Elgar TrueWave TW 5550 User manual

T r ueWave
AC P ow er Source
Models TW 3700 and TW 5550
Operation Manual
©2001 by Elgar Electronics Corporation
This document contains information proprietary to Elgar Electronics Corporation. The information contained herein is
not to be duplicated or transferred in any manner without prior written permission from Elgar Electronics Corporation.
September 20, 2004 Document No. M161696-01 Rev D
E L GAR ELECT RONICS CORPORATION
9250 Brown Deer Road
San Diego, CA 92121-2294
1-800-733-5427
Tel: [phone]
Fax: [phone]
Email: [e-mail]
www.elgar.com
Via Acquanera, 29 22100 Como
tel. 031.526.566 (r.a.) fax 031.507.984
[e-mail] www.calpower.it

i
E L GAR ONE YEAR WARRAN T Y
Elgar Electronics Corporation (hereinafter referred to as Elgar) warrants its products to be free from defects in
material and workmanship. This warranty is effective for one year from the date of shipment of the product to the
original purchaser. Liability of Elgar under this warranty shall exist provided that:
•the Buyer exposes the product to normal use and service and provides normal maintenance on the product;
•Elgar is promptly notified of defects by the Buyer and that notification occurs within the warranty period;
•the Buyer receives a Return Material Authorization (RMA) number from Elgar’s Repair Department prior to
the return of the product to Elgar for repair, phone 800-73-ELGAR (800-733-5427), ext. 2295;
•the Buyer returns the defective product in the original, or equivalent, shipping container;
•if, upon examination of such product by Elgar it is disclosed that, in fact, a defect in materials and/or
workmanship does exist, that the defect in the product was not caused by improper conditions, misuse,
or negligence; and,
•that Elgar QA seal and nameplates have not been altered or removed and the equipment has not been
repaired or modified by anyone other than Elgar authorized personnel.
This warranty is exclusive and in lieu of all other warranties, expressed or implied, including, but not limited to,
implied warranties of merchantability and fitness of the product to a particular purpose. Elgar, its agents, or
representatives shall in no circumstance be liable for any direct, indirect, special, penal, or consequential loss
or damage of any nature resulting from the malfunction of the product. Remedies under this warranty are
expressly limited to repair or replacement of the product.
CONDI T I ON S OF WARRANT Y
•To return a defective product, contact an Elgar representative or the Elgar factory for an RMA number.
Unauthorized returns will not be accepted and will be returned at the shipper’s expense.
•For Elgar products found to be defective within thirty days of receipt by the original purchaser, Elgar will
absorb all ground freight charges for the repair. Products found defective within the warranty period, but
beyond the initial thirty-day period, should be returned prepaid to Elgar for repair. Elgar will repair the unit
and return it by ground freight pre-paid.
•Normal warranty service is performed at Elgar during the weekday hours of 7:30 am to 4:30 pm Pacific time.
Warranty repair work requested to be accomplished outside of normal working hours will be subject to Elgar
non-warranty service rates.
•Warranty field service is available on an emergency basis. Travel expenses (travel time, per diem expense,
and related air fare) are the responsibility of the Buyer. A Buyer purchase order is required by Elgar prior to
scheduling.
•A returned product found, upon inspection by Elgar, to be in specification is subject to an inspection fee and
applicable freight charges.
•Equipment purchased in the United States carries only a United States warranty for which repair must be
accomplished at the Elgar factory.
Committed to Quality...Striving for Excellence

ii
This page intentionally left blank.

