Electrolux EWC 10550 W User manual

User Manual
EWC 10550 W - EWC 12550 W
Washing Machine
132967470.qxd 26/05/2008 8.52 Pagina 1

132967470.qxd 26/05/2008 8.52 Pagina 2

electrolux 3
Welcome to the world of Electrolux
Thank you for choosing a first class product from Electrolux, which hopefully will
provide you with lots of pleasure in the future. The Electrolux ambition is to offer a
wide variety of quality products that make your life more comfortable. You find
some examples on the cover in this manual. Please take a few minutes to study
this manual so that you can take advantage of the benefits of your new machine.
We promise that it will provide a superior User Experience delivering Ease-of-
Mind. Good luck!
132967470.qxd 26/05/2008 8.52 Pagina 3

4 contents electrolux
Contents
Safety information..............................5
Product description ...........................7
Control panel .....................................8
Use..................................................11
Washing hints ..................................16
Washing programmes......................19
Programme information ...................21
Care and cleaning ...........................22
What to do if....................................25
Technical data .................................29
Consumption values ........................30
Installation .......................................31
Environment concerns .....................35
The following symbols are used in this manual:
Important information concerning your personal safety and information on how
to avoid damaging the appliance.
General information and tips
Environmental information
132967470.qxd 26/05/2008 8.52 Pagina 4

safety information electrolux 5
Safety Information
In the interest of your safety and to
ensure the correct use, before
installing and first using the
appliance, read this user manual
carefully, including its hints and
warnings. To avoid unnecessary
mistakes and accidents, it is
important to ensure that all people
using the appliance are thoroughly
familiar with its operation and safety
features. Save these instructions
and make sure that they remain
with the appliance if it is moved or
sold, so that everyone using it
through its life will be properly
informed on appliance use and
safety.
General safety
●It is dangerous to alter the
specifications or attempt to modify
this product in any way.
●During high temperature wash
programmes the door glass may get
hot. Do not touch it!
●Make sure that small pets do not
climb into the drum. To avoid this,
please check into the drum before
using.
●Any objects such as coins, safety
pins, nails, screws, stones or any
other hard, sharp material can cause
extensive damage and must not be
placed into the machine.
●Only use the advised quantities of
fabric softener and detergent.
Damage to the fabric can ensue if
you over-fill. Refer to the
manufacturer’s recommendations of
quantities.
●Wash small items such as socks,
laces, washable belts etc in a
washing bag or pillow case as it is
possible for such items to slip down
between the tub and the inner drum.
●Do not use your washing machine to
wash articles with whalebones,
material without hems or torn
material.
●Always unplug the appliance and
turn off the water supply after use,
clean and maintenance.
●Under no circumstances should you
attempt to repair the machine
yourself. Repairs carried out by
inexperienced persons may cause
injury or serious malfunctioning.
Contact your local Service Centre.
Always insist on genuine spare parts.
Installation
●This appliance is heavy. Care should
be taken when moving it.
●When unpacking the appliance,
check that it is not damaged. If in
doubt, do not use it and contact the
Service Centre.
●All packing and transit bolts must be
removed before use. Serious
damage can occur to the product
and to property if this is not adhered
to. See relevant section in the user
manual.
●After having installed the appliance,
check that it is not standing on the
inlet and drain hose and the worktop
is not pressing the electrical supply
cable.
●If the machine is situated on a
carpeted floor, please adjust the feet
in order to allow air to circulate freely
●Always be sure, that there is no
water leakage from hoses and their
connections after the installation.
132967470.qxd 26/05/2008 8.52 Pagina 5

