Electrolux EWN 16781 W User manual

User Manual
EWN 16781 W
Washing Machine
132972260 EN.qxd 30/03/2007 15.32 Pagina 1

132972260 EN.qxd 30/03/2007 15.32 Pagina 2

electrolux 3
Welcome to the world of Electrolux
Thank you for choosing a first class product from Electrolux, which hopefully will
provide you with lots of pleasure in the future. The Electrolux ambition is to offer a
wide variety of quality products that make your life more comfortable. You find
some examples on the cover in this manual. Please take a few minutes to study
this manual so that you can take advantage of the benefits of your new machine.
We promise that it will provide a superior User Experience delivering Ease-of-
Mind. Good luck!
132972260 EN.qxd 30/03/2007 15.32 Pagina 3

4 contents electrolux
Contents
Safety information..............................5
Product description ...........................7
Control panel.....................................8
Use....................................................9
Washing hints ..................................22
International wash code symbol ......25
Washing programme ..................26-27
Programme information ...................28
Care and cleaning ...........................30
Something not working....................33
Techical data ...................................37
Consumption values ........................38
Installation .......................................39
Environment concerns.....................43
Guarantee conditions ......................44
Customer service centres................46
The following symbols are used in this manual:
Important information concerning your personal safety and information on how
to avoid damaging the appliance.
General information and tips
Environmental information
132972260 EN.qxd 30/03/2007 15.32 Pagina 4

safety information electrolux 5
Safety Information
In the interest of your safety and to
ensure the correct use, before
installing and first using the
appliance, read this user manual
carefully, including its hints and
warnings. To avoid unnecessary
mistakes and accidents, it is
important to ensure that all people
using the appliance are thoroughly
familiar with its operation and safety
features. Save these instructions
and make sure that they remain
with the appliance if it is moved or
sold, so that everyone using it
through its life will be properly
informed on appliance use and
safety.
General safety
●It is dangerous to alter the
specifications or attempt to modify
this product in any way.
●During high temperature wash
programmes the door glass may get
hot. Do not touch it!
●Make sure that small pets do not
climb into the drum. To avoid this,
please check into the drum before
using.
●Any objects such as coins, safety
pins, nails, screws, stones or any
other hard, sharp material can cause
extensive damage and must not be
placed into the machine.
●Only use the advised quantities of
fabric softener and detergent.
Damage to the fabric can ensue if
you over-fill. Refer to the
manufacturer’s recommendations of
quantities.
●Wash small items such as socks,
laces, washable belts etc in a
washing bag or pillow case as it is
possible for such items to slip down
between the tub and the inner drum.
●Do not use your washing machine to
wash articles with whalebones,
material without hems or torn
material.
●Always unplug the appliance and
turn off the water supply after use,
clean and maintenance.
●Under no circumstances should you
attempt to repair the machine
yourself. Repairs carried out by
inexperienced persons may cause
injury or serious malfunctioning.
Contact your local Service Centre.
Always insist on genuine spare parts.
Installation
●This appliance is heavy. Care should
be taken when moving it.
●When unpacking the appliance,
check that it is not damaged. If in
doubt, do not use it and contact the
Service Centre.
●All packing and transit bolts must be
removed before use. Serious
damage can occur to the product
and to property if this is not adhered
to. See relevant section in the user
manual.
●After having installed the appliance,
check that it is not standing on the
inlet and drain hose and the worktop
is not pressing the electrical supply
cable.
●If the machine is situated on a
carpeted floor, please adjust the feet
in order to allow air to circulate freely
●Always be sure, that there is no
water leakage from hoses and their
connections after the installation.
132972260 EN.qxd 30/03/2007 15.32 Pagina 5

