Elements International B.12010.MR User manual

Assembly Instruction For
Caution: Please read instructions thoroughly before unpacking assembly parts. Sharp, exposed
staple tips can cause injury, therefore, for your protection, please remove any exposed staples
used in packing.
1. We recommend that you should assemble this product with the assistance of another person; this will make assembly
easier, and will help to eliminate damage to the product or injury to persons during assembly.
2. Be sure to check all packing materials carefully for small parts that may have come loose inside the carton during
shipment.
3. Please do not over tighten screws or bolts.
4. Please put all parts on a non-abrasive floor before assembly, and follow the assembly steps to assemble your newly
purchased product correctly and efficiently.
MIRROR
B.12010.MR
NO.
A
B
C
D
HARDWARE LIST
Q'TY
8
8
8
1
HARDWARE DESC
JCBC SCREW (M6 x 40MM)
SPRING WASHER (M6 x 13MM)
FLAT WASHER (M6 x 19MM)
M4 ALLEN KEY (65MM)
MADE IN MALAYSIA PAGE 1 OF 2
STEP 1
CODE
PB.12010.
MRHW
NO.
1
2
3
PART LIST
Q'TY
1
2
1
PART DESC
MIRROR
MIRROR SUPPORT RAIL
DRESSER
CODE
PB.12010.
MR
PB.12010.
MRSLT
PB.12010.
DR
3
2
A
B
C
D

Assembly Instruction For
PAGE 2 OF 2
STEP 2
COMPLETED
MADE IN MALAYSIA
MIRROR
B.12010.MR
1
3
2
2
2
A
B
C
D
1
