ELGO Electric AZ16I series User manual

I series
Installation manual
AZ16I-000-E_10-06.doc Doku Art. Nr. 799000023
Battery operated
ABSOLUTE - Linear encoder and indicator System
with integrated sensor and magnetic tape guidance
Features
• Measuring distances up to 8 meters possible
• Unique definition of the zero point
(no further referencing necessary)
• Permanent retention of all data and settings
• Reserve energy up to 4 years
• AUTO-POWER-OFF function with adjustable „switch on“ time
• Switch over for absolute / incremental mode
• Millimeters or Inches operation
• Fraction views in the Inch mode possible
• User friendly menu levels
• Completely guided by magnetic tape guidance rail
• Key can be enabled or disabled individually
• Adjustable reference value and 3 tool offsets
• Symbols individually selectable (mm/inches/arrows etc.)
• Costumer specified housing and guidance possible

2
1. INTRODUCTION 3
2. SAFETY 3
3. DETERMINATION OF THE RAIL AND TAPE LENGTH 4
3.1 Complete assembled guide rail 4
3.2 Guide rail and Magnetic tape - Self assembling 4
5. THE AZ16I IN OPERATION 5
5.1 Initial operation 5
5.1.1 Detection of measuring direction 5
5.1.2 Referencing 5
5.3 Parameter settings 7
6. BATTERY CHANGE 9
7. MAGNETIC TAPE 10
Handling 10
Processing note for sticking 11
Resistance to chemicals of the magnetic tape 11
Sticking and cutting 11
7. TECHNICAL SPECIFICATIONS (PRELIMINARY) 12
9. TYPE DESIGNATION 13
10. LIABILITY EXCLUSION / GUARANTEE 14

3
1. Introduction
The new linear „Absolute“ encoder and indicator unit AZ16 is based on the proven magnetic
measuring principle. According to its battery supply, no wirings are necessary and the systems
is able to operate as a complete stand alone unit. The max. possible measuring distance
amounts to 8 meters. By using the AUTO-POWER-OFF mode the max. service life span of the
battery amounts up to 4 years.
The magnetic sensor is integrated in the indicator housing. Further a version with an external
sensor is available (AZ16E).
Characteristics of the AZ16I variant (integrated sensor):
For recording of measurement a guide rail in suitable length is provided (please indicate when
order). The maximum length of a guide rail amounts to 2 m. It is possible to reach the max.
measuring distance of 8 m by arranging 4 single 2 m rails in one line.
Guide rails up to 2 meters are already assembled with the necessary magnetic tape. In case of
longer measuring lengths, the tape is delivered separately an must fitted by the costumer him-
self.
The guideway for the rail is located on the rear of the indicator unit.
On request the system can be supplied also without guidance and guide rail, then the user
must provide and guarantee for a suitable mechanical guiding system. It must be ensured, that
the sensor (integrated in the indicator) keeps the correct distance (0... 1.5 mm) along the
whole measuring distance coplanar to the magnetic tape.
2. Safety
Please note: Before first commissioning read this installation manual carefully and
observe absolutely the installation instructions. The measuring system is only dedi-
cated for recording lengths. The type label is intended for exact identification of the
measuring system. The label is situated on the indicator housing. It informs about
the exact type designation (see chapter 9), the delivery date and the production
number. When contacting the company ELGO Electric GmbH please use these
terms.
Attention!
The company ELGO Electric GmbH is not liable for possible damages to machines
and or to persons, which can result from defective material at the measuring sys-
tem and the following circuit. The machine manufacturer is responsible for taking
and realizing the necessary safety precautions.

4
3. Determination of the rail and tape length
Basically the following applies with an order of magnetic tape:
Ordered length of tape = effective measuring distance + 100 mm
For further details see the „Type designation“ at the end of the manual.
3.1 Complete assembled guide rail
(for effective measuring distances up to 1.885 m)
With measuring distances < 2 m (effective 1.885 m), the guide rail is already factory-assembled
with the magnetic tape. The side of the zero point is provided with a 4.2 mm mounting hole. For
this further 15 mm must be added.
The total length of the rail is calculated as follows:
Rail length = Ordering length of magnetic tape + 15 mm
3.2 Guide rail and Magnetic tape - Self assembling
(for effective measuring distances > 1.885 m)
If distances > 1,885 meters must be measured, the guide rail is multipart supplied, since for
transport-technical reasons only a maximum length of 2 m are possible. The single rail parts still
have no mounting holes. These must done by the user and also be fastened align at a suitable
place then.
The magnetic tape must be inserted after arraying the rail parts into the slot of the rails and stuck
together with the special sticky tape, attached at the magnetic tape. Subsequently for protection,
a cover band must be stuck together with the magnetic tape.
Included in delivery:
• Magnetic tape, sticky tape and cover band (order-related length)
• Aluminium profile rail parts (total length = ordered tape length + 15 mm)
Mounting:
1. Align and fasten the rail parts at the measuring place
2. Insert the magnetic tape into the rail slots
3. Detect the measuring direction (see chapter 5.1.1)
4. Stick the tape into the guide rail slot
5. Stick the cover band for protection
15 mm Magnetic tape length = effective measuring length + 100 mm
Aluminium guide rail
Magnetic tape

