Electrolux VIVA LOGIC User manual

MODEL:
VIVA LOGIC
COVER 4
Videocon Industries Limited
14Km Stone, Aurangabad-Paithan Road, Chitegaon,
Dist-Aurangabad-431105
Tel : [phone] Fax : -1-2431-251551
COVER 1

FEATURES AND ACCESSORIES
FEATURES
Transparent window，unique outlook design：Adopting the transparent
cover, gives clarity at aglance in the course of washing．
Spraying water flow，washing more drastically：Adopting unique pulsator can
produce spraying water flow from the bottom，to break up the wrapped clothing，
so that the clothing can be washed more sufficiently and uniformly．
Dynamic soak，powerful washing：Adopting the model of dynamic soak，the
detergent will better be dissolved by water and fully infiltrated into the clothes，
especially wash the stubborn dirt off the clothes．
Compact structure，pleasing appearance and durable：The Cabinet sprayed
with plastic powder and the base made of engineering plastic，make it
resistible to corrosion and durable．
INDEX
Features and accessories
Names of parts and sample installation
Sample installation
Installation of the water inlet hose
Installation of the drain hose
Power source and grounding
Installation of the Ｒａｔ Ｍｅｓｈ
Sample operation
Control panel design
Fully automatic program
Operation method
Delay time program
Confirmation of the delay and inspection
Cancel the delay time or alternate the delay time
Use the cleaning solution for twice
Pre－wash of dirty clothes
Load Size and detergent
Weight standard of the clothes
Washing tips
Method of maintenance
Trouble shooting
Other functions
Specifications
Precautions 14
Additional explanation
Ratmesh
with Screw
Tap Adaptor
Warranty terms and Conditions １５－１６
FUZZY LOGIC wash to make your machine decide water level as per cloth load
and give best optimized wash performance.
FIVE special wash programs to suit your different type of clothes and family
washing requirements during different seasons.
Memory back up : This functions enables your machine to complete the remaining
cycles after the power resumes.
HOT, COLD, WARM options for water you are using for washing. This functions
helps you to get better washing results, less detergent consumption.
DIGITAL DISPLAY : Helps you set delay time, so that washing machine can work
for you as per your desired timings, also helps you to check the remaining time
of your wash cycle.
Automatic Power OFF when washing finishes.
Auto balance for intellectual and automatic correction while spinning.
Automatic defect discrimination thru beep alarm.

NAMES ＯＦPARTS AND SAMPLE INSTALLATION
Names of respective parts
Sample Ｉnstallation
Step 1：
Step 2：
Step 3：
The washing machine should be placed inside the room with aflat floor，which is convenient
for water supply and drain，has low moisture and no direct sunshine，and does not freeze in
winter．
All foam packing （including the fixing frame on the base foam）should be taken off，otherwise
the washing machine will not work．
Please adjust the washing machine even according to the instructions below to make the
washing machine run steadily in low noise．
1． Loose the fixing pole on the adjusting foot，screw in or screw out the adjusting foot to
make the four feet placed even on the floor．
2． When the floor is slanting or uneven，it is not easy to make even only by the adjusting
foot．Then the rubber band can be added to the un－flat place．
SAMPLE INSTALLATION
3． Use athread tied with bulky objects to be hung on the side face and face side．As the figure：when A＝A＇，
B＝B＇，that is to show that the washing machine is placed flat．
4．After the adjustment the fixing pole should be screwed back and tight．
Notices：
o
If the washing machine is not placed flat （maximum inclination angle is 2），it may cause great vibration or
automatic check and rectification or other abnormal circumstances will often take place in the course of spinning．
All foam packing including the fixing frame on the base foam in the step 2．
Bukly objects
Base foam Fixing frame
Screw in
Screw out
Loose Adjustable foot
Fixing pole
Tight
Installation of the water inlet hose
1．Check the tap mouth．If it is not even，it can be filed even．
2．Screw loose the locking ring，but do not let the locking ring drop off．Screw the four screws at the same
distance．
3．Put the universal connector into the tap and stick to the tap mouth at the most and then screw in the
screws．
4．Screw tight the locking ring to the right at the most．
5．Pull the skirt of one end of the water inlet hose downwards，and then plug in the universal connector．A
sound of ＂
6．Grasp the water inlet hose by hand and pull it downward to see whether it is secured.
7．Screw the nut on the other end of the water inlet hose into the water inlet of the washing machine to the
most．
KA－TA＂means proper connection．
Step 4：
Skirt
Tap
File
If the calibre of the tap
is big，the connecting
ring can be taken off．Connecting ring Locking ring
Inner
Tub
Filter
Pulsator
Top Lid
Control
Panel
Base
Cabinet
Drain
Hose
Power
Cord
Top
Frame

