves 5
Positionin the door shelves 5
Health and Sa ety Guidelines 5
Maintenance and Cleaning 6
Internal cleanin 6
External cleanin 6
When the appliance is not in use 6
Chan in the li ht bulb 6
Defrostin 6
Something not working 7
Service and Spare Parts 8
Customer Care 8
Guarantee Conditions 9
Instructions or the
Installer
Technical Speci ication 10
Installation 11
Positionin 11
Shelf holders 11
Electrical Connection 12
Rear Spacers 13
Door Reversal 13
Disposal o old Appliances
The symbol on the product or on its packa in
indicates that this product may not be treated as
household waste. Instead it shall be handed over to
the applicable collection point for the recyclin of
electrical and electronic equipment. By ensurin this
product is disposed of correctly, you will help prevent
potential ne ative consequences for the environment
and human health, which could otherwise be caused
by inappropriate waste handlin of this product. For
more detailed information about recyclin of this
product, please contact your local city office, your
household waste disposal service or the shop where
you purchased the product.

2
IMPORTANT SAFETY INFORMATION
It is most important that this instruction book should be retained with the appliance or uture
re erence. Should the appliance be sold or trans erred to another owner, or should you move house and
leave the appliance, always ensure that the book is le t with the appliance in order that the new owner
can get to know the unctioning o the appliance and the relevant sa ety in ormation.
This in ormation has been provided in the interest o sa ety. You MUST read it care ully be ore installing
or using the appliance.
Installation
• This appliance is heavy. Care should be taken when
movin it.
• It is dan erous to alter the specifications or attempt
to modify this product in any way.
• Care must be taken to ensure that the appliance
does not stand on the electrical supply cable.
Important: if the supply cable is dama ed, it must
be replaced by a special cable available from the
manufacturer or its service a ent.
• Any electrical work required to install this appliance
should be carried out by a qualified electrician or
competent person.
• Parts which heat up should not be exposed.
Whenever possible, the back of the appliance
should be close to a wall but leavin the required
distance for ventilation as stated in the installation
instructions.
• The appliance should be left for 2 hours after
installation before it is turned on, in order to allow
the refri erant to settle.
Child Sa ety
• Do not allow children to tamper with the controls or
play with the product.
• Keep all packa in well away from children.
General Sa ety
•Take utmost care when handling your appliance
so as not to cause any damages to the cooling
unit with consequent possible luid leakages.
•The appliance must not be located close to
radiators or boilers.
•Avoid prolonged exposure o the appliance to
direct sunlight.
•Do not use other electrical appliances (such as
ice cream makers) inside o re rigerating
appliances, unless they are approved or this
purpose by the manu acturer.
During Use
• This appliance is desi ned for domestic use only,
specifically for the stora e of edible foodstuffs only.
• Frozen food must NOT be re-frozen once it has
thawed out.
• Do not place carbonated or fizzy drinks in the
freezer.
• Do not remove items from the freezer if your
hands are damp/wet, as this could cause skin
abrasions or frost/freezer burns.
• Ice lollies can cause ‘frost/freezer burns’ if
consumed strai ht from the freezer.
• Manufacturers’ stora e recommendations should
be strictly adhered to. Refer to relevant
instructions.
• The coolin plate or refri erated freezer shelves
in this appliance contain channels throu h which
the refri erant passes. If these are punctured this
will cause substantial dama e to the appliance
and result in food loss. DO NOT USE SHARP
INSTRUMENTS to scrape off frost or ice. Under
NO circumstances should solid ice be forced off
the linin or shelves. Solid ice should be allowed
to thaw, when defrostin the appliance. See
Defrost Instructions.
Maintenance and Cleaning
• Switch off and unplu the appliance before
carryin out any cleanin or maintenance work.
Servicing
• This product should be serviced by an authorised
en ineer and only enuine spare parts should be
used.
• Under no circumstances should you attempt to
repair the machine yourself. Repairs carried out
by inexperienced persons may cause injury or
serious malfunctionin . Refer to your local
Electrolux Service Force Centre and always insist
on enuine spare parts.
At the end o the Appliance
Li e
• When disposin of your appliance, use an
authorised disposal site.
• Remove the plu and ensure that any locks or
catches are removed, to prevent youn children
bein trapped inside.

fridge
INSTRUCTION BOOK
2223 384-31
ERC 3025 X
© Electrolux plc 2005