iii
S AF E T Y NOT ICE
Before applying power to the system, verify that the TW Series unit is configured properly for the user’s
particular application.
WAR NI NG!
HAZARDOUS VOLTAGES IN EXCESS OF 280 VRMS, 600V PEAK MAY BE
PRESENT WHEN COVERS ARE REMOVED. QUALIFIED PERSONNEL MUST
USE EXTREME CAUTION WHEN SERVICING THIS EQUIPMENT. CIRCUIT
BOARDS, TEST POINTS, AND OUTPUT VOLTAGES MAY BE FLOATING
ABOVE (BELOW) CHASSIS GROUND.
Installation and service must be performed by qualified personnel who are aware of dealing with attendant
hazards. This includes such simple tasks as fuse verification.
Ensure that the AC power line ground is connected properly to the TW Series unit input connector or
chassis. Similarly, other power ground lines including those to application and maintenance
equipment must be grounded properly for both personnel and equipment safety.
Always ensure that facility AC input power is de-energized prior to connecting or disconnecting the
input/output power cables.
During normal operation, the operator does not have access to hazardous voltages within the
chassis. However, depending on the user’s application configuration, HIGH VOLTAGES
HAZARDOUS TO HUMAN SAFETY may be generated normally on the output terminals. Ensure
that the output power lines are labeled properly as to the safety hazards and that any inadvertent
contact with hazardous voltages is eliminated. To guard against risk of electrical shock during
open cover checks, do not touch any portion of the electrical circuits. Even when the power is off, capacitors
can retain an electrical charge. Use safety glasses during open cover checks to avoid personal injury by any
sudden failure of a component.
Due to filtering, the unit has high leakage current to the chassis. Therefore, it is essential to operate this unit
with a safety ground.
Some circuits are live even with the front panel switch turned off. Service, fuse verification, and
connection of wiring to the chassis must be accomplished no less than five minutes after power has
been removed via external means; all circuits and/or terminals to be touched must be safety
grounded to the chassis.
After the unit has been operating for some time, the metal near the rear of the unit may be hot enough to
cause injury. Let the unit cool before handling.
Qualified service personnel need to be aware that some heat sinks are not at ground, but at high potential.
CAU T I ON !
380V 3-PHASE INPUT POWER SYSTEMS (4 WIRE) MUST HAVE A
NEUTRAL CONNECTION. (FOR UNITS BUILT BEFORE JUNE 1004: THE
NEUTRAL MUST NOT BE SWITCHED. APPLY NEUTRAL BEFORE PHASE
VOLTAGE OR SERIOUS DAMAGE TO THE EQUIPMENT MAY RESULT).

iv
For safe operation, it is required that output power neutral be connected to chassis ground. The TW system
is shipped with a ground wire between power neutral and chassis ground.
These operating instructions form an integral part of the equipment and must be available to the operating
personnel at all times. All the safety instructions and advice notes are to be observed.
Neither Elgar Electronics Corporation, San Diego, California, USA, nor any of the subsidiary sales
organizations can accept any responsibility for personnel, material or consequential injury, loss or damage
that results from improper use of the equipment and accessories.
S AF E T Y SYMBOLS
C A U T IO N
R isk of Electrical Shock
C A U T IO N
R e fe r to Accompanying Documents
Off (Supply)
S ta nd by (Supply)
On (Supply)
P ro te ctive Conductor Terminal
Fuse
D irect Current (D C)
A ltern atin g
T hree –P ha se
E arth (Ground) Terminal
C h ass is Ground
C u rrent (AC)
A ltern atin g Current