SAMPLE INSTALLATION
Notices：
After installation，do not start the washing machine in hurry．First open the tap to let the water press
into the water inlet hose to check whether there is any leakage in the connectors on the both ends．When the
pressure is too high，please shut the tap alittle to avoid water leakage．
Installation of the drain hose
1．Press the fixing ring with hand to make it loose and
engaged on the drain hose and put the drain hose
into the leading skirt of drain hose in the bottom of
the washing machine to the end at the most （soak the
head of the drain hose in warm water，it will make
the engagement easy），and loose the fixing ring to
let it clasp the drain hose．
Step 5：
Cabinet
Fixing ring
Leading ring
Drain hose
Inner hose
SAMPLE INSTALLATION AND SIMPLE OPERATION
Step 6：
Power source and grounding
The washing machine employs alternative current with the rated voltage and frequency．When the
voltage fluctuates between 10％of rated voltage，the washing machine can work normally．Aspecial power
socket for the washing machine had better be set beside the washing machine for convenience and safety．
The method of connection of the socket is as the figure below：
Grounding wire
Rated voltage ￣
Notices：
The socket and the grounding wire must be installed by an
electrician to prevent incorrect installation or use of the socket，
and to guarantee the safety of use of electricity．
The power wire of the washing machine employs Y
connection and the replacement of the power wire should be
carried out by professionals．
No connection of the grounding wire with the neutral wire，
otherwise the cabinet will be charged，which is likely to cause
the danger of electric shock．
Installation of the Rat Mesh
o
1．Slant the washing machine with angle of 45 in the direction of
the arrows showed in the figure，put the side with the clasper to
the washing machine and the other side to the ground，insert base
cover along the direction of the upper slot of the base from the
back side of the washing machine．
2．Put the base cover straight to the point and then press the base
cover upward till there is asound of ＂Gaba＂and then screw in
aself－tapping screw（without the self－tapping screw for plastic
cabinet）．
Step 7：
Hole for Self－tapping screw
Slot
Base cover
Sample Ｏperation
Preparations before using：
1．Lay the drain hose at proper place.
2．Connect t he water inlet hose and open the tap．
3．Put the power plug into the socket．
4．Take out the coins and other sundries and shake off the mud and sand on the clothes．
5．Determine water level．Press ＂Water level＂button to select the water level．
6．Press ＂Power＂switch button．
7．Press ＂Start／Pause＂button．The washing machine will go into operation by the automatic program of standard．
Notices：
If you want to set other programs，please see and read ＂Full automatic program＂and ＂Self－program＂．
According to your needs，select corresponding programs for your service．
2．It had better put the outlet of the drain hose into the nearby drainage permanently，which can save
the trouble that the drain hose has to be connected each time before use．If the drainage is far from the
washing machine，it can be solved by connection of the drain hoses head with end to extend．
Notices：Drain faults will be caused when the drain hose is blocked．

