Elframo BE Series User manual

Power switch Power Light Drain Switch Heating Light Cycle Switch Cycle Light
(if drain pump fitted)
Wash Arm Rinse Arm Drain Plug Wash Pump Filter
Suction Hose Adjuster Outlet Hose Connection

To switch the machine on
•Fit drain plug into drain plug hole
•Close the dishwasher door
•Switch on the main power switch, the dishwasher will now fill and heat. The dishwasher is ready
to use when the heating light goes off.
•Press the cycle switch for 2 seconds, the cycle light will illuminate, after the cycle light goes out
the cycle is complete. To drain the dishwasher (Gravity drain)
•Switch power off
•Remove the drain plug
•Leave the door open
•When the machine is empty clean out the dishwasher including the wash pump filter.
To drain the dishwasher (Pumped drain)
•Leave power switched on
•Open door
•Remove the drain plug
•Press and hold the drain switch until the machine is empty
•Switch off the power
•Clean out the machine including wash pump filter
Integral water softener regeneration (daily)
•With the dishwasher drained and clean remove the salt container lid
•Pour in 1 mug full of dishwasher salt and replace lid.
•Close the dishwasher door
•With the main power switch off, press and hold the cycle switch for 3 seconds, the water softener
will then go through a regeneration cycle, this is indicated by the cycle light illuminating and the
power light being off. Regeneration will take 20 minutes.
•
THE WATER SOFTENER MUST BE REGENERATED EVERY DAY.
Installation
•Carefully unpack the glass washer / dishwasher.
•Peel off the white plastic protective coating
•Open the wash tank door, remove the baskets and any other loose items.
•Fit the 4 plastic feet to the bottom of the machine.
•Fit wash arms, rinse arms (top and bottom) + drain plug and wash pump filter
•Connect the detergent pump to the rear of the machine using the fitted plug and socket
On the rear of the machine you will have
•Clear plastic hose - Connect this to the outlet hose connection on the detergent pump (the other
end of the hose with the weight goes into the detergent container)
•A small latex hose. The open end goes into the rinse aid container.
•A Grey ribbed drain hose this is to be connected to your drainage supply. Machines with a drain
pump fitted are able to pump the waste water out of the machine up to a height of 600 mm from
the bottom of the machine.
•Machines without a drain pump rely on gravity to drain, therefore the drains must at all times be
below the bottom of the machine.
•Water hose. Connect this via a double check valve to either your water softener or your mains cold
water supply.
•Cable with 13 amp plug fitted for connection to a suitable socket