6electrolux safety information
●If the appliance is installed in a
location subject to frost, please read
the “dangers of freezing”chapter.
●Any plumbing work required to install
this appliance should be carried out
by a qualified plumber or competent
person.
●Any electrical work required to install
this appliance should be carried out
by a qualified electrician or
competent person.
Use
●This appliance is designed for
domestic use. It must not be used
for purposes other than those for
which it was designed.
●Only wash fabrics which are
designed to be machine washed.
Follow the instructions on each
garment label.
●Do not overload the appliance. See
the relevant section in the user
manual.
●Before washing, ensure that all
pockets are empty and buttons and
zips are fastened. Avoid washing
frayed or torn articles and treat
stains such as paint, ink, rust, and
grass before washing. Underwired
bras must NOT be machine washed.
●Garments which have been in
contact with volatile petroleum
products should not be machine
washed. If volatile cleaning fluids are
used, care should be taken to
ensure that the fluid is removed from
the garment before placing in the
machine.
●Never pull the power supply cable to
remove the plug from the socket;
always take hold of the plug itself.
●Never use the washing machine if
the power supply cable, the control
panel, the working surface or the
base are damaged so that the inside
of the washing machine is
accessible.
Child safety
●This appliance is not intended for
use by person (including children)
with reduced physical sensory or
mental capabilities or lack of
experience and knowledge unless
they have been given supervision or
instruction concerning use of the
appliance by a person responsible
for their safety.
●The packaging components (e.g.
plastic film, polystyrene) can be
dangerous to children - danger of
suffocation! Keep them out of
children’s reach
●Keep all detergents in a safe place
out of children’s reach.
●Make sure that children or pets do
not climb into the drum. To avoid
that they could remain closed inside
the drum the machine incorporates
special feature. To activate this
device, rotate the button (without
pressing it) inside the door clockwise
until the groove is horizontal. If
necessary use a coin.
To disable this device and restore
the possibility of closing the door,
rotate the button anti-clockwise until
the groove is vertical.
P1131
132967470.qxd 26/05/2008 8.52 Pagina 6

product description electrolux 7
Product description
Detergent dispenser drawer
Control panel
Door opening handle
Drain pump
Adjustable feet
5
4
3
2
1
Prewash
Wash
Fabric Softener
1 2
3
4
5
EN004
Detergent dispenser drawer
Your new appliance meets all modern requirements for effective treatment of laundry
with low water, energy and detergent consumption.
The ECO valve system allows total use of detergent and reduces water
consumption so saving energy.
132967470.qxd 26/05/2008 8.52 Pagina 7

8electrolux control panel
Control panel
Programme selector dial
Temperature button
Spin reduction button
Prewash button
Extra Rinse button
5
4
3
2
1
1 2 3 4 6 7 85 10
9
Symbols
●Cottons , Synthetics , Delicates ,Easy iron , Jeans , Spin ,
Drain , Rinses ,
Lingerie , Silk , Handwash , Wool , Sport
Intensive , Cottons Eco AA , Special programmes
●Cold ,Rinse hold , Prewash , Extra rinse , Delay , Time
manager , Door locked , Child safety Lock
Henceforth, the programme selector dial, the different buttons and the display
and the Door locked pilot light will be indicated in all the book with the relevant
numbers given in the table below.
Delay Start button
Display
Start/Pause button
Door locked pilot light
Time Manger buttons
10
9
8
7
6
132967470.qxd 26/05/2008 8.52 Pagina 8

control panel electrolux 9
Duration of selected
programme/
After selecting a programme, the
duration is displayed in hours and
minutes (for example 2.05). The
duration is calculated automatically on
the basis of the maximum
recommended load for each type of
fabric. After the programme has
started, the time remaining is updated
every minute.
/Delayed start
The selected delay set by pressing the
relevant button appears on the display
for a few seconds, then the duration of
the previously selected programme is
displayed.
/Alarm codes
In the event of operating problems,
some alarm codes can be displayed,
for example E20 (see chapter «What to
do if...»).
7.1 /Incorrect option selection
If an option which is not compatible
with the set wash programme is
selected, the message Err is displayed
for a few seconds and the integrated
red light of button 8starts blinking.
/End of programme
When the programme has finished
three blinking zeros 0.00 are displayed,
the pilot light 9and the pilot light of
button 8go out and the door can be
opened.
Washing programme phase
icons
By selecting the wash programme, the
washing programme phase icons
corresponding to the various phases
making up the programme are shown
in the bottom of the display.
After the machine has started, only the
running icon stays on. When the
programme has finished, three flashing
zero (0.00) is displayed.
7.2
2.05
7.1
7.27.3
7.4 7.5
Display (7)
132967470.qxd 26/05/2008 8.52 Pagina 9

