Element SUM-3AC Quick setup guide

JSUM—SAC
1 Leg
8 Stage
ASSEMBLY
&
USE
INSTRUCTIONS
40030914V.A

.CAUTION / INFORMATION ~
Make sure no obstacles are in the desk's
path.
Make sure the desktop is not touching
any walls.
Make sure all cards are appropriate
length to
accommodate the change
in height.
Pinch Point
Keep hands and
fingers clear.
Keep children
away from electric height-adiustable desks, control
units and handsets.
There is a risk at injury and electric
shock.
l A Do not
place any objects taller than 20'I underneath the desk. A l
A Do not open any of the components - the Legs, Control Box, or Switch. A
There is a danger of electric shock.
This product is designed with a duty cycle at 10%
(2 min. on, I8 min. oft).
o In the event of a power outage or it the power
cord is unplugged, 0
a manual reset may be necessary - see USE section.
.USE / LIABILITY
This height adiustable desk
has
electric motors and is designed for use in dry work areas only.
The desk height is adjustable so that
it can be
positioned at the most
ergonomically suitable height.
Any other use is at user's risk.
Under no circumstances does the manufacturer
accept warranty claims or liability claims
For damages caused
from improper use or handling of the desk frame.
IMPORTANT:
Please read this manual carefully.
If this
desk is sold, please provide this
manual to the
buyer.

.
,...
Arab-rpm
‘
.12.;JJ
JR
4mm
Allen
Wrench
[includedl
PARTS
LIST
“Control Box
Handset
a Power Cord
nCable (1.3m) 2
Phillips
Head Screwdriver
and/or Power Drill
Frame End A
Frame End B
Center Rail
Side Bracket
M
(aroma:
Pa rt
[EMsxzs Set Screw
lpreinstallecl)
mexl
4 Machine Screw
8
l2
Méxl 4 CS Machine
Screw] 2
M5x20 Wood
Screw
M5xl 6 Wood Screw
Cable Clip
18
4
15

.ASSEMBL
) Lay out all components and hardware to ensure that you have all the components and hardware listed on the parts page.
M’
2
Working on the underside of the desktop or on a non-scratch surface, place the Center Rails (part 4)
inside the Frame Ends A (part 30) and 3b) as shown. The Center Rails (part 4) have the hollow
side facing up and the tabs on the Frame Ends (parts 30 and 3b) are on the botom - see inset.
0 The tops
on
the
Frame
Ends
should
trace inboora o
0 "he Center Qails [part 4) have the open side facing upwards o
in the above image
3 Insert the Side Brackets (part 5)
into the Frame Ends
(parts
3a and 3b).
Place the Lifting Columns (port 1) in the Frame Ends as shown.
4 If the desktop is predrilled,
adiust all the components so that the
holes in the frame ends and side brackets line up with the holes
in the desktop.
It the desktop is not predrilled, we recommend
l
placing the side brackets at least 1/2' inboard at
the desktop l
edges and centering the Side Brackets (part 5) fore and aft. /l ‘
Using the supplied
Allen Wrench and eight (1 2) belli CS
Machine Screws (part 12) attach the Lifting Columns (part I)
to the Frame Ends (parts 30 and 3b)
5
Center
the Center Rails (parts 4) in the Frame Ends
(parts 3a and 3b). Lock down the Center Rails with the
eight )8) preinstalled M8x25 Set Screws [port
)0).
For each Leg (part i), attach 0 Foot (part 2) with tour [4) M6xl4
6 Machine Screws (part i l) and tighten in a cross-pattern.

