SPECIFICATIONS
Elkay Cooler Floor Mount Hands-Free Non-Filtered Refrigerated
Stainless
Model EFOA8S1Z
In keeping with our policy of continuing product improvement, Elkay reserves the right to change product specifications without notice. Please visit elkay.com for
the most current version of Elkay product specification sheets. This specification describes an Elkay product with design, quality, and functional benefits tothe user.
When making a comparison of other producers’ offerings, be certain these features are not overlooked.
Elkay REV 09102021 1333 Butterfield Road, Suite 200 © 2021 Page 1
EFOA8S1Z Downers Grove, IL 60515 EFOA8S1Z_spec.pdf
PRODUCT SPECIFICATIONS
Elkay Cooler Floor Mount Hands-Free Non-Filtered Refrigerated
Stainless. Chilling Capacity of 8.0 GPH (gallons per hour) of 50F
drinking water, based on 80F inlet water and 90F ambient, per
ASHRAE 18 testing. Features shall include Hands Free. Furnished with
Flexi-Guard ® Safety Bubbler. Mechanical Top Bubbler Button
activation. Product shall be Floor Mount/Freestanding, for Indoor
applications, serving 1 station(s). Unit shall be certified to UL 399 and
CAN/CSA C22.2 No. 120. Unit shall be lead-free design which is
certified to NSF/ANSI 61 & 372 (lead free) and meets Federal and State
low-lead requirements.
Special Features:
Hands Free
Finish:
Stainless Steel
Power:
115V/60Hz
Bubbler Style:
Flexi-Guard ® Safety Bubbler
Activation by:
Mechanical Top Bubbler Button
Mounting Type:
Floor Mount/Freestanding
Chilling Capacity*:
8.0 GPH
Full Load Amps
5
Rated Watts:
420
Dimensions (L x W x H):
18" x 14-1/2" x 41-1/2"
Approx. Shipping Weight:
72 lbs.
Installation Location:
Indoor
No. of Stations Served:
1
*Based on 80° F inlet water & 90° F ambient air temp for 50° F chilled
drinking water.
Mechanically-Activated bubbler continues to supply water in
event of service disruptions.
COOLING SYSTEM
Compressor: Hermetically-sealed, reciprocating type,
single phase. Sealed-in lifetime lubrication.
Condenser: Fan cooled, copper tube with aluminum
fins. Fan motor is permanently lubricated.
Cooling Unit: Combination tube-tank type. Continuous
copper tubing with is fully insulated with EPS foam that
meets UL requirements for self-extinguishing material.
Refrigerant Control: Refrigerant R-134a is controlled by
accurately calibrated capillary tube.
Temperature Control: Easily accessible enclosed
adjustable thermostat is factory preset. Requires no
adjustment other than for altitude requirements.
Included with Product:
Water Cooler
Ships in one box.
AMERICAN PRIDE. A LIFETIME TRADITION.
Like your family, the Elkay family has values and traditions that
endure. For almost a century, Elkay has been a family-owned and
operated company, providing thousands of jobs that support our
families and communities.
PRODUCT COMPLIANCE
ASME A112.19.3/CSA B45.4
Buy American Act
CAN/CSA C22.2 No. 120
NSF/ANSI 61 & 372 (lead free)
UL 399
Installation Instructions (PDF)
5 Year Limited Warranty on the refrigeration system of the unit.
Electrical components and water system are warranted for 12 months
from date of installation. Warranty pertains to drinking water
applications only. Non-drinking water applications are not
covered under warranty.
Warranty (PDF)
PART:________________________________QTY: _____________
PROJECT:______________________________________________
CONTACT:______________________________________________
DATE:__________________________________________________
NOTES:_________________________________________________
APPROVAL:_____________________________________________

SPECIFICATIONS
Elkay Cooler Floor Mount Hands-Free Non-Filtered Refrigerated
Stainless
Model EFOA8S1Z
In keeping with our policy of continuing product improvement, Elkay reserves the right to change product specifications without notice. Please visit elkay.com for
the most current version of Elkay product specification sheets. This specification describes an Elkay product with design, quality, and functional benefits tothe user.
When making a comparison of other producers’ offerings, be certain these features are not overlooked.
Elkay REV 09102021 1333 Butterfield Road, Suite 200 © 2021 Page 2
EFOA8S1Z Downers Grove, IL 60515 EFOA8S1Z_spec.pdf
Optional Accessories
EWF172
Elkay WaterSentry VII Filter Kit (Coolers + Fountains)
Spec Sheet (PDF)
LK1110
Elkay Glass Filler
Spec Sheet (PDF)
97446C
Accessory - Bubbler Kit Vandal-Resistant
Spec Sheet (PDF)
