Electrolux LAVALOGIC EWM 3000 User manual

599 51 13-50
SERVICE MANUAL
Washing
EN
DGS-TDS-N
Edition: 11.2004
Frontloading
washing machines
EWM 3000
Advanced

- 2 - 599 51 13-50 EN
DGS-TDS-N 11.2004 C.D. © Electrolux
Index
Characteristics ( features ) ........................................................................... 4
1. Operating e ements / pane ........................................................................... 5
1.1 One button input phi osophy ......................................................................... 5
1.2 The pane ...................................................................................................... 5
1.3 The program se ection switch ...................................................................... 5
2. Additiona programes .................................................................................... 6
2.1 Gent e spin .................................................................................................... 6
2.2 Spining .......................................................................................................... 6
2.3 Fast unba ance contro system FUCS..........................................................6
2.3.1 Fast unba ance contro system FUCS .......................................................... 7
2.4 Pumping ....................................................................................................... 8
2.5 Starching ...................................................................................................... 8
2.6 E-Program .................................................................................................... 8
2.7 Easy Iron ....................................................................................................... 9
2.8 Refresh ......................................................................................................... 9
2.9 Fashion ......................................................................................................... 9
2.10 Si k ................................................................................................................ 9
3. Option buttons / disp ay .............................................................................. 10
3.1 Prewash ..................................................................................................... 10
3.2 Sensitive ..................................................................................................... 10
3.3 Stain ........................................................................................................... 10
3.4 Time Saver ................................................................................................. 11
3.5 Speed dese ection ...................................................................................... 11
3.6 The mu ti-disp ay ......................................................................................... 12
3.7 The duration-disp ay ................................................................................... 12
3.8 Moisture / oading ........................................................................................ 12
3.9 Start - Pause .............................................................................................. 13
3.10 The e ectronic program-cyc e disp ay ......................................................... 13
3.10 The inte igent door ock .............................................................................. 14
3.11 Door ocking conditions .............................................................................. 14
4. Additiona features ...................................................................................... 15
4.1 Stand-by operation ...................................................................................... 15
4.2 Drum ight ................................................................................................... 15
4.2 Suds coo ing ............................................................................................... 16
4.2.1 Activate suds coo ing .................................................................................. 16
4.2.2 Deactivate suds coo ing ............................................................................. 16
4.3 Rinse+ cyc e ............................................................................................... 17
4.3.1 Activate rinse+ cyc e ................................................................................... 17
4.3.2 Deactivate rinse+ cyc e .............................................................................. 17
4.4 Variomatic oosening-up spin ...................................................................... 18
4.4.1 Activate variomatic oosening-up spin ......................................................... 18
4.4.2 Deactivate variomatic oosening-up spin .................................................... 18
4.5 Safety device .............................................................................................. 19
4.5.1 Activate the safety device ........................................................................... 19
4.5.2 Switch off the savety device ....................................................................... 19
4.5 The hand- aundry program ......................................................................... 20
4.5.1 Differences to the woo program ................................................................ 20
5. Water intake system ................................................................................... 21
5.1 Waterdistributer + va ve .............................................................................. 21
5.2 Drawer ........................................................................................................ 22
5.3 Water-intake diargrams .............................................................................. 23
5.3.1 Kind of aundry messurement ..................................................................... 23
5.3.2 Fast damping technic ................................................................................. 23
5.3.3 Water intake diagrames ............................................................................. 24
5.4 Definition ART2 rinsing ............................................................................. 24
5.4 Definition ART2 rinsing ............................................................................. 25
5.4.1 Rinse techno ogy ........................................................................................ 25

