Elgento E14020 User manual

www.elgento.co
12 LITRE
HALOGEN
OVEN
MODEL E14020
YOUR SAFETY &
INSTRUCTION MANUAL
PLEASE READ CAREFULLY

2
CUSTOMER SUPPORT TEAM: [phone]
TECHNICAL DATA
Description: 12 Litre Halogen Oven
Model: E14020
Rated Voltage: 220 - 240V
Frequency: ~ 50Hz / 60Hz
Power consumption: 1300W
DOCUMENTATION
We declare that this product conforms to the following product legislation in accordance with the
following directive(s):
2014/30/EU Electromagnetic Compatibility Directive.
2014/35/EU Low Voltage Directive.
2011/65/EU Restriction of Hazardous Substances Directive.
1935/2004/EC Materials & Articles in Contact With Food (LFGB section 30 & 31).
RK Wholesale LTD Quality Assurance, United Kingdom
WARRANTY
This product is guaranteed for 12 months from the date of original purchase. If any defect arises due
to faulty materials of workmanship, the faulty products must be returned to the place of purchase.
Refund or replacement is at the discretion of the retailer.
The following conditions apply:
• The product must be returned to the retailer with proof of purchase.
• The product must be installed and used in accordance with the instructions contained in this
instruction guide.
• It must be used only for domestic purposes.
• It does not cover wear and tear, damage, misuse or consumable parts.
• RK Wholesale LTD has limited liability for incidental or consequential loss or damage.
• This guarantee is only Valid in the UK and Eire Only.
An extended warranty is available for this appliance.
See back page for details.

3
www.elgento.co
WIRING SAFETY FOR UK USE ONLY
IMPORTANT
As the colours in the
mains lead of this
appliance may not
correspond with the
coloured markings
identifying the terminals
in your plug, please
proceed as follows:
The wires in the mains lead are coloured in
accordance with the following code:
Blue neutral [N] Brown live [L]
Green/Yellow [EARTH]
Plug Fitting Details (Where Applicable).
The wire coloured blue is the neutral and must
be connected to the terminal marked [N] or
coloured black.
The wire coloured brown is the live wire and
must be connected to the terminal marked [L] or
coloured red.
The wire coloured green/yellow must be
connected to the terminal marked with the letter
[E] or marked .
On no account must either the brown or the blue
wire be connected to the [EARTH] terminal .
Always ensure that the cord grip is fastened
correctly.
The plug must be tted with a fuse of the same
rating already tted and conforming to BS 1362
and be ASTA approved.
If in doubt consult a qualied electrician who will
be pleased to do this for you.
Non-Rewireable Mains Plug
If your appliance is supplied with a non-
rewireable plug tted to the mains lead and
should the fuse need replacing, you must use an
ASTA approved one (conforming to BS 1362 of
the same rating).
If in doubt, consult a qualied electrician who will
be pleased to do this for you.
If you need to remove the plug – disconnect
it from the mains – and then cut it o of the
mains lead and immediately dispose of it in a
safe manner. Never attempt to reuse the plug or
insert it into a socket outlet as there is a danger
of an electric shock.
WARNING:
This Appliance MUST be Earthed
FUSE

4
CUSTOMER SUPPORT TEAM: [phone]
PRODUCT SAFETY
When using any electrical appliance, basic safety precautions should
always be followed including the following:
• Check that the voltage of the
main circuit corresponds with
the rating of the appliance
before operating.
• Please ensure that the
appliance is used on a
stable, level, and heat
resistant surface.
• DO NOT immerse cords,
plugs or any part of the
appliance in water or any
other liquid.
• DO NOT leave the appliance
unattended while it is
operating.
• Close supervision is
necessary when any
appliance is used by or near
children.
• Take care when any
appliance is used near pets.
• This appliance can be
used by children aged
from 8 years and above
and persons with reduced
physical, sensory or mental
capabilities or lack of
experience and knowledge
if they have been given
supervision or instruction
concerning use of the
appliance in a safe way and
understand the hazards
involved.
• Children should not play with
the appliance.
• Cleaning and user
maintenance should not
be undertaken by children
without supervision.
• Switch o at the wall socket
then remove the plug from
the socket when not in use
or before cleaning.
• If the supply cord or
appliance is damaged,
stop using the appliance
immediately and seek advice
from the manufacturer, its
service agent or a similarly
qualied person.
• DO NOT let the cord hang
over the edge of a table
or counter or let it come
into contact with any hot
surfaces.
• The use of accessory
attachments other than
those supplied is not
recommended.
• DO NOT pull the plug out by
the cord as this may damage
the plug and/or the cable.
• DO NOT use this product
for anything other than its
intended use.