On ＆off power
Power
Automatic power off
CONTROL PANEL DESIGN
Start／Pause
After program selection，press
the button to start．
Press the button to pause i n the
course of operation，press the
button again the program
continues till the program is
finished．
Press water level button，to select
the appropriate water level, that
ｍａｔｃｈｅｄ ｔｈｅ ｌｏａｄ ｓｉｚｅ．
Water Level 1 : Light ON
Water level Press the button to select
＂WASH ＂RINSE＂＂SPIN
＂SOAK ＂WASH ＂RINSE ＂SPIN
＂WASH ＂WASH ＂RINSE
＂RINSE ＂SPIN ＂SPIN
＂＋ ＋ ＂，
＂＋ ＂＋ ＂＋ ＂，
＂， ＂＋ ＂，
＂＋ ＂， ＂．
Press the button to preset delay
time．Less than 24 hours each press
the button，the delay－time is added
an hour ．More than 24 hours each
press the button，the delay－time is
added 6hours，after to 48 hours，the
preset indicator is come back origin
status．If always press the button，
the delay time will automatically
change．
Delay
In order to protect controller，the interval of switching on and off power should be more than 30 seconds.
r
！
FULLY AUTOMATIC PROGRAM
Fully Automatic Program
Notices：
The
total time
included the
time of entering
water
and
the drain time．
Total time can change
depending on the pressure of the
tap
water and
the
drain
speed．
Press the button to set the wash
mode of water inlet to HOT or
COLD．When the lights of
HOT and COLD are ON at the
same time，the HOT water and
COLD water are coming．
By pressing the button ａｇａｉｎyou
can select HOT，COLD and WARM
water to be used．
TEMPERATURE
By washing requirement you may
optional select the programs of
＂FUZZY ＂BULKY
＂ECONOMY＂ ＂WOOL
＂DELICATE ＂ANTI－WRINKLE
＂（light）／ ＂（flash），
（light）／ ＂（flash）
＂（light）／ ＂（flash）．
Program
Selection of function
Fuzzy
Spin （min.）Total time
Wash 12 minutes
Wash 2minutes
Wash 10 minutes
Wash 15 minutes
Wash 15 minutes
2Times
1Times ＋1Times
2Times
2Times
2Times
2Times
6
1
2
7
Only Drain
10
33
47
34
27
1． ＂CHILD LOCK＂function：After starting，press the ＂FUNCTION＂and ＂WATER LEVEL＂button at
the same time，this ＂CHILD LOCK＂function can be set，then all buttons will be locked and not to be
selected （including the ＂POWER＂button），the indication is displayed ＂CL＂one second every 5
seconds，and press the ＂FUNCTION＂and ＂WATER LEVEL＂button at the same time again to unlock
the function．
2．In the course SOAK ，the washer does not stop completely，it will wash interval to let the washing
evenly mix with the detergent．
Additional explanation
P．ress WATER LEVEL &
Child
Lock
Wash 8minutes
Only Drain
About 43
Economy
Rinse
Wash
Delicate
Features of eight fully auto program are as follows:
Heavy
Wool
Anti-wrinkle
F．UNCTION at same time to
a．ctivate CHILD LOCK.
Water Level 2 : Light OFF
Water Level 3 : Light ON
Water Level 4 : Light OFF
Proceed same way to water
level 8.
CHILD LOCK
* PLS DO NOT MATCH THE CONTROL PANEL WITH YOUR MACHINE.
THIS IS SCHEMATIC DIAGRAM ONLY AND CAN VARY FROM YOUR MACHINE.
Program
Heavy
Econo my
F．or more details read “Additional
E．xplanation” on page 8.
（Spray rinse）
Clothes Type
-
Less dirty Clothes
Women under
Dirty Clothes like
Woolen clothes
-
garments, articles
with embroidery
Coats, Jeans, Bed
Sheets, etc.
/
/Wool
/

Union suit including coat and
trousers（blended）about 800g
Pyjamas including coat and
trousers （cotton）about 500g
Long sleeves shirt
（blended）about 200g
Bedsheet （cotton）
about 500g
Bath towel （cotton）
about 300g
Trunks （cotton）
about 50g
Short sleeves shirt
（cotton）about 130g
Socks （blended）
about 50g
Press the button，the digital light of delay time
turn on，the number begins to add from 1，it adds an hour
as per press in 24 hours，it adds 6hours as per press in the
period of 24 hours to 48 hours．Press the button again，the
light of delay time turn off．Continuously press the
button over 1．5seconds
＂DELAY＂ is
ed
is ed
，the number begins to automatically
change according to the above rules．Loose the button，the
number stops to change．
Method of use of the button＂DELAY＂
OPERATION METHOD
Operation method
Delay time program
Delay time means the beginning time of washing．
1．Switch on the power．
2．Open the tap and hang the drain hose up．
3．Put into the washing and detergent．
4．Select the proper water level according to the
quantity of clothes．
5．Select the functions and programs．
6．Press ＂DELAY＂button to select the beginning
Time of washing．
7．Close the lid and press ＂START／PAUSE＂button．
Confirmation of the delay and inspection
After the delay function is started，the corresponding
light will be flashed，and other lights are turned off．
Cancel the delay time，or alternate the delay time
Press ＂POWER＂button to cancel delay time．
To change the delay time，please cancel delay time，and then press ＂Delay＂button to reset．
Use the cleaning solution for twice
1．Put in the washing in the first batch and detergent and press ＂Wash ＂Function
2．Take out the washing in the first batch after hearing the buzzing sound．
3．Put in the washing in the second batch，and run ＂W
4．Take out the washing in the second batch after hearing the buzzing sound．
5．Put in the washing in the first batch and press＂Function
＂or ＂button to set the Single
＂wash＂to run．
ash＂，＂Rinse＂，＂Spin＂．
＂button to run ＂Rinse＂and ＂Spin＂．
After the delay function is started，press ＂Delay＂button continuously，you may inspect the program and
function set，loosen the button，the program will automatically come back delay status．
One of the＂Rinse／Spin＂program can be selected to perform pre－wash as for clothes seriously stained
with mud，and then add washing powder and select the full program to wash．
Pre－wash of dirty clothes
Notices：
Please use the water that temperature is below 50．
If the water level is less than the set ＂Water level＂，the machine will add water automatically．
OPERATION METHOD
Load size and the detergent
Water volume is different because of clothes variety．When the washing machine does not
operate well，please adjust clothes volume and water level．
The water volume above listed is based on normal clothes volume．
Notices：
The highest priority of using the detergent is low and mid foam detergent．
The volume of detergent is changed with different type of clothes．You need read user manual．
Weight standard of the clothes
Put the easily damaged and loose clothes into mesh before washing．
Put bulk clothes and easily suspended clothes at the bottom of tub．
Turn the easily damaged face of clothes inside before washing．
If the clothes hold webbing and zipper you need to tie and zipper that before washing．
Get rid of mud on clothes before washing．
You can add some washing powder on the specially dirty place before washing．
Washing tips
About 25
About 30 g
About 34 g
About 38 g
About 43 g
About 48 g
About 48 L
About 53 L About 53 g
About 25 L
About 30 L
About 34L
About 38 L
About 43 L
About 15 g
About 18 g
About 20g
About 23g
About 26 g
About 29 g
About 32 g
8
7
6
5
4
3
1
Water level Water volume Weight of laundry Concentrated
washing powder
(Each 0.6 g needs 1 liter of water)
Common
washing powder
(Each 1 g needs 1 liter of water)
2
About 17LAbout 17gAbout 10g
5.2〜5.5kg
4.4〜5.2kg
3.6〜4.4kg
2.8〜3.6kg
2.0〜2.8kg
1.2〜2.0kg
0.8〜1.2kg
<0.8kg