6 safety information electrolux
●If the appliance is installed in a
location subject to frost, please read
the “dangers of freezing”chapter.
●Any plumbing work required to install
this appliance should be carried out
by a qualified plumber or competent
person.
●Any electrical work required to install
this appliance should be carried out
by a qualified electrician or
competent person.
Use
●This appliance is designed for
domestic use. It must not be used
for purposes other than those for
which it was designed.
●Only wash fabrics which are
designed to be machine washed.
Follow the instructions on each
garment label.
●Do not overload the appliance. See
the relevant section in the user
manual.
●Before washing, ensure that all
pockets are empty and buttons and
zips are fastened. Avoid washing
frayed or torn articles and treat
stains such as paint, ink, rust, and
grass before washing. Underwired
bras must NOT be machine washed.
●Garments which have been in
contact with volatile petroleum
products should not be machine
washed. If volatile cleaning fluids are
used, care should be taken to
ensure that the fluid is removed from
the garment before placing in the
machine.
●Never pull the power supply cable to
remove the plug from the socket;
always take hold of the plug itself.
●Never use the washing machine if
the power supply cable, the control
panel, the working surface or the
base are damaged so that the inside
of the washing machine is
accessible.
Child safety
●This washing machine is not
intended for use by young children
or infirm persons without
supervision.
●Young children should be supervised
to ensure that they do not play with
the appliance.
●The packaging components (e.g.
plastic film, polystyrene) can be
dangerous to children - danger of
suffocation! Keep them out of
children’s reach
●Keep all detergents in a safe place
out of children’s reach.
●Make sure that children or pets do
not climb into the drum. To avoid this
the machine incorporates special
feature. To activate this device, rotate
the button (without pressing it) inside
the door clockwise until the groove
is horizontal. If necessary use a coin.
To disable this device and restore
the possibility of closing the door,
rotate the button anti-clockwise until
the groove is vertical.
P1076
132972260 EN.qxd 30/03/2007 15.32 Pagina 6

electrolux product description 7
Product description
Detergent dispenser drawer
Control panel
Door opening handle
Drain pump
Adjustable feet
5
4
3
2
1
Prewash
Wash
Fabric Softener
1 2
3
4
5
Time
Manager
Extra
Rinse
Temp. Spin Easy Iron Delay
Start/
Pause
Prewash
Prewash
Special Cottons
Delicate
uick wash
Duvet
Jeans
Wool
Lingerie
Shirt
Curtains
Hand wash
Silk
Synthetics
Economy
Economy
EWN 16781 W
7Kg Direct Spray
EN001
Detergent dispenser drawer
Your new appliance meets all modern requirements for effective treatment of laundry
with low water, energy and detergent consumption.
The New Jet system allows total use of detergent and reduces water consumption
so saving energy.
132972260 EN.qxd 30/03/2007 15.32 Pagina 7

8electrolux control panel
Control panel
Programme selector dial
Temperature button
Spin reduction button
Easy Iron button
Extra Rinse button
Delay button
Display
Start/Pause button
Time manger buttons
9
8
7
6
5
4
3
2
1
1 3 4 5 872 6 9
Time
Manager
Extra
Rinse
Temp. Spin Easy Iron Delay
Start/
Pause
Prewash
Prewash
Special Cottons
Delicate
uick wash
Duvet
Jeans
Wool
Lingerie
Shirt
Curtains
Hand wash
Silk
Synthetics
Economy
Economy
EWN 16781 W
7Kg Direct Spray
132972260 EN.qxd 30/03/2007 15.33 Pagina 8

