Elkay EWTLA Series Installation manual

98094C (11/04)
EWTLA8*1J EWTLA8*2J
PAGE1
FIG. 1
SEE FIG. 4 7
7
SEE FIG. 3
36
38
32, 39, 40
17,18,20
37
SEE FIG. 4
SEE FIG. 3
14 31
21
35
26
15
27, 39, 40
30
13
33
22, 23, 24, 25
29
41
34
28
41
EWTLA Pressure Cooler
USES HFC-134A REFRIGERANT
INSTALLATION, CARE & USE MANUAL
19
16

98094C (11/04)
EWTLA8*1J EWTLA8*2J
PAGE2
FIG. 2
E = INSURE PROPER VENTILATION BY MAINTAINING 4" (102mm) (MIN.) CLEARANCE FROM CABINET LOUVERS TO WALL.
ASEGURE UNAVENTILACIÓNADECUADA MANTENIENDO UN ESPACIO E 4" (102mm) (MÍN.) DE HOLGURAENTRE LA REJILLA DE VENTILACIÓN DEL MUEBLE Y LA PARED ASSUREZ-VOUS UNE BONNE VENTILATION EN GARDANT 4" (102mm) (MIN.) ENTRE LES ÉVENTS DE L’ENCEINTE ET LE MUR.
F = POWER CORD 4 FEET (1219mm) LONG
CABLE ELÉCTRICO DE 4 PIE (1219mm), DE LARGO CORDOND’ALIMENTATION4' (1219mm)
FINISHED FLOOR PISO ACABADO PLANCHER FINI
LEGEND/LEYENDA/LÉGENDE A= RECOMMENDED WATER SUPPLY LOCATION 3/8 O.D. UNPLATED COPPER TUBE CONNECT STUB OUT 1-1/2 IN. (38mm)
FROM WALL SHUT OFF BY OTHERS
SE RECOMIENDAUBICAR EL TUBO CORTO DE CONEXIÓNAL TUBO DE COBRE SIN CHAPAR DE 3/8" DE DIÁM. EXT. A1-1/2"
(38mm) FUERADE LALLAVEDE PASOEN LAPAREDCOLOCADAPORTERCEROS.
EMPLACEMENT RECOMMANDÉ D'ALIMENTATION EN EAU PAR TUBE EN CUIVRE NON PLAQUÉ DE 3/8 PO. (9,5 mm) D.E.
CONNECTANT UNE TUYAUTERIE DE 1-1/2 PO. (38 mm) DEPUIS LE ROBINET D'ARRÊT FOURNI PAR D'AUTRES.
B = RECOMMENDED LOCATION FOR WASTE OUTLET 1-1/4” O.D. DRAIN
UBICACIÓN RECOMENDADAPARAEL DRENAJE DE SALIDADEAGUA, DE 1¼” DE DIÁMETRO. EMPLACEMENTRECOMMANDÉ POUR LE DRAIN DED.E.1-1/4" DE SORTIE D’EAU.
C = 1-1/4 TRAP NOT FURNISHED
PURGADORDE 1¼ NO PROPORCIONADO SIPHON1-1/4 NON FOURNI
D = ELECTRICAL OUTLET LOCATION
UBICACIÓNDE LA TOMA DE ELECTRICIDAD EMPLACEMENTDE LA PRISE DE COURANT