IASSEMBLY_
Double-check
that the wood screws are not too long for your desktop A
A and won't
puncture the surface when screwed
all
the
way
in.
P
.-
b‘
\\e recommend that \~ou
aredxrill any holes needed
for
fasteners
o
"
o it \Our
desktop Is not predrillea‘. Never use countersunk sCrews. ’
7 Doublecheck
that the desk base
is properly positioned on the underside
of the desktop.
Attach the desk base to
the underside of the desktop using eighteen (l 8)
M5x'20 Wood Screws [part 13).
Attached the Control Box (part 6) to the underside of the desktop
with tw0 [2) leO Wood Screws [part 14) close enough to one
Leg (part ll so that the cable from the Leg (part 1] reaches the
Control Box (part
0). Connect the cable on the Leg (part I l closest
to the Control Box (part o1.
Attach
the Handset (part 7] to
the underside of the desktop so the
8 front of the handset
is flush with the front
desktop edge (or recessed
up to l/8'). The handset may
be placed anywhere along the front
edge of the
desktop but we recommend
placing it toward an end
so it does not interfere
with your chair when seated. Use two
('2)
le6 Wood Screws (part 14)
to attach the handset to the desktop.
Connect the Cables
(part 9) to the other Legs (part I] and to the Control Box (part
6).
Connect the Power
Cord (part 8) to the Control Box (part 6].
Do not overtighten screws
in this step.
A
Use
the adhesive-backed Cable Clips (part 15) A Overtightening could cause damage to the
components.
to secure the other cables so they
do not sag.
9 Turn the assembled desk right~side up. With at least two people, grab the DESK BASE
(not the desktop)
and tum the
desk right~side up. Adiust the prei'nstalled glides on the Feet (part 2) as needed.
IO Plug the Power Cord (part 8) into a l 10v outlet.
A Make sure no obstacles
are
in the
desk's path. A
Make sure the desktop is not touching any walls.
Make sure all cards are appropriate length to accommodate the change in height.
IMPORTANT:
You must RESET the desk pn‘ar to use.
RESET
PROCEDURE: Press and
hold the DOWN button on the Handset (part 7) until the desk reaches its lowest height.
Release
the DOWN button. Press and hold the DOWN
button again until the LED display reads 'RST' or about
10
seconds on non-LED
handset models. Release the DOWN button. Press and hold the DOWN button again until the
desk lowers a little bit more,
slightly rises and stops. Release the DOWN button. Your desk is now ready to use.
The heddesk base can
be adjusted by
pressing and holding either the UP or DOWN button until
the desired height is
reac
.
To program
up to four presets (on
some models]: Use the up/down buttons to find a
desired
height, then press 'M'
followed by a number
1 - 4.
CAUTION: Once
a preset button
is pushed, the desk will move to the programmed
height lsee Caution box above)-
CAUTlON: If a different
control box is
placed on a desk with partially extended
legs, you must
RESET prior to moving UP.

.TROUBLE
SHOOTING—
lf your desk is not functioning properly it may need to be reset. Follow the RESET procedure
outlined
in the USE section.
It your
desk has a
handset with an LED readout and it displays 'RST' (reset),
perform the reset procedure
outlined in the
USE section.
It the LED readout
displays
an error message ('Erl ' - 'Er13") confirm that
all wired connections are secure
(legs to cables,
cables to control box). Then perform the reset procedure outlined in the USE section.
It the error message persists after the reset procedure, contact your seller.
If the height between the legs exceeds 1 .5 inches, stop the reset procedure & contact your
seller.
it the handset displays 'HOT',
let the base cool down for 20 minutes.
.SPEClFlCATlONS
_. -. r
42 min-77mm-
Trovel
1.5” er
secon (no 00)
lam -- 1500N
10%. Max. 2 mins on I8 mins 0
So start RE—
A 'usto e evein studs
4 Memory presets [some m e s] 4 Memory presets (some moe s)
PROGRAMMING
V some models »
Press
the DOWN button on the Handset (part 7) until the base reaches its lowest position. Press and hold the DOWN
button again until the LED display reads 'RST'.
Press and hold the 1 button (about 5 seconds) while
the LED flashes 'RST' and then switches
to either: Fl 5 l—
10.] = OneTouch
10.2 —- Constant-Touch
Release the
1 button. Press the 1 button again until the desired setting is reached. Once the chosen setting is
displayed, release the button
and wait about 5 seconds for the display to return to 'RST'.
Finish the reset process by pressing and holding
the DOWN button until the desk lowers
a little bit more, slightly
rises and stops. Release
the button. The new program setting is saved and your desk is now ready
to use.
HSETTING
THE LED RETRACTED HEIGHT
(some'mode si,:—-=i"~t...‘—-‘«."
‘ ~
Press the DOWN button on the Handset [part 7] until the base reaches its lowest position. Measure the distance from
floor to the top surface at the desktop. It the
number on the LED
display does NOT match your measurement, follow
these steps:
Press and hold the DOWN button until the LED display reads 'RST'. l:l El l— Press and hold
the 'M" button [about
5
seconds] until the LED displays the flashing height. {It the display returns to 'RST' before the next step is taken, repeat
this step.) Use the UP/DOWN buttons to change the value at the starting height so that
it matches your measurement.
Wait about 5 seconds and the display will return to 'RST.”
Finish the reset process by pressing
and holding
the DOWN button again until the desk
lowers a little bit more,
slightly
rises and stops.
Release the button. The new starting height value is saved and your desk is now ready to use.
Note:
the LED display has a $0.]
tolerance.