Elgar TrueWave v
CONT E NT S
Warranty ........................................................................................................................ i
Safety Notice.................................................................................................................iii
Safety Symbols .............................................................................................................iv
S E CT I ON 1 –GE NE R AL DESCRIPTION
1.1 Introduction.......................................................................................................1-1
1.2 Input Specifications ..........................................................................................1-2
1.3 Output Specifications........................................................................................1-2
1.4 Front Panel Display ..........................................................................................1-4
1.5 GPIB and RS-232 Readback............................................................................1-5
1.6 Measurements..................................................................................................1-6
1.6.1 Parameters Measured ..........................................................................1-6
1.7 Protection and Safety.......................................................................................1-6
1.8 Agency Requirements ......................................................................................1-7
1.9 Physical Specifications.....................................................................................1-7
1.10 Environmental Data..........................................................................................1-7
1.11 Other Standard Features..................................................................................1-8
1.12 Options .............................................................................................................1-9
S E CT I ON 2 –I N S T ALLATION
2.1 Introduction.......................................................................................................2-1
2.2 Unpacking.........................................................................................................2-1
2.3 Pre-Installation Inspection ................................................................................2-1
2.4 Installation ........................................................................................................2-2
2.5 Air Intake and Exhaust .....................................................................................2-2
2.6 Installation/Dimensional Drawings....................................................................2-3
2.7 Input/Output Connectors ..................................................................................2-6
2.7.1 BNC Connectors...................................................................................2-7
2.7.2 DFI (Discrete Fault Indicator)................................................................2-7
2.7.3 IEEE 488.2 ...........................................................................................2-8
2.7.4 RS-232 Connector................................................................................2-8
2.7.5 Grounding.............................................................................................2-9

Contents TW 3700 • TW 5550
Elgar TrueWave
vi
2.8 Input Power Requirements............................................................................... 2-9
2.8.1 187 to 264 VRMS 3-Phase Operation (3-Wire USA) ......................... 2-10
2.8.2 342 to 457 VRMS 3-Phase Operation (4-Wire INTL)......................... 2-10
2.8.3 Single-Phase Input Connections........................................................ 2-10
2.9 Output Connections to the Load .................................................................... 2-11
2.9.1 TW 5550 Output Connections............................................................ 2-11
2.9.2 TW 3700 Output Connections............................................................ 2-13
2.10 Wiring of Unit ................................................................................................. 2-13
2.10.1 Wire Gauge Selection ........................................................................ 2-13
S E CT I ON 3 –OP E R AT I ON
3.1 Program Parameters........................................................................................ 3-1
3.2 Menu Parameters............................................................................................. 3-1
3.3 Overview of TW Front Panel Operations ......................................................... 3-2
3.4 Displaying Readbacks...................................................................................... 3-2
3.5 Setting Programmable Parameters.................................................................. 3-3
3.6 Menu System ................................................................................................... 3-5
3.7 Menu Tree........................................................................................................ 3-6
3.8 Menu Operations.............................................................................................. 3-7
3.8.1 Menu Prompts and Key Sequences................................................. 3-12
3.9 Password Protection ...................................................................................... 3-12
3.9.1 Creating the Password..................................................................... 3-12
3.9.2 Clearing the Password ..................................................................... 3-13
3.10 Sample Menu Changes.................................................................................. 3-13
3.10.1 Change TW GPIB Address............................................................ 3-13
3.10.2 Set TW to Close Output Relay at Power Up .................................. 3-13
3.10.3 Place TW into Standby Mode After Power Up............................... 3-14
3.10.4 Place Front Panel Program Keys into Disabled Mode ................... 3-14
3.10.5 Place Front Panel Program Keys into Enabled Mode.................... 3-15
3.10.6 Place TW into DC Mode ................................................................ 3-15
3.10.7 Place TW into ACDC Mode ........................................................... 3-16
3.10.8 Place TW into AC Mode................................................................. 3-16
3.10.9 Set Current Foldback Mode ........................................................... 3-17
3.10.10 Set TW into Current Shutdown Mode ............................................ 3-17
3.10.11 Set TW Shutdown Time Value....................................................... 3-18
3.10.12 Store a Machine State ................................................................... 3-18
3.10.13 Recall a Machine State .................................................................. 3-19

