ELEKTRA CX Series User manual

Electric bathroom
dryers
ELEKTRA CX
RU
Instrukcja montażu PL
Installation manual UK
Èíñòðóêöèÿ ïî ìîíòàæó
www.elektra.eu

Key safety notes
Unless it is used under super-
vision or in accordance with the
instructions provided by persons
responsible for their safety, the
product must not be operated by
children under the age of 8 or
individuals with sensory-motor or
mental disability or persons with
previous experience with or
knowledge about the product.
Children must not play with the
product. Unsupervised children
must not clean or perform
maintenance of the product.
• The product may only be used
for its intended purpose
following all instructions for
installation and operation
included in this manual.
• The heated towel rail is not
a toy, therefore keep the
appliance out of reach of
children without parental
supervision.
3
Note:

• For the sake of safety of
children the heated towel rail
should be installed so that its
bottom part is out of reach
of small children, i.e. at least
60 cm above the floor.
• Please mind that the surface of
the working towel rail is hot.
Touching it can result in burns.
• The heated towel rail is not
a weight-bearing structure.
Avoid stepping on it or using
it as a ladder.
• Do not immerse any part of
the appliance in water
(e.g. in a bathtub etc.).
• The product is fitted with
a nondetachable power supply
cord which, in case of any
damage, should be replaced by
manufacturer or in a dedicated
repair shop, in order to avoid
danger.
• In case of inappropriate
functioning of the appliance,
or any damage to its elements,
4
Electric bathroom
dryers ELEKTRA CX

immediately disconnect the
mains plug and contact
the vendor.
• Removal of the protective
plugs, placing objects into the
appliance or filling the body up
with liquid in prohibited. Such
activity may cause electric shock
or damage to the towel rail.
• Repairs and technical modifica-
tions carried out by unqualified
personnel may be dangerous
for users.
• Should any additional connect-
ing elements, such as regula-
tors, switches, extension leads
etc. be required, they must be
selected appropriately
(see information included in
their technical specifications)
and they must comply with the
applicable laws and regulations.
• If you are out of home for
a longer period of time, as
well as during cleaning of the
towel rail, disconnect the mains
plug (do not pull the cord!)
5

or, for the CX...N version, switch
the device off by using the
ON/OFF switch.
The electric heated towel rail
must be situated at least 60 cm
away from baths, basins, sinks,
showers, pools etc.
PLEASE USE THE APPLIANCE IN
ACCORDANCE WITH THE GUIDE-
LINES INCLUDED IN THE
INSTALLATION, USE AND MAIN-
TENANCE INSTRUCTION MANUAL
AND READ THE WARRANTY
CONDITIONS.
6
Electric bathroom
dryers ELEKTRA CX

Application
Technical data
ELEKTRA CX electric bathroom dryer is intended
for drying towels, garments etc. washed in
water. It can be installed in any room where
electric power is available (~230V, 50/60Hz),
and is especially suited for bathrooms, kitchens,
bathing rooms, hairdressers' etc. The bathroom
dryer's design ensures its constant safe opera-
tion. The temperature increase of the dryer's
exposed surface, during continuous operation,
does not exceed 60°C.
Power supply: ~230V AC, 50/60Hz
Power consumption: 95÷230W
Power consumption depends on bathroom dryer
type. Power consumption data are given on the
nameplate.
Power output and IP protection rate: dependent
on the model of the heated towel rail.
For relevant information, see the rating plate.
Weight: Weight depends on the model of the
heated towel rail and is stated on the product
label.
Protection Class according to IEC: I (The electric
heatedtowelrailisaIprotectionclassapplian-
ce. It means that the power supply cord is
fitted with a protective conductor, which must
be connected to the PE protective conductor of
the electrical system directly - for the CX...N
version of the device, or through a socket
equipped with an adequate protective pin
– for the standard version of the device. 7

Mounting Instructions
of the standard CX version
of the dryer, with a plug
1. Assemble the brackets without screws (6)
and plugs (8) (as per the drawing).
2. Select bathroom dryer position on the wall.
3. Drill holes at pre-located points,
and insert plugs.
4. Using screws (6) mount brackets (7)
to the wall (as per the drawing).
5. Using screws (9) fix the bathroom dryer
and heater to the bracket, together with
the elements previously mounted to it.
Body of the dryer
M6 screw
Ø13 sleeve
Washer
M6 nut
1
2
3
4
5
Screw 6x70
Body of the bracket
Plug Ø10x50
Screw 2.9x9.5
6
7
8
9
Bracket elements
8
Electric bathroom
dryers ELEKTRA CX