ISETTING
THE UPPER & LOWER LIMITS
This base is designed
to go to its minimum and maximum heights, allowing for the widest possible range. It you prefer
to change the
settings to a more narrow range, follow these steps:
Make sure the power
is ON
and a number reads
in the LED display (it no number appears, please follow the Reset
procedure
described
in the USE section).
To Set the
Upper-Limit
Position:
Use the
UP/ DOWN
buttons to move the base to the desired maximum-height position. Press the
'M' button and release.
Press
the UP button
and release. The
LED display will flash
'5 -". Press and hold the 'M' button (about
2 seconds) until the
LED
display changes
to '999'.
The display will automatically
return to the selected height. The new upper
limit is now set.
To Set the
LOWer-Limit Position:
Use the UP/
DOWN buttons to
move the base to the desired
minimum-height position. Press the 'M' button and release.
Press
the DOWN button and release.
The LED display will flash '5 -'. Press and hold the 'M'
button (about 2 seconds)
until the
LED display changes to '000". The display will automatically return to the selected height. The new lower limit
is now set.
To Remove the Upper/ Lower Limit Positions:
Press the 'M'
button and release.
The LED display will Flash '5 -". Within
5 seconds, press the 'M' button again and
hold for 2 seconds.The LED
display will change to '555' and then
automatically return to the height display.
The upper and lower
limits are now removed.
A A RESET
procedure requires the desk base to full retract (beyond any
lower limit set). A
Please
ensure that you have the proper clearance below
the desk base.
After
the upper and lower
limits are set, the previous memory positions ( l, 2,
3, 4) may be outside the new range of
movement. It so, simply
reset the memory positions.
It you attempt to revise a
previously set upper or lower limit and it is outside of the
existing range, you will need to
remove
the previously set upper/ lower limits first.
IHANDSET LOCK tsome models)
To lock the handset:
Press and hold the 'M' button (about 8 seconds) until the LED display switches to 'S
-' and then to 'LOC." Release
the button.
To unlock the handset:
Press and hold the 'M' button (about 8 seconds) until the LED switches from 'LOC'
to the height display. Release
the button.
CHANGING INCHES TO CENTIMETERS (some
m‘oéls't
Press the DOWN button on the Handset (part 7) until the
base reaches its lowest position.
Press and hold the DOWN
button again until the LED display reads 'RST'.
H E '—
Press and hold the 2
button (about 5 seconds) while the LED
flashes 'RST" and then switches to either:
(0.3 = cm
(0.4
= inches
Release the 2 button. Press
and hold the 2 button
again until the desired setting is reached. Once the chosen setting
is
displayed, release the button
and wait about 5 seconds
for the display to return to 'RST'.
Finish the reset
process by pressing
and holding the DOWN button until the desk lowers a little bit more, slightly
rises and stops. Release the
button. The new measurement
setting is saved
and your desk is now ready to use.

V_u‘u—.
,w;
Zelement
117937 NE Sandy Blvd.
Portland, OR 97230
tel: [phone]
www.elementcontract.com
[email protected]
,<..,..........--—......__.A
‘....~