use electrolux 9
Use
First Use
●Ensure that the electrical and water
connections comply with the
installation instructions.
●Remove the polystryrene block and
any material from the drum.
●Run a cotton cycle at 90°C, without
any laundry in the machine, to
remove any manufacturing residue
from the drum and tub.
Acoustic signals
The machine is provided of an acoustic
device, which sounds in the following
cases:
●when selecting a wash programme
●when depressing the options buttons
●in case of a wrong selection
●at the end of the cycle
●in the event of operating problems
By pressing the «Easy Iron» and «Extra
Rinse» buttons simultaneously for
about 6 seconds, the acoustic signal is
deactivated (except for the events of
operating problems).
By pressing these 2 buttons again, the
the acoustic signal is reactivated.
Child safety lock
This device permits you to leave the
appliance unsupervised without having
the worry that children might be injured
by or cause damage to the appliance.
This function remains able also when
the washing machine is not working.
Set this option before pressing the
Start/Pause and after having selected
the required wash programme.
To enable (disable) this option press
simoultaneously for about 6 seconds
«Extra Rinse» and «Delay» buttons until
the icon appears (disappears) on
(from) the display.
Daily Use
Load the laundry
Open the door by carefully pulling the
door handle outwards. Place the laundry
in the drum, one item at a time, shaking
them out as much as possible. Close
the door.
Measure out the detergent and the
fabric softener
Pull out the dispenser drawer until it
stops. Measure out the amount of
detergent required, pour it into the main
wash compartment and, if you wish
to carry out a programme with the
«prewash» phase, pour it into the
compartment marked .
P0004N
Temp. Spin Easy Iron Delay
Rinse
Time
Manager
Extra
Start/
Pause
132972260 EN.qxd 30/03/2007 15.33 Pagina 9

10 electrolux use
If required, pour fabric softener into the
compartment marked (the amount
used must not exceed the “MAX” mark
in the drawer). Close the drawer gently.
Select the required programme
Turn the programme selector dial to the
required programme.
The buzzer sounds. The washing
machine will propose a temperature and
automatically select the maximum spin
value provided for the programme you
have chosen.
You can change these values by
operating the corresponding buttons. The
Display shows the following information
about the selected programme proposed:
temperature
spin speed
phase icons making up the
programme
soil degree
duration
5
4
3
2
1
C0065
C0064
The green Start/Pause light starts to flash.
The selector dial is divided into following
sections:
●Cottons , Cottons +Prewash,
Synthetics , Synthetics
+Prewash and Delicates .
●Economy programmes: Cottons
and Synthetics .
●Spin , Delicate spin , Drain ,
Rinses .
●Special : Quick Wash ,,
Handwash , Wool , Silk ,
Shirts , Lingerie , Duvet ,
Curtains and Jeans .
The selector dial can be turned either
clockwise or anticlockwise. Position «O»
to Reset programme/ Switching OFF of
the machine.
At the end of the programme the
selector dial must be turned to
position «O», to switch the machine
off.
Prewash
Prewash
Special Cottons
Delicate
uick wash
Duvet
Jeans
Wool
Lingerie
Shirt
Curtains
Hand wash
Silk
Synthetics
Economy
Economy
1 2 3 4 5
132972260 EN.qxd 30/03/2007 15.33 Pagina 10

use electrolux 11
Attention!
If you turn the programme selector dial
to another programme when the
machine is working, the red
Start/Pause pilot light will flash 3 times
and the message Err will appear on the
display to indicate a wrong selection.
The machine will not perform the new
selected programme.
Programme Option buttons
Depending on the programme, different
functions can be combined. These must
be selected after choosing the desired
programme and before depressing the
Start/Pause button.
Select the temperature
Press this button repeatedly to increase or
decrease the temperature, if you want
your laundry to be washed at a
temperature different from the one
proposed by the washing machine.
Maximum temperatures are 90°C for
Cottons, 60°C for Cotton Eco and
Synthetics, 40°C for Synthetics Eco,
Delicates, Lingerie, Duvet, Curtains
and Jeans programmes, Wool and
fabrics to be handwashed, 30°C for
Quick Wash, Silk, Shirt and while
corresponds to cold wash.
During the washing cycle the
thermometer is animated.
Temp. Spin Easy Iron Delay
Rinse
Time
Manager
Extra
Start/
Pause
Select the spin speed, No spin,
Rinse Hold or Night Cycle option
Press the Spin button repeatedly to
change the spin speed, if you want your
laundry to be spun at a speed different
from the one proposed by the washing
machine.
During the spinning phase the spiral is
animated.
Maximum speeds are:
●for Cottons: 1600 rpm;
●for Jeans programme: 1200 rpm;
●Wool and Handwash: 1000 rpm
●for Synthetics, Shirt and Lingerie:
900 rpm;
●for delicate fabrics, Silk, Quick Wash,
Duvet and Curtains: 700 rpm.
No spin option eliminates all the
spin phases (in some programmes
increases also the number of rinses).
Rinse Hold : by selecting this
option the water of the last rinse is not
emptied out to prevent the fabrics from
creasing.
When the programme has finished the
display shows a 0.00 flashing, the
(Door) icon is still visualized, the
Start/Pause light is off and the door is
locked to indicate that the water must
be emptied out.
Temp. Spin Easy Iron Delay
Rinse
Start/
Pause
Time
Manager
Extra
132972260 EN.qxd 30/03/2007 15.33 Pagina 11