TW 3700 • TW 5550 Contents
Elgar TrueWave
vii
3.10.14 Recall Factory Configuration ..........................................................3-19
3.10.15 Specify LOCAL Sense....................................................................3-20
3.10.16 Specify REMOTE Sense ................................................................3-20
3.10.17 Place TW into PLL Lock Mode.......................................................3-21
3.10.18 Program Sync Connector to Send a Pulse
at Phase A Zero Crossing ..............................................................3-21
3.10.19 Program TW Amp Gains to Respond to
Control BNC Connector..................................................................3-22
3.10.20 Specify TW Installed Amps Qty......................................................3-22
3.10.21 Place TW into Parallel Amplifiers Mode .........................................3-23
3.10.22 Set Password .................................................................................3-23
3.10.23 Clear Password ..............................................................................3-24
3.11 Master/Slave Operation..................................................................................3-25
3.11.1 Overview..........................................................................................3-25
3.11.2 Master/Slave: Step by Step Instructions..........................................3-25
3.11.3 Return to Standalone Operation......................................................3-28
S E CT I ON 4 –MAI NT E NANCE
4.1 Periodic Service................................................................................................4-1
APPENDIX A
Fault Operations.........................................................................................................A-1
L I S T OF TABLES
Table 2-1 Recommended Mounting Slide.............................................................2-2
Table 2-2 TW Input/Output Connectors................................................................2-6
Table 2-3 DFI Connector Pinout ...........................................................................2-7
Table 2-4 IEEE 488.2 Connector Pinout...............................................................2-8
Table 2-5 RS-232 Connector................................................................................2-8
Table 2-6 Input Currents for 3-Phase Input Power ...............................................2-9
Table 2-7 Single-Phase Input Configurations .....................................................2-10
Table 2-8 Recommended Wire Gauge Selection Guide.....................................2-14

Contents TW 3700 • TW 5550
Elgar TrueWave
viii
L I S T OF FIGURES
Figure 1-1 Elgar TrueWave AC Power Source...................................................... 1-1
Figure 2-1 Mounting Dimensions, Front View........................................................ 2-3
Figure 2-2 Mounting Dimensions, Top and Side View........................................... 2-4
Figure 2-3 Rear Panel ........................................................................................... 2-5
Figure 2-4 Parallel Connections .......................................................................... 2-12
Figure 2-5 Sense Lead Connections for 3-Phase Output.................................... 2-12
Figure 3-1 TW 5550 Three Phase Master/Slave Wiring...................................... 3-29
Figure 3-2 TW 5550 Single Phase Master/Slave Wiring ..................................... 3-30

Elgar TrueWave 1-1
S E CT I ON 1 GE NE R AL DESCRIPTION
1.1 I NT R ODU CT I ON
The Elgar TrueWave™Series AC power source, models TW 3700 and TW 5550 use
transformerless, direct coupled amplifiers and a DSP-based sine wave controller for
testing a variety of complex electronics.
Figure 1-1 Elgar TrueWave AC Power Source (Rack Mount Version)
Programming is accomplished at the front panel or with a personal computer (PC).
The TrueWave communicates with the PC through a GPIB or RS-232 interface.
Programming commands are defined in the TW Programming Manual, Elgar Document
No. M161469-02.
One to three phase AC sine wave or DC output is specified by pushbutton/LED menu-
based control. Incremental and absolute voltage and current setpoints are available at
the TW front panel. The TW incorporates a hierarchical menu system to set system
parameters.
The TrueWave sources are true DC as well as AC power supplies. Up to 312 VRMS
are available in AC or AC+DC modes. Multi-phase models can be switched to single or
three-phased operation via the front panel or the GPIB.
A wide frequency range of DC or 40 Hz to 500 Hz is available for a broad array of
applications. Utilizing the latest in AC switch mode technology, the TW has less than
-60 dB of noise and ripple with total harmonic distortion (THD) of <0.5%. A crest factor
of 3.25 provides high peak-to-RMS current capability. An optional input power factor
correction (PFC) of .99 is also available.

