Elektra Bregenz DKW 6565 X User manual

DKW 6565 X - DKW 9565 X
EN - DE
01M-9202833600-5221-01
01M-9202823600-5221-01
User Manual
Cooker Hood

2 / EN Cooker Hood / User Manual
CONTENTS
ENGLISH 3-16
DEUTSCH 17-31

Please read this user manual first!
Dear Valued Customer,
Thank you for preferring this ElektraBregenz appliance. We hope that you get the best
results from your appliance which has been manufactured with high quality and state-
of-the-art technology. For this reason, please read this entire user manual and all
other accompanying documents carefully before using the appliance and keep it as a
reference for future use. If you handover the appliance to someone else, give the user
manual as well. Follow the instructions by paying attention to all the information and
warnings in the user manual.
Remember that this user manual may also apply to other models. Differences between
models are explicitly described in the manual.
Meanings of the Symbols
Following symbols are used in various sections of this user manual:
CImportant information and useful hints about
usage.
AWARNING: Warnings against dangerous situa-
tions concerning the security of life and property.
WARNING: Warning for danger of fire.
BWARNING: Warning for electric shock.
This appliance has been produced in environmentally friendly facilities without harming the nature.

4 / EN Cooker Hood / User Manual
1 Important safety and environmental instructions
1.1 General safety
Important Safety Instructions Read
Carefully And Keep For Future
Reference This section contains
safety instructions that will help
protect from risk of fire, electric
shock, exposure to leak micro-
wave energy, personal injury or
property damage. Failure to follow
these instructions shall void any
warranty.
•ElektraBregenz products com-
ply with the applicable safety
standards; therefore, in case of
any damage on the appliance
or power cable, it should be re-
paired or replaced by the dealer,
service center or a specialist and
authorized service alike to avoid
any danger. Faulty or unqualified
repair work may be dangerous
and cause risk to the user.
•This appliance is intended to be
used in household and similar
applications such as:
– Staff kitchen areas in shops,
offices and other working en-
vironments;
– Farm houses
– By clients in hotels, and other
residential type environments;
– Bed and Breakfast type envi-
ronments.
•Operate the appliance for its
intended purpose only as de-
scribed in this manual.
•The manufacturer cannot be held
liable for damages resulting from
improper installation or misuse of
the product.
•This appliance can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental ca-
pabilities or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the appliance
in a safe way and understand the
hazards involved.
•Children shall not be allowed
play with the appliance. Cleaning
and user maintenance shall not
be made by children without su-
pervision.

Cooker Hood / User Manual 5 / EN
1 Important safety and environmental instructions
•The minimum distance between
the supporting surface for the
cooking vessels on the hob and
the lowest part of your product
must be at least 65 cm.
•If the instructions for installation
for the gas hob specify a greater
distance, this has to be taken
into account.
•Make sure that your mains
power supply complies with the
information supplied on the rat-
ing plate of the appliance.
•Never use the appliance if the
power cable or the appliance it-
self is damaged.
•Prevent damage to the power
cable by not squeezing, bending,
or rubbing it on sharp edges.
Keep the power cable away from
hot surfaces and naked flame.
•Use the appliance with a
grounded outlet only.
WARNING: Do not connect the
appliance to the mains until the
installation is fully complete.
•Place the appliance in a way so
that the plug is always accessible.
•Do not touch the lamps if they
have operated for a long time.
They can burn your hands since
they will be hot.
•Follow the regulations set out by
competent authorities on dis-
charge of the exhaust air (this
warning is not applicable for use
without flue).
•Operate your appliance after put-
ting a pot, pan etc. on the hob.
Otherwise, high heat may cause
deformation in some parts of
your product.
•Turn off the hob before taking the
pot, pan etc. from it.
•Do not leave hot oil on the hob.
Pans with hot oil may cause self
combustion.
•Pay attention to your curtains
and covers since oil may catch
fire while cooking food such as
fries.
•Grease filter must be cleaned
at least monthly. Carbon filter
must be replaced at least every
3 months.