- 3 - 599 51 13-50 EN
DGS-TDS-N 11.2004 C.D. © Electrolux
5.5 First rinse .................................................................................................... 26
5.6 Additiona rinse ........................................................................................... 26
5.7 Second rinse .............................................................................................. 26
5.8 Softening rinse ............................................................................................ 27
6. Coo down ................................................................................................... 27
7. Aqua contro system ................................................................................... 28
7.1 Genera construction .................................................................................. 28
7.2 F oating switch ............................................................................................ 28
8. The pressure sensor .................................................................................. 29
8.1 Function of the ana og sensor .................................................................... 29
9. The automatic foot ...................................................................................... 29
10. Components ............................................................................................... 30
10.1 Program / temperature se ection switch ..................................................... 30
10.2 The NTC sensor ......................................................................................... 31
10.3 The heating e ement ................................................................................... 31
10.4 The drain pump .......................................................................................... 32
10.5 The recircu ation pump ............................................................................... 32
10.6 The in et va ves ........................................................................................... 33
10.7 The motor ................................................................................................... 33
11. Motor contro ing EPW ................................................................................. 34
11.1 Signa s from main e ectronic board to the motor e ectronic ....................... 34
12. Customer service test program .................................................................. 35
12.1 Fau t indications .......................................................................................... 36
12.2 C assification of a arm codes ..................................................................... 37
13. Spinning profi es ......................................................................................... 38
13.1 Intermediate spin ........................................................................................ 38
13.1 Intermediate spin ........................................................................................ 39
13.2 Fina spin .................................................................................................... 40
13.2 Fina soin .................................................................................................... 41
13.2 Fina spin .................................................................................................... 42
13.3 Spinning cyc es of the extra programs ....................................................... 43
13.3 Spinning cyc es of the extra programs ....................................................... 44
14. Technic ....................................................................................................... 45
14.1 Wiring p an .................................................................................................. 45
14.2 Circuit diagram ........................................................................................... 46
14.3 Legend ........................................................................................................ 47
14.4 Funktion chart ............................................................................................. 49
10. Service - Instructions .................................................................................. 50
10.1 Access from the front side of the app iance ............................................... 50
10.1.1 Worktop ...................................................................................................... 50
10.1.2 Pane , knobs and buttons ........................................................................... 50
10.1.2 Pane , knobs and buttons ........................................................................... 51
10.1.3 Be ows ....................................................................................................... 51
10.1.3 Be ows ....................................................................................................... 52
10.1.4 Drain pump ................................................................................................. 53
10.1.5 Door ock .................................................................................................... 53
10.1.6 Tub front, weight ......................................................................................... 54
10.1.7 Door, door g ass, door rings, door hinge and ocking hook ......................... 54
10.2 Access from the rear side of the app iance ................................................ 55
10.2.1 Rear p ate ................................................................................................... 55
10.2.2 Assemb ing position of motor, motor e ectronic DC, heating e ement ........ 55
10.2.3 Motor ........................................................................................................... 56
10.2.4 The heating e ement ................................................................................... 56
10.2.5 NTC sensor ................................................................................................ 57
10.3 Access from the top side of the app iance .................................................. 57
10.3.1 Pressure switches ...................................................................................... 57
10.3.2 Disassemb y of the main e ectronic board ................................................. 58
10.3.3 The va ves .................................................................................................. 58
10.3.4 Water distributor ......................................................................................... 59

- 4 - 599 51 13-50 EN
DGS-TDS-N 11.2004 C.D. © Electrolux
- E ectronic machine
- Foam detection
- FUCS unba anced oad system
- Motor is pu s width contro ed
- Pressure sensor
- Recircu ation - system
- Carboran tub
- Maxima number of drum revo ution 1800 1/min
- Automatic foot
- 4 additiona programmes
Characteristics (features)

- 5 - 599 51 13-50 EN
DGS-TDS-N 11.2004 C.D. © Electrolux
1.2 The panel
Machine class 8xx4x / LED version
- 1 mu tidisp ay, time of duration
- LED´s for the program cyc e
- LED´s for option buttons
Machine class 8xx4x / background illuminated
- 3 mu tidisp ays, spinspeed adjustment
rest moisture in % / oad in %, time of duration
- Disp ay for the program cyc e is background i uminated
- Function of the buttons are background i uminated
1. Operating elements / panel
1.1 One button input philosophy
Every washing program with its temperature can be adjusted with the program se ection switch.
1.3 The program selection switch
- 15 basic programs
- 6 program b ocks
-Cotton / Linen / Easy-Cares
- Starching / Drain / Spin
-Energy-Saving
- Easy Iron / Refresh /
Fashion / Si k
-De icates
- Hand aundry / Woo
- On / Off - switch integrated in
program-se ector
- Quick program correction possib e