5
www.elgento.co
• This appliance is for
household use only.
• DO NOT carry the appliance
by the power cord.
• DO NOT use the appliance
outdoors.
• Extreme caution must be
used when moving the oven
when it contains hot food,
water, or other hot liquids.
• DO NOT switch on the oven
if the bowl is empty.
• Allow lid and bowl to cool
down rst before cleaning
with water.
• Never touch the outer
surface of the oven during its
operation or before it cools.
Use the handles or knobs.
• The use of oven gloves or a
cloth is recommended when
removing lid or handling
contents.
• DO NOT use the appliance
if the glass lid or bowl is
cracked or chipped.
• DO NOT switch on the oven
when it is upside down or
laid on its side.
• Use of an extension cord
with this appliance is not
recommended. However,
if it is necessary to use
an extension lead, ensure
that the lead is suited to
the power consumption
of the appliance to avoid
overheating of extension
cord, appliance or plug point.
DO NOT place the extension
cord in a position where it
can be pulled on by children
or animals or tripped over.
• In the unlikely event the
appliance develops a fault,
stop using it immediately
and seek advice from the
Customer Support Team.
HIGH VOLTAGE HOT SURFACE

6
CUSTOMER SUPPORT TEAM: [phone]
WHAT’S IN THE BOX
Instruction manual
Halogen oven
Low rack
High rack
Tongs
1. Bowl
2. Lid motor block
3. Timer (60 mins)
4. Safety handle
5. Thermostat (125-250oC)
6. Indicator lights
7. Stand / handles
4
5
6
7
1
2
3
BEFORE YOUR FIRST USE:
1. Remove your appliance from the packaging.
2. Before using the appliance for the rst time, carefully clean the bowl and lid.
3. Do not immerse the lid in any liquid
4. Your appliance is now ready for normal use.
5. Dispose of the packaging in a responsible manner.
Dispose of the packaging in a responsible manner.

7
www.elgento.co
USING YOUR APPLIANCE
Thermostat:
Sets the cooking temperature from 125°C to
250°C.
Timer:
The timer dial is marked in minutes and has a
reminder bell, which sounds when the cooking
time is completed.
When setting the manual timer, always turn
the timer past the time you wish to set, before
turning the timer back to the correct time.
Operating your appliance for the rst time:
When you are ready to use the appliance,
be sure that the timer controls are in the “o”
position and unplugged. We recommend a trial
run to familiarise yourself with your appliance
and to eliminate any problem substances or oil
that may have been used for packaging and
shipping.
1. Plug the cord into a 220-240 volt AC
outlet.
2. Set the timer control to 10 minutes and
set the temperature control to Thaw/
Wash.
3. A small amount of smoke and odour may
be detected. This is normal.
4. To avoid scratching, marring,
discolouration or re hazard, do not store
anything on top of the oven, especially
during operation.
TIP: You can line the bottom of the bowl with
aluminium foil to catch any fat. This will make
clean-up easier.
Thawing Food:
The thaw/wash setting allows you to thaw out
most foods. The ‘wash’ reminds you to clean
any liquids from the bowl after thawing before
cooking.
The convection oven will thaw most foods.
Simply place onto one of the wire racks, set the
thermostat to thaw and allow approximately 40
minutes per kg.
Large items like meat joints should be turned at
least once during the thawing process.
Note: Any liquids or juices from thawed food
should be thoroughly cleaned from the bowl
before cooking.
Operating your appliance:
1. Prepare the bowl. While cooking the
surface of the bowl will be considerably
hot, be sure to place the appliance on a
heatproof surface.
2. Place the rack in the bowl and place food
in the centre of the rack to receive best air
circulation. Allow 1cm space between the
food and bowl.
3. Cover the bowl with the lid. Ensure it is
sealed correctly.
4. Plug the cord into wall outlet.
5. Turn the thermostat to the desired
temperature.
6. Set the timer using the reference table as
a guide. Push handle back to start. The
red and green indicator lights will go on to
indicate that cooking has started.
7. The halogen oven will automatically shut
o when cooking time has been reached.
Note: When using the timer may continue to
tick after the Halogen Oven has shut o and
nished cooking.
8. When roasting, line the bottom of the bowl
with foil to catch any drippings.