6 / EN Cooker Hood / User Manual
1 Important safety and environmental instructions
•Product shall be cleaned ac-
cordance with user manual. If
cleaning was not carried out in
accordance with user manual,
there may be fire risk.
•Do not use non-fire-resistant
filtering materials instead of the
current filter.
•Only use the original parts or
parts recommended by the man-
ufacturer.
•Do not operate the product with-
out the filter and do not remove
the filters while the product is
running.
•In the event of be started any
flame, de-energize your product
and cooking appliances.
•In the event of be started any
flame, cover the flame and never
use water to extinguish.
•Unplug the appliance before
each cleaning and when the ap-
pliance is not in use.
•The negative pressure in the envi-
ronment should not exceed 4 Pa
(4x10 bar) while the hood for elec-
tric hob and appliances running on
another type of energy but electric-
ity operate simultaneously.
•In the environment where the
appliance is being used, the ex-
haust of devices running on fuel
oil or gas, such as room heater
must be absolutely isolated or
device must be hermetical type.
•When connecting the flue, use
pipes with a diameter of 120 or
150 mm. Pipe connection must
be as short as possible and have
as few elbows as possible.
•Danger of choking! Keep all the
packaging materials away from
children.
CAUTION: Accessible parts may
become hot when used with cook-
ing appliances.
•The product outlet must not be
connected to air channels that
include other smoke.
•The ventilation in the room may
be insufficient when the hood for
electric hob is used simultane-
ously with the devices operating
on gas or other fuels (this may
not apply to appliances that only
discharge the air back into the
room).

Cooker Hood / User Manual 7 / EN
1 Important safety and environmental instructions
•Objects placed on the product
may fall. Do not place any ob-
jects on the product.
•Do not flambe under the your
product.
WARNING: Before installing the
Hood, remove the protective films.
•Never leave high naked flames
under the hood when it is in op-
eration
•Deep fat fryers must be contin-
uously monitored during use:
overheated oil can burst into
flames.
1.2 Compliance with the WEEE
Directive and Disposing of the Waste
Product:
This product complies with EU WEEE Directive
(2012/19/EU). This product bears a classification
symbol for waste electrical and electronic equip-
ment (WEEE).
This symbol indicates that this product
shall not be disposed with other
household wastes at the end of its ser-
vice life. Used device must be returned
to offical collection point for recycling
of electrical and electronic devices. To find these
collection systems please contact to your local au-
thorities or retailer where the product was pu-
chased. Each household performs important role
in recovering and recycling of old appliance.
Appropriate disposal of used appliance helps pre-
vent potential negative consequences for the envi-
ronment and human health.
1.3 Compliance with RoHS Directive
The product you have purchased complies with EU
RoHS Directive (2011/65/EU). It does not contain
harmful and prohibited materials specified in the
Directive.
1.4 Package Information
Packaging materials of the product are
manufactured from recyclable materials
in accordance with our National
Environment Regulations. Do not dis-
pose of the packaging materials together with the
domestic or other wastes. Take them to the pack-
aging material collection points designated by the
local authorities.

8 / EN Cooker Hood / User Manual
596
427
401
352 400 330
20
211
164
395
Mın:752 Max:1082
80 24
1
2
3
4
5
6
1. Inner chimney
2. Outer chimney
3. Grease filter (Behind glass cover)
4. Glass cover
5. Control panel
6. Lighting
2.2 Technical Data
Model DKW 6565 X DKW 9565 X
Supply voltage & Frequency 220-240V ~ 50 Hz
Lamp Power 10.1 W
Motor Power 275 W
Flow rate – 3. Level 574 m³/h 581 m³/h
Flow rate – Boost 756 m³/h 779 m³/h
Insulation Class of Motor Class F
Insulation Class Class I
DKW 6565 X
DKW 9565 X
2.1 Overview
2 General appearance