General Description TW 3700 • TW 5550
1-2 Elgar TrueWave
1.2 I NP U T SPECIFICATIONS
Voltage
187 to 264 VRMS, 3Ø L-L (3 wire), or
342 to 457 VRMS, 3Ø L-L (4 wire).
Power Factor
0.99 for PFC input configured units
0.6 for USA rectifier configured units
0.35 for International rectifier.
Efficiency
70% minimum at full load.
Ride Through
3 msec with rectifier input configuration, 10 msec with PFC
input configuration.
Frequency
47 to 63 Hz minimum (47 to 440 Hz for PFC input only)
1.3 OU T P U T SPECIFICATIONS (at 25ºC unl ess specified)
Calibration Interval
1 year.
Waveshape
DC and sine.
Dropout
Dropout of an integer number of cycles on any
combination of phases, at any phase angle, and
at any programmable frequency is possible via
GPIB command. Sub-integer number of cycles
can be achieved by varying the phase angle.
Programming is referenced to phase A and all
phase dropouts coincide. (Some variable
propagation delay will occur.)
Power, Reactive
3700 or 5550 VARMS maximum as configured.
Load Power Factor
0 lagging to 0 leading.
Voltage Programming Range
Range 1: 1 minimum to 156 VRMS maximum,
Range 2: 2 minimum to 312 VRMS maximum.
Voltage Programming Accuracy
(GPIB/Front panel) without load
0.1% maximum of full scale.
Voltage Programming Resolution
(GPIB/Front panel)
0.03% VRMS maximum (12 bits).

TW 3700 • TW 5550 General Description
Elgar TrueWave 1-3
Voltage Programming Accuracy
(Analog)
2% of full scale.
Voltage Stability, excluding
external analog control
0.1% maximum with constant line, load,
temperature
Current Programming Range
per channel
Range 1: 0 to 16.0 Amps RMS maximum,
Range 2: 0 to 8.0 Amps RMS maximum
Current Programming Accuracy
(GPIB/Front Panel)
1% of full scale + 0.5% of actual
Current Programming Resolution
(GPIB/Front panel)
0.03% maximum (12 bits)
Current Stability
(in constant current mode)
0.5% of setting after 10 minute warmup
Inductive Output Impedance
(high range)
104µh typical in low output impedance mode
Resistive Output Impedance
(high range)
0.050Ωtypical in low output impedance mode
Load Transient Recovery,
Voltage mode
0.5 msec typical to within 2% of final value
Noise
>60 dB RMS below full scale
Distortion,
Output Voltage
0.5% THD maximum
Line Voltage Regulation,
Voltage mode
0.05% maximum of full scale for ±10% line
change
Load Voltage Regulation
0.15% maximum of full scale
Lead drop
5 VRMS total (sum of both lead drops)
Current Crest Factor
3.25 minimum
Frequency Range
45 to 500 Hz minimum
Frequency Drift
100 ppm maximum of programmed value per ºC

General Description TW 3700 • TW 5550
1-4 Elgar TrueWave
Frequency Programming
Accuracy (GPIB/Front panel)
0.1% maximum of programmed value
Frequency Programming
Resolution (GPIB/Front panel)
0.1 Hz maximum
Phase Programming Accuracy
1º typical
Phase Programming Resolution
0.1º minimum
Overvoltage Protection Accuracy
1% of full scale + 1% of actual maximum peak
voltage
Overvoltage Protection Range
116% of rated output
Overvoltage Protection
Response Time
0.3 msec maximum for voltages exceeding peak
voltage
Overcurrent Protection Accuracy
1% of full scale + 1% of reading maximum
Overcurrent Protection Range
115% of rated output
Overcurrent Protection
Response Time
100 msec maximum
Overcurrent Protection Effect
Shutdown or constant current, selectable
1.4 F R ONT PANEL DISPLAY
Output Voltage Accuracy
0.3% of full scale plus 0.2% of reading maximum
Output Voltage Resolution
0.1 VRMS maximum
Output Current Accuracy
0.3% of full scale + 0.5% of reading maximum
Output Current Resolution
0.01 Amps RMS maximum
Output Power Range
0 to 1900 W per phase minimum
Output Power Accuracy
2.5% of full scale maximum
Output Power Resolution
10 W maximum
Crest Factor Accuracy
1% of full scale maximum for output > 200VA