12 electrolux use
To empty out the water:
●turn the programme selector dial to
«O»
●select the (Drain), (Spin) and
(Delicate Spin) programme
●reduce the spin speed if needed, by
means of the relevant button
●depress Start/Pause button
●at the end of the programme, the
display shows a 0.00 flashing.
The (Door) icon desappears and
the door can be opened.
Night Cycle : by selecting this
option, the machine will not drain the
water of the last rinse, so as not to
wrinkle the laundry.
As all spinning phases are suppressed,
this washing cycle is very noiseless and
it can be selectionned at night or in
times with a more economical power
rate.
In some programmes the rinses will be
performed with more water.
When the programme has finished, the
display shows a 0.00 flashing, the
(Door) icon is still visualized, the
Start/Pause light is off and the door is
locked to indicate that the water must
be emptied out.
To empty out the water, please
read the previous option steps.
Select the Easy Iron option
Selecting this button the laundry is
gently washed and spun to avoid any
creasing. In this way ironing is easier.
Furthermore the machine will perform
some additional rinses for cotton and
synthetics.
This function can be used for cotton,
synthetic fabrics and the programme
Jeans.
Select the Extra Rinse option
This button can be selected with all
programmes except the Wool,
Handwash, Duvet, Lingerie, Silk, Quick
Wash and Shirt programmes. The
machine performs some additional
rinses.
This option is recommended for people
who are allergic to detergents, and in
areas where the water is very soft.
Select the Delay start
Before you start the programme, if
you wish to delay the start, press the
Delay Start button repeatedly, to select
the desired delay.
The corresponding icon will appear
on the display in the upper part of the
display.
The selected delay time value (up to 20
hours) will appear on the display for
about 3 seconds, then the duration of
the programme will appear again.
Temp. Spin Easy Iron Delay
Rinse
Start/
Pause
Time
Manager
Extra
Temp. Spin Easy Iron Delay
Rinse
Time
Manager
Extra
Start/
Pause
132972260 EN.qxd 30/03/2007 15.33 Pagina 12

use electrolux 13
You must select this option after you
have set the programme and before you
press the Start/Pause button.
If you wish to add laundry in the
machine during the delay time you will
press Start/Pause button to put the
machine in pause. Add the laundry,
close the door and press Start/Pause
button again.
You can cancel the delay time at any
moment, before you press the
Start/Pause button.
The wash programme can be delayed
from 30 min - 60 min - 90 min, 2 hours
and then by 1 hour up to a maximum of
20 hours by means of this button.
Selecting the delayed start.
• Select the programme and the
required options.
• Select the delay start.
• Depress Start/Pause button: the
machine starts its hourly countdown.
The programme will start after the
selected delay has expired.
Cancelling the delayed start
• Depress Start/Pause button.
• Depress Start/Pause button, the
symbol 0’ is displayed.
• Depress Start/Pause button again.
Temp. Spin Easy Iron Delay
Rinse
Time
Manager
Extra
Start/
Pause
The Delay Start cannot be selected
with Drain programme.
Display
The display shows the following
information:
Duration of the selected programme
After selecting a programme, the
duration is displayed in hours and
minutes (for example 2.05). The
segments inside the clock icon are
animated.
The duration is calculated automatically
on the basis of the maximum
recommended load for each type of
fabric.
After the programme has started, the
time remaining is updated every minute.
Washing programme phase icons
By selecting the wash programme, all
the washing programme phase icons
corresponding to the various phases
making up the programme are shown in
the upper part of the display.
Temp. Spin Easy Iron Delay
Rinse
Start/
Pause
Time
Manager
Extra
Temp. Spin Easy Iron Delay
Rinse
Start/
Pause
Time
Manager
Extra
132972260 EN.qxd 30/03/2007 15.33 Pagina 13