Cooker Hood / User Manual 9 / EN
3.1 Controlling the Appliance
KEY FUNCTION
A : Light On
/ Off
You may illuminate the cooking area
by pressing this button. Re-press the
button to turn off the lamp.
B : 1. Stage
Button
The hood operates in 1st speed level
by pressing this button. Press this
button again to switch off the appli-
ance.
C : 2. Stage
Button
The hood operates in 2nd speed
level by pressing this button. The
display and hood turn off when you
press this button again to switch off
the appliance.
D : 3rd Stage
Button
The hood operates in 3rd speed level
by pressing this button. The display
and hood turn off when you press
this button again to switch off the
appliance.
E : High Level
Button
When the appliance is switched to
high level in use, the high level light
indicator will blink. This indicates
that the high level ventilation mode
is active. Appliance will operate 7
minutes in this mode and will switch
to one lower level after 7 minutes
and will continue to operate at the
switched mode.
3.2 Energy efficient usage
•When using your appliance, adjust the speed
settings according to vapour and odour intensity,
in order to save energy.
•Use low speeds (1-2) under normal conditions,
and high speed (3) for intense odour and vapour.
•The lamps on the hood are placed for illuminat-
ing the cooking area.
3 Operation of the appliance
•Using them for environmental lighting shall
cause unnecessary energy expenditure and in-
sufficient lighting.
3.3 Operating the hood
•Your appliance contains a motor that has various
speeds.
•For better performance, we recommend using
low speeds under normal conditions and high
speeds in cases of strong odours and intense
vapour.
•You can start your appliance by pressing on the
desired speed setting button. (B, C, D).
•You may illuminate the cooking area by pressing
the lamp (A).
3.4 Automatic stop
Your appliance has Automatic Stop feature, ena-
bling it to ventilate for a bit more and remove the
unwanted odours and vapour inside the environ-
ment and turn off automatically after the cooking
is done. To enable Automatic Stop feature, press
the any speed stage button (B, C, D) on the control
panel for longer than 2 seconds; the 15-minute
timer function shall be activated. When the au-
tomatic stop feature is active, pressing the same
speed button shall disable the automatic stop
function and the appliance’s motor shall stop. This
feature is disables when you switch between dif-
ferent speed stages. If you want the appliance to
stop automatically, you need to enable the auto-
matic stop feature again.

10 / EN Cooker Hood / User Manual
3.5 Replacement of Lamp
If the lamp of your device fails, contact the author-
ized service for lamp replacement.
Model DKW 6565 X DKW 9565 X
Bulb
Bulb Power 10.1 W
Holder / Socket LED bar
Bulb Voltage 220 - 240 V
Size 294 mm
ILCOS Code DBL-3/840-220/240-
FP-12/294
Luminous flux 377 lm 638 lm
Correlated colour
temperature
4000 K
This product contains a light source of energy ef-
ficiency class “F”.
3.6 Operation with chimney
connection
•Vapour is extracted through the
flue duct, which is fastened to
the connection head on the
hood.
•The diameter of the flue duct must be the same
as the connection ring. In horizontal settings, the
pipe has to have a slight upward slope (around
10º) so that the air can exit the room easily.
3.7 Operation without chimney
connection
•Air is filtered through the carbon
filter and recirculated in the
room. Carbon filter is used
when it is impossible to use a
flue in the house.
•In flueless use, remove the flaps inside the flue
adapter.
•Remove the grease filter. To install the carbon
filter, fit the filter to the tabs by centring it on
the plastic piece on both sides of the fan body.
tighten it by turning right or left.
•Replace grease filter.
3 Operation of the appliance