TW 3700 • TW 5550 General Description
Elgar TrueWave 1-5
Power Factor Accuracy
4% of full scale maximum for output > 200VA
Frequency Accuracy
0.25% of reading
Output Phase Accuracy
0.5% of scale
Output Phase Resolution
0.3% of scale
1.5 GP I B AND R S -232 READB ACK
Output Voltage Accuracy
0.3% of full scale + 0.2% of reading maximum
Output Voltage Resolution
0.1 VRMS maximum
Output Current Accuracy
0.3% of full scale + 0.5% of reading maximum
Output Current Resolution
0.01 Amps RMS maximum
Output Power Range
0 to 1900 W per phase minimum
Output Power Accuracy
2.5% of full scale maximum
Output Power Resolution
10 W maximum
Crest Factor Accuracy
1% maximum for output > 200VA
Power Factor Accuracy
4% maximum for output > 200VA
Output Phase Accuracy
0.5% of scale
Output Phase Resolution
0.3% of scale

General Description TW 3700 • TW 5550
1-6 Elgar TrueWave
1.6 ME AS U R E ME NT S
1.6 .1 P ar ameter s Measured
•1- or 3-Phase to Neutral RMS Output Voltages
•1- or 3-Phase to Phase Voltages are Calculated
•1- or 3-Phase RMS Output Currents
•1- or 3-Phase Peak Current
•Output Frequency
•1- or 3-Phase Power
•1- or 3-Phase VA
•Power Factor of Load Calculated from 1 or 3 Phases
•Crest Factor of Load Calculated from 1 or 3 Phases
•Output Phase B Relative to Phase A
1.7 P R OT E CT I ON AND S AF E T Y
Overvoltage Shutdown: Programmable for 15V to 255V peak, 156V range;
30V to 510V peak, 312V range.
Undervoltage Shutdown: Automatic, not programmable.
Programmable Current Limit Shutdown: Can be set to 1% of range;
0.5A to 16.0A for 156V range, 0.5A to 8.0A for 312V range.
Programmable Current Limit with Timed Shutdown: Can be set to 1% of range;
the timeout can be set from 100 msec to 10 sec.
Overtemperature Shutdown: Automatic, not programmable.

TW 3700 • TW 5550 General Description
Elgar TrueWave 1-7
1.8 AGE NCY REQUIREMENT S
The TrueWave conforms to the following agency requirements:
•European Community CE, including:
EN61010-1 1993, Installation Category III
EN55011 Group 1, Class A
EN50082-1 1992
•FCC Part 15, Class A
1.9 P H Y S I CAL SPECIFICATIONS
Height: 8.75" (222 mm)
Width: 19" (483 mm)
Depth: 23.5" (597 mm)
Weight:TW 3700 89 lbs. (40 kg),
TW 5550 115 lbs. (52 kg)
Cooling: Air is drawn in from the front, top, and sides and exhausted through the rear
of the chassis.
1.10 E NVI R ONME NT AL DATA
Operating Temperature: 0°C to 45°C (32°F to 113°F).
Note temperature measured at air inlet of TW. If cabinet mounted, cabinet inlet air may
be rated at lower maximum temperature due to warming of inlet air.
Storage Temperature: -40°C to 70°C (-40°F to 158°F).
Humidity (Non-condensing): 0 to 85% at 31°C (88°F);
derate to 50% at 40°C (104°F).
Operating Shock: 10g for 11 ms.
Operating Vibration: 1g, 5 to 55 Hz dwell on resonances for 2 minutes maximum.
Altitude: Operating 6,560 ft., Non-operating 40,000 ft.
For Indoor Use Only