10 electrolux control panel
Heating phase
During the washing cycle the display
shows a temperature icon to indicate
that the appliance has started the
heating phase of the water in the tub.
Soil level icons
When selecting a programme on the
display appears an icon indicating the
degree of soilness automatically
proposed by the machine.
Child lock
This device permits you to leave the
appliance unsupervised during it’s
functioning.
Door locked light (9)
The pilot light 9 illuminates to indicate
that the appliance starts operating and
the door is locked.
This light indicates if the door can be
opened:
• light on: the door cannot be opened.
• light off: the door can be opened.
7.5
7.4
7.3
132967470.qxd 26/05/2008 8.52 Pagina 10

Use
First Use
●Ensure that the electrical and water
connections comply with the
installation instructions.
●Remove the polystryrene block and
any material from the drum.
●Pour 2 litres of water into the main
wash compartment of the
detergent drawer in order to
activate the ECO valve. Then run a
cotton cycle at 90°C, without any
laundry in the machine, to remove
any manufacturing residue from the
drum and tub. Pour 1/2 a measure
of detergent into the dispenser
drawer and start the machine.
Acoustic signals
The machine is provided with an
acoustic device, which sounds in the
following cases:
●at the end of the cycle
●in the event of operating problems
By pressing buttons 4and 5
simultaneously for about 6 seconds,
the acoustic signal is deactivated
(except for the events of operating
problems).
By pressing these 2 buttons again, the
the acoustic signal is reactivated.
Child safety lock
This device permits you to leave the
appliance unsupervised and not to
worry that children might be injured by
or cause damage to the appliance.
This function remains able also when
the washing machine is not working.
There are two different ways to set this
option:
before pressing button 8: it will be
impossible to start the machine.
after pressing button 8: it will be
impossible to change any other
programme or option.
To enable or disable this option press
simultaneously for about 6 seconds
buttons 5and 6until on the display,
the icon appears or disappears.
Daily Use
Load the laundry
Open the door by carefully pulling the
door handle outwards. Place the
laundry in the drum, one item at a time,
shaking them out as much as possible.
Close the door.
Measure out the detergent and the
fabric softener
Pull out the dispenser drawer until it
stops. Measure out the amount of
detergent required, pour it into the
main wash compartment and, if
you wish to carry out the prewash,
pour it into the compartment marked
.
P0004
2
1
use electrolux 11
132967470.qxd 26/05/2008 8.52 Pagina 11

12 electrolux use
If required, pour fabric softener into the
compartment marked (the amount
used must not exceed the “MAX” mark
in the drawer). Close the drawer gently.
Select the required programme by
turning the programme selector
dial (1)
Turn the programme selector dial to
the required programme.
The Start/Pause light starts to flash
and the Display shows the duration of
the selected programme.
The selector dial can be turned either
clockwise or anticlockwise. Position O
corresponds to Reset programme/
Switching OFF the machine.
At the end of the programme the
selector dial must be turned to
position O, to switch the machine
off.
C0071
C0070
Attention!
If you turn the programme selector dial
to another programme when the
machine is working, the red of button 8
will flash 3 times and the message Err
will apperar on the display to indicate a
wrong selection. The machine will not
perform the new selected programme.
Programme Option buttons
Depending on the programme, different
functions can be combined. These
must be selected after choosing the
desired programme and before
pressing the button 8.
When these buttons are pressed, the
corresponding pilot lights come on.
When they are pressed again, the pilot
lights go out.
Select the temperature by pressing
button 2
Press this button repeatedly to
increase or decrease the temperature,
if you want your laundry to be washed
at a temperature different from the one
proposed by the washing machine.
Select the spin speed or Rinse
Hold option
by pressing button 3
When selecting a programme, the
appliance automatically proposes the
maximum spin speed provided for that
programme.
Press button 3repeatedly to change
the spin speed, if you want your
laundry to be spun at a speed different
from the one proposed by the washing
machine. The relevant light will light up.
132967470.qxd 26/05/2008 8.52 Pagina 12