Cooker Hood / User Manual 11 / EN
CBefore cleaning and maintenance,
unplug the product or turn off the
switch.
4.1 Cleaning of the grease filter
This filter retains the oil particles in the air. Grease
filter may change colour as they are washed; this
is normal and does not require replacing your
grease filter.
•Push the grease filter lock forward.
•Then pull it slightly down and pull it out. Oth-
erwise, you can bend the filter. Wash and rinse
Grease filter with liquid detergent and replace
grease filter to their sockets by by carrying out
the steps specified above in reverse order. This
filter retains the oil particles in the air.
CYou may wash your grease filter in
the dishwasher.
ACAUTION: In case of normal use,
clean your filter once in a month.
4.2 Replacement of Carbon Filters
Odour removing filters contain charcoal (Active
carbon). Grease filter must be installed in the prod-
uct, regardless of whether or not carbon filters are
used.
•Remove the grease filter.
•To remove the carbon filter, remove the car-
bon filter from its housing by rotating it coun-
ter-clockwise from the tab.
•Install the new carbon filter.
•Install the grease filter.
A
CAUTION
•Carbon filter shall never be
washed.
•Replace carbon filters once every
3 months.
•You can obtain the carbon filter
from the authorized services.
4 Cleaing and maintenance

12 / EN Cooker Hood / User Manual
AWARNING: Before starting the in-
stallation, read the safety informa-
tion on user manual.
BWARNING: Failure to install with
screws and stabilizers in accordance
with these instructions may result in
electric shock.
For the installation of the hood, please contact the
nearest Authorized Service.
It is the customer’s responsibility to prepare the
location and electrical installation of the hood.
5.1 Position of the appliance
Figure 1
•Distance between the cooker and the cooker
hood must be considered prior to assembly. This
distance should be 65 cm (Figure 1).
•Distance must be measured from the surface of
grate for gas cookers,
•from surface of glass for electric cookers.
5.2 Installation Accessories
12345
678910
11 12 13
DKW6565 X - DKW 9565 X
EN- DE
01M-9202833600-4921-01
01M-9202823600-4921-01
UserManual
CookerHood
1. Product
2. Outer Chimney
3. Inner Chimney
4. Chimney Connection Plate
5. Ø150/120mm Plastic Flue Adapter
6. User Manual
7. Assembly Pattern
8. 2x Ø6mm Plastic Dowel
9. 4x Ø8mm Plastic Dowel
10.4x 4.8x50 Wall Mount Screw
11.2x 3.9x22 Chimney Connection Plate Screw
12.4x 3.5x9.5 Chimney Connection Screw
13.Chimney Clamp
The information required to make the location suit-
able for the installation of the hood is given below.
5.3 Wall Mounting
ACAUTION: Use protective gloves
and glasses while performing drilling
and cutting operations.
•Wall must be flat, straight and have the suffi-
cient bearing capacity.
5 Installation of appliance

Cooker Hood / User Manual 13 / EN
product will be installed and mark the installa-
tion holes (Figure 2/b).
•Drill hang holes with Ø8mm drill and insert the
pins (Figure 2/b).
•Insert 2x4.8x50 hang screws, ensuring that
there is a 5 mm space between the screw head
and the wall (Figure 2/b).
Figure 3
1. Hanger Plate
2. Hanging Plate Connection Screw
•Loosen the connection screws to pull up the
hanging plates found on the body of the appli-
ance and then tighten the screws (Figure 3/a).
•Open the filter cover.
•Remove the metal oil filter.
•If the diameter of the air discharge pipe is
lower than 150 mm, install Ø150/120 mm flue
adapter.
Ø 4,8 x 50 mm
Figure 4
5 Installation of appliance
•Depth of drilling holes must comply with the
length of bolts.
•The bolts and dowels provided are suitable for
brick walls. For other construction material (e.g.
drywall, plate, porous concrete), suitable fixing
dowels and nuts shall be used.
Figure 2
ACAUTION: Before drilling, ensure
that there are no power, gas or wa-
ter pipes in the close proximity of the
drilling locations.
•Draw a central point line on the wall, from the
ceiling to the lower side of the hood (Figure 2).
•There is a notch in the middle of the flue connec-
tion plate. Place the central point of this notch,
which is found on the flue connection plate, on
the vertical line you drew on the wall. Align it
vertically and use a pen to mark the holes to
which the flue connection plate will be installed
(Figure 2/a).
•Drill the marked points with a Ø6mm drill and
insert 2x Ø6mm plastic pins in these holes (Fig-
ure 2/a).
•Fix the flue connection plate to the wall with
3.9x22 screws (Figure 2/a).
•To drill hang holes for the hood, stick the in-
stallation template to the surface to which the