Body of the dryer
Body of the bracket
1
2
Bracket elements for the bathroom dryer CX…N
9
Mounting Instructions
of the special CX...N
version of the dryer,
with a power supply cord
in the dryer's body
The special CX...N version of the bathroom dryer
varies from the standard one with the power
supply cord of the dryer led directly out
through the body, and not terminated with
a plug.
1. Mount elements of the three brackets of the
dryer according to the mounting instructions
of the standard CX version of the dryer
above.
2. The fourth element, through which the
power supply cord is led, is not mounted
to the wall.
Screw 2.9x9.5
Power supply cord
3
4

Connection to the mains
and adjustment
(switching the appliance on & off)
To start the bathroom dryer's operation, for the CX
standard version of the device (with a plug), insert the
plug into an earthed electrical socket (230V ~50Hz).
• In order to start the operation of the heated towel
rail, connect the plug to an earthed electrical socket
and set the switch into position "I". Occasional
monitoring of the appliance's operation is advisable.
• Only original factory fitted elements (cords, plugs)
can be used for direct electrical mains connection of
the appliance.
• To switch off the heated towel rail, it is enough to
set the switch into position "0" it is not necessary
to disconnect the mains plug.
• For the heated towel rails fitted with power supply
cords without plugs, designed for fixed connection
to electrical mains, electrical wiring must be equipped
with protective devices enabling disconnection of the
appliance on both poles for bipolar switches, or
disconnection of the live wire from the power supply
for unipolar switches. Applied devices for disconnection
from the power supply should be designed so that
their air gaps should exceed 3 mm.
To start the bathroom dryer's operation, for the
CX...N version of the device with the power supply
cord in the body (without a plug):
10
Electric bathroom
dryers ELEKTRA CX
Packaging elements can be dangerous
for children. Keep the packaging out of
reach of children.
Note:

11
Products marked with (allowable
temperature: 150°C), and (allowable
temperature: 200°C) can hang on the
bathroom dryer for an unlimited period
of time. In case of other markings, special
attention must be paid, since there is
a possibility of fabric fibres sticking to
the bathroom dryer surface.
Note:
Recommendations for use
• No part of the appliance must be immersed
in water (e.g. in a bathtub etc.).
• The heated towel rail is designed for drying
fabrics washed in water only. Do not dry
products soaked in inflammable liquids.
• Never use the bathroom dryer as a ladder.
• The surface temperature of the bathroom
dryer does not exceed 60°C.
• Covering the bathroom dryer's surface, when
switched on, will increase its temperature more
than for an uncovered dryer. The actual tempera-
ture depends on the type and thickness of hung
fabric. For this reason attention must be paid to
the information regarding the ironing tempera-
ture stated by the fabric manufacturers.
The appliance must not be dismantled or
repaired by the customer. If the manufacturer
or customer service finds irregularities in use,
the warranty becomes null and void.

12
Electric bathroom
dryers ELEKTRA CX
Maintenance
Disconnect the power supply before starting to
clean the appliance. Wash the appliance surface
with a sponge or cloth moistened with water
with the addition of mild detergents
(e. g. dish washing liquid).
Water must not drip on the appliance during
cleaning. Never use caustic or abrasive cleaning
agents, or sharp objects, since these may
damage the towel dryer surface. The bathroom
dryer must not be reconnected until the cleaned
surfaces are completely dry. External surfaces
must not be painted with any paints or
varnishes.
• Varnished elements of the body of
the heated towel rail
Use warm water and mild detergents
(e.g. washing-up liquid) to wash the body.
• Chrome plated elements of the body of
the heated towel rail
Use mild detergents or cleaning products
dedicated for maintenance of chromium-plated
surfaces to wash the body.
• Plastic elements: connecting and mounting
components
Use warm water and mild detergents to wash
the surfaces. External surfaces must not be
painted or varnished.