5
4. Display assignment
5. The AZ16I in operation
5.1 Initial operation
5.1.1 Detection of measuring direction
On the magnetic tape is an arrow marker, which indicates the positive direction.
According to the following image, the arrow of the tape must show to the right.
The counting direction (+/-) can be changed by the register P01 (see chapter 5.4).
Front view
5.1.2 Referencing
Setting the zero-point: A new AZ16I unit shows always the absolute value of the magnetic tape
and should be calibrated to the zero point at one time. The reference value default setting in reg-
ister P09 is 0. To assign a zero point to an arbitrary position, move to the desired
zero-point and press the buttons F + Set together.
Reference value: Alternatively an arbitrary value can be entered in P09, to set a demanded ref-
erence measurement by pressing F + Set together.
5156,9
Marker
Positive direction
(
when P
0
1 =
d
ef
au
lt settin
g)
Magnetic Tape
battery condition direction arrow tool offset 3 (1, 2 or 3 possible)
absolute mode
sign measurement unit

6
5.2 Basic functions (overview)
Fraction views in Inch- Mode
SET
In the inch mode four different
fraction views can be selected:
Press SET for one time: LSB = 1/64 Inch
Press SET for two times: LSB = 1/32 Inch
Press SET for three times: LSB = 1/16 Inch
Press SET for four times: LSB = 0.001 Inch
Absolute-/ relative measurement
Press Incr/Abs to switch over from „absolute“ to „relative“ measurement:
The actual value shows „0“ and also "INC" appears in the display.
With a renewed pressing of Incr/Abs the display switches back to
„absolute“ measurement and the display shows the real absolute value
again and „ABS“ also.
Incr/
Abs
Reference value
FSet
By pressing F + Set together, the display sets
to the reference value, deposited in register P09.
Switch back from the sleep mode
F
The unit switches into the sleep mode after completion of the adjustable
time in register P04, if there are no changes in the display value and no
key is pressed.
To switch back from the sleep mode, the button Fmust be pressed.
*
Tool offset
Switches over betwee three adjustable Tool Offsets. These can be
depostided in the registers P10/11/12.
The display appears (right above):
, or .
The selectet tool offset will be added to the actual value.
21 3

7
5.3 Parameter settings
F
1) Press button F for 3 seconds.
"P01" (Parameter 01) appears in the display window.
Set
3) Select the desired decade by pressing Set
Incr/
Abs
4) Adjust the desired value by using the Incr/Abs button
F
5) Press F to select the next parameter
Repeat No. 2)... 4) for the next parameter
F
6) Press F for 3 seconds
The display shows the actual value again
F
2) Press button F
The appropriate parameter value appears in the display
3 sec.
3 sec.
Default settings
If during battery insertion the button Incr/Abs
is pressed, the unit sets all registers to the default settings.
Incr/
Abs

8
5.4 Parameter list
P 01 / Configuration of system:
0 =
XXXXX
1 =
Positive counting direction
Negative counting direction
0 =
1 =
mm operation (0.1 mm resolution)
Inch operation (0.1 inches resolution)
0 =
1 =
mm/Inch symbol disabled
mm/Inch symbol enabled
( default setting = 11100 )
0 =
1 =
Arrow symbol for „positive direction“ disabled
Arrow symbol for „positive direction“ enabled
0 =
1 =
LCD in standby mode disabled
LCD in standby mode enabled
(Display "OFF" and battery condition)
P 03 / Decimal place: ( default setting = 1 )
X= 0...3 (for mm operation only)
P 05 / keyboard interlock: ( default setting = 111 )
XXX
0 =
1 =
button Set disabled
button Set enabled
0 =
1 =
button Incr/Abs disabled
button Incr/Abs enabled
0 =
1 =
button *disabled
button *enabled
P 04 / Auto power off time: ( default setting = 10 s )
X= 0...99 seconds ( 0 = standby mode disabled) X