14 / EN Cooker Hood / User Manual
Hold the cooker hood by its body and place it on
the mounting screws on the wall and tighten the
screws (Figure 4).
Secure the cooker hood with two 4.8x50 screws to
the wall through the mounting hole on the interior
of the appliance (Figure 4).
A
WARNING: As the bends and el-
bows in the aluminium pipe will
cause a decrease in the air suction
power, using these must be avoided
as much as possible.
5.4 Connecting to Chimney
Figure 5
1. Flap Pin Socket
2. Flap Pin
Insert the plastic pin (Figure 5/area no. 2) on the
pin socket on the motor exhaust (Figure 5/area
no.1). Then bend the flap lightly to insert the other
pin on the flap and insert the other pin to its socket
(Figure 5).
If you are going to use the Ø 120/150 mm plastic
Chimney adapter, connect one end of the pipe to
this adapter, if you are not going to use it, to the
direct output on the product. Connect the other
end of the pipe to your chimney. Check that these
two connections are tight enough so they will not
come out when the appliance runs on full power.
Ensure that the flaps inside the Chimney work
when tightened with clamp. Connect the Chimney
connection duct outside the adapter (Figure 6/a).
If the connection duct is fitted inside the adapter,
suction of air shall not occur as the Chimney flap
that prevents the return of air will remain closed
(Figure 6/b). The length of the pipe connection as
well as the number of elbows must be as mini-
mum as possible.
A : Chimney exit pipe
B : Chimney Clamps
C: Plastic Chimney
The valves are closed then the appliance is not
operating and prevent possible outside odour and
dust from entering inside.
Ok Not Ok
(a) (b)
Figure 6
5.5 Installation of the Hood to the
Chimney
Make the electrical connection of your hood be-
fore starting the installation of the chimney. Slip
the Chimney plates around the body. Screw the
Chimney to the Chimney fastening plates availa-
ble on the motor cabin. (Figure 7).
Install the Chimney to the Chimney fastening plate
that is secured to the wall from its upper outer
edges (Figure 7).
5 Installation of appliance

Cooker Hood / User Manual 15 / EN
Figure 7
1. Inner Chimney
2. Outer Chimney
5 Installation of appliance

16 / EN Cooker Hood / User Manual
6 Troubleshooting
Troubleshooting Root cause Help
Appliance is not working. Check your fuses. Fuse may be blown, inspect and restore it.
Appliance is not working. Check the electrical connection. Mains voltage shall be between 220 and 240 V.
Appliance is not working. Check the electrical connection. Check if other appliance in your kitchen
operate.
Illumination light does
not operate.
Check the electrical connection. Mains voltage shall be between 220 and 240 V.
Illumination light does
not operate.
Inspect the lamp switch. Lamp switch shall be at “on” position.
Illumination light does
not operate.
Inspect the lamps. The lamps of the appliance shall illuminate.
Air inlet of the appliance
is inadequate.
Inspect the aluminium filter. Under normal operating conditions, Grease filter
shall be cleaned at least once in a month.
Air inlet of the appliance
is inadequate.
Check the air discharge chimney. The air discharge chimney shall be at “on” po-
sition.
Air inlet of the appliance
is inadequate.
Inspect the carbon filter. The filters of the appliances with carbon filters
shall be replaced once in every 3 months under
normal conditions.