14 electrolux use
After you have pressed the Start/Pause
button and the machine has started, the
Door icon is lighted-on and only the
phase running icon stays on.
When the programme has finished, a
flashing zero (0.00) is displayed and the
(Door) icon desappears.
Delay
The selected delay (20 hours max) set
by means of the relevant button appears
on the display for about 3 seconds, then
the duration of the previously selected
programme is displayed. The relevant
phase icon is lighted-on.
The delay time value decreases by one
unit every hour and then, when 1 hour
remains, the time decreases every
minute.
Incorrect option selection
If an option which is not compatible with
the set wash programme is selected,
the message Err is displayed at the
bottom of the display for about 2
seconds and the integrated red
Start/Pause light start flashing.
Temp. Spin Easy Iron Delay
Rinse
Time
Manager
Extra
Start/
Pause
Temp. Spin Easy Iron Delay
Rinse
Time
Manager
Extra
Start/
Pause
Alarm codes
In the event of operating problems,
some alarm codes can be displayed, for
example E20 (see paragraph
“Something not working”).
End of programme
When the programme has finished a
flashing zero is displayed, the (Door)
icon desappears and the door can be
opened.
Heating phase
During the washing cycle the display
shows the temperature icon animated
to indicate that the appliance has
started the heating phase of the water
in the tub.
Temp. Spin Easy Iron Delay
Rinse
Time
Manager
Extra
Start/
Pause
Temp. Spin Easy Iron Delay
Rinse
Time
Manager
Extra
Start/
Pause
Temp. Spin Easy Iron Delay
Rinse
Time
Manager
Extra
Start/
Pause
132972260 EN.qxd 30/03/2007 15.33 Pagina 14

use electrolux 15
Select the Start/Pause
To start the selected programme, press
the Start/Pause button; the green pilot
light stops flashing.
The “door” icon appears on the
display to indicate that the appliance
starts operating and the door is locked.
To interrupt a programme which is
running, depress the Start/Pause
button: the green pilot light starts to
flash.
To restart the programme from the
point at which it was interrupted,
press the Start/Pause button again.
If you have chosen a delayed start, the
machine will begin the countdown.
If an incorrect option is selected, an
integrated red pilot light of the “Start/
Pause” button flashes 3 times the
message Err is displayed for about 2
seconds. Three acoustic signals
sound.
Select the “Time Manager” option
Temp. Spin Easy Iron Delay
Rinse
Start/
Pause
Time
Manager
Extra
Temp. Spin Easy Iron Delay
Rinse
Start/
Pause
Time
Manager
Extra
This function allows you to modify the
washing time, automatically proposed
by the washing machine. By pressing
the «Time manager buttons «+/-»
repeatedly, the duration of the washing
cycle can be increased or decreased.
The soil level icon visualized on the
display will change to indicate which
type of soil degree you have chosen.
(*) Max. load for cotton: 3.5 kg.
Max. load for synthetic and
delicate: 2 kg.
Note
Once the programme has started the
Time manager option cannot be
changed.
Attention!
The “Time Manager” option cannot
be selected with the Economy
programmes.
Soil
Level Icon Type of fabric
Intensive For heavy soiled items
Normal For normal soiled items
Daily For daily soiled items
Light For slightly soiled items
Quick For very slightly soiled items
Super
Quick (*)
For items used or worn for a
short time
132972260 EN.qxd 30/03/2007 15.33 Pagina 15