- 6 - 599 51 13-50 EN
DGS-TDS-N 11.2004 C.D. © Electrolux
2. A itional programes
2.1 Gentle spin
Se ect with program se ection switch gent e spin
a most same as hand aundry - fina spin
2.2 Spining
Se ect with program se ection switch spining
a most the same as boi ed / co ored fina spin with 2 pre-spinning phases
2.3 Fast unbalance control system FUCS
Common function:
The FUCS system has 4 phases:
1. Start phase
2. Distribution phase
3. Time out phase
4. Measuring phase
1. Start phase:
In this phase the drumspeed is increased up to 80 1/min.
2. Distribution phase:
During this phase the aundry shou d be distributed we ba anced by regu ating the drumspeed.
This phase ends, if 120 1/min are reached or the time of 120s ( at wo 60s ) is expired.
If the time is expired its ca ed Time out (Tout).
3. Time out phase:
This phase is excecuted, if the distribution phase has ended in cause of a time out.
This step is neccessary because the drumspeed has to be increased up to 120 1/min.
4. Measuring phase:
During this phase a unba anced oad detection is excecuted ike known before.
The spinning cyc e is excecuted, depending on the amount of unba anced oad.
An forced acce eration happens if the unba anced oad is to high.
Forced acce eration: Sma unba anced oad 1023 1/min
Big unba anced oad 700 1/min

- 7 - 599 51 13-50 EN
DGS-TDS-N 11.2004 C.D. © Electrolux
2. .1 Fast unbalance control system FUCS








 
WLPH>V@
V
H
W

V
S
H
H
G
VKRUW)8&6
)8&6WLPHRXW
'LVWULEXWLRQ
SKDVH
0HDV
XULQJ
SKDVH
6WDUW
SKDVH
7LPHB
RXW
SKDVH

- 8 - 599 51 13-50 EN
DGS-TDS-N 11.2004 C.D. © Electrolux
2.4 Pumping
Se ect with program se ection switch position pumping.
Pumping unti switching point of the pressure switch (Foam niveau)
additiona 30 sec. fixed pumping time
2.5 Starching
Se ect with program se ection switch position starching.
It's the same rinse as the 3. rinse from boi ed / co ored
- fi ing to washing eve (ca. 5,4 ) chamber 1,
- after that fi ing over softener chamber (2,5 - 1 min. mechanic - 2,5 ) + circu ation pump,
- then 3,4min. reversing 70% mech. 53 1/min + circu ation pump, fina spin
2.6 E-Program
Se ect with program se ection switch position energy saving.
- energy and water saving, wash cyc e at approx. 67°C
- extended wash time

- 9 - 599 51 13-50 EN
DGS-TDS-N 11.2004 C.D. © Electrolux
2.8 Refresh
2.9 Fashion
2.7 Easy Iron
Se ection with program se ection switch, position easy iron.
- temperature 40°C; oad 1 kg
- fi ing to cottons/ inen eve
- mechanic 25%
- ON 12 sec / OFF 4 sec, 53 1/min
- 3 rinse cyc es
- program takes about 90 min
Se ection with program se ection switch, position refresh.
- temperature 30°C; oad 2.5 kg
- fi ing to refresh eve
- mechanic 70%
- ON 21 sec / OFF 9 sec, 53 1/min
- 2 rinse cyc es
- program takes about 20 min
Se ection with program se ection switch, position fashion.
- temperature 40°C; oad 2.5 kg
- fi ing to de icate eve
- mechanic 40%
- ON 8 sec / OFF 12 sec, 40 1/min
- 3 rinse cyc es
- program takes about 70 min
2.10 Silk
Se ection with program se ection switch, position silk.
- temperature 30°C; oad 1 kg
- fi ing to de icate eve
- mechanic 10%
- ON 3 sec / OFF 27 sec, 27 1/min
- 3 rinse cyc es
- program takes about 46 min