Bitte lesen Sie zunächst diese Anleitung!
Sehr geehrte Kundin, sehr geehrter Kunde,
Vielen Dank, dass Sie sich für dieses Gerät der Marke ElektraBregenz entschieden
haben. Wir sind überzeugt, dass Sie mit diesem Gerät, das mit den höchsten
QualitätsanforderungenundmodernsterTechnologiehergestelltwurde,besteErgebnisse
erzielen werden. Bitte lesen Sie die gesamte Bedienungsanleitung und alle anderen
Begleitdokumente aufmerksam, bevor Sie das Gerät verwenden; bewahren Sie sie zum
künftigen Nachschlagen sicher auf. Wenn Sie das Gerät an jemanden weitergeben,
händigen Sie ihm bitte auch diese Anleitung aus. Befolgen Sie die Anweisungen, indem
Sie alle Informationen und Warnhinweise in der Bedienungsanleitung beachten.
Bitte denken Sie daran, dass diese Bedienungsanleitung eventuell für mehrere Modelle
geschrieben wurde. Unterschiede zwischen den Modellen werden in der Anleitung klar
und deutlich beschrieben.
Bedeutung der Symbole
Folgende Symbole werden in den verschiedenen Abschnitten dieser Anleitung
verwendet:
CWichtige Informationen und nützliche Hinweise zur
Verwendung.
AWARNUNG: Warnhinweise zu gefährlichen
Situationen im Hinblick auf die Sicherheit von Leib,
Leben und Eigentum.
Warnung vor Brandgefahr.
BWarnung vor Stromschlägen.
Dieses Gerät wurde in umweltfreundlichen, modernen Einrichtungen ohne schädliche Auswirkungen auf
die Natur hergestellt.

18 / DE Dunstabzugshaube / Bedienungsanleitung
1.1 Allgemeine Sicherheit
Wichtige Sicherheitsanweisungen
sorgfältig lesen und zum künftigen
Nachschlagen aufbewahren
Dieser Abschnitt enthält
Sicherheitsanweisungen, die
beim Schutz vor Personen-
und Sachschäden, Bränden,
Stromschlägen und dem
Austreten von Mikrowellenenergie
helfen. Bei Nichtbeachtung dies-
er Anweisungen erlischt die
Gewährleistung.
•ElektraBregenz-Produkte stim-
men mit geltenden Sicher-
heitsstandards überein; daher
sollten Gerät oder Netzkabel zur
Vermeidung von Gefahren im
Falle von Schäden durch den
Händler, ein Kundencenter oder
einen spezialisierten, autorisi-
erten Serviceanbieter repariert
oder ersetzt werden. Fehlerhafte
oder unqualifizierte Reparaturen
können Gefahren und Risiken für
den Benutzer verursachen.
•Dieses Gerät ist für den Einsatz
in Haushalten und ähnlichen
Bereichen vorgesehen, wie:
– In Betriebsküchen, Läden,
Büros und anderen Arbeit-
sumgebungen;
– Bauernhöfen;
– Von Gästen in Hotels und an-
deren Wohnumgebungen;
– Pensionen und Jugendher-
bergen.
•Das Gerät darf nur für seinen in
dieser Anleitung beschriebenen
vorgesehenen Zweck verwendet
werden.
•Der Hersteller haftet nicht für
Schäden, die auf unsachgemäße
Installation oder fehlerhaften Ge-
brauch zurückzuführen sind.
•Das Gerät darf nur dann von
Kindern ab 8 Jahren und Perso-
nen mit körperlichen oder geis-
tigen Einschränkungen genutzt
werden, wenn diese beaufsichtigt
werden oder gründlich über den
richtigen und sicheren Umgang
mit dem Gerät aufgeklärt wurden
und sich sämtlicher möglicher
Gefahren bewusst sind.
1 Wichtige Sicherheits- und Umweltanweisungen