9
Parameter list (continuation)
P 09 / Reference value: ( default setting = 0.0 mm / 0.000 Inch )
- 999999.9 mm ... + 999999.9 mm ( - 9999.999 Inch ... + 9999.999 Inch )
P 10 / tool offset 1: ( default setting = 10.0 mm / 0.100 Inch )
- 999999.9 mm ... + 999999.9 mm ( - 9999.999 Inch ... + 9999.999 Inch )
P 11 / tool offset 2: ( default setting = 20.0 mm / 0.200 Inch )
- 999999.9 mm ... + 999999.9 mm ( - 9999.999 Inch ... + 9999.999 Inch )
P 12 / tool offset 3: ( default setting = 30.0 mm / 0.300 Inch )
- 999999.9 mm ... + 999999.9 mm ( - 9999.999 Inch ... + 9999.999 Inch )
P 99 / Software version:
Indicates the software version of the unit
6. Battery change
Remove the back wall of the display unit to change the batteries (commercial battery type,
size AA, 1.5 V) with a standard unit (internal battery case). All values and settings remains in
case of changing the batteries.
Please pay attention to the correct polarity!
The polarity is marked by a label inside the housing.

10
7. Magnetic Tape
The magnetic tape consists of 3 components (see picture 1)
• a magnetized flexible rubber tape (Pos. 3), which is connected factory made with a
• steel band (Pos. 5) and a
• covering band (Pos. 1) , which is intended for the protection of the rubber tape.
• For mechanical protection of the magnetic tape the covering band must be stuck on. Addi-
tionally it protects the magnetic tape from extreme external magnetic influences.
To reach a complete adhesion between the several materials a special sticky tape is used
(Pos. 2, Pos. 4, Pos. 6).
Pos. 1
–
Coverin
g
band
Pos. 2
–
Sticky tape
Pos. 3
–
Ma
g
netic rubber tape
Pos. 4 - Sticky tape
Pos. 5
–
Steel band
Pos. 6 - Sticky tape
Factory
bonded
Picture 1: Components of the magnetic tape
Handling
To avoid tension in the magnetic tape, don’t tuck or twist it. Avoid also to store or to handle it
with the magnetic rubber tape to the inside (min. bend radius 150 mm).
Magnetized
synthetic tape
Steel band
Picture 2: Storage and transport

11
Processing note for sticking
The provided sticky tapes stick well on clean, dry and plain surfaces. The more pollution exists
the more proper the surface has to be. A surface roughness of Ra<= 3,2 (Rz<= 25 / N8) is rec-
ommendable. Typical solvent for cleaning surfaces are a 50/50 - isopropyl-alcohol / water mix-
ture or heptane. The surfaces of materials as copper, brass etc. should be sealed to avoid an
oxidation. The stability of the adhesion is directly depending on the contact, which the adhesive
develops to the stuck surfaces. A high pressure results in a good surface contact.
The optimal sticking temperature is between + 21°C and 38°C.
Avoid colder sticking surfaces than + 10 °C, because in this case the adhesive becomes to hard
and perhaps a sufficient immediate adhesion is hardly to achieve. After proper sticking the sta-
bility of the connection is ensured also when the temperature is below zero. The final tackiness
of a sticking is from experience reached after approximately 72 hours (at + 21 °C). For sticking
use only the provided sticky tape.
Resistance to chemicals of the magnetic tape
The magnetic tape shows no or only small effects when contacting permanently the following
materials after 2 to 5 years: Formic acid, Glycerol 93°C, Linseed oil, Soy beans oil, Cotton seed
oil, N-hexane, Lactic acid, Formaldehyde 40%, Isooctane, Petroleum.
Poor to medium effects result when contacting permanently the following materials after ap-
proximately 1 year: Acetone, Gasoline, Acetic acid 30%, Olein acid, Acetylene, Steam, Acetic
acid, pure Acetic acid, Sea water, Ammonia, Acetic acid 20%, Isopropyl ether, Stearic acid 70°C
anhydrous, Kerosene.
Strong effects result when contacting permanently the following materials after 1 to 5
months: Benzene, Nitric acid 70%, Turpentine, Toluene, Lacquer solvent, Nitric acid red and
Vitriolic, Carbon Tetrachloride, Trichloroethane, Nitrobenzene, Hydrochloric acid 37% and 93°C,
Tetrahydrofuran, Xylene.
Sticking and cutting
Attention! When sticking the magnetic tape pay attention to the marks on the mag-
netic tape. A faulty installation delivers incorrect values. An already stuck magnetic
tape is ruined after removing and can't be used again. Observe also the counting
direction of the measuring system.
The magnetic tape and the covering band must be cut to the exact length before sticking:
Magnetic tape length = measuring length + 0.1 m
Preferably the magnetic tape should be stuck into a nut or aligned to an edge.
Procedure for sticking:
1. The magnetic tape is already factory bonded with the steel band, in between is a double sided
sticky tape. Stick the provided sticky tape onto the carrier side (= steel band).
2. Now adjust the magnetic tape and stick it onto the surface. The best way to stick the mag-
netic tape is to do it in two steps. Remove the first half of the adhesive film from the sticky tape
and stick it, then do the rest length.
3. Then stick the sticky tape onto the covering band. It is not important on which side of the
covering band the sticky tape is stuck on.
4. Stick the covering band onto the visible brown magnetic rubber tape