98094C (11/04)
EWTLA8*1J EWTLA8*2J
PAGE3
FIG. 3 FIG. 4
NOTE:
WHENINSTALLINGREPLACEMENT BUBBLER
ANDPEDESTAL,TIGHTENNUT(ITEM12)ONLY
TO HOLD PARTS SNUG IN POSITION.
DONOTOVERTIGHTEN.
BASIN
9
10
11
12
8
Stream height is factory set at 35 PSI. If supply
pressurevariesgreatlyfromthis,removeItems
1 & 2 and adjust screw on
Item 4. Clockwise adjustment will raise stream
andcounter-clockwiseadjustmentwill lower
stream. For best adjustment, stream should hit
basinapproximately6-1/2"(165mm)from
bubbler.
BASIN
4
3
1
5
6
2
When provided
1
6
7
2
43
5
ITEM NO.
Filter Head Ass’y
Screw #8-18 X .75 PH
Fitting - Superseal 3/8” (10mm)
Fitting - Superseal 1/4” (6mm)
Filter Ass’y
Elbow - 3/8” (10mm)
Bracket
1
2
3
4
5
6
7
51294C
70792C
70823C
70822C
51299C
70818C
22490C
DESCRIPTION
PART
NO.
WATERSENTRY®FILTERPARTSLIST
FIG. 5

98094C (11/04)
EWTLA8*1J EWTLA8*2J
PAGE4
40089C
40048C
15005C
61313C
40169C
50986C
20776C
20713C
56073C
40322C
56011C
55997C
75580C
31513C
36208C
66743C
56237C
31490C
30664C
27681C
70018C
66703C
36094C
36158C
35768C
35959C
55996C
45702C
66576C
66534C
70682C
40022C
40088C
See Color Table
See Color Table
See Color Table
See Color Table
See Color Table
See Color Table
50368C
70750C
56092C
100322740560
15009C
PRINTED IN U.S.A.
PARTS LIST 115V
ITEM NO. PARTNO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
*22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
Cover
Button
Regulator Retaining Nut
Regulator
Hex Nut
RegulatorHolder
Basin
Basin (GF Only)
Bubbler Assy
Orifice Assy
Housing Assy
Pedestal
Bubbler Locknut
Cold Control
PowerCord
Condenser
FanShroud
FanMotor
Fan Blade
Fan Bracket
Fan Blade Nut
Drier
Compressor Serv. Pak
Overload
Relay Cover
Relay
Strainer
Tailpipe Assy
Heat Exchanger
Evaporator
Fitting - Tee
Waste Connection Assy
Assy - Tailpipe
Panel-Left Side (Right Unit)
Panel-Right Side (Right Unit)
Panel-Front (Right Unit)
Panel-Left Side (Left Unit)
Panel-Right Side (Left Unit)
Panel-Front (Left Unit)
Receptor - Drain
Clamp
Poly. Tubing (Cut to Length)
Gasket (GF)
Nipple - Bubbler (GF)
DESCRIPTION
Item No. 33
Part No.
COLORTABLE
Gray Beige
Almond
Stainless Stl
Sandalwood
Granite
Light Gray
20639C
21465C
20641C
21463C
27174C
27175C
20675C
20676C
20672C
21454C
27150C
27154C
PANEL
COLOR Item No. 34
Part No.
Item No. 36
Part No. Item No. 37 Part No.
Item No. 35
Part No.
20646C
21468C
20648C
21466C
27177C
27178C
20736C
21479C
20737C
21478C
27189C
27190C
Item No. 38
Part No.
20684C
20685C
20681C
21456C
27153C
27154C
20732C
21477C
20733C
21476C
27186C
27187C
Gray Beige
Almond
Stainless Stl
Sandalwood
Granite
Light Gray
PANEL
COLOR
COLORTABLE
36024C
31430C
36085C
36195C
35768C
36050C
35826C
14
17
22*
23
24
25
NS
PowerCord
FanMotor
Compressor Serv. Pak
Overload
Relay Cover
Relay
Power Inlet
PART. NO. DESCRIPTIONITEM NO.
220V/50Hz
*INCLUDES RELAY & OVERLOAD. IF UNDER WARRANTY,
REPLACEWITHSAMECOMPRESSORUSEDINORIGINALAS-
SEMBLY.
NOTE: All correspondence pertaining to any of the above
water coolers or orders for repair parts MUST include Model
No. and Serial No. of cooler, name and part number of replace-
ment part.
FIG. 6
42
43
Glass Filler Shown
for Reference Only