TROUBLE SHOOTING
Exceptional
phenomenon Cause Solution
No indication
in controller
The power plug is not plugged tight．
The power switch is not switched on．
Not press ＂START／PAUSE＂button．
Power cut．
Re－plug the power plug．
Check the power socket，or change other
Socket.Press
＂START／PAUSE＂button．
Wait for switching on electricity．
The inlet hose
leakage
Do not rightly connect the tap with the
universal connector．
Do not screw tight the nut of the water
inlet hose．
Re－install rightly the universal connector．
Screw tight the nut．
Does not drain The drain hose is wrung or jammed．The drain hose is made swimmingly，and
solve the problem of jam．
Dose not inject water Stop water．
Do not open the tap．
Whether the wire netting in the water
inlet was stopped up by the sundries．
Wait for coming water．
Open the tap．
Clean the netting according to the method
of ＂Cleaning of the water inlet＂．
Spinning stops and
water injecting begins
in the course of spin
Cause by that the washing placed
uneven．
This is automatic rectification for spinning
in the washing program．That the washing
are too much or too little，or that the washing
machine is not placed plane will cause the
unbalance in time of spinning．If there is
still abnormal circumstances after
checking the above mentioned points，
please pull out the power plug and contact
with local service as soon as possible．
Does not spin After end to drain，do not close the lid．
Open the lid in course of spinning．
Close the upper lid．
Intermittent spinning In order to attain the better spinning
effect．
Belong to the normal phenomenon
generally．
Before using the
machine water exsits
in the drain hose．
Remainning water due to testing or
experiment in the factory．Belong to t he normal phenomenon
generally．
Notices：
The washing machine does not work normally because the voltage is low or too high．Please pull out the plug
and wait till the voltage becomes normal．
If there is still abnormal circumstances after checking the above－mentioned points，please pull out the plug．
Do not repair it by yourself at home，which is very dangerous．
METHOD OF MAINTENANCE
The following cases are not faults
1．There is water injection in time of washing or rinsing，which is due to that the washer senses the inadequacy of water and
exchanges water level automatically．
2．There is the phenomenon of intermittent spinning in the beginning of spinning，which is performed to achieve better spinning
effects．
3．In the course of spin，the program return to the wash program．Because that is designed to rectify the unbalanced distribution
of load in the spin tub．
Method Of Maintenance
After the whole washing program
Maintenance of shell
The washing machine will give Buzzer sound
after any program operation to remind you of
out the load or going on with other operations.
After finishing washing，please shut off the tap，pull
out the plug in case of water leakage or fire accident．
Use soft cloth to wipe off the water
and dirt on the surface each time
after use of the washing machine．
Detergent，propellant and other
chemicals are not allowed to use，
for they can cause damage to the
surface．
Cleaning the water inlet
After long time use，the water inlet mesh bag may
be blocked with smudginess，and should be
cleaned according to the following steps：
1．Switch on the power，followed by shutting off the tap ．
2．Let the washer works for 5seconds so that water
flows into the tub through the water inlet hose．then turn
off the power．
3．Unload the water inlet hose and clean the mesh
bag, then restore the water inlet assembly．
After using the washing machine for aperiod，please
clean it according to the following steps：
1．Take out the lint filter．
2．Turn the mesh bag outside and wash it clean in the
3．Restore it and refix it．
Cleaning of the lint filter
water.
4. There is water sound from Spin Tub. This is because there is balancing liquid in Spin Tub Balancer ring. It is for reducing
vibration of spinning.
5. Control panel remains warn after Power is switched OFF. This is due to heat in electrical parts below Control Panel.