8
CUSTOMER SUPPORT TEAM: [phone]
Application examples
Reference table of time and temperature for
cooking various foods
Temperature
(oC)
Cooking Class Quantity Minutes
200 Whole Chicken 21/4kg 70-75
200 Sliced Pork 500g 7-8
200 Drumsticks 8 Pieces 15
250 Fish 10 Pieces 7-8
200 Clam 500g 5-7
250 Shrimps 500g 5
250 Corn 4 Pieces 10
150 Cake 1 Case 20
250 Potato 500g 25
250 Red Prawn 4 Pieces 15
250 Crab Meat 500g 10
For meats weighing from 1-1.5 Kg, set
temperature at 200oC
Cook for the following (approximate) times
Type of meat Minutes
Beef,
boneless,
whole roast
rare: 15-20
medium: 20-25
well done: 25-30
Beef, rib
roast, rump or
chuck
rare: 15-20
medium: 20-25
well done: 25-30
Ham with
bone & fully
cooked
medium: 12-15
Pork loin
(boneless) well done: 20-25
Loin with
bone well done: 25-30
Pork ribs well done: 25-30
Roasting:
• Lining the bottom of the bowl with foil will
help to catch any drippings from the roast.
• Use a low rack to let hot air circulate freely.
• The propelled hot air of the halogen oven
cooks meat evenly and seals in any juices.
A meat thermometer is recommended.
• Without a meat thermometer, follow the
time temperature table included in the
booklet, or follow a chart given for a regular
oven and simply subtract 25°C.
Roast whole chicken:
• Rinse chicken thoroughly and add desired
seasoning.
• Spices such as garlic, black pepper and
salt are recommended.
• Before roasting, allow seasoning to
penetrate for a few hours.
• The base of the bowl can be lined with
aluminium foil to catch drippings.
• Roast for approximately 30 minutes per
1kg at 200°C.
Whole roasts:
• With the fatty portion facing upward put
meat directly on low rack.
• Season to your taste. Insert meat
thermometer.
• Temperature for roasting is usually 25°C
less than for regular or conventional
roasting.
• Cooking time depends on type and size of
roast.
Note: the process of cooking and cooking
time may vary, depending on depth and size of
mixture or preparing dish.

9
www.elgento.co
Grilling and broiling:
• For broiling or grilling with a halogen oven,
the temperature should be set between
220-250°C.
• To bring the food closer to source of the
heating air, the high rack should be used.
• Add hickory liquid smoke or mesquite to
get a smoky avour.
• Any seasoning should be applied to the
surface of the meat.
• If the sh or meat is lean, spray the rack or
grill with non-stick vegetable oil, or brush
with cooking oil prior to arranging the sh/
meat on the grill.
• This will minimise food sticking to the grill.
• For browner or more seared surfaces,
broil on both sides as with thick stocks or
steaks.
• For thinner pieces, no turning is necessary.
• As with toasting, items to be grilled should
be placed on the high rack and should be
between 220-240°C. When deciding the
best temperature setting to use, consider
the thickness of the food.
• A 3cm thick steak would require a lower
temperature and longer cooking time than
a 1cm thick steak. Also remember that
frozen food like burgers need a longer
cooking time.
• You may wish to turn the food halfway
through the grilling process to ensure even
colouring.
Pies:
• For pre-cooked chilled pies, simple place
on a high rack for 8 - 12 minutes at 220°C.
• For frozen/uncooked pies, use the same
position and temperature and increase the
temperature, depending on the size and
content of the pie.
Bread rolls:
• To reheat fresh bread rolls, wrap each roll
with foil, place on the low rack and heat at
200°C for 5-7 minutes.
• If the rolls are a few days old they can be
brushed with a little milk, placing them on
the high rack and heating for 6-9 minutes
at 180°C.
Frozen food:
• Large items like meat joints or poultry
cannot be cooked from frozen and must
be thawed thoroughly rst, however, some
foods cook best from frozen.
• Simply follow the cooking instructions on
the packaging as a guideline.
• Due to the ecient nature of the halogen
oven, the cooking time for frozen products
is often shorter than that of a conventional
oven.
Baking:
• The temperature for the cooking of
uncovered dishes is usually 20 to 40°C
lower than in the traditional oven.
• No pre-heating is necessary in the halogen
oven when baking. Often, the centre of the
cake batter will take longer to cook than
the section closest to the rim.
• A bunt cake pan or tube pan is
recommended for use, rather than a larger
layered cake pan.