- 10 - 599 51 13-50 EN
DGS-TDS-N 11.2004 C.D. © Electrolux
3.2 Sensitive
3.3 Stain
3. Option buttons / isplay
3.1 Prewash
- specia program supp ement with an additiona rinse cyc e
- reduced washing mechanic
- automatic coo ing
- to treat very dirty aundry
- stain remover is rinsed in optimized in time (after the bio phase)
When setting woo / hand wash you can not se ect the program supp ements using the buttons!
- If you chose woo with prewash it is not possib e
because this function is ocked.
- Prewash is genera y co d
- Different wash mechanics
They depend on the chosen main program
- It takes about 25 min.
- 5 min circu ation pump on
- After the prewash the main program is automatically started

- 11 - 599 51 13-50 EN
DGS-TDS-N 11.2004 C.D. © Electrolux
3.4 Time saver
3.5 Spee eselection
- the speed dese ection button on y inf uences the fina spin speed
- setting via key button function
- With the automatic cyc es the maximum fina speed is indicated first.
- You can dese ect the fina spin with a cyc es, i.e. rinse hold.
- Reduced wash cyc e for ess dirty aundry with the program white /
co ored, easy care in 3 steps (L, M, S)
- setting via key button function
L approx. 119 min
M approx. 91 min (saving 25% time)
S approx. 63 min (saving 50% time)
or
RINSE HOLD

- 12 - 599 51 13-50 EN
DGS-TDS-N 11.2004 C.D. © Electrolux
3.6 The multi- isplay
3.7 The uration- isplay
or
3.8 Moisture / loa ing
- indicates pre-se ected start time (up to 19h), adjustab e in 1h steps
- after the start time is chosen the start button must be pushed to
activate the pre-se ected start time.
- If you press the break button during the pre-se ected start time the door
can be opened.
- indicates the additiona soaking time
- once programe has started, indicates the estimated duration of
program / remaining duration inminutes
- indicates fau ts (for examp e C1)
- update IR - Interface
- without button, on y mu ty disp ay
- On y 8xxxx range with bachground i umination has the disp ay
- If the oad is defent y recognized (after approx. 10 min.), the rest
moisture is disp ayed. They are a ternating disp ayed in a 1min. rhytm
in %
- If woo / de icate wash or additiona programs are chosen the disp ay is
out of function.
- The oad is disp ayed in 10 % steps.
- Before programstart, it indicates the estimated program time.
The estimated program time can be corrected automatica y.
The times of prewash, mainwash, rinse and spinning wi be added
and corrected.
- indicates estimated duration of program / remaining duration in
minutes. The duration in minutes can be corrected because of the
Sensor ogic, Fuzzy - Logic and UKS.
- indicates the end of program

- 13 - 599 51 13-50 EN
DGS-TDS-N 11.2004 C.D. © Electrolux
3.9 Start - Pause
3.10 The electronic program-cycle isplay
- indicates the se ected program steps
- indicates the actua steps during the program
- indicates the end of program
- indicates at the end of program "Over Dosing", that means too
much detergent is used.
- indicates fau t codes
- In the customer service program it a so indicates water eve s
Displayed with LED's or backround illumination
- After the program and the options are chosen you start the machine
with the start button.
After that moment you can on y change the spinspeed.
- Pause: Program stops in any position.
- During the pausetime the change of the program isn't possib e.
- If you turn the se ection switch during the program you must restart
the machine.