use electrolux 13
Rinse Hold: by selecting this option
the water of the last rinse is not
emptied out to prevent the fabrics from
creasing. When the programme has
finished the display shows 0.00
flashing, the pilot light 9is on, the light
of button 8is off and the door is
locked to indicate that the water must
be emptied out.
To empty the water out please read
chapter «At the end of the
programme».
Select the Prewash option by
pressing button 4
Select this option if you wish your
laundry to be prewashed at 30°C
before the main wash.
The Prewash ends with a short spin in
programmes for cotton and synthetic
fabrics, whereas in the programmes for
delicate fabrics the water is only
drained.
Select the Extra Rinse option by
pressing button 5
The machine performs some additional
rinses. This option is recommended for
people who are allergic to detergents,
and in areas where the water is very
soft.
Select the Delay Start by pressing
button 6
Before you start the programme, if you
wish to delay the start, press button 6
repeatedly, to select the desired delay.
The relevant light will illuminate.
The selected delay time value (up to 20
hours) will appear on the display for a
few seconds, then the duration of the
programme will appear again.
You must select this option after you
have set the programme and before you
press button 8.
If you wish to add laundry in the
machine during the delay time you will
press button 8to put the machine in
pause. Add the laundry, close the door
and press button 8again.
You can cancel or modify the delay time
at any moment, before you press
button 8.
The wash programme can be delayed
from 30 min - 60 min - 90 min, 2 hours
and then by 1 hour up to a maximum of
20 hours by means of this button.
Selecting the delayed start
• Select the programme and the
required options.
• Select the delay start.
• Press button 8: the machine starts its
hourly countdown.
The programme will start after the
selected delay has expired.
Cancelling the delayed start
• Press button 8.
• Press button 6button once until the
symbol 0’ is displayed.
• Press button 8again.
The Delay Start can not be selected
with Drain programme.
Select the Start/Pause by pressing
button 8
To start the selected programme, press
button 8; the green pilot light stops
flashing.
To interrupt a programme which is
132967470.qxd 26/05/2008 8.52 Pagina 13

14 electrolux use
running, press button 8: the green pilot
light starts to flash.
To restart the programme from the point
at which it was interrupted, press
button 8again.
If you have chosen a delayed start, the
machine will begin the countdown.
If an incorrect option is selected, an
integrated red pilot light of button 8
flashes for 3 times the message Err is
displayed for a few seconds.
Select the Time Manager option by
pressing buttons 10
This function allows you to modify the
washing time, automatically proposed
by the washing machine.
By pressing this buttons repeatedly, the
duration of the washing cycle can be
increased or decreased.
A soil level icon will appear on the
display to indicate the choosen degree
of soil.
(*) We recommend you to reduce the load
sizes.
Attention!
This option cannot be selected with the
Economy cottons programmes.
The availability of these soil level icons
change according to the type of fabric
as shown in the follwing chart.
Altering an option or a running
programme
It is possible to change some option
before the programme carries it out.
Before you make any change, you must
pause the washing machine by pressing
button 8.
(Only the Time Manager option cannot
be modified after the programme has
started. )
Changing a running programme is
possible only by resetting it. Turn the
programme selector dial to Oand then
to the new programme position. Start
the new programme by pressing button
8 again. The washing water in the tub
Soil
Level Icon Type of fabric
Intensive For heavy soiled items
Normal For normal soiled items
Daily For daily soiled items
Light For slightly soiled items
Quick For very slightly soiled items
Super
Quick (*)
For items used or worn for a
short time
Fabric Soil Level
Cottons
Intensive Normal Daily Light Quick S. Quick
95°/90°C XXXXXX
60°C XXXXXX
40°C XXXXXX
30°C XXXXXX
(cold)
XXXXXX
Synthetics
Delicates
60°C
X X X X
40°C X X X X
40°C X X X X
30°C X X X X
30°C X X X X
(cold)
X X X X
(cold)
X X X X
132967470.qxd 26/05/2008 8.52 Pagina 14