General Description TW 3700 • TW 5550
1-8 Elgar TrueWave
1.11 OT H E R STANDARD F E AT U R E S
•1- to 3-Phase Programmable
•IEEE 488.2 Interface
•SCPI Protocol
•Waveform Trigger Output
(1 MegΩLoad Drive; positive edge is at 0° ±30
µs, 0 to 5V logic)
•SYNC OUT. User programmed for:
Cycle Start, all cycles
For loads ≥2 kΩ: Vout ≤1V Low State; Vout ≥2.4V High State;
Negative edge is at 0° ±30
µs.
•CLOCK/LOCK
CLOCK pulses at programmed frequency for loads ≥2 kΩVout ≤1V Low State;
Vout ≥2.4V High State. Negative edge is at 0° ±30
µs.
LOCK locks output to input 'TTL' frequency; signal needs to supply
pull down current of 15 mA with voltage drop of ≤0.6V; no pull up needed.
Negative edge is at 0° ±30
µs.
•LOCK Specifications
Frequency range is 40.00 Hz to 500.00 Hz.
Tracking range is ±10% of programmed center frequency.
Duty cycle is 50% ±10%.
Slew rate is .02% of input frequency/second, maximum, which produces a maximum
phase shift of 5° from the lock input falling edge to the output rising edge.
The rising edge of the output will be locked to the falling edge of the lock input and
will have less than a 30 µsec propagation delay.
Maximum output jitter when locked is <1% of lock input period.
PLL lock is achieved in <5 seconds.
•External Amplitude Modulation
0 to 5 VRMS provides 0 to ≥20% output amplitude modulation
(±2% of full scale output).

TW 3700 • TW 5550 General Description
Elgar TrueWave 1-9
•External Direct Input
Normal Amplifier, 0 to 5 VRMS (DC to 500 Hz) or ±5 VDC input for zero to full scale
programmed voltage output (±2% of full scale output).
•External Gain Control
0 to ±7.07 VDC provides zero to full scale programmed voltage output
(±2% of full scale output).
•External Input Impedance
≥10 kΩ.
•System Firmware
System firmware is stored in flash memory. This makes it possible to upgrade the
firmware without disassembling or returning the unit.
1.12 OP T I ONS
•Parallelable for additional power above 5550 VA requires accessory attachment
cable.
•Input Power Factor Correction to 0.99
S P E CI F I CAT I ONS ARE SUBJECT TO CH AN GE WIT HOUT NOTICE.

General Description TW 3700 • TW 5550
1-10 Elgar TrueWave
This page intentionally left blank.

Elgar TrueWave 2-1
S E CT I ON 2 I NS T ALLATI ON
2.1 I NT R ODU CT I ON
The Elgar TW 3700 or TW 5550 has been fully calibrated and tested prior to shipment.
The instrument is ready for immediate use upon receipt.
WAR NI NG! The TrueWave unit weighs 89–115 lbs. (40–52 kg),
depending on the model. A minimum two–person lift is required!
WAR NI NG! Hazardous voltages are present when operating this
equipment. Please read the Safety Notice at the beginning of this
manual prior to installation, operation, or maintenance.
2.2 U NPACK I NG
Perform a visual inspection of the shipping container prior to accepting the package
from the carrier. If extensive damage to the shipping container is evident, a description
of the damage should be noted on the carrier's receipt and signed by the driver of the
carrier agent.
If damage is not apparent until the instrument is unpacked, a claim for concealed
damage should be placed with the carrier. In addition, the shipping container(s) and
filler material should be saved for inspection. Forward a report of damage to the Elgar
Service Department. Elgar will provide instructions for repair or replacement of the
instrument.
If the instrument needs to be returned to Elgar, suitable shipping containers and
packing materials must be used. If proper packing material is not available, contact
Elgar to provide containers and shipping instructions.
2.3 P R E -I NS T ALLATION INS P E CT I ON
Perform a visual inspection of the instrument when it is removed from the shipping
container. Check for shipping damage such as dents, scratches, distortion, and
damaged connectors.