16 electrolux use
The availability of these soil level icons
change according to the type of fabric
as shown in the following chart:
Altering an option or a running
programme
It is possible to change any option
before the programme carries it out.
Before you make any change, you
must pause the washing machine by
pressing the Start/Pause button.
(Only the Time Manager option
cannot be modified after the
programme has started. )
Changing a running programme is
possible only by resetting it. Turn the
programme selector dial to Oand then
to the new programme position. The
washing water in the tub will not
emptied out. Start the new programme
by depressing the Start/Pause button
again.
Interrupting a programme
Depress the Start/Pause button to
interrupt a programme which is
running, the corresponding light starts
to flash. Depress the button again to
restart the programme.
Cancelling a programme
Turn the selector dial to Oto cancel a
programme which is running. Now you
can select a new programme.
Opening the door after the
programme has started
First set the machine to pause by
pressing the Start/Pause button.
If the “door” icon desappears on
the display, the door can be opened.
If the “door” light does not goes
off, this means that the machine is
already heating, that the water level is
above the bottom edge of the door or
that the drum is turning. In this case
the door can not be opened.
If you cannot open the door but you
need to open it you have to switch the
machine off by turning the selector dial
to O.
After about 3 minutes the door can be
opened (pay attention to the water
level and temperature!).
Fabric Soil Level
Cottons
90°C XXXXXX
60°C XXXXXX
40°C XXXXXX
50°C XXXXXX
30°C XXXXXX
(cold)
XXXXXX
Synthetics
Delicates
60°C X X X X
50°C X X X X
40°C X X X X
40°C X X X X
30°C X X X X
30°C X X X X
(cold)
X X X X
(cold)
X X X X
132972260 EN.qxd 30/03/2007 15.33 Pagina 16

use electrolux 17
At the end of the programme
The machine stops automatically.
Some acoustic signals sound for 2
minutes.
If the Rinse Hold or Night Cycle
options have been selected, the
Start/Pause light goes off, a flashing
“0.00” will appear on the display, the
(Door) icon is still visualized and the
door remains locked to indicate that
the water must be emptied out before
opening the door.
To empty out the water please read
the steps on the Rinse Hold option
paragraph.
At the end of the cycle, turn the
programme selector dial to «O»to
switch the machine off. Remove the
laundry from the drum and carefully
check that the drum is empty. If you do
not intend to carry out another wash,
close the water tap. Leave the door
open to prevent the formation of
mildew and unpleasant smells.
132972260 EN.qxd 30/03/2007 15.33 Pagina 17

columns and margins electrolux 1818 electrolux washing hints
Washing hints
Sorting the laundry
Follow the wash code symbols on each
garment label and the manufacturer’s
washing instructions. Sort the laundry as
follows: whites, coloureds, synthetics,
delicates, woollens.
Temperatures
Before loading the laundry
Never wash whites and coloureds
together. Whites may lose their
“whiteness” in the wash.
New coloured items may run in the first
wash; they should therefore be washed
separately the first time.
Make sure that no metal objects
are left in the laundry (e.g. hair
clips, safety pins, pins).
Button up pillowcases, close zip
fasteners, hooks and poppers. Tie any
belts or long tapes.
Remove persistent stains before
washing.
Rub particularly soiled areas with a
special detergent or detergent paste.
Treat curtains with special care. Remove
hooks or tie them up in a bag or net.
Maximum loads
Recommended loads are indicated in
the programme charts.
General rules:
Cotton, linen: drum full but not too
tightly packed;
Synthetics: drum no more than half full;
Delicate fabrics and woollens: drum
no more than one third full.
Washing a maximum load makes the
most efficient use of water and energy.
For heavily soiled laundry, reduce the
load size.
Laundry weights
The following weights are indicative:
Removing stains
Stubborn stains may not be removed by
just water and detergent. It is therefore
advisable to treat them prior to washing.
Blood: treat fresh stains with cold water.
For dried stains, soak overnight in water
with a special detergent then rub in the
soap and water.
90°
for normally soiled white
cottons and linen (e.g. tea
cloths, towels, tablecloths,
sheets...)
50°/60°
for normally soiled, colour
fast garments (e.g. shirts,
night dresses, pyjamas....) in
linen, cotton or synthetic
fibres and for lightly soiled
white cotton (e.g.
underwear).
(Cold)
30°-40°
for delicate items (e.g. net
curtains), mixed laundry
including synthetic fibres and
woollens bearing the label
«pure new wool, machine
washable, non-shrink».
1200 gbathrobe
100 gnapkin
700 gquilt cover
500 gsheet
200 gpillow case
250 gtablecloth
200 gtowelling towel
100 gtea cloth
200 gnight dress
100 gladies’ briefs
600 gman’s work shirt
200 gman’s shirt
500 gman’s pyjamas
100 gblouse
100 gmen’s underpants
132972260 EN.qxd 30/03/2007 15.33 Pagina 18