use electrolux 15
will not emptied out.
Interrupting a programme
Press button 8to interrupt a
programme which is running, the
corresponding light starts to flash. Press
the button again to restart the
programme.
Cancelling a programme
Turn the selector dial to Oto cancel a
programme which is running. You can
now select a new programme.
Opening the door after the
programme has started
First set the machine to pause by
pressing button 8.
If the light 9goes off, the door can be
opened.
If the light 9 does not goes off, this
means that the machine is already
heating, that the water level is above
the bottom edge of the door.
In this case the door can not be
opened.
If you cannot open the door but you
need to open it you have to switch the
machine off by turning the selector dial
to O. After a few minutes the door can
be opened (pay attention to the
water level and temperature!).
After closing the door, it is necessary to
select the programme and options
again and press button 8.
At the end of the programme
The machine stops automatically, the
pilot light of button 8 goes off and
three blinking «0.00» will appear on the
display.
If a programme with option that ends
with water still in the tub has been
selected, the pilot light 9remains lit
and the door locked to indicate that
the water must be emptied out before
opening the door.
To empty out the water:
●turn the programme selector dial to
O
●select the Drain or the Spin
programme
●reduce the spin speed if needed, by
pressing the relevant button
●press button 8
At the end of programme, the pilot
lights 9goes off and the door can be
opened.
Turn the programme selector dial to
«O» to switch the machine off.
Remove the laundry from the drum and
carefully check that the drum is empty.
If you do not intend to carry out
another wash, close the water tap.
Leave the door open to prevent the
formation of mildew and unpleasant
smells.
132967470.qxd 26/05/2008 8.52 Pagina 15

16 electrolux washing hints
Washing hints
Sorting the laundry
Follow the wash code symbols on each
garment label and the manufacturer’s
washing instructions. Sort the laundry as
follows: whites, coloureds, synthetics,
delicates, woollens.
Temperatures
Before loading the laundry
Never wash whites and coloureds
together. Whites may lose their
“whiteness” in the wash.
New coloured items may run in the first
wash; they should therefore be washed
separately the first time.
Make sure that no metal objects
are left in the laundry (e.g. hair
clips, safety pins, pins).
Button up pillowcases, close zip
fasteners, hooks and poppers. Tie any
belts or long tapes.
Remove persistent stains before
washing.
Rub particularly soiled areas with a
special detergent or detergent paste.
Treat curtains with special care. Remove
hooks or tie them up in a bag or net.
Maximum loads
Recommended loads are indicated in
the programme charts.
General rules:
Cotton, linen: drum full but not too
tightly packed;
Synthetics: drum no more than half full;
Delicate fabrics and woollens: drum
no more than one third full.
Washing a maximum load makes the
most efficient use of water and energy.
For heavily soiled laundry, reduce the
load size.
Laundry weights
The following weights are indicative:
Removing stains
Stubborn stains may not be removed by
just water and detergent. It is therefore
advisable to treat them prior to washing.
Blood: treat fresh stains with cold water.
For dried stains, soak overnight in water
with a special detergent then rub in the
soap and water.
90°or
95°
for normally soiled white
cottons and linen (e.g. tea
cloths, towels, tablecloths,
sheets...)
60°
for normally soiled, colour
fast garments (e.g. shirts,
night dresses, pyjamas....) in
linen, cotton or synthetic
fibres and for lightly soiled
white cotton (e.g.
underwear).
30°-40°-
(cold)
for delicate items (e.g. net
curtains), mixed laundry
including synthetic fibres and
woollens bearing the label
«pure new wool, machine
washable, non-shrink».
1200 gbathrobe
100 gnapkin
700 gquilt cover
500 gsheet
200 gpillow case
250 gtablecloth
200 gtowelling towel
100 gtea cloth
200 gnight dress
100 gladies’ briefs
600 gman’s work shirt
200 gman’s shirt
500 gman’s pyjamas
100 gblouse
100 gmen’s underpants
132967470.qxd 26/05/2008 8.52 Pagina 16