10
CUSTOMER SUPPORT TEAM: [phone]
Cakes:
• Pre-heat the oven to 220-230°C for 3
minutes.
• When selecting an appropriate cake tin to
use, be sure that it will t comfortably in the
bowl. Always place the cake tin on the low
rack-never directly onto the bottom of the
bowl.
• When using the recipes from elsewhere,
deduct 10°C from the recommended
cooking temperature.
• Cooking time depends entirely upon the
size of cake you are making but it is easy to
monitor its progress with the see-through
glass bowl.
Biscuits and pastries:
• Take a suitable pan and lightly grease it.
• Place it on the low rack.
• The best temperature for biscuits and
pastries is 220 - 230°C.
• Cooking times will vary depending on the
chosen recipe; the approx. time is generally
12 -15 minutes.
Suggested baking times and temperatures
Food Temperature
(oC)
minutes
Brownies 150 18-20
Buns 200 10-12
Cakes, layer 150 18-20
Cakes, loaf 150 30-35
Cornbread 180 18-20
Cookies: drop 160 8-10
Cookies: rolled 160 10-12
Muns 180 12-15
Pies/pastries/pie
crust
200 8-10
With lling (no top
crust)
160 25-30
With lling (two
crusts)
180 35-40
Breads, rolls 180 12-15
Loaf 160 25-30

11
www.elgento.co
CLEANING & CARE
Remove plug from the mains socket, and allow
the appliance to cool down before cleaning.
Do not immerse the lid unit of the appliance
in water and make sure no water enters the
appliance.
Clean the base unit by wiping it with a damp
cloth. A little detergent can be added if the
appliance is heavily soiled.
Do not use scouring pads, steel wool or any
form of strong solvents or abrasive cleaning
agents to clean the appliance, as they may
damage the outside surfaces of the appliance.
Clean all accessories in warm soapy water, do
not use any scouring pads, steel wool or any
strong solvents or abrasive cleaning agents
when cleaning accessories.
Make sure that the appliance is cleaned after
every use.
IMPORTANT!
Allow to dry fully after cleaning before using
again.
Do not use the appliance if damp. Ensure the
appliance is completely clean and dry before
storing.
STORAGE:
To store your appliance:
Unplug power cord from the power outlet and
clean as instructed.
Allow the appliance to dry fully.
Store on a at, dry level surface out of reach of
children.
WARNING:
DO NOT IMMERSE ANY ELECTRICAL PART
OF THE APPLIANCE IN WATER SUCH AS
MOTOR UNITS OR PLUGS.
PLEASE SEE CLEANING SECTION FOR
FURTHER INSTRUCTIONS.
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here
may not be disposed of in domestic rubbish.
You are required to dispose of old electrical
and electronic appliances like this separately.
Please visit www.recycle-more.co.uk or
www.recyclenow.co.uk
for access to information about the recycling
of electrical items.
Please visit www.weeeireland.ie for access to
information about the recycling of electrical
items purchased in Ireland.
The WEEE directive, introduced in August
2006, states that all electrical items must be
recycled, rather than taken to landll.
Please arrange to take this appliance to your
local Civic Amenity site for recycling, once it
has reached the end of its life.

We hope you enjoy your appliance for many years.
As a thank you for purchasing one of our fantastic products,
we are oering you an extra 1 year peace of mind.
*To receive your extra guarantee period, register your appliance online
within 28 days of purchase by visiting:
www.elgento.co
Make sure to retain your original receipt.
Should you have a problem
with your appliance or need any spare parts please call our
Customer Support Team on:
[phone]
Distributed throughout the UK by RK Wholesale LTD
1118.V7