Function of fault alarm
Indication of fault
Cause of fault
Phenomenon
Alarm of the
buzzing sound
Solution of alarm
Alarm for
water injection
Entering water less than 16
minutes，reset water level．
Alarm for
opening lid delay time．Open the lid
when the washer is spinning．
Imbalance alarm Be examined imbalance for
the third time．
Drain alarm After draining for 4minutes，
does not finished to drain．
The buzzer goes
on buzzing
sound for 10
seconds．If the
alarm does not
be solved ，every
16 minutes re－
buzzs for 10
seconds．
Open the lid to
deal with faults，
then close the lid
to solve the
alarm．
Function of automatic power－off
1．Start 10 minutes later to not work，automatically shut off the power．
2．After end to wash and the buzzer sounds 6times，automatically shut off the power at once．
Function of adjusting for unbalance
1．If the clothes are placed uneven before spinning，easy to result in bigger vibrancy of spinning．The washing
machine has afunction of adjusting unbalance．When working，the system of the washing machine always
inspects running state．If finding aphenomenon that the spinning vibrancy is too big，the washing machine
automatically start the adjusting program To adjust the clothes｀sstate．
2．The washing machine can adjust unbalance twice，if no effect，it will alarm．
Function of fault alarm
Open the lid after start the
seconds．
Function of fault alarmFunction of fault alarmFunction of fault alarm
OTHER FUNCTIONS
Function of fault alarm
PRECAUTIONS
Safe use of power
Keep away from dampness
Please plug the power cord into the special voltage．
The plug－in and plug－out of the wire should go on
with the plug held with hand．
Don＇tplace the washing machine in extreme
damp surroudings，for dampness may
weaken the insulation of the machine，which may
cause electric shock or faults．
Don＇tuse hot water Don＇topen the lid in time of spinning
Don＇tuse hot water over 50 to avoid deformation
of the plastics．If the lid is opened in time of spinning，the washing
machine will arrest at once，which will shorten the
service life．Please avoid opening the lid in the
course of operation as possible
and furthermore，don＇t
put hands into the tub，
for it is very dangerous
that the clothes wind
the hand despite of low
speed of rotation．
Avoid spray of water Keep away from smoke and fire
Don＇tlet water spray onto the switch or the
panel in case of electric shock and faults．Don＇tplace lighted candles，cigarettes and thermos
nearby to avoid fire accidents or deformation of the
plastics．
E1
E2
E3
E4
of fault
526 (W) x 536 (D) x 915(H) mm.
Net Dimension
Net Weight 31 kg
53 Ltr.
230V, 50 Hz
360W (Wash)
SPECIFICATIONS
6.0kg
Capacity
VIVA LOGIC
Item

WARRANTY TERMS AND CONDITIONS WARRANTY TERMS AND CONDITIONS
15 16
1. Repair or replacement, free of charges, of any part or parts of your ELECTROLUX washing machine except Top Lids, Knobs,
Inlet/Drain Hose and Lint Filter for a period of 24 months from the date of invoice/bill when we identify the defects as due
to faulty material or workmanship and not due to improper usage or faulty electric supply/connection.
10. If any colored internal or external components are replaced there will be commitment to ensure that shades match
with the original or other components. The replaced shades, patterns, tints may vary from the customer’s unit due to
continuous usage of unit. Any matching components changed at customer’s request will be on chargeable basis except
the component which are actually needed.
15km. STONE, AURANGABAD-PAITHAN ROAD,
VILLAGE CHITEGAON, TALUKA PAITHAN,
AURANGABAD - 431 105,
MAHARASHTRA, INDIA.
PHONE No. - 02431 - 329271,329783
TEKCARE INDIA PRIVATE LIMITED.,
For any doubts or clarifications please contact us on-
E MAIL : [email protected] Web : www.servicedelight.com

AUTHORISED SERVICE CENTERS
17
Warranty Registration
Warranty Registration
(Local Sales office Copy)