Oil based paint: moisten with benzine
stain remover, lay the garment on a soft
cloth and dab the stain; treat several
times.
Dried grease stains: moisten with
turpentine, lay the garment on a soft
surface and dab the stain with the
fingertips and a cotton cloth.
Rust: oxalic acid dissolved in hot water
or a rust removing product used cold.
Be careful with rust stains which are not
recent since the cellulose structure will
already have been damaged and the
fabric tends to hole.
Mould stains: treat with bleach, rinse
well (whites and fast coloureds only).
Grass: soap lightly and treat with bleach
(whites and fast coloureds only).
Ball point pen and glue: moisten with
acetone (*), lay the garment on a soft
cloth and dab the stain.
Lipstick: moisten with acetone as
above, then treat stains with methylated
spirits. Remove any residual marks from
white fabrics with bleach.
Red wine: soak in water and detergent,
rinse and treat with acetic or citric acid,
then rinse. Treat any residual marks with
bleach.
Ink: depending on the type of ink,
moisten the fabric first with acetone (*),
then with acetic acid; treat any residual
marks on white fabrics with bleach and
then rinse thoroughly.
Tar stains: first treat with stain remover,
methylated spirits or benzine, then rub
with detergent paste.
(*) do not use acetone on artificial silk.
Detergents and additives
Good washing results also depend on
the choice of detergent and use of the
correct quantities to avoid waste and
protect the environment. Although
biodegradable, detergents contain
substances which, in large quantities,
can upset the delicate balance of nature.
The choice of detergent will depend on
the type of fabric (delicates, woollens,
cottons, etc.), the colour, washing
temperature and degree of soiling.
All commonly available washing machine
detergents may be used in this
appliance:
• powder detergents for all types of
fabric,
• powder detergents for delicate fabrics
(60°C max) and woollens,
• liquid detergents, preferably for low
temperature wash programmes (60°C
max) for all types of fabric, or special
for woollens only.
The detergent and any additives must
be placed in the appropriate
compartments of the dispenser drawer
before starting the wash programme.
If using concentrated powder or liquid
detergents, a programme without
prewash must be selected.
The washing machine incorporates a
recirculation system which allows an
optimal use of the concentrated
detergent.
Pour liquid detergent into the dispenser
drawer compartment marked just
before starting the programme.
Any fabric softener or starching additives
must be poured into the compartment
marked before starting the wash
programme.
washing hints electrolux 17
132967470.qxd 26/05/2008 8.52 Pagina 17

Follow the product manufacturer’s
recommendations on quantities to use
and do not exceed the «MAX» mark
in the detergent dispenser drawer.
Quantity of detergent to be used
The type and quantity of detergent will
depend on the type of fabric, load size,
degree of soiling and hardness of the
water used.
Water hardness is classified in so-called
“degrees” of hardness. Information on
hardness of the water in your area can
be obtained from the relevant water
supply company, or from your local
authority.
Follow the product manufacturers’
instructions on quantities to use.
Use less detergent if:
• you are washing a small load,
• the laundry is lightly soiled,
• large amounts of foam form during
washing.
Degrees of water hardness
Level
Degrees
German
°dH
French
°T.H.
Characteristic
10-7 0-15soft
28-14 16-25medium
315-21 26-37hard
4> 21 > 37very hard
18 electrolux washing hints
132967470.qxd 26/05/2008 8.52 Pagina 18