washing hints electrolux 19
Oil based paint: moisten with benzine
stain remover, lay the garment on a soft
cloth and dab the stain; treat several
times.
Dried grease stains: moisten with
turpentine, lay the garment on a soft
surface and dab the stain with the
fingertips and a cotton cloth.
Rust: oxalic acid dissolved in hot water
or a rust removing product used cold.
Be careful with rust stains which are not
recent since the cellulose structure will
already have been damaged and the
fabric tends to hole.
Mould stains: treat with bleach, rinse
well (whites and fast coloureds only).
Grass: soap lightly and treat with bleach
(whites and fast coloureds only).
Ball point pen and glue: moisten with
acetone (*), lay the garment on a soft
cloth and dab the stain.
Lipstick: moisten with acetone as
above, then treat stains with methylated
spirits. Remove any residual marks from
white fabrics with bleach.
Red wine: soak in water and detergent,
rinse and treat with acetic or citric acid,
then rinse. Treat any residual marks with
bleach.
Ink: depending on the type of ink,
moisten the fabric first with acetone (*),
then with acetic acid; treat any residual
marks on white fabrics with bleach and
then rinse thoroughly.
Tar stains: first treat with stain remover,
methylated spirits or benzine, then rub
with detergent paste.
(*) do not use acetone on artificial silk.
Detergents and additives
Good washing results also depend on
the choice of detergent and use of the
correct quantities to avoid waste and
protect the environment. Although
biodegradable, detergents contain
substances which, in large quantities,
can upset the delicate balance of nature.
The choice of detergent will depend on
the type of fabric (delicates, woollens,
cottons, etc.), the colour, washing
temperature and degree of soiling.
All commonly available washing machine
detergents may be used in this
appliance:
• powder detergents for all types of
fabric,
• powder detergents for delicate fabrics
(60°C max) and woollens,
• liquid detergents, preferably for low
temperature wash programmes (60°C
max) for all types of fabric, or special
for woollens only.
The detergent and any additives must
be placed in the appropriate
compartments of the dispenser drawer
before starting the wash programme.
If using concentrated powder or liquid
detergents, a programme without
prewash must be selected.
The washing machine incorporates a
recirculation system which allows an
optimal use of the concentrated
detergent.
Pour liquid detergent into the dispenser
drawer compartment marked just
before starting the programme.
Any fabric softener or starching additives
must be poured into the compartment
marked before starting the wash
programme.
132972260 EN.qxd 30/03/2007 15.33 Pagina 19

20 electrolux washing hints
Follow the product manufacturer’s
recommendations on quantities to use
and do not exceed the «MAX» mark
in the detergent dispenser drawer.
Quantity of detergent to be used
The type and quantity of detergent will
depend on the type of fabric, load size,
degree of soiling and hardness of the
water used.
Water hardness is classified in so-called
“degrees” of hardness. Information on
hardness of the water in your area can
be obtained from the relevant water
supply company, or from your local
authority.
Follow the product manufacturers’
instructions on quantities to use.
Use less detergent if:
• you are washing a small load,
• the laundry is lightly soiled,
• large amounts of foam form during
washing.
Degrees of water hardness
Level
Degrees
German
°dH
French
°T.H.
Characteristic
10-7 0-15soft
28-14 16-25medium
315-21 26-37hard
4> 21 > 37very hard
132972260 EN.qxd 30/03/2007 15.33 Pagina 20