Standard version. Power supply cord with plug.
Type Power
[W]
Colour
Dimensions
width x height
[mm]
Special version. Power supply cord without plug.
Connection through the bracket.
CX 700
CX 700r
CX 700c
CX 800
CX 800r
CX 800c
CX 900
CX 900r
CX 900c
130
130
95
175
175
175
230
230
230
527 x 697
527 x 697
527 x 697
527 x 997
527 x 997
527 x 997
527 x 1227
527 x 1227
527 x 1227
White
RAL
Chromium
White
RAL
Chromium
White
RAL
Chromium
Type Power
[W]
Colour
Dimensions
width x height
[mm]
CX 700N
CX 700Nr
CX 700Nc
CX 800N
CX 800Nr
Nc
CX 900N
CX 900Nc
CX 800
CX 900Nr
527 x 697
527 x 697
527 x 697
527 x 997
527 x 997
527 x 997
527 x 1227
527 x 1227
527 x 1227
130
130
95
175
175
175
230
230
230
White
RAL
Chromium
White
RAL
Chromium
White
RAL
Chromium
13

Environment protection
In accordance with the applicable regulations of
law, electric appliances no longer in use must be
disposed of in an appropriate manner. A marking
shown on the product or its packaging indicates
that the appliance must not be disposed of with
household waste.
It is a duty of users to deliver appliances no
longer in use to a specialised point of environ-
mentally safe waste disposal. Local authorities,
municipal services or your product dealer may be
contacted in order to receive detailed information
concerning local waste collection system for
electric appliances.
Remember that household waste management
plays a crucial role in the process of reclaiming
and recycling resources from appliances no
longer in use. Through observing these require-
ments we help protecting the natural environ-
ment.
The electric heated towel rail does not contain
any substances classified as harmful or hazardous
to the environment.
No hazardous substances, materials or subparts
are present in the device, as listed in Annex 5
to the Waste Electrical and Electronic Equipment
Reusing and recycling of appliances no longer
in use:
14
Electric bathroom
dryers ELEKTRA CX

Act (WEEE).
No element or subpart of the device can be
reused.
When disassembling the device no longer in use:
• Disconnect the power supply cords.
• Dispose of the steel body of the device
as steel metal waste.
• Separate plastic elements: fixing brackets,
insulation of power supply cords, plug case
etc. and recycle.
• Dispose of the copper wires of electric cables
as copper metal waste.
• Recycle electronic components in order
to reclaim raw materials.
The electric heated towel rail does not contain
any substances classified as harmful or hazardous
to health.
The product is compliant with and meets the
requirements of the applicable standards and
regulations:
2014/35/UE Low Voltage Directive (LVD)
2011/65/UE Restriction of Hazardous Substances
(RoHS II) Directive
The electric heated towel rail has the marking.
Health protection
Applicable standards
and regulations
15

Warranty
ELEKTRA grants a 2-year warranty
(from the date of purchase) for ELEKTRA
bathroom dryers.
Warranty conditions
1. For the claim to be recognized, the following
are required:
a) installation of the dryer in accordance
with this installation manual;
b)proof of purchase of the bathroom dryer;
c) the correctly filled warranty card.
2. The warranty shall be null and void if any
changes to the construction design are made,
any repairs are performed individually or
the data plate is removed or damaged.
3. The warranty shall not cover defects:
a) occurring as a result of fortuitous events
such as: fire, flood, lightning, activity
of chemical agents, overvoltages in the
power supply network;
b)mechanical defects of the dryer and
accessories such as: connection cords,
plugs, etc.;
c) related to improper installation and use.
4. ELEKTRA undertakes, as part of warranty,
to cover expenses associated solely with
replacement or repair of a faulty product
resulting from manufacturing defects.
16
Electric bathroom
dryers ELEKTRA CX

Claims shall be submitted together with
the Warranty Card and the proof of
purchase to the point of sale of the
dryer or to ELEKTRA.
Note:
Type
Colour
Serial
Number
Date
Clerk / Installer
signature
Company
Stamp / Seal
17

Suszarki
elektryczne
ELEKTRA CX
RU
Instrukcja montażu PL
Installation manual UK
Èíñòðóêöèÿ ïî ìîíòàæó
www.elektra.pl