- 14 - 599 51 13-50 EN
DGS-TDS-N 11.2004 C.D. © Electrolux
3.10 The intelligent oor lock
- E ectrica - magnetic door ock ; To open the door you have to use
the button on the pana
- If you want to open the door the machine must have power
- Emergency opening with the knob on the base pane .
Displayed with LED's or backround illumination
#FGPSFTUBSUEPPSJTPQFO 3FE%PPSJTPQFO
3FEGMBTIJOH4UBSUCVUUPOJTQSFTTFEXIJMF
UIFEPPSJTPQFO
#FGPSFTUBSUEPPSJTDMPTFE (SFFO%PPSDBOCFPQFOFE
"GUFSTUBSUEPPSJTDMPTFE (SFFO%PPSXJMMCFMPDLFE-&%TUBZTPO
(SFFOBTMPOHBTOPMPDLJOH
DPOEJUJPOTBSFGVMGJMMFE BMTPJGUIF
CSFBLCVUUPOJTQVTIFE
0GG*TOPUJMMVNJOBUFEJGUIFUIFEPPSJT
MPDLFE-PDLJOHDPOEJUJPOT
"GUFSFOEPGQSPHSBNF (SFFO5IFEPPSJTOPUMPDLFEBOEDBOCF
PQFOFE
3FE5IFEPPSJTPQFOFE
3.11 Door locking con itions
1. Niveau >= fN 2
2. water temperature >= 60°C
3. nist >= 60 1/min drum
4. nsoll >= 120 1/min drum at the end of spinning
5. NTC short circuit
6. Broken tacho generator
7. Since the first heating the door must be ocked

- 15 - 599 51 13-50 EN
DGS-TDS-N 11.2004 C.D. © Electrolux
4. A itional features
4.1 Stan -by operation
On y machines with background i umination have this feature!
1. During the pre - se ected start time:
3 min. after the ast operation a disp ays exept the mu ti disp ay are shut down.
Any kind of operation (press a button) stops the stand - by - modus and starts a
the according disp ays.
2. After the end of program:
3 min. after the end of program without any operation a disp ays are shut down exept
the LED "END" or perhaps a disp ayed fau t code.
You can stop this standby ike shown in point 1.
Use : Less energy consumption.
The drum light is activated....
.... if the machine is switched on and the door is opened,
.... or the user opens the door
.... or the user presses the door / ight button if the machine isn't in the stand-by-modus.
The drum light is switched off ....
.... if the fixed time of 3 min. has run out,
.... or the user c oses the door
.... or the machine starts the stand-by-modus.
The ha ogen amp is owered in sma brightness steps.
If the drum ight is switched on, the user is ab e to enghten the fixed i umination time,
when he presses the door / ight button.
4.2 Drum light

- 16 - 599 51 13-50 EN
DGS-TDS-N 11.2004 C.D. © Electrolux
4.2.2 Deactivate suds cooling
Programming before program start:
- Set se ection switch to position short spin.
- Keep prewash button pressed at east 5 sec.
- To confirm the main wash LED is f ashing for 5 sec.
- Whi e the main wash LED is f ashing, re ease the prewash button.
- When the f ashing has stopped, the suds coo ing is active.
Programming before program start:
- Set se ection switch to position short spin.
- Keep prewash button pressed at east 5 sec.
- Immediate y when pressing the button, the main wash LED is f ashing.
- After 5 sec the f ashing stopps and the LED is it continuous y for 5 sec.
- Whi e the main wash LED is it continuous y, re ease the prewash button.
- After the main wash LED has stopped ighting, the suds coo ing is cance ed.
In order to check whether the suds cooling is activated, set the program selection switch to
short spin and press the prewash button shortly. When the main wash LED is flashing,
the suds cooling is activated.
4.2.1 Activate suds cooling
4.2 Su s cooling