12
7. Technical specifications (preliminary)
AZ16I (battery powered absolute encoder and indicator system with an integrated sensor)
POWER SUPPLY 2 internal AA sized batteries (1,.5 V)
or an external battery box with arbitrary 1.5 V batteries sizes
Battery service life 1... 4 years (depends on adjusted switch-on time)
Distance Sensor - Tape max. 1.5 mm
Resolution of encoder 0.1 mm
Measuring units mm’s or INCHES
Measuring length max. 8 m
Principle of Measurement Magnetic, absolute
Character of Measurement Linear, no rotative movements possible
LCD-Display 6 Decades, height = 8 mm, with battery condition, signs and symbols
Keypad Membrane keypad
Operating temperature + 5... + 50° C
Stock temperature 0... 70° C
Humidity Not condensing, max. 80 %
Altitude max. 2000 m above sea level
Protection class IP 43
Outer dimensions W x H = 96 x 72 mm
Cut out W x H = 93 x 67 mm
Depth (install depth) 32.0 mm
(total depth) 37.5 mm
Magnetic tape for AZ16
Code Absolute, single track system
Extension coefficient a = 16 x 10-6 K-1
Linear extension ∆L = L x αx∆ϑ (L= measuring length in meters)
Dimensions (W x H) 10 mm x ca. 1.8 mm
min. bend radius 150 mm
Operating temperature 0... + 50° C
Protection class IP 67

13
9. Type designation
AZ16I- 000- 2- X
Type
SN- Number:
Power supply
Housing / Guidance
AZ16I: Indicator with integrated sensor
000 = Standard
001 = First special version
0 = for Aluminium Guide Rail (25 x 6 mm)
0-
Options
2 = 2 internal 1.5 V batteries (AA)
Magnetic tape and guide rail for AZ16I
Magnetic tape length to order = Effective measuring length + 100 mm
A) With effective measuring distances smaller than 1.885 m, the guide rail is already assembled
with the magnetic tape (Please note: Owing to the mounting hole, the rail is 15 mm’s
longer!)
B) With effective measuring distances larger than 1.885 m, several guide rail parts (according
to the total length) and a separately magnetic tape are included in the delivery and must be
assembled by the user.

14
10. Liability exclusion / Guarantee
We have checked the contents of this instruction manual carefully, to the best of our knowledge
and belief for conformity with the described hardware and software. Nevertheless errors, mis-
takes or deviations can not be excluded, therefore we do not guarantee complete conformity.
Necessary corrections are included in the subsequent editions.
We appreciate your ideas and improvement suggestions very much.
Reprint, duplication and translation, even in extracts, are only allowed with a written authoriza-
tion by the company ELGO Electric GmbH. Our objective is to improve our products constantly,
therefore we keep all rights reserved for any technical modifications without any notice.
ELGO Electric does not assume any liability for possible errors or mistakes.
The guarantee period is to two calendar years from the date of delivery and includes the deliv-
ered unit with all its components. ELGO Electric GmbH will at its option replace or repair without
charge defects at the unit or the included parts, verifiable caused by faulty manufacturing
and/or material in spite of proper handling and compliance to the instruction manual.
Damages verifiably not caused by ELGO-Electric GmbH and due to improper handling are ex-
cluded from any guarantee e.g. by applying faulty voltage, diffusion of liquid into the interior of
the engine, using force, scratching the surface, chemical influences etc.!
Subject to modifications © ELGO Electric GmbH 2006