Dunstabzugshaube / Bedienungsanleitung 19 / DE
•Kinder dürfen nicht mit dem
Gerät spielen. Reinigungs- und
Wartungsarbeiten dürfen nicht
unbeaufsichtigt von Kindern aus-
geführt werden.
•Der Abstand zwischen der Stütz-
fläche für Kochgeschirr auf dem
Kochfeld und dem niedrigsten
Teil der Abzugshaube muss
mindestens 65 cm betragen.
•Falls die Anweisungen zur In-
stallation eines Gasherdes einen
größeren Abstand angeben, ist
dieser einzuhalten.
•Stellen Sie sicher, dass Ihre
Stromversorgung mit den Anga-
ben am Typenschild des Gerätes
übereinstimmt.
•Benutzen Sie das Gerät niemals,
wenn das Netzkabel oder das
Gerät selbst beschädigt ist.
•Vermeiden Sie Schäden am
Netzkabel, indem Sie es nicht
quetschen, knicken oder über
scharfe Kanten ziehen. Halten
Sie das Netzkabel von heißen
Oberflächen und offener Flamme
fern.
•Verwenden Sie das Gerät nur mit
einer geerdeten Steckdose.
WARNUNG: Schließen Sie das
Gerät erst nach vollständig ab-
geschlossener Installation an das
Stromnetz an.
•Stellen Sie das Gerät so auf,
dass der Netzstecker immer
zugänglich ist.
•Berühren Sie die Lampen nicht,
falls sie lange Zeit in Betrieb
waren. Sie könnten sich die Fin-
ger verbrennen, da die Lampen
heiß werden.
•Befolgen Sie die von zuständigen
Behörden festgelegten Richt-
linien zum Abführen von Abluft
(diese Warnung ist bei Einsatz
ohne Abzug nicht zutreffend).
•Nehmen Sie Ihr Gerät erst in
Betrieb, nachdem Sie ein Koch-
geschirr auf das Kochfeld gestellt
haben. Andernfalls könnte hohe
Hitze zur Verformung von Teilen
Ihres Geräts führen.
•Schalten Sie die Kochfelder
ab, bevor Sie das Kochgeschirr
herunternehmen.
•Lassen Sie kein heißes Öl auf das
Kochfeld gelangen. Kochgeschirr
mit heißem Öl kann sich selbst
entzünden.
1 Wichtige Sicherheits- und Umweltanweisungen

20 / DE Dunstabzugshaube / Bedienungsanleitung
•Achten Sie auf Vorhänge und
Abdeckungen, da Öl beim Zu-
bereiten von Lebensmitteln, wie
Pommes frites, Feuer fangen
kann.
•Der Fettfilter muss mindestens
einmal im Monat ersetzt werden.
Der Kohlefilter muss mindestens
alle 3 Monate ersetzt werden.
•Das Produkt muss entsprechend
der Bedienungsanleitung gerein-
igt werden. Falls die Reinigung
nicht entsprechend der Bedi-
enungsanleitung durchgeführt
wird, besteht Brandgefahr.
•Verwenden Sie kein nicht feuer-
beständiges Filtermaterial an-
stelle des aktuellen Filters.
•Verwenden Sie nur Originalteile
und vom Hersteller empfohlene
Teile.
•Verwenden Sie das Gerät nicht
ohne Filter. Entfernen Sie die
Filter nicht, während das Gerät
läuft.
•Sollte sich etwas entzünden, un-
terbrechen Sie als erstes sofort
die Energieversorgung.
•Ersticken Sie ein Feuer mit einer
geeigneten Decke oder ähnlich,
verwenden Sie zum Löschen
niemals Wasser.
•Trennen Sie das Gerät vor
jeder Reinigung und bei Nicht-
benutzung von der Stromver-
sorgung.
•Der Unterdruck in der Umgebung
darf 4 Pa (4 x 10 bar) nicht über-
schreiten, während die Dunstab-
zugshaube für das elektrische
Kochfeld und Geräte mit einer
anderen Energiequelle als Strom
gleichzeitig laufen.
•Falls sich ein mit Heizöl oder
Brenngasen betriebenes Gerät,
z. B. Heizungen, in der Nähe der
Dunstabzugshaube befindet,
muss die Abluft dieses Gerätes
vollständig getrennt abgeführt
werden oder es muss herme-
tisch sein.
•Verwenden Sie zum Anschluss
des Abzugs Rohre mit einem
Durchmesser von 120 oder 150
mm. Der Rohranschluss muss
möglichst kurz sein und sollte
möglichst wenige Biegungen
aufweisen.
1 Wichtige Sicherheits- und Umweltanweisungen