- 17 - 599 51 13-50 EN
DGS-TDS-N 11.2004 C.D. © Electrolux
4. .2 Deactivate rinse+ cycle
An extra rinse cycle increases water consumption and program run time!
4. .1 Activate rinse+ cycle
4.3 Rinse+ cycle
Programming before program start:
- Set se ection switch to position short spin.
- Keep sensitive button pressed at east 5 sec.
- Immediate y when pressing the button, the rinse+ LED is f ashing.
- After 5 sec the f ashing stopps and the LED is it continuous y for 5 sec.
- Whi e the rinse+ LED is it continuous y, re ease the sensitive button.
- After the rinse+ LED has stopped ighting, the rinse+ cyc e is cance ed.
Programming before program start:
- Set se ection switch to position short spin.
- Keep sensitive button pressed at east 5 sec.
- To confirm the rinse+ LED is f ashing for 5 sec.
- Whi e the rinse+ LED is f ashing, re ease the sensitive button.
- When the f ashing has stopped, the rinse+ cyc e is active.
In order to check whether the rinse+ cycle is activated, set the program selection switch to
short spin and press the sensitive button shortly. When the rinse+ LED is flashing,
the rinse+ cycle is activated.

- 18 - 599 51 13-50 EN
DGS-TDS-N 11.2004 C.D. © Electrolux
4.4 Variomatic loosening-up spin
4.4.1 Activate variomatic loosening-up spin
Programming before program start:
- Set se ection switch to position short spin.
- Keep stain button pressed at east 5 sec.
- To confirm the end LED is f ashing for 5 sec.
- Whi e the end LED is f ashing, re ease the stain button.
- When the f ashing has stopped, the variomatic oosening-up spin is active.
4.4.2 Deactivate variomatic loosening-up spin
Programming before program start:
- Set se ection switch to position short spin.
- Keep stain button pressed at east 5 sec.
- Immediate y when pressing the button, the end LED is f ashing.
- After 5 sec the f ashing stopps and the LED is it continuous y for 5 sec.
- Whi e the end LED is it continuous y, re ease the stain button.
- After the end LED has stopped ighting, the variomatic oosening-up spin is cance ed.
In order to check whether the loosening-up spin is activated, set the program selection switch
to short spin and press the stain button shortly. When the end LED is flashing,
the loosening-up spin is activated.

- 19 - 599 51 13-50 EN
DGS-TDS-N 11.2004 C.D. © Electrolux
Behaviour if a button is pressed:
Behaviour if the prorgam se ection switch is turned:
4.5.2 Switch off the savety device
4.5 Safety de ice
4.5.1 Activate the safety device
- You can activate it, if the program is started with the start button.
- Press the buttons prewash and sensitive at the same time for about 5 sec.
- You can see that the safety device is started if a LED's of the program duration disp ay
are f ashing for about 5 sec.
- After that the duration of the program is disp ayed in the usua way.
- The safety device is started and stays active a so at the end of program.
-A LED's of the program duration disp ay are f ashing for about 5 sec.
After that the duration of the program is disp ayed in the usua way.
-A LED's of the program duration disp ay are f ashing, unti the origina position of
the program knob is se ected.
-The program which was chosen before continues.
-It doesn't inf uence the savety device in it's activity, if the program knob is turned to the
position "OFF".
-Press the buttons prewash and sensitive at the same time for about 5 sec.
-You can see that the savety device is stopped if a LED's of the program duration disp ay
are f ashing for about 5 sec. and then the program duration disp ay must i uminate
comp ete.
- After that the duration of the program is disp ayed in the usua way.

- 20 - 599 51 13-50 EN
DGS-TDS-N 11.2004 C.D. © Electrolux
4.5.1 Differences to the wool program
- about 60 % ess shrink
- water consumption (39 at 30°C), decreased for about 25%
- the wash and rinse resu ts are the same as previous resu ts.
- program duration (36 min. at 30°C), decreased for about 25%
- energy consumption (0,2 kWh at 30°C), decreased for about 10%
- the fina spin speed of 1200 1/min is possib e
4.5 The han -laun ry program
Every piece of aundry with the sign " on y suited for hand- aundry "
can now be washed with the app iance.
The machine wash has an advantage regarding the hand wash.
This proves an expert's report of the Wfk-Institute.
- ess shrink
- the aundry is ess fe ted -> The surface is more even and f eecy
- ess b eaching of co ours
- ess formation of crease
8PPM )BOEMBVOESZ
QSPHSBNNF
%SVNNPWFNFOU  
1BVTF TFL TFL