Washing programmes
Programme/
Temperature Type of laundry Options Description of programme
Cottons
90° - Cold
White and coloured
cotton
Spin Reduction/
Rinse Hold
Prewash, Extra rinse
Time manager
Main wash
Rinses
Long spin at
maximum speed.
Max. load kg 5
** Red. load kg 2.5
Synthetics
60° - Cold
Synthetic or mixed
fabrics
Spin Reduction/
Rinse Hold
Prewash, Extra rinse
Time manager
Main wash
Rinses
Short spin
Max. load kg 2
** Red. load kg 1
Synthetics
Easy Iron
60° - Cold
Synthetic or mixed
fabrics to be gentle
washed and spun
Spin Reduction/
Rinse Hold
Prewash, Extra rinse
Main wash
Rinses
Short spin
Max. load kg 1
Delicates
40° - Cold Delicate fabrics
Spin Reduction/
Rinse Hold
Prewash, Extra rinse
Time manager
Main wash
Rinses
Short spin
Max. load kg 2
** Red. load kg 1
Lingerie
40° - Cold
Special programme
for extremely
delicate hand
washable items.
Spin Reduction/
Rinse Hold
Main wash
Rinses
Short spin
Max. load kg 1
Silk
30° - Cold
Silk items to be
gentle washed and
spun.
Spin Reduction/
Rinse Hold
Main wash
Rinses
Short spin
Max. load kg 1
Jeans
60° - Cold
Special programme
for Jeans items,
pants, shirts,
jackets.
Spin Reduction/
Rinse Hold
Prewash,
Main wash
Rinses
Long spin at
maximum speed
Max. load kg 2.5
washing programmes electrolux 19
** If you select the Super Quick option by pressing Time Manager buttons (10),
we recommend you, to reduce the maximum load as indicated. (Red. load =
reduced load). Full loading is possible however with somewhat reduced clea-
ning results.
132967470.qxd 26/05/2008 8.52 Pagina 19

Rinses
Separate rinse cycle
for cotton hand
washed items.
3 rinses
Long spin
Max. load kg 5
Drain
For emptying out the
last rinse water in
programmes with the
Rinse Hold option
Draining of water
Spin Separate spin for
cottons. Spin reduction
Drain and long spin
at the maximum
speed
Max. load kg 5
Spin Reduction/
Rinse Hold
Extra rinse
O
For cancelling the
wash programme
which is running and
for switching the
machine off.
Wool
40° - Cold
Specially tested
programme for wool
garments bearing the
“Pure new wool, non-
shrink, machine
washable” label.
Spin Reduction/
Rinse Hold
Main wash
Rinses
Short spin
Max. load kg 1
Programme/
Temperature Type of laundry Options Description of programme
Handwash
40° - Cold
Special programme
for hand washing
fabrics.
Spin Reduction/
Rinse Hold
Main wash
Rinses
Short spin
Max. load kg 1
Sport
Intensive
40° - Cold
Heavily soiled sport
items
Spin Reduction/
Rinse Hold, Extra
Rinse
Prewash, Main wash
Rinses
Short spin
Max. load kg 2.5
Washing programmes
Cottons
Eco AA
90° - 40°
White and coloured
cotton economy,
lightly-normally soiled
Spin Reduction/
Rinse Hold
Prewash, Extra rinse
Main wash
Rinses
Long spin at
maximum speed.
Max. load kg 5
20 electrolux washing programmes
132967470.qxd 26/05/2008 8.52 Pagina 20
